SMC Networks WIPCAM-PZ - annexe 1 User manual

EZ Connect N
Draft 11n Wireless USB2.0 Adapter
SMCWIPCAM-PZ
EZ Connect Vision™
Wireless Pan Tilt Zoom IP Camera

Copyright
The information provided by SMC Networks, Inc. (SMC) is believed to be accurate and
reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements
of patents or other rights of third parties which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of SMC. SMC reserves the
right to change specifications at any time without notice.
Copyright © 2009 by
SMC Networks, Inc.
20 Mason
Irvine, CA 92618
All rights reserved. Printed in Taiwan
Trademarks:
SMC is a registered trademark; and EZ Connect Vision is a trademark of SMC Networks,
Inc. Other product and company names are trademarks or registered trademarks of their
respective holders.

1
Warranty and
Product Registration
To register SMC products and to review the detailed warranty statement, please refer to the
Support Section of the SMC Website at http://www.smc.com
SMC Networks, Inc.
20 Mason
Irvine, CA 92618

2
Compliances
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
FCC Caution: To assure continued compliance, (example - use only shielded interface cables
when connecting to computer or peripheral devices) any changes or modifications not
expressly approved by the party responsible for compliance could void the user’s authority to
operate this equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
20cm between the radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter..
IMPORTANT NOTE:
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1
through 11.

3
Industry Canada Statement
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference that may cause undesired
operation of the device
To prevent radio interference to the licensed service, this device is intended to be operated
indoors and away from windows to provide maximum shielding. Equipment (or its transmit
antenna) that is installed outdoors is subject to licensing.
This device has been designed to operate with an antenna having maximum gain of 1.5dBi.
Any antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The
required antenna impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the EIRP is not more than required for successful communication.
EC Declaration of Conformity
SMC contact for these products in Europe is:
SMC Networks Spain, S.L.
Edificio Conata II,
Group CTSG
Fructuos Gelabert 6-8 2o2a
08970 Sant Joan Despi, Barcolona,Spain
This product indicates compliance with the Essential Requirements of the R&TTE Directive
of the European Union (1999/5/EC). This equipment meets the following conformance
standards.
EN 55022:2006 Class B EN55024:1998 +A1:2001 +A2:2003
EN 61000-3-2: 2006 IEC61000-4-2: 1995 +A1 : 1998 +A2 : 2000
IEC61000-4-3: 2002 +A1 :2002
EN 61000-3-3:1995 +A1: 2001+A2:2005 IEC61000-4-4: 2004
IEC61000-4-5: 1995 + A1 : 2000
IEC61000-4-6: 2003 + A1: 2004
IEC61000-4-8: 1993 + A1 : 2000
IEC61000-4-11: 2004
EN 60950-1:2001+A11:2004 IEC60960-1:2001
NCC Statement
依據 低功率電波幅射性電機管理辦法
第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者不
得擅自變更頻率、加大功率或變更原設計之特性及功能
第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干
擾現象時，應立即使用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信
或工業、科學及醫療用電波幅射性電機設備之干擾。

4
Countries of Operation & Conditions of Use in the European
Community
This device is intended to be operated in all countries of the European Community.
Requirements for indoor vs. outdoor operation, license requirements and allowed channels of
operation apply in some countries as described below.
Note: The user must use the configuration utility provided with this product to ensure the channels of
operation are in conformance with the spectrum usage rules for European Community countries
as described below.
．This device requires that the user or installer properly enter the current country of operation in the
command line interface as described in the user guide, before operating this device.
．This device will automatically limit the allowable channels determined by the current country of
operation. Incorrectly entering the country of operation may result in illegal operation and may
cause harmful interference to other system. The user is obligated to ensure the device is operating
according to the channel limitations, indoor/outdoor restrictions and license requirements for each
European Community country as described in this document.
．This device may be operated indoors or outdoors in all countries of European Community using the
2.4GHz band: Channel 1-13.
Declaration of Conformity in Languages of the European
Community
[Czech] Společnost SMC Networks tímto prohlašuje, že toto rádiové
zařízení LAN je ve shoděse základními požadavky a dalšími
příslušnými ustanoveními směrnice 1999/5/ES. Oficiální ES
prohlášení o shoděje uvedeno v příslušné části k produktu na
webu http://www.smc.com
[Danish] SMC Networks erklærer herved, at følgende Radio LAN-enhed
overholder de væsentlige krav og andre relevante bestemmelser i
direktiv 1999/5/EF. Den officielle EU-
overensstemmelseserklæring er tilgængelig under det relevante
produktafsnit på følgende webadresse: http://www.smc.com.
[German] Hiermit erklärt SMC Networks, dass sich dieses Wireless LAN
Gerät in Übereinstimmung mit den grundlegenden
Anforderungen und den anderen relevanten Vorschriften der
Richtlinie 1999/5/EG befindet. Die offizielle EC-Declaration of
Conformity finden Sie im Internet unter http://www.smc.com
unter der entsprechenden Produktkategorie.
[Estonian] Käesolevaga kinnitab SMC Networks, et see Radio LAN seade

5
vastab direktiivi 1995/5/EÜ põhinõuetele ja teistele asjakohastele
sätetele. Ametliku EÜ vastavusdeklaratsiooni leiate vastavast
tootejaotisest aadressil http://www.smc.com.
[English] Hereby, SMC Networks, declares that this Radio LAN device is
in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. The official EC-Declaration
of Conformity can be found under the corresponding product
section on the web http://www.smc.com.
[Spanish] Por medio de la presente SMC Networks declara que el Radio
LAN device cumple con los requisitos esenciales y cualesquiera
otras disposiciones aplicables o exigibles de la Directiva
1999/5/CE. The official EC-Declaration of Conformity can be
found under the corresponding product section on the web
http://www.smc.com
[Greek] Με την παρούσα, ηSMC Networks, δηλώνει ότι ησυσκευή
ασύρματου τοπικού δικτύου συμμορφώνεται με τις ουσιώδεις
απαιτήσεις και τις λοιπές σχετικές διατάξεις της Οδηγίας
1999/5/EΚ. Ηεπίσημη δήλωση συμμόρφωσης EΚπαρέχεται
στην αντίστοιχη ενότητα προϊόντων, στην ιστοσελίδα
http://www.smc.com.
[French] Par la présente SMC Networks déclare que l'appareil Radio LAN
device est conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE. La
déclaration de conformité officielle peut être trouvée sur notre
site internet http://www.smc.com dans la rubrique Produits.
[Italian] Con la presente SMC Networks dichiara che questo Radio LAN
device è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE. La Dichiarazione di
conformità CE ufficiale è disponibile nella sezione dedicata al
rispettivo prodotto sul sito Web http://www.smc.com.
[Latvian] Ar šo SMC Networks deklarē, ka Radio LAN device atbilst
Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to
saistītiem noteikumiem. OficiālāEK atbilstības deklarācija ir
atrodama attiecīgāprodukta sadaļā tīmeklīhttp://www.smc.com.
[Lithuanian] Šiuo „SMC Networks“ deklaruoja, kad šis radijo LAN įrenginys
atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos
nuostatas. Oficialiąjo EB atitikties deklaracijągalima rasti
atitinkamųgaminiųskyriuje šiame tinklalapyje:
http://www.smc.com.
[Dutch] Hierbij verklaart SMC Networks dat het toestel Radio LAN
device in overeenstemming is met de essentiële eisen en de
andere relevante bepalingen van richtlijn 1999/5/EG. Het
officiële EC- gelijkvormigheidattest kan men vinden op de
internetsite http://www.smc.com onder de betrokken
productcategorie.

6
[Maltese] B’dan, SMC Networks, tiddikjara li dan it-tagħmir LAN tar-Radju
huwa konformi mar-rekwiżiti essenzjali u dispożizzjonijiet
rilevanti oħra ta’ Direttiva 1999/5/KE. Id-Dikjarazzjoni ta’
Konformità uffiċjali tal-KE tinsab fit-taqsima korrispondenti fis-
sit ta’ l-Internet http://www.smc.com.
[Hungarian] Az SMC Networks kijelenti, hogy a Radio LAN eszköz megfelel
a vonatkozó alapvetőkövetelményeknek és az 1999/5/EC
irányelv egyéb előírásainak. A hivatalos EC megfelelőségi
nyilatkozat megtalálható a vonatkozó termék ismertetőjénél, a
következőcímen: http://www.smc.com
[Polish] Firma SMC Networks niniejszym oświadcza, że urządzenie Radio
LAN jest zgodne z zasadniczymi wymaganiami oraz pozostałymi
stosownymi postanowieniami Dyrektywy 1999/5/EC. Oficjalna
Deklaracja zgodności UE znajduje sięw odpowiedniej sekcji
produktu w witrynie http://www.smc.com.
[Portuguese] A SMC Networks declara que este dispositivo de LAN de Rádio
está em conformidade com os requisitos essenciais e com outras
provisões relevantes da Directiva 1999/5/CE. A Declaração de
Conformidade CE oficial encontra-se na secção correspondente
do produto na Web, http://www.smc.com.
[Slovenian] Družba SMC Network izjavlja, da je naprava Radio LAN skladna
z bistvenimi zahtevami in drugimi ustreznimi predpisi direktive
1999/5/ES. Za uradno izjavo o skladnosti ES glejte razdelek za
ustrezni izdelek na spletni strani http://www.smc.com.
[Slovak] SpoločnosťSMC Networks týmto vyhlasuje, že toto zariadenie
Radio LAN spĺňa základné požiadavky a ďalšie príslušné
ustanovenia smernice 1999/5/ES. Oficiálne prehlásenie ES o
zhode je uvedené v sekcii príslušného produktu v lokalite
http://www.smc.com.
[Finnish] SMC Networks vakuuttaa täten, että Radio LAN device -
tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen. EY:n
virallinen vaatimustenmukaisuusvakuutus on tuotteen kohdalla
Web-sivustossa http://www.smc.com.
[Swedish] Härmed intygar SMC Networks att denna Radio LAN-apparat
uppfyller de väsentliga egenskapskrav och övriga relevanta
bestämmelser i direktiv 1999/5/EG. Den officiella EG-försäkran
om överensstämmelse finns under motsvarande produktavsnitt
på http://www.smc.com.
[Icelandic] Hér með lýsir SMC Networks því yfir að þessi Radio LAN
búnaður er í samræmi við grunnkröfur og aðrar viðeigandi
kröfur, sem gerðar eru í tilskipun 1999/5/EB. Opinberu EB-
samræmisyfirlýsinguna er að finna í viðeigandi hluta um þennan
búnað á vefsetrinu http://www.smc.com.
[Norwegian] SMC Networks erklærer herved at Radio LAN-enheten er i

7
samsvar med de grunnleggende kravene og øvrige relevante krav
i direktiv 1999/5/EF. Denne offisielle EU-
konformitetserklæringen finnes under korresponderende
produktseksjon på Internett: http://www.smc.com.
Countries of Operation & Conditions of Use in EC/ EFTA member
states
[English] This device is a 2.4 GHz wireless LAN transceiver, intended for
indoor home and office use in all notified EC and EFTA member
states. In accordance with article 6.4 of the R&TTE Directive
1999/5/EC the following EC/ EFTA member states have been
notified: Austria, Belgium, Denmark, Finland, France, Germany,
Italy, Luxembourg, Netherlands, Norway, Spain, Sweden,
Switzerland, United Kingdom, Portugal, Greece, Ireland, Iceland.
Requirements for outdoor operation, like license requirements and
allowed channels of operation apply in some countries. Please
contact your local regulation authority or SMC Networks for
details on current restrictions for outdoor use.
[French] Ce produit est un appareil radio LAN transceiver de 2.4 GHz
destiné aux PME et à l’utilisation domestique dans tous les pays
certifiés conformes aux conditions de l’EU et de l’EFTA. En
accord avec l’article 6.4 de la R&TTE directive 1999/5/EC, the
membres de la EU et de l’EFTA sont les suivants : Autriche,
Belgique, Danemark, finalnde, France, Allemagne, Italie,
Luxembourg, Pays-Bas, Norvège, Espagne, Suède, Suisse,
Royaume-Uni, Portugal, Grèce, Irelande, Icelande. Des conditions
sont appliquées à certains pays pour l’utilisation en extérieur, tels
que des licences spécífiques et des canaux d’opération. Veuillez
contacter votre autorité locale ou SMC Networks pour plus de
détails quant aux restrictions actuelles concernant l’utilisation en
extérieur.
[Dutch] Dit toestel is een 2.4 Ghz draadloze Lan transceiver, bestemd
voor gebruik binnen huis en kantoor in alle geïnformeerde
lidstaten van de EC en de EFTA. In overeenstemming met artikel
6.4 van de R&T TE Directive 1999/5/EC zijn de volgende
EC/EFTA lidstaten verwittigd: België, Denemarken, Duitsland,
Finland, Frankrijk,Griekenland, Ierland, IJsland, Italië,
Luxemburg, Nederland, Noorwegen,Oostenrijk, Portugal, Spanje ,
Verenigd Koninkrijk, Zweden, Zwitserland. Benodigdheden voor
gebruik buiten, zoals gebruiksvergunningen en toegelaten
werkkanalen zijn van toepassing in sommige landen. Gelieve uw
lokale instantie of SMC Networks te contacteren voor details op
huidige beperkingen voor gebruik in buitenlucht.
[Spanish] Este aparato es un transmisor inalámbrico de 2.4 GHz, previsto
para el uso interior en domicilios y Pymes en todos los Estados de
la CE y la EFTA notificados. De acuerdo con el artículo 6.4 de la
Directiva R&TTE 1999/5/EC los siguientes estados de la CE y
de la EFTA han sido notificados: Austria, Bélgica, Dinamarca,

8
Finlandia, Francia, Alemania, Italia, Luxemburgo, Países Bajos,
Noruega, España, Suecia, Suiza, Reino Unido, Portugal, Grecia,
Irlanda, Islandia. Los requisitos para su uso exterior, como
requerimiento de licencia y canales de operación permitidos se
aplican en algunos países. Por favor contacte la autoridad
reguladora local o SMC Networks para más detalles en relación
con las restricciones actuales para uso exterior.
[German] Dieses Wireless LAN Gerät arbeitet im 2.4 GHz Frequenzband
und ist für den Einsatz im Innenbereich in den benachrichtigten
EC/ EFTA Mitgliedstaaten geeignet. In Übereinstimmung mit
Artikel 6.4 der R&TTE Direktive 1999/5/EC wurden folgende
Mitgliedstaaten benachrichtigt: Österreich, Belgien, Dänemark,
Finland, Frankreich, Deutschland, Italien, Luxemburg,
Niederlande, Norwegen, Spanien, Schweden, Schweiz,
Großbritannien, Portugal, Griechenland, Irland, Island. Für den
Einsatz im Aussenbereich sind in einigen Ländern Lizenzen
erforderlich oder die Anzahl der Kanäle ist eingeschränkt. Bitte
kontaktieren Sie Ihre Regulierungsbehörde oder SMC Networks
für die aktuellen Einschränkungen beim Einsatz im
Aussenbereich.
[Czech] Toto zařízení je přijímača vysílačpro bezdrátové sítěLAN v
pásmu 2,4 GHz, určený pro použití v interiéru domácností a
kanceláří ve všech členských zemích ES a ESVO, kterým byl
oznámen záměr uvést zařízení na trh. V souladu s čl. 6 odst. 4
směrnice 1999/5/ES o rádiových zařízeních a telekomunikačních
koncových zařízeních byly uvědoměny tyto členské zeměES nebo
ESVO: Belgie, Dánsko, Finsko, Francie, Irsko, Island, Itálie,
Lucembursko, Německo, Nizozemsko, Norsko, Portugalsko,
Rakousko, Řecko, Spojené království, Španělsko, Švédsko,
Švýcarsko. Na použití ve venkovním prostředí se v některých
zemích vztahují určité požadavky, např. požadavky na licenci nebo
provoz v povolených kanálech. O omezení venkovního použití se
informujte u místních regulátorůnebo u společnosti SMC
Networks.
[Danish] Enheden er en 2,4 GHz trådløs LAN-transceiver, beregnet til
indendørs hjemme- og kontorbrug i alle notificerede EU- og
EFTA-medlemslande. I henhold til afsnit 6.4 i R&TTE-direktivet
1999/5/EF er følgende EU-/EFTA-medlemslande notificeret:
Østrig, Belgien, Danmark, Finland, Frankrig, Tyskland,
Grækenland, Island, Irland, Italien, Luxembourg, Holland, Norge,
Portugal, Spanien, Sverige, Schweiz og Storbritannien. I visse
lande gælder der krav vedrørende udendørs betjening af enheden,
f.eks. licenskrav og tilladte betjeningskanaler. Kontakt de lokale
lovgivende myndigheder eller SMC Networks for at få oplysninger
om aktuelle begrænsninger vedrørende udendørs betjening.
[Estonian] See seade on 2.4 GHz juhtmeta LAN vastuvõtu-saatejaam, mis on
mõeldud kodus ja kontoris kasutamiseks kõikides teavitatud EÜ ja
Euroopa Vabakaubanduse Assotsiatsiooni (EFTA) liikmesriikides.
Vastavalt R&TTE direktiivi 1999/5/EÜ paragrahvile 6.4 on
teavitatud järgmisi EÜ/EFTA liikmesriike: Austriat, Belgiat,

9
Taanit, Soomet, Prantsusmaad, Saksamaad, Itaaliat, Luksemburgi,
Hollandit, Norrat, Hispaaniat, Rootsit, Šveitsi, Ühendkuningriiki,
Portugali, Kreekat, Iirimaad, Islandi. Mõningates riikides kehtivad
väljas kasutamiseks nõuded, näiteks litsentsinõuded ja lubatud
töökanalid. Palun teavitage vastavat kohalikku ametkonda või
ettevõtet SMC Networks’i, kui soovite täpsemaid andmeid väljas
kasutamisel kehtivate piirangute kohta.
[Greek] Αυτή ησυσκευή είναι ένας ασύρματος πομποδέκτης τοπικού δικτύου
2,4 GHz, που προορίζεται για οικιακή και επαγγελματική χρήση σε
εσωτερικό χώρο, σε όλα τα κράτη-μέλη της ΕΚ και της ΕΖΕΣ.
Σύμφωνα με το άρθρο 6.4 της Οδηγίας για ραδιοεξοπλισμό και
τηλεπικοινωνιακό τερματικό εξοπλισμό (R&TTE), 1999/5/ΕΚ,
έχουν ανακοινωθεί τα ακόλουθα κράτη-μέλη ΕΕ/ΕΖΕΣ: Αυστρία,
Βέλγιο, Δανία, Φιλανδία, Γαλλία, Γερμανία, Ιταλία, Λουξεμβούργο,
Ολλανδία, Νορβηγία, Ισπανία, Σουηδία, Ελβετία, Ηνωμένο
Βασίλειο, Πορτογαλία, Ελλάδα, Ιρλανδία, Ισλανδία. Σε ορισμένες
χώρες επιβάλλονται απαιτήσεις για χρήση σε εξωτερικό χώρο, όπως
απαιτήσεις παραχώρησης άδειας και επιτρεπόμενα κανάλια
λειτουργίας. Απευθυνθείτε στην τοπική αρμόδια αρχή ήστην SMC
Networks για λεπτομέρειες σχετικά με τους τρέχοντες περιορισμούς
για χρήση σε εξωτερικό χώρο.
[Italian] Il presente device è un ricetrasmettitore LAN wireless da 2,4
GHz, previsto per l'uso in interni a casa e in ufficio in tutti gli Stati
membri della CE e dell'EFTA notificati. Conformemente
all'articolo 6.4 della Direttiva 1999/5/CE R&TTE, sono stati
notificati i seguenti Stati membri della CE/dell'EFTA: Austria,
Belgio, Danimarca, Finlandia, Francia, Germania, Grecia, Irlanda,
Islanda, Italia, Lussemburgo, Norvegia, Paesi Bassi, Portogallo,
Regno Unito, Spagna, Svezia, Svizzera. In alcuni Paesi si applicano
i requisiti per il funzionamento in esterni, quali requisiti di licenza
e canali consentiti. Contattare l'Autorità normativa locale del
proprio Paese o SMC Networks per informazioni dettagliate sulle
limitazioni correnti per l'utilizzo in esterni.
[Latvian] Šīierīce ir 2,4 GHz bezvadu LAN raiduztvērējs, kas paredzēts
izmantošanai iekštelpās mājās un birojos visās paziņotajās EK un
EBTA (European Free Trade Association - Eiropas brīvās
tirdzniecības asociācija) dalībvalstīs. Atbilstoši radioiekārtu un
telekomunikāciju gala iekārtu direktīvas 1999/5/EK 6.4. pantam
paziņotās EK/EBTA valstis ir : Austrija, Beļģija, Dānija, Somija,
Francija, Vācija, Itālija, Luksemburga, Nīderlande, Norvēģija,
Spānija, Zviedrija, Šveice, ApvienotāKaraliste, Portugāle, Grieķija,
Īrija, Islande. Dažās valstīs ir spēkāierobežojumi lietošanai ārvidē,
piemēram, licences prasības un darbībai atļautie kanāli. Lūdzu,
sazinieties ar vietējo regulējošo instanci vai SMC Network, lai
saņemtu informāciju par pašreizējiem ierobežojumiem lietošanai
ārvidē.
[Lithuanian] Šis įrenginys yra 2,4 GHz belaidis LAN siųstuvas-imtuvas, skirtas
naudoti patalpose namie ar biure visose notifikuotose EB ir ELPA
šalyse narėse. Pagal RTTE Direktyvos 1999/5/EB 6.4 straipsnį,
notifikuotos yra šios EB/ELPA šalys narės: Austrija, Belgija,
Danija, Suomija, Prancūzija, Vokietija, Italija, Liuksemburgas,

10
Nyderlandai, Norvegija, Ispanija, Švedija, Šveicarija, Jungtinė
Karalystė, Portugalija, Graikija, Airija, Islandija. Kai kuriose šalyse
galioja tam tikri reikalavimai norint naudoti įrenginįlauke, pvz.,
licencijos ir suteikti ryšio kanalai. Jei norite sužinoti, kokie
apribojimai galioja norint naudoti įrenginįlauke, kreipkitės į
nacionalinęreguliavimo institucijąarba „SMC Networks“.
[Maltese] Dan it-tagħmir huwa LAN transreciever mingħajr fili ta’ 2.4 GHz
maħsub biex jintuża fuq ġewwa fi djar u uffiċċini fil-pajjiżi
notifikati tal-KE u
l-Istati Membri ta’ l-EFTA. B’mod konformi ma’ Artikolu 6.4 tad-
Direttiva R&TTE 1999/5/KE l-Istati Membri tal-KE/EFTA li
ġejjin ġew notifikati: L-Awstrija, Il-Belġju, Id-Danimarka, Il-
Finlandja, Franza, Il-Ġermanja, L-Italja, Il-Lussemburgu, L-
Olanda, In-Norveġja, Spanja, L-Iżveżja, L-Iżvizzera, Ir-Renju
Unit, Il-Portugal, Il-Greċja, L-Irlanda, L-Islanda. Rekwiżiti għal
tħaddim fuq barra, bħal ħtiġijiet ta’ liċenzja u kanali permessi għal
tħaddim japplikaw f’ċertu pajjiżi. Jekk jogħġbok ikkuntattja lill-
awtorità regolarorja lokali jew SMC Networks għal dettalji dwar
restrizzjonijiet attwali dwar l-użu fuq barra.
[Hungarian] Ez az eszköz egy 2,4 GHz-es vezeték nélküli LAN adó-vevő,
amely beltéri és irodai használatra készült, és az összes értesített
EC- és EFTA-tagországban használható. Az 1999/5/EC jelű
R&TTE előírás 6.4-es cikkének megfelelően a következőEC/
EFTA tagországok kaptak értesítést: Ausztria, Belgium, Dánia,
Finnország, Franciaország, Németország, Olaszország,
Luxemburg, Hollandia, Norvégia, Spanyolország, Svédország,
Svájc, Egyesült Királyság, Portugália, Görögország, Írország és
Izland. Egyes országokban külön előírások vonatkoznak a kültéri
használatra, például a licencre és az engedélyezett csatornákra. A
kültéri használatra vonatkozó aktuális előírásokkal kapcsolatos
részletekért forduljon a helyi szabályozó hatósághoz vagy az SMC
Networkshöz.
[Polish] Niniejsze urządzenie to urządzenie do odbierania i przesyłania
sygnału (transceiver) w bezprzewodowej sieci LAN o
częstotliwości 2,4 GHz, przeznaczone do użytku wewnątrz
pomieszczeń, w domach i biurach we wszystkich krajach
członkowskich UE i EFTA. Zgodnie z artykułem 6.4 dyrektywy
1999/5/EC dotyczącej norm dla urządzeńradiowych i
końcowych urządzeńteletransmisyjnych powiadomione zostały
następujące kraje członkowskie: Austria, Belgia, Dania, Finlandia,
Francja, Niemcy, Włochy, Luksemburg, Holandia, Hiszpania,
Szwecja, Szwajcaria, Wielka Brytania, Portugalia, Grecja, Irlandia,
Islandia. W niektórych krajach obowiązująwymagania dotyczące
działania na zewnątrz budynków, na przykład wymagania
licencyjne i dozwolone kanały pracy. Szczegółowe informacje na
temat obowiązujących ograniczeńużytkowania zewnętrznego
można uzyskać, kontaktując sięz lokalnym urzędem regulacji lub
firmąSMC Networks.
[Portuguese] Este dispositivo é um transreceptor de LAN sem fios de 2,4 GHz,
destinado a uma utilização interior em casa e no escritório, em
todos os Estados membros notificados da CE e da EFTA. De

11
acordo com o artigo 6.4 da Directiva sobre R&TTE 1999/5/CE,
foram notificados os seguintes Estados membros da CE/EFTA:
Áustria, Bélgica, Dinamarca, Finlândia, França, Alemanha, Itália,
Luxemburgo, Holanda, Noruega, Espanha, Suécia, Suíça, Reino
Unido, Portugal, Grécia, Irlanda, Islândia. Os requisitos para uma
utilização no exterior, tais como de licença e de canais de
funcionamento permitidos aplicam-se a alguns países. Para obter
informações sobre as restrições de utilização no exterior, contacte
a autoridade local competente ou a SMC Networks.
[Slovenian] Ta naprava je oddajno-sprejemna enota za brezžično lokalno
omrežje, namenjena uporabi na domu ali v pisarni v vseh
priglašenih državah članicah ES in EFTA. Skladno s členom 6.4
Direktive 1999/5/ES o radijski opremi in telekomunikacijski
terminalski opremi so bile obveščene naslednje države članice
ES/EFTA: Avstrija, Belgija, Danska, Finska, Francija, Nemčija,
Italija, Luksemburg, Nizozemska, Norveška, Španija, Švedska,
Švica, Velika Britanija, Portugalska, Grčija, Irska, Islandija. V
nekaterih državah veljajo zahteve za delovanje na prostem, kot so
zahteve za dovoljenje in dovoljeni kanali za delovanje. Če
potrebujete natančne informacije o trenutnih omejitvah uporabe
na prostem, se obrnite na lokalni regulativni organ ali družbo SMC
Networks.
[Slovak] Toto zariadenie je prijímača vysielačpre bezdrôtové siete v pásme
2,4 GHz a je určené na použitie v interiéroch domácností a
kancelárií vo všetkých členských štátoch ES a EZVO, ktorým bol
oznámený zámer uviesťzariadenie na trh. V súlade s čl. 6 odst. 4
smernice 1999/5/ES o rádiovom zariadení a koncových
telekomunikačných zariadeniach boli upovedomené nasledujúce
členské štáty ES/EZVO: Belgicko, Dánsko, Francúzsko, Fínsko,
Grécko, Holandsko, Island, Írsko, Luxembursko, Nemecko,
Nórsko, Portugalsko, Rakúsko, Španielsko, Švajčiarsko, Švédsko,
Taliansko, Veľká Británia. V niektorých štátoch sa na prevádzku v
exteriéroch vzťahujú určité požiadavky, napríklad požiadavky na
licenciu alebo požiadavky na prevádzkové kanály. Podrobné
informácie o aktuálnych obmedzeniach pri prevádzke v
exteriéroch vám poskytnú miestne regulačné orgány alebo
spoločnosťSMC Networks.
[Finnish] Laite on 2,4 GHz:n langaton LAN-vastaanotin, joka on tarkoitettu
koti- ja toimistokäyttöön kaikissa EY:n ja EFTAn jäsenmaissa,
joihin siitä on ilmoitettu. Radio- ja telepäätelaitedirektiivin
1999/5/EY mukaisesti seuraaville EY-/EFTA-maille on
ilmoitettu: Itävalta, Belgia, Tanska, Suomi, Ranska, Saksa, Italia,
Luxemburg, Alankomaat, Norja, Espanja, Ruotsi, Sveitsi, Iso-
Britannia, Portugali, Kreikka, Irlanti ja Islanti. Joissakin maissa
ulkokäyttöä koskevat erilliset vaatimukset, kuten erikseen anottava
lupa ja sallittujen kanavien rajoittaminen. Ota yhteyttä paikalliseen
käyttöä valvovaan viranomaiseen tai SMC Networksiin, jos haluat
lisätietoja laitteen ulkokäytön rajoituksista.
[Swedish] Apparaten är en 2,4 GHz trådlös LAN-mottagare för
inomhusbruk i hem och på kontor i alla underrättade EG- och
EFTA-medlemsstater. Enligt artikel 6.4 i R&TTE-direktivet

12
1999/5/EG är följande EG-/EFTA-stater underrättade:
Österrike, Belgien, Danmark, Finland, Frankrike, Tyskland,
Italien, Luxemburg, Nederländerna, Norge, Spanien, Sverige,
Schweiz, Storbritannien, Portugal, Grekland, Irland och Island. I
vissa länder tillkommer krav för utomhusbruk, t.ex. licenskrav och
tillåtna användarkanaler. Kontakta lokala tillsynsmyndigheter eller
SMC Networks för information om aktuella bestämmelser för
utomhusbruk.
[Icelandic] Þessi búnaður er 2,4 GHz þráðlaust LAN sendiviðtæki til
notkunar innanhúss á heimili og skrifstofu í öllum tilkynntum
aðildarríkjum EB og EFTA. Í samræmi við grein 6.4 í R&TTE
tilskipuninni 1999/5/EB hefur eftirfarandi aðildarríkjum
EB/EFTA verið tilkynnt þar um: Austurríki, Belgía, Danmörk,
Finnland, Frakkland, Þýskaland, Ítalía, Lúxemborg, Holland,
Noregur, Spánn, Svíþjóð, Sviss, Bretland, Portúgal, Grikkland,
Írland, Ísland. Kröfur fyrir notkun utanhúss, svo sem kröfur um
leyfi og heimilaðar rásir eiga við í sumum löndum. Hafið samband
við reglugerðaryfirvöld á hverjum stað eða SMC Networks til að
fá upplýsingar um gildandi takmarkanir á notkun utanhúss.
[Norwegian] Denne enheten er en trådløs 2.4 GHz LAN-mottaker som er
beregnet for innendørs privat- og kontorbruk i alle underrettede
EF- og EFTA-medlemsstater. I overensstemmelse med artikkel
6.4 i R&TTE-direktivet 1999/5/EF, har følgende EF-/ EFTA-
medlemsstater blitt underrettet: Østerrike, Belgia, Danmark,
Finland, Frankrike, Tyskland, Italia, Luxembourg, Nederland,
Norge, Spania, Sverige, Sveits, Storbritannia, Portugal, Hellas,
Irland og Island. Krav for utendørsbruk, som lisenskrav og tillatte
brukskanaler, gjelder i noen land. Ta kontakt med din lokale
regulerende myndighet eller SMC Networks for detaljert
informasjon om gjeldende begrensninger for utendørs bruk.
Safety Compliance
Underwriters Laboratories Compliance Statement
Important! Before making connections, make sure you have the correct cord set. Check it (read the
label on the cable) against the followings:
Operating Voltage Cord Set Specifications
UL Listed/CSA certified Cord Set
Minimum 18AWG
Type SVT or SJT three conductor cord
Maximum length of 15 feet
120Volts
Parallel blade, grounding type attachment plug rated 15A, 125V
Cord Set with H05VV-F cord having three conductors with minimum
diameter of 0.75mm2
IEC-320 receptacle
240Volts(Europe only)
Male plug rated 10A,250V
The unit automatically matches the connected voltage. Therefore, no additional adjustments are
necessary when connecting it to any input voltage within the range marked on the power adapter.

13
Information for Power Source
This unit is to be used with a class 2 or level 3 external power adapters, approved suitable for used in
North America equipment installation, having an output voltage rating of 12V DC, and output current
ratings of 1.5A or equivalent. The external AC adapter must be complied with the requirements of LPS
(Limited Power Sources).

14
Index
Preface…………………………………………………………………………... 15
Chapter 1 Introduction ………………………………….............................. 16
1.1 Checking the Package Contents………………………………………………… 16
1.2 Getting to Know Your Camera……………………………………….………….. 16
1.3 Features and Benefits……………...………………….…………………………. 17
1.4 System Requirements……………………………………………….…………… 19
Chapter 2 Hardware Installation…………………………………………..... 20
2.1 Installing the Wall Mount Kit……….…………………………………………….. 20
2.2 Connecting the Camera to LAN/WLAN………………………………………… 20
2.3 Applications of the Camera..…………………………………………………….. 21
Chapter 3 Accessing The Camera….…………………………………….... 22
3.1 Using IPFinder…………………………………………………………………….. 22
3.2 Accessing to the Camera………………………………………………………… 22
3.3 Configuring the IP Address of the PC…………………………………………... 25
Chapter 4 Configuring The Camera………………………………………... 26
4.1 Using the Web Configuration……………………………………………………. 26
4.2 Using Smart Wizard ……………………………………………………………… 26
4.3 Basic Setup…………………………………………………............................... 29
4.4 Network Settings…………..……………………………………………………… 31
4.5 Pan/Tilt Settings…………………………………………………………………… 35
4.6 Setting up Video & Audio…………………………………………………........... 36
4.7 Event Server Configuration…………………..………………………………….. 39
4.8 Motion Detect…………………..………………………………………………….. 42
4.9 Event Config……………………………………………………………………….. 42
4.10 Tools……………………………………………………………………………..... 46
4.11 USB……………………………………………………………………………….. 47
4.12 Information……………………………………………………………………….. 48
Appendix………………………………………………………………………... 49
A.1 Specification………………………………………………………………………. 49
A.2 GPIO Terminal Application…………………………………………………….... 50
A.3 GNU General Public License…..…………………………….………………….. 51

15
PREFACE
Thanks for purchasing the Wireless Pan Tilt Zoom IP Camera, a powerful dual-codec
wireless network camera with the 2-way audio function that provides a high-quality
image and on-the-spot audio via an Internet connection. The Infrared LEDs and light
sensor enable the camera to capture images even in a dark environment. The camera’s
Pan/Tilt functions allow you to control the camera to monitor everywhere remotely.
Through the GPIO connectors, the camera can attach a variety of external devices for
your specific purposes. The camera can be installed as a standalone system within your
application environment easily and quickly, and supports remote management function
so that you can access and control it using a Web browser on your PC.
This guide provides you with the instructions and illustrations on how to use your
camera, which includes:
Chapter 1 Introduction describes the features of the camera. You will also
know the components and functions of the camera.
Chapter 2 Hardware Installation helps you install the camera according to
your application environment. You can use this camera at home, at
work, at any where you want.
Chapter 3 Accessing the Camera lets you start using your camera without
problem. The camera can be set up easily and work within your
network environment instantly.
Chapter 4 Configuring the Camera guides you through the configuration of
the camera using the Web browser on your PC.
Chapter 5 Appendix provides the specification of the camera and some useful
information for using your camera.
NOTE: The illustrations and configuration values in this guide are for reference only. The actual
settings depend on your practical application of the camera.

16
CHAPTER 1
INTRODUCTION
1.1 Checking the Package Contents
Check the items contained in the package carefully. You should have the
following:
5Wireless Pan Tilt Zoom IP Camera.
5AC Power Adapter.
5External Antenna.
5Wall Mount Kit.
5GPIO Connector
5RJ45 Ethernet Cable
5Installation CD
5Quick Installation Guide.
5Warranty Information Card.
5GPL notice.
NOTE :Once any item contained is damaged or missing, contact the authorized dealer of your
locale.
1.2 Getting to Know Your Camera
Lens Assembly
Power LED
indicates the camera
is powered on with
the steady amber
light.
Light Sensor
is used to trigger on and off the
Infrared LEDs according the
environmental light level.
USB Port*
allows you to connect an
external USB device. It
provides the power
distribution up to 500mA.
Infrared LEDs (x7)
allow your camera to
capture clear image in
a dark environment.
Internal Microphone
allows the camera to
receive sound and voice.
Link LED
indicates the camera’s
network connectivity
with the flashing green
light.
Antenna

17
Front View
*The camera’s USB1.1 port supports WCN (Windows Connect Now) technology, which allows
you to use the notebook computer to set up and store your wireless networking configuration
on the USB storage device, and then retrieve the wireless settings when you connect the USB
storage device to the camera.
NOTE: After long pressing the Unmount button for four seconds, the Power LED starts flashing.
When the Power LED resumes the steady amber light, you can remove the USB device
safely.
Rear View
1.3 Features and Benefits
MPEG4/MJPEG Dual-codec Supported
The camera provides you with excellent images by the MPEG4/ MJPEG dual-codec
selectable technology, allowing you to adjust image size and quality, and bit rate
according to the networking environment.
2-way Audio Capability
The built-in microphone of the camera provides on-the-spot audio via the Internet,
allowing you to monitor the on-site voice. In addition, you can connect an external
speaker to the camera to speak through the camera.
Day & Night Surveillance Supported
The seven Infrared LEDs around the standard lens assembly enable the camera to
capture crystal clear images in the dark environment or at night. When the Light
Sensor detects the environmental light level becomes low, the camera captures the
images in black & white mode using these infrared LEDs.
Optimal Viewing
USB Unmount Button
is used to remove the
connected USB device
safely.
External Antenna
Connector connects the
external antenna.
GPIO Connectors
is used to connect the
external devices.
Audio-out Connector
connects an external
active speaker.
Reset Button
will restart the camera when it is
pressed quickly; when it is
pressed and held for five
seconds, the camera will resume
the factory default settings.
DC Power Connector
connects the AC power
adapter, in order to
supply power to the
camera.
Ethernet Cable Connector
connects the network cable,
which supports the NWay
protocol so that the camera
can detect the network
speed automatically.

18
With the pan/tile functions, you can easily monitor everywhere via the camera by
moving the camera lens to the left/right (165/165 degrees) or up/down (90/15
degrees). In addition, you can assign up to eight positions for the camera, enabling
you to move the camera lens to the desired position quickly.
Supports RTSP
The camera supports RTSP (Real Time Streaming Protocol), which is a technology
that allows you to view streaming media via the network. You can view the real-time
video with the Quick Time player or RealPlayer. To view the real-time streaming
image on your computer, open the Web browser and enter the RTSP link: rtsp://(IP
address of the camera)/mpeg4. (Note: RTSP is restricted to user’s internet
bandwidth and image resolution setting. Image quality might be impacted.)
Supports Multiple Profiles
The camera supports multiple profiles simultaneously, so that you can separately set
up different image settings (such as image quality and frame rate) for the three video
types of the camera: MPEG4, MJPEG, and 3GPP.
I/O Connectors Provided
The camera provides the I/O connectors on the rear panel (IN/OUT), which provide
the physical interface to send and receive digital signals to a variety of external
alarm devices. You can connect a special featured device, and then configure the
settings and control the device from the GPIO Trigger window of Web Configuration.
Remote Control Supported
By using a standard Web browser or the bundled IPCamera Manager software
application, the administrator can easily change the configuration of the camera via
Intranet or Internet. In addition, the camera can be upgraded remotely when a new
firmware is available. The users are also allowed to monitor the image and take
snapshots via the network.
Supports Connection to the External Devices
With the auxiliary Input/Output connectors, you can connect the camera to a variety
of external devices, such as the external speaker and the USB device.
Multiple Platforms Supported
The camera supports multiple network protocols, including TCP/IP, SMTP e-mail,
HTTP, and other Internet related protocols. Therefore, you can use the camera in a
mixed operating system environment, such as Windows 2000 and Windows XP.
Multiple Applications Supported
Through the remote access technology, you can use the cameras to monitor various
objects and places for your own purposes. For example, babies at home, patients in
the hospital, offices and banks, and more. The camera can capture both still images
and video clips, so that you can keep the archives and restore them at any time.
