Smeg LS9209A-3 User manual

INSTRUCTION MANUAL
DISHWASHER

Contents
13
1. Description of the controls________________________________14
2. Troubleshooting _______________________________________22
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the
information you need about the right conditions for the proper, safe use
of your dishwasher.
The individual sections are laid out to provide you with a step-by-step
guide to all your appliance's functions; the texts are easy to understand
and are complete with detailed illustrations.
This user-friendly manual will provide answers to all your questions
about use of the dishwasher.
For any other information about use and maintenance of the dishwasher,
read the enclosed manual carefully.
USER INSTRUCTIONS: useful information is provided for the use of the
washing programs and all the dishwasher's functions.

User instructions
14
1. Description of the controls
1.1 Front panel
All the dishwasher control are grouped on the front panel.
1ON/OFF BUTTON
2SELECTION PROGRAMS BUTTONS (P1...P5)
3POWER ON LIGHT
4PROGRAMS LIGHTS
5NO SALT LIGHT
6NO RINSE AID LIGHT
7PROGRAM PHASES LIGHTS
8RECESSED DOOR HANDLE

User instructions
15
DURATION CONSUMPTION
PROGRAM SELECTION TYPE AND GRADE DIRT PROGRESS
PROGRAM MINUTES
(2)
WATER
LITRES (1)
POWER
KWh (2)
SOAK
PANS AND DISHES
IN WAITING OF
COMPLETING
THE LOAD
Cold prewash 9 5 0,02
DELICATE DISHES NOT
VERY DIRTY
Wash at 45°C
Cold rinse
Rinse at 68°C
59 120,90
ECO (*)
PANS AND DISHES
NOT VERY DIRTY BUT
WITH DRY RESIDUALS
Wash at 55°C
Cold rinse
Rinse at 68°C
Dry
125 131,01
NORMAL
PANS AND DISHES
DIRTY AND WITH
DRY RESIDUAL
Cold prewash
Wash at 65°C
Cold rinse
Rinse at 68°C
Dry
80171,20
SUPER
PANS AND DISHES
WITH DRY RESIDUALS
VERY DIRTY AND
Prewash at 45°C
Wash at 70°C
2 cold rinses
Rinse at 68°C
Dry
10520 1,50
Only run the soak program with half loads.
(*) Reference program as per EN 50242 standard.
(1) Average power consumption with the softener set on level 2.
(2) The cycle duration and power consumption may vary according to the water and room
temperatures, and the type and amount of dishes.
TABLE FOR CERTIFICATION BODIES
Reference standard EN 50242
Reference program P3 - ECO
Load 10 place-settings
Type of detergent B
Amount of detergent 25 g
Rinse aid setting Depending on the model 3/4 or 4/6

User instructions
16
Before starting a washing program make sure that:
•The water supply tap is open.
•The correct amount of detergent has been added to the
dispenser.
•The baskets have been correctly loaded.
•The spray arms are able to rotate freely and without
obstruction.
•The dishwasher door is securely closed.
LIGHTING
When the ON/OFF button (1) is pressed, the dishwasher switches on
and the light (3)comes on. About 2 seconds later, the
PHASES/PROGRAM lights (7)will come on.
1.2 Washing programs
The dishwasher is equipped with a control panel, described in chapter
"1. Description of the controls", from which it is possible to carry out all
the power switch-on, switch-off and programming operations.

User instructions
17
PROGRAMMING
In this model of dishwasher, all programming procedures can only be
carried out with the door closed. As long as the door is open, the
PROGRAMS lights (4)and PHASES/PROGRAM lights (7)will remain
off.
SELECTION PROGRAM
The program selection is possible
through the relative buttons (2).
When the button relating to the program required is pressed, the relative
light will come on to confirm the operation.
START PROGRAM
To start the dishwasher, press the button of the PROGRAM (2) required
for a few seconds, until the light of the first phase of the selected
program starts to flash (confirmation beep).
As the program runs, the PHASES/PROGRAM lights (7) will indicate the
current cycle status.
The light of the phase in progress will
flash, while the lights of the previous and
subsequent phases remain on.
N.B. during execution of programs which
do not include a prewash, the first
PHASES/PROGRAM light (7) will remain
off.
Pr
e
w
as
h
W
as
h
Rinse
Dr
y

User instructions
18
END PROGRAM
When the program finishes, a buzzer sounds
briefly and all the PHASES/PROGRAM lights
(7)flash.
Press any of the SELECTION PROGRAMS buttons (2), stops the light
flashins, and the dishwasher is now ready to perform a new cycle;
opening and shutting the door or switching the appliance off and on has
the same effect.
INTERRUPTION OF A PROGRAM
In order to interrupt a running program it is necessary:
•press one of the SELECTION PROGRAMS buttons (2);
•keep the button pressed until the PROGRAM PHASES lights (7)
come on (confirmation buzzer);
•start the program (see “START PROGRAM”).
TO CHANGE A PROGRAM
To change the running program it is necessary:
•to interrupt the running program (see “INTERRUPTION OF A PROGRAM”);
•select the new program;
•start the new program (see “START PROGRAM”).

User instructions
19
ANNULLING A PROGRAM
To annul the program in progress, it must first be interrupted (see
“INTERRUPTION OF A PROGRAM”).
Now press buttons P1+P2 simultaneously and
the first three program lights will come on.
In case that the door is opened during the operation, to the next door
closing it is going to be necessary to start the program as shown in
paragraph “START PROGRAM”. The program will resume from the point in
which it was interrupted.
In case that the tub temperature is higher than 50°C the program
will start about 30 seconds later.
The washing cycle will not take place if the dishwasher door is left open
or not properly closed.

User instructions
20
TO SAVE ON ENERGY! … AND PROTECT THE ENVIRONMENT
•Always try to run the dishwasher fully loaded.
•Do not wash the dishes in running water.
•Use the washing program that is most appropriate for each type of
load.
•Do not carry out any preliminary rinsing.
•If available, connect the dishwasher to a hot water supply up to
60°C.
•When possible, skip the drying cycle by leaving the door open
when the washing cycle is complete; the air and the residual heat
will dry the dishes perfectly.
TO CUT DOWN ON DETERGENT CONSUMPTION! … AND PROTECT
THE ENVIRONMENT
The phosphates contained in dishwasher detergents are harmful to the
environment. To avoid using excessive amounts of detergent and to
save on electricity, observe the following:
•separate the more delicate items from dishes that are more
resistant to aggressive detergents and high temperatures;
•do not pour the detergent directly on the dishes.
REMOVING THE DISHES
At the end of the washing program, wait at least 20 minutes before
removing the dishes, to allow them to cool down. To prevent any water
droplets on the upper basket from falling on the dishes in the lower
basket, it is advisable to unload the lower basket first, and then the
upper basket.

User instructions
21
ADJUSTING THE WATER SOFTENING SYSTEM
The dishwasher is equipped with an device for the user to adjust the
water softening system according to the hardness of the water supply.
According to the machine model, the selector which acts on the
adjustment may be located:
•inside the plastic locking ring located on the right-hand side, inside
the dishwasher;
•inside the water softener, just below the cap.
Both allow for adjustment to 5settings:
WATER HARDNESS TABLE
WATER HARDNESS
German Degrees (°dH) French Degrees (°dF) SETTING
0 - 4 0 - 7 Setting N. 1 NO SALT
5 - 15 8 - 25 Setting N. 1
16 - 23 26 - 40 Setting N. 2
24 - 31 41 - 60 Setting N. 3
32 - 47 61 - 80 Setting N. 4
48 - 58 81 - 100 Setting N. 5
Contact your local water board for information on the hardness of your
water supply.

User instructions
22
2. Troubleshooting
In case of a malfunction, the dishwasher will identify the program by
switching on a combination of lights.
When an alrm is present, all the
PROGRAM lights (4)come on, while the
PHASES/PROGRAM lights (7)identify
the error code:
CODE PHASES LIGHTS DESCRIPTION
E1 The anti-flooding system (if installed) has been
tripped.
E2 The system which limits the water level inside the
dishwasher (safety unit) has been tripped.
E3 The appliance is not able to pump out the water.
E4 Temperature sensor disconnected.
E5 The appliance is not able to take in water.
E6 The appliance is not able to pump out the water
from the tank.
E7
The appliance is not able to measure the amount
of water loaded accurately (on models with turbine
flow-regulator only).
E8 Anomaly in the system which distributes water to
the basket (where installed).
E9
The maximum level of water for loading has been
exceeded (on models with turbine flow-regulator
only).

INSTRUCTION MANUAL
W
WA AR RN NI IN NG GS SA AN ND DR RE EC CO OM MM ME EN ND DA AT TI IO ON NS S, ,G GU UI ID DE EF FO OR RT TH HE EU US SE EO OF FB BA AS SK KE ET TS S
A
AN ND DF FO OR RC CL LE EA AN NI IN NG GD DI IS SH HW WA AS SH HE ER RS S

Contents
19
1. Safety and operating instructions ___________________________ 20
2. Installation and hook-up __________________________________ 22
2.1 Water supply connection _____________________________________________________ 22
2.2 Electrical connection ________________________________________________________ 23
3. Operating instructions ____________________________________ 24
3.1 Using the water softening system ______________________________________________ 24
3.2 Using the rinse aid and detergent dispensers _____________________________________ 25
3.3 General warnings and recommendations ________________________________________ 27
3.4 Using the baskets___________________________________________________________ 28
4. Cleaning and maintenance ________________________________ 31
4.1 General warnings and recommendations ________________________________________ 31
Thank you for choosing one of our products.
You are advised to read this manual carefully; it contains all the information you need about the right
conditions for the proper, safe use of your dishwasher.
The individual sections are laid out to provide you with a step-by-step guide to all your appliance's
functions; the texts are easy to understand and are complete with detailed illustrations.
Following the cleaning instructions provided here will keep your dishwasher's performance at peak
levels in the long term.
This user-friendly manual will provide answers to all your questions about use of the dishwasher.
INSTALLATION INSTRUCTIONS: these are intended for the qualified technician who must carry
out the installation, hook-up and testing of the appliance.
USER INSTRUCTIONS: useful advice is provided for the use of baskets, spray arms, containers and
filters.

Safety instructions
20
1. Safety and operating instructions
THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER
WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS
CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN
COMPLIANCE WITH THE REGULATIONS IN FORCE. THIS APPLIANCE IS INTENDED FOR DOMESTIC USE, AND
COMPLIES WITH THE EEC DIRECTIVES 72/23, 89/336 (INCLUDING 92/31) CURRENTLY IN FORCE, INCLUDING THE
PREVENTION AND ELIMINATION OF RADIO FREQUENCY INTERFERENCE. THE APPLIANCE IS DESIGNED FOR
THE FOLLOWING PURPOSE: WASHING AND DRYING OF DISHES; ANY OTHER USE SHALL BE CONSIDERED
IMPROPER. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR USES OTHER THAN THOSE
DESCRIBED ABOVE.
THE NAME PLATE FEATURING THE TECHNICAL DATA, SERIAL NUMBER AND MARKINGS IS VISIBLY POSITIONED
ON THE INNER EDGE OF THE DOOR. THE NAME PLATE ON THE INNER EDGE OF THE DOOR MUST NEVER BE
REMOVED.
DO NOT LEAVE THE DISCARDED PACKAGING MATERIALS UNSUPERVISED WITHIN THE HOME. SEPARATE THE
VARIOUS MATERIALS WHICH MAKE UP THE PACKAGING AND TAKE THEM TO THE NEAREST SORTED WASTE
COLLECTION CENTRE.
THE APPLIANCE MUST BE PROVIDED WITH AN EARTH CONNECTION IN ACCORDANCE WITH THE ELECTRICAL
SAFETY REGULATIONS IN FORCE.
THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR DAMAGE TO PERSONS OR PROPERTY RESULTING
FROM THE FAILURE TO EARTH THE APPLIANCE OR FROM A DEFECTIVE EARTH CONNECTION.
IF THE APPLIANCE IS NOT CONNECTED TO THE ELECTRICAL POWER SUPPLY BY MEANS OF A PLUG, IT IS
NECESSARY TO INSTALL AN ISOLATION SWITCH WITH A CONTACT OPENING GAP OF AT LEAST 3 MM.
THE PLUG ON THE POWER CORD AND THE CORRESPONDING SOCKET OUTLET MUST BE OF THE SAME TYPE,
AND MUST CONFORM TO THE REGULATIONS IN FORCE. CHECK THAT THE VOLTAGE AND FREQUENCY OF THE
ELECTRICAL POWER SUPPLY MATCH THE RATINGS ON THE NAME PLATE. AVOID USING ADAPTORS OR SHUNT
CONNECTIONS.
NEVER UNPLUG THE APPLIANCE BY PULLING THE POWER CORD.
•AFTER INSTALLATION, THE PLUG MUST REMAIN ACCESSIBLE.
•IN THE EVENT OF DAMAGE TO THE POWER CORD, HAVE IT REPLACED BY A QUALIFIED TECHNICIAN.
•AFTER CHANGING THE POWER CORD, MAKE SURE THAT THE BRACKET WHICH SECURES THE CORD IS
FIXED SECURELY IN PLACE.
IF THE APPLIANCE IS INSTALLED ON A CARPETED OR COVERED FLOOR, ENSURE THAT THE OPENINGS ON ITS
UNDERSIDE ARE NOT OBSTRUCTED.
ALWAYS SWITCH OFF THE DISHWASHER AFTER EACH USE TO AVOID WASTING ELECTRICITY.
OBSOLETE APPLIANCES MUST BE RENDERED UNUSABLE. CUT OFF THE MAINS POWER CORD AFTER
UNPLUGGING IT FROM THE WALL OUTLET, AND MAKE SAFE ANY COMPONENTS WHICH MIGHT BE DANGEROUS
FOR CHILDREN (LOCKS, DOORS, ETC.). THE APPLIANCE MUST THEN BE TAKEN TO A SORTED WASTE
COLLECTION CENTRE.

Safety instructions
21
IN THE EVENT OF A FAULT, DISCONNECT THE DISHWASHER FROM THE ELECTRICAL POWER SUPPLY AND
SHUT OFF THE WATER TAP. THEN CALL IN A QUALIFIED TECHNICIAN.
DO NOT USE APPLIANCES WHICH HAVE BEEN DAMAGED DURING TRANSIT! IF IN DOUBT, CONSULT YOUR
DEALER.
THE APPLIANCE MUST BE INSTALLED AND CONNECTED IN ACCORDANCE WITH THE INSTRUCTIONS PROVIDED
BY THE MANUFACTURER OR BY A QUALIFIED TECHNICIAN.
THE APPLIANCE IS INTENDED FOR USE BY ADULTS. DO NOT ALLOW CHILDREN TO COME NEAR OR PLAY WITH
THE DISHWASHER. KEEP CHILDREN AWAY FROM DETERGENTS AND FROM THE OPEN DISHWASHER DOOR.
THE PACKAGING MATERIALS (PLASTIC BAGS, POLYSTYRENE, METAL BARS, ETC.) MUST NOT BE LEFT WITHIN
THE REACH OF CHILDREN.
KEEP CHILDREN AWAY FROM THE OPEN DISHWASHER. THE APPLIANCE MAY CONTAIN RESIDUES OF
DETERGENT WHICH CAN CAUSE IRREVERSIBLE DAMAGE TO THE EYES, MOUTH, AND THROAT, AS WELL AS
POSSIBLE DEATH BY SUFFOCATION.
DO NOT INTRODUCE SOLVENTS SUCH AS ALCOHOL OR TURPENTINE WHICH MAY CAUSE AN EXPLOSION.
DO NOT LOAD DISHES THAT ARE SOILED WITH ASH, WAX OR PAINTS.
LEANING OR SITTING ON THE DISHWASHER DOOR WHEN OPEN MAY CAUSE THE APPLIANCE TO OVERTURN,
PUTING PEOPLE AT RISK.
DO NOT DRINK THE WATER RESIDUES WHICH MAY BE PRESENT INSIDE THE DISHES OR DISHWASHER AT THE
END OF THE WASHING PROGRAM AND BEFORE THE DRYING CYCLE.
KNIVES OR OTHER SHARP-ENDED COOKING UTENSILS MUST BE PLACED IN THE CUTLERY BASKET BLADE-
DOWN, OR LAID HORIZONTAL IN THE TOP BASKET. TAKE CARE NOT TO CUT YOURSELF AND ENSURE THAT
THEY DO NOT PROJECT FROM THE BASKET.
AQUASTOP MODELS
THE AQUASTOP DEVICE PREVENTS FLOODING IN THE EVENT OF A WATER LEAK. WHEN THE AQUASTOP
DEVICE IS TRIPPED, CALL IN A QUALIFIED TECHNICIAN TO IDENTIFY AND REPAIR THE FAULT.
IN MODELS EQUIPPED WITH THE AQUSTOP DEVICE, THERE IS A SOLENOID VALVE INSIDE THE WATER INTAKE
HOSE. DO NOT CUT THE HOSE AND DO NOT ALLOW THE SOLENOID VALVE TO DROP INTO WATER. IN THE
EVENT OF DAMAGE TO THE WATER INTAKE HOSE, DISCONNECT THE APPLIANCE FROM THE ELECTRICAL
POWER SUPPLY AND FROM THE WATER SUPPLY.
IMMEDIATELY AFTER INSTALLING THE DISHWASHER, PERFORM A QUICK TEST OF THE APPLIANCE FOLLOWING
THE INSTRUCTIONS BELOW. IF THE DISHWASHER FAILS TO OPERATE CORRECTLY, DISCONNECT IT FROM THE
ELECTRICAL POWER SUPPLY AND CALL THE NEAREST TECHNICAL SERVICE CENTRE.
DO NOT ATTEMPT TO REPAIR THE APPLIANCE.
THE DISHWASHER MEETS ALL THE REQUIREMENTS SET OUT BY THE REGULATIONS IN FORCE CONCERNING
SAFETY AND ELECTRICAL EQUIPMENT. ANY TECHNICAL CHECKS SHOULD BE CONDUCTED EXCLUSIVELY BY A
TRAINED AND AUTHORISED TECHNICIAN: REPAIRS CARRIED OUT BY UNAUTHORISED PERSONS WILL
INVALIDATE THE WARRANTY, AS WELL AS POSING A POTENTIAL HAZARD TO THE USER.
The manufacturer declines all responsibility for damage to persons or property resulting from failure to
observe the above precautions, from tampering with even a single component of the appliance, or from the use
of non original spare parts.

Installation instructions
22
2. Installation and hook-up
Remove the polystyrene basket retainers.
Position the appliance in the desired place of installation. The back or sides of the dishwasher may
be placed up against walls or other furniture units.
If the dishwasher is installed near a heat source, fit the special insulating panel to prevent
overheating and malfunction of the appliance.
To ensure stability, install integrated or built-under dishwashers only under continuous worktops,
and screw them to the adjacent units.
To facilitate the installation procedure, the intake and drain hoses can be positioned in any
direction; make sure that the hoses are not kinked, crushed or pulled too tightly. A hole at least
8 cm in diameter is required to allow the power supply cable and pipes to pass.
Level the appliance on the floor using its adjustable feet. This operation is essential for ensuring
correct operation of the dishwasher.
For free-standing models only: if the appliance is not built-in and is therefore accessible on one
side, the door hinge area must be covered for safety reasons (injury hazard).
The covering fixtures are available as an accessory from specialist dealers or the After-Sales
Service.
Some models are equipped with only one adjustable foot at the rear, which can be adjusted by
turning the screw on the lower front part of the appliance.
2.1 Water supply connection
Preventing the risk of clogging or damage: if the water pipe is new or has not been used for a
long time, before connecting to the water supply check that the water is clear and free of impurities,
to prevent damage to the appliance.
The dishwasher must always be connected to the water system with new hoses; old or used
hoses must never be reused.
CONNECTING TO THE WATER SUPPLY
Connect the intake hose to a cold water supply with ¾” gas thread, inserting the filter Asupplied
with the dishwasher.
Take care to screw the hose firmly into place with your hands and then complete by
tightening about ¼ of a turn with pliers. In dishwashers equipped with the ACQUASTOP
device, the filters is already fitted inside the threaded ring.

Installation instructions
23
The dishwasher can also be connected to a hot water supply not exceeding 60°C. Supplying the
appliance with hot water cuts down the washing time by approximately 20 minutes, but slightly
reduces its effectiveness. Make the connection to the domestic hot water supply using the same
procedure described for connecting to the cold water supply.
DRAIN CONNECTION
Insert the dishwasher’s drain hose into a drain pipe
having a diameter of at least 4 cm, or alternatively,
place it inside the kitchen sink using the plastic support
provided, taking care not to crush or excessively bend
the hose. It is important to prevent the hose from
coming loose and falling. For this purpose, the plastic
support is equipped with a hole for tying it to the wall or
water tap.
The free end should be positioned at a height of
between 30 and 100 cm, and should never be
submerged in water.
If a horizontal drain extension hose is used (for a
maximum of 3 m) the drain hose can be placed at a
maximum height of 85 cm from the ground.
2.2 Electrical connection
Plug the power cord into a suitable electrical outlet, according to the instructions given in chapter
"1. Safety and operating instructions".

User instructions
24
3. Operating instructions
Once the dishwasher has been correctly installed, prepare for use as follows:
•Adjust the water softening system;
•Add the regenerating salt;
•Add the rinse aid and detergent.
3.1 Using the water softening system
The amount of scale contained in the water (water hardness
index) can cause whitish staining on the dry dishes, which
tend to become dull over time. The dishwasher is equipped
with an automatic softening system which uses a special
regenerating salt to reduce the hardness of the water.
The dishwasher is factory set for water hardness level 3
(average hardness 41-60°dF –24-31°dH).
When using water of medium hardness, the regenerating salt container should be refilled after
approximately 20 washing cycles. The salt container can hold approximately 1.5 Kg of salt in
grains. Some models are equipped with an optical no-salt indicator. In these models, the cap of the
salt container contains a green float which descends as the salt concentration in the water drops.
When the green float can no longer be seen through the transparent cap, the container must be
topped up with regenerating salt. The container is situated at the bottom of the dishwasher. After
removing the lower basket, unscrew the salt container cap by turning it anticlockwise and pour in
the salt using the funnel supplied with the dishwasher. Before replacing the cap, remove any salt
residues from around the opening.
•When using the dishwasher for the first time, in addition to the salt it is also necessary to add
one litre of water to the container.
•Each time the salt container is refilled, make sure that the cap is securely closed. The
mixture of water and detergent must never penetrate the salt container, as this would
compromise the operation of the regeneration system. In the event of this occurring, the
warranty will be invalidated.
•Only use regenerating salt specially formulated for domestic dishwashers. If using salt tablets,
do not fill the container completely.
•Do not use table salt as it contains insoluble substances which, over time, may damage the
water softening system.
•When necessary, refill the regenerating salt container before starting the washing program.
In this way, the excess saline solution will be immediately removed by the water; the prolonged
presence of salt water inside the tank may lead to corrosion.
Be careful not to confuse the salt and detergent packages; adding detergent to the salt
container will damage the water softening system.
SALT

User instructions
25
3.2 Using the rinse aid and detergent dispensers
The detergent and rinse aid dispensers are situated on the
inner part of the door: the detergent dispenser is on the left,
and the rinse aid dispenser is on the right.
With the exception of the SOAK program, before every washing cycle it is necessary to add the
required amount of detergent to the detergent dispenser. The rinse aid, on the other hand, should
only be added as required.
ADDING THE RINSE AID
The rinse aid helps the dishes dry faster and prevents the formation of scale deposits and staining;
it is automatically added to the water during the final rinse cycle, from the container situated on the
inner side of the door.
To add rinse aid:
•Open the door.
•Rotate the container cap anticlockwise by ¼ of a turn and remove it.
•Add the rinse aid until the container is full (approximately 140 cc). The optical level indicator on
the side of the cap should be completely obscured. Refill the rinse aid when the optical level
indicator becomes clear again, or when the rinse aid warning light illuminates.
•Replace the cover and turn it in a clockwise direction.
•Use a cloth to remove any spillage of rinse aid which might lead to the formation of excess
foam.
ADJUSTING THE RINSE AID DISPENSER SETTING
The dishwasher is factory set for medium water hardness. However it possible to change the
setting by turning the dispenser’s selector to the desired position: the amount of rinse aid
dispensed is proportional to the selector position.
•To adjust the rinse aid setting, rotate the dispenser cap through a quarter turn in an
anticlockwise direction and remove it.
•Then use a screwdriver to rotate the rinse aid selector to the desired position.
•Replace the cap, turning it clockwise.
•The amount of rinse aid must be increased if the washed dishes appear dull or feature circular
stains.
•If, on the other hand, the dishes are sticky or have white streaks, it is necessary to reduce the
rinse aid setting.

User instructions
26
ADDING THE DETERGENT
To open the detergent dispenser cap, lightly press the button P. Add the detergent and close the
cap carefully.
During the washing cycle, the dispenser will be opened automatically.
•When a SUPER program is selected, in addition to the normal dose of detergent, it is
necessary to add an additional amount inside compartment Gor H.
•Use only detergents specially formulated for dishwashers. For optimal washing results it is
important to use a good quality detergent.
•The detergent packs must be sealed and stored in a dry place to prevent the formation of
lumps which may negatively affect washing results. Once opened the detergent packs should
not be kept for too long, otherwise the detergent loses its effectiveness.
•Do not use detergents formulated for washing dishes by hand, because they produce a great
deal of foam and may negatively affect the operation of the dishwasher.
•Add the correct amount of detergent. An insufficient amount of detergent will result in a partial
removal of dirt from the dishes, whereas an excessive amount is wasteful and does not
improve the washing results.
•The market offers liquid and powder detergents with differing chemical compositions, which
may contain phosphates, or be phosphate-free but contain natural enzymes.
- Detergents containing phosphates are more effective against grease and starch at
temperatures above 60°C.
-Enzyme detergents, on the other hand, are also effective at lower temperatures (from 40 to
55°C) and are more easily biodegradable. With enzyme detergents it is possible to obtain at
low temperatures comparable results to those which can only be achieved at 65°C using
traditional detergents.
For the safeguarding of the environment we recommend the use of phosphate- and chlorine
free detergents.
•Also available are tablet detergents which state that that no salt or rinse aid is required. In
some cases, these detergents might not give good results, especially with short and/or low-
temperature washing cycles.
If performance problems (e.g. a white coating on the tank or dishes, poor drying, dirt on dishes
at the end of the wash) are noted, users are advised to return to conventional products
(granular salt, powder detergent and liquid rinse aid).
However, please note that on return to the use of conventional salt, a number of cycles will be
required before the system becomes fully efficient again, so traces of white coating may still be
found on the tank and dishes. If the problem persists for too long, contact the After-Sales
Service.
•When using detergent in tablet form (bear in mind that we recommend the use of three
separate products: detergent, salt and rinse aid), place the tablets in the cutlery rack. The
dispenser is designed to use powder or liquid detergent and the door does not open completely
during the washing cycle. This means that a tablet is not completely dissolved (released),
which may lead to the following:
-not enough detergent released during the cycle, with poor washing results;
-the detergent forms a solid block in the distributor and is released during the final rinse cycle.
The introduction of detergent into the rinse aid dispenser, even in liquid form, will damage
the dishwasher.
