Smeg St8646u User manual

INSTRUCTION MANUAL

CONTENTS

Rev. 0.1 1

Contents

1 INTRODUCTION ........................................................................................ 3

2 IMPORTANT SAFETY INSTRUCTION......................................................... 5

3 INSTALLATION AND HOOK-UP ............................................................... 12

4 OPERATING INSTRUCTIONS .................................................................. 15

4.1 Using the rinse-aid and detergent dispensers........................................... 16

4.1.1 Adding the rinse-aid ................................................................................. 17

4.1.2 Adjusting the rinse-aid dispenser setting .................................................. 17

4.1.3 Adding the detergent ............................................................................... 18

4.2 General warnings and recommendations ................................................. 20

4.3 Using the racks ........................................................................................ 22

4.3.1 Lower rack............................................................................................... 23

4.3.2 Cutlery basket .......................................................................................... 25

4.3.3 Upper rack ............................................................................................... 26

5 CLEANING AND USER-MAINTENANCE .................................................. 29

5.1 General warnings and recommendations ................................................. 29

5.2 Cleaning the water intake ﬁlter ................................................................. 30

5.3 Cleaning the spray arms........................................................................... 30

5.4 Cleaning the ﬁlter unit............................................................................... 32

5.5 General warnings and recommendations for correct maintenance............ 33

5.6 Troubleshooting minor problems .............................................................. 34

6 TECHNICAL DATA ................................................................................... 36

2 Rev. 0.1

1 INTRODUCTION

rehsawhsidsihtesuoT.stcudorpruofoenognisoohcrofuoyknahT

correctly and safely, please read this manual carefully. The manual

is divided into sections giving you a step-by-step guide to all your

appliance’s functions. The texts are easy to understand and are

complete with detailed illustrations. Following the cleaning instruc-

tions provided here will keep dishwasher performance at peak levels

in the long term. This user-friendly manual will provide answers to all

your questions about use of the dishwasher.

This manual comprises the following sections:

INTRODUCTION: general information about the manual.

WARNINGS: a list of warnings concerning safety and use of the

dishwasher.

INSTALLATION INSTRUCTIONS: for the qualiﬁed technician who

must carry out the installation, hook-up and testing of the appli-

ance.

foesuehtrofdedivorpsiecivdalufesu:SNOITCURTSNIRESU

racks, spray arms, containers and ﬁlters.

Nomenclature of ﬁgures and tables:

The progressive number of each ﬁgure is shown in the bottom right-

hand corner of the relative box. An example of a progressive number

is “Fig. 4-01”, where the ﬁrst number (4) indicates the section to

which the ﬁgure belongs, while the second number (01) indicates

the progressive number of the ﬁgure in section 4 (Fig. 4-01 is the

ﬁrst ﬁgure in section 4). The tables are numbered in the same way,

bearing in mind that “Tab.” is used instead of “Fig.” (e.g.: Tab. 4-01

is the ﬁrst table in section 4). If a table occupies more than one page,

a letter is added after the progressive number (e.g.: “Tab. 4-01a”,

Tab. 4-01b”).
