Smeg SA31-1MX User manual

installation
and operating
instructions
SA31-1MX
microwave
sme
g
technology with style
���
�
��

1
CONTENTS
INSTALLATION AND EARTHING INSTRUCTIONS 2
IMPORTANT SAFETY INSTRUCTIONS 3
WHICH UTENSILS CAN BE USED IN THE OVEN? 5
CONTROL PANEL 6
SPECIFICATIONS 7
ACCESSORIES 7
HOW TO SET THE OVEN CONTROLS 8
GENERAL GUIDE LINES 11
BEFORE CALLING FOR SERVICE 12
QUESTIONS AND ANSWERS 13
CARE OF YOUR MICROWAVE OVEN 13
YOUR PRODUCT GUARANTEE 14
CONDITIONS 14
THIS GUARANTEE DOES NOT COVER ANY OF THE FOLLOWING:- 14
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result in
harmful exposure to microwave energy. It is important not to defeat or tamper with the safety
interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
(c) WARNING : If the door or door seals are damaged, the oven must not be operated until it has been
repaired by a competent person: (1) door (bent), (2) hinges and latches (broken or loosened), (3)
door seals and sealing surfaces.
(d) WARNING : It is hazardous for anyone other than a competent person to carry out any service or
repair operation which involves the removal of a cover which gives protection against exposure to
microwave energy.
(e) WARNING : Liquids or other foods must not be heated in sealed containers since they are liable to
explode.
(f) WARNING : Only allow children to use the oven without supervision when adequate instructions
have been given so that the child is able to use the oven in a safe way and understands the hazards
of improper use.
(g) WARNING : When the appliance is operated in the combination mode, children should only use the
oven under adult supervision due to the temperatures generated.

2
INSTALLATION AND EARTHING INSTRUCTIONS
How to examine your microwave oven after unpacking.
Unpack oven, remove all packing material, and examine the
oven for any damage such as dents, broken door, latches or
cracks in the door. Do not remove the film from inside the door.
Notify dealer immediately if the oven is damaged. Do not install if
the oven is damaged.
Where to place your microwave oven.
1. Place the oven on a flat and stable surface.
2. The microwave oven shall not be placed in a cabinet unless it
has been tested in a cabinet.
3. Surface of the oven is protected by a plastic film which should
be removed before using.
4. Leave space behind and sides and upper of the oven. All air
vents should be kept a clearance.
If all vents are covered during operation, the oven may
overheat and, eventually, lead to oven failure.
5. Keep away from radio and TV sets. If the oven is located close
to a TV, radio interference may result.
6. Keep away from heating appliances and water taps. Keep the
oven away from hot air, steam or splash when choosing a
place to position it, or the insulation might be adversely
affected and breakdowns occur.
7. The minimum height of free space necessary above the top
surface of the oven is minimum 170mm.
Prior to use (If your oven has a grill element)
In order to protect your oven during transportation and storage,
the grill element is covered with a protective coating. To remove
this coating the grill element must be heated for 5 minutes. This
procedure will produce some bad odours as the protective
coating on the element disappears.
To remove the coating, use the following procedures:
1. Place an overproof and microwave safe bowl, containing
200cc of water or more, in the oven.
2. Press the convection button.
3. Set the time to 5 minutes.
4. Press the start button.
5. When the 5 minutes has elapsed, an acoustic signal sounds.
Note:
The protective coating has now been removed and the oven is
ready to use. Please be aware that your oven now is very hot.
6. Open the oven door and remove the bowl with water (use
oven gloves when removing the bowl).
CHILD LOCK
To prevent child from operating the oven, install the childlock key.
1. Touch Stop/Clear button for 3 seconds.
Indicator lock is indicated and all buttons do not operate.
2. Touch Stop/Clear button for 3 seconds once again, then
childlock is canceled.
-WARNING: Only allow children to use the oven without
supervision when adequate instructions have been given so
that the child is able to use the oven in a safe way and
understands the hazards of improper use.
Electrical Connection
WARNING-THIS APPLIANCE MUST BE EARTHED.
REFER TO RATING PLATE FOR VOLTAGE AND CHECK
THAT THE APPLIANCE VOLTAGE CORRESPONDS WITH
THE SUPPLY VOLTAGE IN YOUR HOME.
The flexible mains lead must be correctly connected, as below, to
a three pin plug of not less than 13 AMP capacity. You must use
a 3 pin plug which should be marked with the number BS 1363
and it should be fitted with 13 AMP fuse marked with the number
BS 1362.
We recommend the use of good quality plugs and wall sockets
that can be switched off when the machine is not in use.
IMPORTANT-The wires in the mains lead fitted to this appliance
are coloured in accordance with the following code
GREEN AND YELLOW-EARTH
BLUE-NEUTRAL
BROWN-LIVE
As the colour of the wires in the mains lead of this appliance may
not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
Power supply
• Check your local power source. This oven requires a current of
approximately 15(12)amperes, 240V 50Hz.
• Power supply cord is about 1.2 meters long.
• The voltage used must be the same as specified on this oven.
Using a higher voltage may result in a fire or other accident
causing oven damage. Using low voltage will cause slow
cooking. We are not responsible for damage resulting from use
of this oven with a voltage of ampere fuse other than those
specified.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified person
in order to avoid a hazard.
The wire which is coloured GREEN AND YELLOW must be
connected to the terminal in the plug which is marked with the
letter "E" or the earth symbol or coloured GREEN AND
YELLOW, or GREEN.
The wire which is coloured BLUE must be connected to the
terminal which is marked with the letter "N" or coloured BLACK,
or BLUE.
The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter "L" or coloured RED , or
BROWN.
If the terminals in the plug are unmarked or you are in any doubt
as to the correct connections, consult a qualified electrician.
If you do not make the proper electrical connections you will
damage your microwave oven and possibly injure yourself.
Neither the manufacturer nor the supplier are liable if this
happens.
MOULDED PLUGS
Should it be necessary to remove a moulded on plug from the
mains cable, it should be cut off and replaced with a suitable
replacement.
The moulded plug cannot be used for any other appliance,
therefore remove the fuse and dispose immediately and safely to
prevent anyone, especially children from plugging it in to a wall
socket, which will create a safety hazard.
Should the mains lead ever require replacement, it is essential
that this operation be carried out by a qualified electrician and
should only be replaced with a flexible cord obtained from the
manufacturer.
Applicable only if moulded plug is fitted.
After replacement of a fuse in the plug, the fuse cover must be
refitted. If the fuse cover is lost, a replacement cover is obtained.
The colour of the correct replacement fuse cover is that of the
coloured insert in the base of the plug or the colour that is
embossed in words in the base of the plug recess or elsewhere
on the plug. Always state this colour when ordering a
replacement fuse cover.
Only 13 amp replacement fuses which are ASTA approved to BS
1362 should be fitted

3
IMPORTANT SAFETY INSTRUCTONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
WARNING : To prevent fire, burns, electric shock and other warnings:
Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance
from this oven:
SAVE THESE INSTRUCTIONS
1. Do not use the oven for any reason other than food
preparation, such as for drying clothes, paper, or any other
nonfood items or for sterilizing purposes.
2. Do not use the oven when empty, this could damage the
oven.
3. Do not use the oven cavity for any type of storage, such
as papers, cookbook, cookware, etc.
4. Do not operate the oven without the glass tray in place. Be
sure it is properly sitting on the rotating base.
5. Make sure you remove caps or lids prior to cooking when
you cook food sealed in bottles.
6. Do not put foreign material between the oven surface and
door. It could result in excessive leakage of microwave
energy.
7. Do not use recycled paper products for cooking. They may
contain impurities which could cause sparks and/or fires
when used during cooking.
8. Do not pop popcorn unless popped in a microwave
approved popcorn popper or unless it's commercially
packaged and recommended especially for microwave
ovens. Microwave popped corn produces a lower yield
than conventional popping; there will be a number of
unpopped kernels. Do not use oil unless specified by the
manufacturer.
9. Do not cook any food surrounded by a membrane, such
as egg yolks, potatoes, chicken livers, etc., without first
piercing them several times with a fork.
10. Do not pop popcorn longer than the manufacturer's
directions. (popping time is generally below 3 minutes).
Longer cooking does not yield more popped corn, it can
cause scorchings and fire.
Also, the cooking tray can become too hot to handle or
may break.
11. If smoke is observed, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
12. When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
13. The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
14. Always test the temperature of food or drink which has
been heated in a microwave oven before you give it to
somebody, especially to children or elderly people. This
is important because things which have been heated in a
microwave oven carry on getting hotter even though the
microwave oven cooking has stopped.
15. Eggs in their shell and whole hard-boiled eggs should not
be heated in microwave ovens since they may explode,
even after microwave heating has ended.
16. Keep the waveguide cover clean at all times. Wipe the
oven interior with a soft damp cloth after each use. If you
leave grease or fat anywhere in the cavity it may
overheat, smoke or even catch fire when next using the
oven.
17. Never heat oil or fat for deep frying as you cannot control
the temperature and doing so may lead to overheating
and fire.
18. Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
19. a) Be cautions about touching parts other than control
panel during or immediately following grill or combi
cooking.
b) Always use hot pads or oven mitts when placing or
removing food and/or accessories from the oven.
20. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
21. Children should be supervised to ensure that they do not
play with the appliance.

4
1. Do not use the oven for any reason other than food
preparation, such as for drying clothes, paper, or any other
nonfood items or for sterilizing purposes.
They may catch on fire.
2. Do not use the oven when empty, this could damage the
oven.
3. Do not use the oven cavity for any type of storage, such as
papers, cookbook, cookware, etc.
4. Do not operate the oven without the turntable tray in place.
Be sure it is properly sitting on the rotating base.
5. Be caution when removing the turntable tray after cooking
meats that may have caused an accumulation of grease in
the tray.
6. Unlike microwave-only ovens, this oven may become hot
on the cabinet and oven door.
Always use hot pads or oven mitts when placing or
removing food and/or accessories from the oven.
Be cautions about touching parts other then control panel
during or immediately following grill or combination
cooking.
7. If the oven is hot from combination cooking, do not use
plastic or Styrofoam cookware for microwave cooking.
They may melt.
8. Do not use recycled paper products for cooking.
They may contain impurities which could cause sparks
and/or fires when used during cooking.
9. Do not continue to cook with metal utensils if sparking
appears. See "Accessories" section on page 7 for proper
use of cookware.
10. Do not leave the oven unattended during short cooking
times. Overcooking and fire may result.
11. Do not cook any food surrounded by a membrane, such as
egg yolks, potatoes, chicken livers, etc., without first
piercing them several times with a fork.
12. Do not pop popcorn unless popped in a microwave
approved popcorn popper or unless it's commercially
packaged and recommended especially for microwave
ovens. Microwave popped corn produces a lower yield
than conventional popping; there will be a number of
unpopped kernels. Do not use oil unless specified by the
manufacturer.
13. Do not attempt to operate this appliance with the door
open.
14. Do not attempt to remove covers, panels, etc.
15. Look at the oven from time to time when food is heated or
cooked in disposable containers of plastic, paper or other
combustible materials.
16. If smoke is observed, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
17. Microwave heating of berverages can result in delayed
eruptive boiling, therefore care has to be taken when
handling the container.
18. Make sure you remove caps or lids prior to cooking when
you cook food sealed in bottles.
19. Do not put foreign material between the oven surface and
door. It could result in excessive leakage of microwave
energy.
20. Do not pop popcorn longer than the manufacturer's
directions. (popping time is generally below 3 minutes).
Longer cooking does not yield more popped corn, it can
cause scorchings and fire.
Also, the cooking tray can become too hot to handle or may
break.
21. When heating food in plastic or paper containers, keep an
eye on the oven due to the possibility of ignition.
22. Always test the temperature of food or drink which has
been heated in a microwave oven before you give it to
somebody, especially to children or elderly people. This is
important because things which have been heated in a
microwave oven carry on getting hotter even though the
microwave oven cooking has stopped.
23. Eggs in their shell and whole hard-boiled eggs should not
be heated in microwave ovens since they may explode,
even after microwave heating has ended;
24. Keep the waveguide cover clean at all times. Wipe the
oven interior with a soft damp cloth after each use. If you
leave grease or fat anywhere in the cavity it may overheat,
smoke or even catch fire when next using the oven.
25. Never heat oil or fat for deep frying as you cannot control
the temperature and doing so may lead to overheating and
fire.
26. During use the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
General Use
Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this
oven:

5
Microwave function only
Utensils and cooking containers used in a microwave oven
should be of a material that does not act as a barrier to
microwave energy. Generally this means that you should cook
in either (paper), plastic, glass or ceramic. Metal pans reflect
microwave energy and inhibit cooking, and should not be
used. In addition to material, the shape of the container should
also be considered. Round oval shapes give the most even
cooking. Square or rectangular containers may over-cook
foods in the corners because more energy is absorbed there.
Shallow containers give more even cooking results.
Utensils made of china and ceramic excellent to use in your
microwave oven. Most types of glass are also very good.
Lead crystal glass can crack and should therefore, not be
used. Plastics and paper can also be used, provided they
can withstand the temperature of the heated food. For
cooking only use plastics, which will withstand a temperature
of over 120˚C, e.g. polypropene and polyamide. Some plastic
materials, e.g. melamine, will be heated by the microwave,
and be damaged. To find out if a certain container is suitable,
the following simple test can be made:
Place the empty container and a glass of water inside the
microwave oven. The water is needed because the oven
must not be operated empty or with empty containers only.
Let the oven work on full power for one minute. A suitable
container will only be lukewarm.
Metal containers, e.g. saucepans or frying pans should not
be used in microwave ovens. Nor should plates or vessels
with decorations be used since metal e.g. gold, might be part
of the decoration and such decorations will be damaged.
Small pieces of aluminiuum foil can be
used, but only to shield the areas that
would over-cook (e.g. for covering
chicken wings, leg tips and fish tails) but
the foil must not touch the side of the
oven as damage may occur.
TO AVOID EXPLOSION AND SUDDEN BOILIING 1. Eggs
Never cook eggs in their shells. Steam will build up inside
the shell during cooking and the egg will explode.
If you want to cook or reheat eggs which have not been
broken up by scrambling or mixing, you must always
pierce the yolks or these will also explode. You should
slice shelled hard boiled eggs before you reheat them in
your microwave oven.
2. Piercing
Always pierce food which has a skin or membrane, for
example, potatoes, tomatoes, apples, sausages etc. If you
don't pierce them, steam will build up inside and they may
explode.
3. Lids
Always remove the lids of jars and containers and take
away food containers, before you cook using your
microwave oven. If you don't, then steam and pressure
might build up inside and cause an explosion even after
the microwave cooking has stopped.
WHICH UTENSIL CAN BE USED IN THE OVEN?
WARNING
Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to be
boiling due to surface tension of the liquid. Visible bubbling
or boiling when the container is removed from the microwave
oven is not always present. this could result in very hot
liquids suddenly boiling over when a spoon or other utensilis
is inserted into the liquid.
To reduce the risk of injury to persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
e) Use extreme care when inserting a spoon or other utensil
into the container.
Glass (general) No Yes (1) No
Glass (heat resistant) Yes Yes Yes
Glass-ceramic and
ceramic (heat resistant) Yes Yes (1) Yes (1)
Earthenware Yes Yes Yes
China (heat resistant) Yes Yes Yes
Plastic (general) No Yes (2) No
Plastic (heat resistant) Yes (2) Yes (2) Yes (2)
Aluminium foil containers
/aluminium foil Yes Yes (3) Yes
Metal baking tins Yes (4) No Yes (4)
Metal (pots.pans, etc) Yes No No
Paper No Yes No
1. Without metal parts or metal trims.
2. Some plastics are heat-proof only to certain temperatures.
Check carefully!
3. It is possible to use aluminium foil to shield deliate areas of
food (this prevents over-cooking).
4. Metal tins can be used in the combination methods, however
if these are very deep, they will greatly reduce the efficiency,
as metal shields the microwave energy from the food.
Caution:
• There are a number of accessories available on the
market. Before you buy, make sure they are suitable
for microwave use.
• When you put food in the microwave oven, make sure
that food, food supports or covering do not come in
direct contact with any of the internal walls or the ceiling
of the cavity since discolouration may take place.
Only use utensils that are suitable for use in microwave ovens.
Before use, the user should check that utensils are suitable for use in microwave ovens.
Material Grill &
Convection
cooking Microwave
cooking Combined cooking

6
CONTROL PANEL
M/W
High Mid-Hi
no Mid-Low cups Low g
Mid
Welght
Power Frozen
Pizza Dinner
Plate
Defrost Beverage Muffin
M e n u
1. Baked Potato
2. Fresh Vegetable
3. Soup
4. Fish Fillet
5. Meat Loaf
Welght
Stop
Clear
Start
Speedy Cook
Def.
Menu
Program
Cook
Time
When blinking, the oven is
operating in WEIGHT
DEFROST.
When blinking, the oven is
operating in TIME DEFROST.
When blinking, the oven is
operating in MICROWAVE
COOK (5 STEPS)
- HI
- MID-HI
- MID
- MID-LOW
- LOW
DIAL KNOB - Used to
enter the cooking time and
weight input.
Stop/Clear Button - Used
to pause or clear all
information manually put into
the oven.
When blinking, the oven is
operating in MENU.
When blinking, the oven is
operating in PROGRAM.
(ONE-TOUCH COOK)
- FROZEN PIZZA
- DINNER PLATE
- BEVERAGE
- MUFFIN
When blinking, the oven is
ready for input mode.
MENU key
WEIGHT key
Start Button - Used to start
the selected cycle.
Speedy Cook Button - Used
to quickly program cooking
time in 30 seconds
increments.

7
SPECIFICATIONS
EXTERNAL VIEWS
Power supply 240V~,50Hz
Power consumption 1,250 W
Microwave Output power 950 W (IEC 705)
Frequency 2,450 MHz
Outside Dimensions (W x H x D) 526 x 345 x 408 mm (20.6 x 13.6 x 16.1 in)
Cavity Dimensions (W x H x D) 335 x 245 x 335 mm (13.2 x 9.6 x 13.2 in)
Net Weight 18.5 kg (40.8 lbs)
Timer 60 minutes
Select function Microwave/One touch cook/Menu cook/Defrost
Microwave power level 5 stages
* Specifications are subject to change without notice.
Microwave oven is a Group 2 ISM equipment in which radiofrequency energy is intentionally generated and used in the form of
electromagnetic radiation for the treatment of material. This oven is a Class B equipment suitable for use in domestic establishments and in
establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purposes.
350
318 345
526
238
408
ACCESSORIES
Use it under the glass turn-table when the turning function
is needed. Never put other utensils than the glass turn-table
directly on the roller cross. Use a mild detergent, water and
a soft cloth to clean the roller cross.
• Place the roller guide in the oven.
May be used with all cooking methods. The glass turn-table
collects the dripping juices and food particles that otherwise
would stain and soil the interior of the oven. It may also be
used as a cooking utensil.
• Place the glass turn-table on the roller.

8
■MICROWAVE COOKING
SETTING THE CONTROLS
1. Press button. The display will show " : 0".
This oven has 5 power levels from HI to LOW.
2. Press the button to
select the desired microwave
power level.
For example: power level
"MID-HI"
Press button two times more.
3. Turn the DIAL KNOB for the
desired cooking time.
For example: 18 minutes
Turn right or left the DIAL
KNOB.
Then, 18:00 will show in the
dispaly.
Time can be set up from 10
seconds to 60 minutes.
4. Press button.
The oven will now start microwave cook for 18 minutes at
power level "MID-HI".
5. Four beeps will sound at the end of the cooking time.
The indicator light will go off. The display panel will return to
the "0". The oven light will turn off and the turntable will stop
turning.
■TIME DEFROST
SETTING THE CONTROLS
1. Press button twice.
2. Turn the DIAL KNOB for the
desired defrosting time.
For example: 18 minutes
Time can be set up from 10
seconds to 60 minutes.
3. Press button
4. Four beeps will sound at the end of the cooking time.
The indicator light will go off. The display panel will return to
the "0". The oven light will turn off and the turntable will stop
turning.
HOW TO SET THE OVEN CONTROLS
Tips:
• Be sure to read the cookbook's introduction before
operating the oven.
• Also remember to read this operating instruction for
proper safety information and instruction before using the
oven.
• See the cookbook for specific recipes.
• Prior to setting the controls, place one cup of water in the
oven, on a heat-proof glass measuring cup, for testing
purposes.
• When setting the controls, every time a button is
pressed, a beep can be heard.
Note:
• To insure the best microwave and defrost results, be
sure to start with a cool oven. This is important if grill, or
combination was used prior to microwave cooking. The
cooling fan wil run for five minutes after the end of
cooking.
• The variable power Level settings equal the following
wattage.
Note:
• After the end of microwave cooking, the cooling fan will
run for five minutes.
• It is displayed after an interval of 10 seconds from 10
seconds to 5 minutes, 30 seconds from 5 minutes to 10
minutes, 1 minute from 10 minutes to 60 minutes.
Note:
• During the defrosting operation, turn the food over after
hearing a 4-beep by 4 times for complete defrost.
M/W
DISPLAY HI MID MID MID LOW
-HI -LOW
POWER 100% 80% 60% 40% 20%
LEVEL
M/W
START
START
M/W
M/W
M/W
MID-HI
M/W
MID-HI
WEIGHT TIME
DEFROST

DEFROST
DEFROST

9
■WEIGHT DEFROST
SETTING THE CONTROLS
1. Press button.
2. Turn the DIAL KNOB for the desired defrosting weight.
For example: 2.3kg
3. Press button.
4. The display will show the
defrosting time.
5. Four beeps will sound at the end of the cooking time.
The indicator lights will go off. The display panel will return to
the "0". The oven light will turn off and the turntable will stop
turning.
■PROGRAM COOKING
(ONE-TOUCH COOKING)
One touch cook allows you to cook or reheat many of your
favorite foods by touching just one pad. To increase quantity,
touch chosen pad until number in display is same as desired
quantity to cook.(except for MUFFIN & DINNER PLATE)
SETTING THE CONTROLS
1. Touch FROZEN PIZZA pad.
When you touch FROZEN
PIZZA pad, "200" is
displayed.
After 1.5 seconds, the display is changed into cooking time of
quantity and the oven starts cooking.
2. Touch FROZEN PIZZA pad
once more.
When you touch FROZEN
PIZZA pad, "300" is
displayed.
1. Touch DINNER PLATE pad.
When you touch DINNER
PLATE pad, "300" is
displayed.
After 1.5 seconds, the display is changed into cooking time of
quantity and the oven starts cooking.
1. Touch BEVERAGE pad.
When you touch BEVERAGE
pad, "1" is displayed.
After 1.5 seconds, the display
is changed into cooking time of quantity and the oven starts
cooking.
1. Touch MUFFIN pad.
When you touch MUFFIN
pad, "5" is displayed.
After 1.5 seconds, the display is changed into cooking time of
quantity and the oven starts cooking.
Note:
• This mode allows you to set weight from 0.1kg to 2.9kg
• During the defrosting operation, turn over the food after
hearing a 4-beep by 4 times.
NOTE: 1.Use only one frozen pizza at a time.
2.Use only frozen pizza for microwave oven.
3.If the cheese of frozen pizza does not melt
sufficiently, cook a few seconds longer.
4.Some brands of frozen pizza may require more
or less cooking time.
* BEVERAGE * (250ml/cup)
• 1 cup(mug) : Touch BEVERAGE once.
• 2 cups(mugs): Touch BEVERAGE twice within 1.5
seconds.
• 3 cups(mugs): Touch BEVERAGE three times within 1.5
seconds.
NOTE: 1. This setting is good for restoring cooled
beverage to a better drinking temperature.
2. Stir after cooking.
DEFROST
DEFROST
START
g
WEIGHT TIME
DEFROST

g
PROGRAM
COOK

g
PROGRAM
COOK

g
PROGRAM
COOK

CUP
PROGRAM
COOK

FROZEN
PIZZA
DINNER
PLATE
BEVERAGE
NO g
PROGRAM
COOK

MUFFIN

10
■MENU COOKING
SETTING THE CONTROLS
1. Press button
Then, "AC-1" will show in the display.
2. Select the desired cooking menu.
For example: roast pork.
Press button once
again then "AC-2" will show in
the display.
3. If you want to select other
cooking, touch the pad again, until display shows your desired
menu.
4. Press button.
The oven will now start programmed cook for menu 2.
The cooking time of the menu 2, fresh vegetable, is 4 or 5.67
minutes.
5. The display will show the cooking time
6. Four beeps will sound at the end of the cooking time.
The indicator light will go off. The display panel will return to
the "0". The oven light will turn off and turntable will stop
turning.
■TO INTERRUPT THE COOKING CYCLE
DURING OPERATION-open the door or
press stop/clear button.
1. The oven will immediately stop.
2. If no further cooking required, press STOP/CLEAR button.
3. The "0" is displayed.
4. To continue cooking, close the oven door and Press
button. The oven will restart.
■GENERAL COOKING HINTS
1. When cooking a roast with an excess amount of fat, it is helpful
to remove the fat at turnove times to prevent pattering.
2. Prick the meats, fish or poultry with a fork to prevent bursting.
Steam builds up pressure in meals, fish or poultry which is
tightly covered by a skin or membrance.
3. Reduce suggested cooking times. It is always better to under-
cook foods rather than to overcook them. If a range of times is
stated in a recipe, cook the food at the minimum suggested
time, check for doneness, and then cook slightly longer if
necessary.
■SPEEDY COOK
SETTING THE CONTROLS
1. Press button.
2. " :30" will
appear in the display window.
3. Whenever this pad is
pressed, cooking time is
increased by 30 seconds.
4. If the time was set this oven will operate automatically after 2
seconds.
5. Four beeps will sound at the end of the cooking time.
The indicator light will go off. The display panel will return to
the "0". The oven light will turn off and the turntable will stop
turning.
■CHILD SAFETY LOCK
The safety lock prevents unwanted oven operation such as
by small children. To set, Press STOP/CLEAR for 2 seconds,
LOCK indicator lights. To cancel, press STOP/CLEAR for 2
seconds, LOCK indicator goes off.
SPEEDY COOK
SPEEDY COOK
Note:
• There is preprogrammed cooking of five menu. (1-5)
• Don't need to set cooking time, power or function.
Note:
• The menu of pre-programmed cooks equal to the
followingAC-1 Baked Potato (1ea, 2ea, 3ea)
AC-2 Fresh Vegetable (200g, 300g)
AC-3 Soup (250g, 350g)
AC-4 Fish Fillets (300g, 500g)
AC-5 Meat Loaf (500g, 700g)
• See the cooking guide for specific recipes.
Note:
• The cooking time increases from 30 seconds to 5
minutes.
MENU
MENU
MENU
START
START
MENU

M/W
g

11
GENERAL GUIDE LINES
Since microwave cooking to some extent is different from
traditional cooking, the following general guidelines should be
considered whenever you use your microwave oven
If the food is undercooked
Check if:
• You have selected the correct power level.
• The selected time is sufficient-the times given in the recipes
are approximate. They depend on initial temperature,
weight and density of the food etc.
• The container is appropriate.
If the food is overcooked,i.e. dried out or burnt
Before you cook again, consider whether:
• The power level was too high.
• The set time was too long-the times in the recipes are
approximate. They depend on initial temperature, weight
and density of the food etc.
Points to remember when defrosting
• The shape of the package alters the defrosting time.
Shallow rectangular packets defrost more quickly than a
deep block.
• Separate pieces as they begin to defrost; freef low slices
defrost more easily.
• Shield areas of food with small pieces of foil if they start to
become warm.
• When defrosting, it is better to under thaw the food slightly
and allow the process to finish during the standing time.
The amount of food
The more food you want to prepare the longer it takes. A rule
of thumb is that double amount of food requires almost
double the time. If one potato takes four minutes to cook,
approximately seven minutes are required to cook two
potatoes.
Starting temperature of food
The lower the temperature of the food which is being put into
the microwave oven, the longer time it takes. Food at room
temperature will be reheated more quickly than food at
refrigerator temperature.
Composition of the food
Food with a lot of fat and sugar will be heated faster than
food containing a lot of water. Fat and sugar will also reach a
higher temperature than water in the cooking process.
The more dense the food, the longer it takes to heat. “Very
dense” food like meat takes longer time to reheat than lighter,
more porous food like sponge cakes.
Size and shape
Smaller pieces of food will cook more quickly than larger
pieces and uniform pieces of food cook more evenly than
irregularly shaped foods.
With unevenly shaped food, the thinner
parts will cook faster than the thicker areas.
Place the thinner chicken wings and legs to
the centre of the dish.
Stirring, turning of foods
Stirring and turning of foods are techniques used in
conventional and well as in microwave cooking to distribute
the heat quickly to the centre of the dish and avoid over-
cooking at the outer edges of the food.
Covering food helps:
• To reduce spattering
• To shorten cooking times
• To retain food moisture
All covering, which will allow microwaves to pass through are
suitable-See above “Which utensils can be used in the
oven?”
Releasing pressure in foods
Several foods are tightly covered by a skin or membrane.
These foods should be pricked with a fork or cocktail stick to
release the pressure and to prevent bursting, as steam builds
up within them during cooking. This applies to potatoes,
chicken livers, sausages, egg yolks and some fruits.
Standing time
Always allow the food to stand for some time after using the
oven. standing time after defrosting, cooking/reheating
always improves the result since the temperature will then be
evenly distributed through out the food.
In a microwave oven foods continue to cook even when the
microwave energy is turned off. They are no longer cooking
by microwaves, but they are still being cooked by the
conduction of the high residual heat to the centre of the food.
The length of standing time depends on the volume and
density of the food. Sometimes it can be as short as the time
it takes you to remove the food from the oven and take it to
the serving table. However, with larger, denser foods, the
standing time may be as long as 10 minutes. During
‘standing’, the internal temperature of the food will rise by as
much as 8˚C and the food will finish cooking in this time.
Arranging food
This is done in several ways in microwave cooking to give
more even cooking results.
If you are cooking several items of the same
food such as jacket potatoes, place them in a
ring pattern for uniform cooking. When
cooking foods of uneven shapes or thickness,
place the smaller or thinner area of the food
towards the centre of the dish where it will be heated last.
Uneven foods such as fish should be arranged in
the oven with the tails to the centre.
If you are saving a meal in the refrigerator or
‘plating’ a meal for reheating, arrange the
thicker, denser foods to the outside of the
plate and the thinner or less dense foods
in the middle.
Place thin slices of meat on top of each
other or interlace them. Thicker slices such
as meat loaf and sausages have to be
placed close to each other. Gravy or sauce
should be reheated in a separate container.
When you cook or reheat whole fish, score
the skin this prevents cracking.
Shield the tail and head with small pieces of
foil to prevent overcooking but ensure the
foil does not touch the sides of the oven.

12
BEFORE CALLING FOR SERVICE
You can often correct operating problems yourself. If
your microwave oven fails to work properly, locate the
operating problem in the chart below and try the
solutions marked for each problems.
If the microwave oven still does not work properly,
contact the nearest Service Center.
Caution:
1. Do not attempt to operate the oven while empty as
this will cause damage.
2. As an exhaust is located in the rear of the oven, install
the oven so as not to block the outlet.
Note:
It is quite normal for steam to be emitted around the
door during the cooking cycle. The door is not intended
to seal the oven cavity completely but its special design
contributes to the complete safety of the appliance.
PROBLEM
Oven will not start
Arcing or sparking
Unevenly cooked foods
Overcooked foods
Undercooked foods
Improper defrosting
SOLUTION
XXXXXX
XXXX
X
XXXX
XXXXX
Is start pad touched?
Is power cord plugged in?
Is door closed?
Set the cooking time.
Use approved cookware only.
Do not operate with oven empty.
Supplied tray must be used.
Turn of stir food.
Completely defrost food.
Push correct numeral pads./Touch correct Function Pads.
Check to see that oven ventilation ports are not blocked.
Open the door slightly and wait 10~15min. for cooling.

13
Q: I accidentally ran my microwave oven without any
food in it. is it damaged?
A: We do not recommend to operating the microwave oven
without any food. However, running the oven empty for a
SHORT time will not damage the oven.
Q: Can I open the door when the oven is operating?
A: The door can be opened anytime durng the oven
operation. Microwave energy will be instantly switched off
and the time setting will maintain until the door is closed.
Q: Does microwave energy pass through the viewing
screen in the door?
A: No. The metal screen bounces back the energy to the oven
cavity. The holes are made to allow light to pass through.
They do not let microwave energy pass through.
Q: My microwave oven causes interference with my TV.
Is this normal?
A: Some radio and TV interference might occur when you
cook with the microwave oven. This interference is similar
to the interference caused by small appliances such as
mixers, vacuums, blow dryers, etc. It does not indicate a
problem with your oven.
Q: How can we know whether the oven is operating or
not'?
A: Oven is operating only when the door is closed.
The operation of fan moter is same as the oven's
operating.
Q: Why does my oven light dim?
A: When cooking with DEF power, the oven must cycle to
obtain the selected power levels. The oven light dims and
clicking noises can be heard when the oven cycles.
Q: When is the oven light on and off?
A: The oven light is on during the cooking time.
Q: Why does steam accumulate on the oven door?
A: During cooking, steam is given off from the food. Most of
the steam is removed from the oven by the air which
circulates in the oven cavity.
However, some steam will condense on cooler surfaces
such as the oven door. This is normal.
Q: Sometimes warm air comes from the oven vents.
Why?
A: The heat given off from the cooking food warms the air in
the oven cavity. This warmed air is carried out of the oven
by the air flow pattern in the oven. There are no
microwave in the air. The oven vents should never be
blocked during cooking.
QUESTIONS AND ANSWERS
Turn the oven off before cleaning.
Keep the inside of the oven clean. When food spatters or
spilled liquids adhere to oven walls, wipe with a damp
cloth. Mild detergent may be used if the oven gets very
dirty. The use of harsh detergent or abrasives is not
recommended.
The outside oven surface should be cleaned with soap
and water, rinsed and dried with a soft cloth. To prevent
damage to the operating parts inside the oven, water
should not be allowed to seep into the ventillation
openings.
If the Control Panel becomes wet, clean with a soft, dry
cloth. Do not use harsh detergents or abrasives on
Control Panel.
If steam accumulates inside or around the outside of the
oven door, wipe with a soft cloth. This may occur when
the microwave oven is operated under high humidity
conditions and in no way indicates malfunction of the unit.
It is occasionally necessary to remove the glass tray for
cleaning. Wash the tray in warm sudsy water or in a
dishwasher.
The roller guide and oven cavity floor should be cleaned
regularly to avoid excessive noise. Simply wipe the bottom
surface of the oven with mild detergent or window cleaner
and dry. The roller guide may be washed in mild sudsy
water or in a dishwasher.
CARE OF YOUR MICROWAVE OVEN
1
2
3
4
5
6
7
ROLLER GUIDE
GLASS TRAY
1
2
The ROLLER GUIDE and oven floor should be
cleaned frequently to prevent excessive noise.
The ROLLER GUIDE MUST ALWAYS be used for
cooking together with the Glass Tray.
1
2
3
4
DO NOT operate the oven without the Glass Tray in
place.
DO NOT use any other Glass Tray with this oven.
If the Glass Tray is hot, ALLOW TO COOL before
Cleaning or placing it in water.
DO NOT cook directly on the Glass Tray.
Glass Tray Roller Guide

14
YOUR PRODUCT GUARANTEE
Dear Customer
Thank you for buying this Daewoo product. In the unlikely
event of a failure all repair work will be carried out by your
retailer or Daewoo approved service centre, for a period of 12
months from date of sale.
Daewoo Electronics Sales UK Ltd. will provide the following
services in order to expedite this guarantee.
Daewoo Electroncs Sales UK Ltd. will guarantee this product
to be free of defects in materials and workmanship at the
time of it's original purchase by consumer to the retailer for a
period of 12 months.
During this period should a fault occur due to improper
materials or workmanship, the retailer, authorised service
centre, or authorised service dealer will carry out repairs at
no cost to yourself.
Replacement products will be offered at the discretion of your
supplying dealer.
This guarantee will be honoured by Daewoo service networks
in other E.C. members states, in accordance with the terms
and conditions which prevail in the member state at the time
service is requested.
CONDITIONS
Any claims made under the terms of the guarantee must be
supported by the original invoice. Bill of sale issued at the
time of sale. Daewoo reserve the right to refuse guarantee
should any of the information on the bill of sale be removed
or changed in any way after the original purchase of the
product by the consumer from the retailer.
Modifications or adjustments made to the product which
enable it to conform to local technical or safety standards in
force in any country other than the one for which the product
was originally designed and manufacutred, are not included
in this guarantee. Failures arising from such modifications,
whether performed properly or not, will not be covered by this
guarantee.
THIS GUARANTEE DOES NOT COVER ANY OF THE FOLLOWING:-
1) Periodic maintenance, the repair or replacement of parts
due to normal wear and tear.
2) Home service transport cost, and other closts and risks of
transport relating directly orindiectly to the guarantee of
the product.
3) Damage to this product resulting from: the above and
misuse, including but not limited to the failure to use this
product for its normal purpose or in accordance with the
instructions on the proper use and maintenance of this
product, and the installation or the use of this product in a
manner inconsistent with the technical or safety standards
in force in the country where the product is used.
4) Repairs carried out by non-authorised service centres.
5) Accidents, acts of God, or any cause beyond the control of
Daewoo including, but not limited to lighting, water, fire
and improper ventilation.
6) Aerial alignment and consumer control adjustments.
7) Batteries whether supplied by Daewoo or not which
become worn or exhausted in use.
This guarantee does not affect your statutory rights as a
consumer, nor your rights against the retalier, arising from
their sales or purchase contract.
In the absence of applicable legislation, this guarantee will be
the consumers sole and exclusive remedy, and neither
Daewoo nor its sussidiary, or distributor shall be liable for any
incidental or consequential damages for breach of any
express or implied guarantee of this product.
For further information regarding this or any other query you
may have about Daewoo products or its services please write
to:-

OMEGA APPLIANCES, DIVISION OF M.E.A. PTY. LTD.
2-8 BAKER STREET, BOTANY NSW 2019
Telephone [phone], Facsimile [phone]
