Smeg CF35PBF User manual

P/No. : MFL62175602
FRIGORIFERO CON
CONGELATORE
Istruzioni per l'uso
Nel ringraziarvi per avere acquistato questo
prodotto SMEG, vi raccomandiamo di leggere
attentamente le seguenti istruzioni e di conservare
questo manuale per eventuali consultazioni future.
KOEL-
VRIESCOMBINATIE
Gebruikershandleiding
Gelieve deze handleiding aandachtig door
te nemen voor u met het toestel aan de slag gaat.
Hou het altijd bij de hand als referentie.
FRIGORÍFICO -
CONGELADOR
Manual do Utilizador
Por favor leia cuidadosamente este Manual do
Utilizador antes
da primeira utilização e
mantenha-o à mão para poder consultá-
lo sempre que necessário.
FRIGORÍFICO
CONGELADOR
Guía del usuario
Lea esta gu.a del usuario con atenci.n antes
de utilizar la unidad
y manténgalmano a mano
para consultas posteriores.
KÜHL-
GEFRIERSCHRANK
Benutzerhandbuch
Bitte lesen Sie dieses Benutzerhandbuch sorgfältig
durch, bevor sie das Gerät in Betrieb nehmen,
und bewahren Sie es griffbereit auf, damit Sie
jederzeit nachschlagen können
REFRIGERATEUR-
CONGÉLATEUR
Guide de l’utilisateur
Veuillez lire ce guide avec attention avant
d’utiliser votre appareil et gardez-le à portée
de la main pour futures références.
FRIDGE-FREEZER
User's Guide
Please read this User's Guide carefully
before operating and keep it handy for
reference at all times.
KYL/FRYS
Användarhandbok
Läs igenom denna användarhandbok innan du
börjar använda kylen/frysen och spara den sedan
för att kunna ta fram den vid behov.
æY°∂π√ -
KATAæYKTH™
√‰ËÁ›Â˜ ÃÚ‹Ûˆ˜
¶·Ú·Î·Ïԇ̠ӷ ‰È·‚¿ÛÂÙ ÚÔÛÂÎÙÈο ÙȘ
Ô‰ËÁ›Â˜ ÚÈÓ ı¤ÛÂÙ Û ÏÂÈÙÔ˘Á›· ÙÔ „˘Á›Ô
Î·È ÊÚÔÓÙ›ÛÙ ӷ ÙȘ ¤¯ÂÙ ‰È·ı¤ÛÈ̘ ·Ó¿
¿Û· ÛÙÈÁÌ‹.
ХОЛОДИЛЬНИК С
МОРОЗИЛЬНЫМ
ОТДЕЛЕНИЕМ
ИНСТРУКЦИЯ ПО
ЭКСПЛУАТАЦИИ
ПЕРЕД ВКЛЮЧЕНИЕМ ХОЛОДИЛЬНИКА
ВНИМАТЕЛЬНО ПРОЧИТАЙТЕ ДАННУЮ
ИНСТРУКЦИЮ И ВСЕГДА ДЕРЖИТЕ ЕЕ
ПОД РУКОЙ.

115
Introduction
Installation
Operation
Suggestion On Food
storage
Care and
Maintenance
Trouble Shooting
Table of Contents
Registration
Important Safety Instruction
Identification of Parts
Installation
Starting
Temperature Control
Vacation
Extra freezing
Self Test
Door Alarm
Ice Making
Defrosting
Storing Food
General Information
Lamp Replacement
To Reverse the Doors
Cleaning
Trouble Shooting
116
116
130
131
131
132
133
133
134
134
134
134
135
137
138
138
139
140

Introduction
Introduction
Registration
The model and serial number are found on the rear of
this unit. This number is unique to this unit and not
available to others. You should record requested
information here and retain this guide as a permanent
record of your purchase. Staple your receipt here.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Important Safety Instruction
BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages.
Always read and obey all safety messages.
This is the safety alert symbol. It alerts you to safety
messages that inform you of hazards that can kill or hurt
you or others or cause damage to the product. All safety
messages will be preceded by the safety alert symbol and
the hazard signal word DANGER, WARNING, or
CAUTION. These words mean:
DANGER
You will be killed or seriously injured if
you don’t follow instructions.
WARNING
You can be killed or seriously injured if
you don’t follow instructions.
CAUTION
Indicates an imminently hazardous
situation which, if not avoided, may
result in minor or moderate injury, or
product damage only.
All safety messages will identify the hazard, tell you how
to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
116

Introduction
Important Safety Instruction
117
Prevent the power cord from being squeezed or
imprinted if the refrigerator is pushed in after the
power plug is extracted during the installation.
It becomes the cause of fire or electric shock.
When moving your appliance away from the wall, be
careful not to roll over or damage the power cord.
Do not allow the power cord bent or pressed by the
heavy object to be damaged.
It may damage the power cord to cause
fire or electric shock.
To reduce the risk of fire, electric shock, or injury to
persons when using your product, basic safety
precautions should be followed, including the
following. Read all instructions before using this
appliance.
1. When connecting the power
The dedicated outlet should be used.
•Using several devices at one outlet
may cause fire.
•The electric leakage breaker may
damage food and the dispenser may
be leaked.
Do not allow the power plug to face upward or to
be squeezed at the back of the fridge-freezer.
Water may be flown into or the plug
may be damaged, which causes fire or
electric shock.
WARNING

Introduction
118
Important Safety Instruction
Pull out the power plug not by grasping
the cord but the plug of its end.
It may cause electric shock or short circuit to
fire.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the fridge-freezer.
•It may cause electric shock or injury.
•When replacing the interior lamp of
the fridge-freezer, make sure that the
rubber ring for preventing the electric
spark within the socket is not taken
off.
Do not pull out the cord or touch the power plug
with wet hands.
It may cause electric shock or injury.
Remove water or dust from the power plug and
insert it with the ends of the pins
securely connected.
Dust, water or unstable connection may
fire or electric shock.
Do not extend or modify the length of the power
plug.
It causes electric shock or fire by the
electric damage of the power cord or
others.

Introduction
119
Important Safety Instruction
Make sure of grounding.
Consult a qualified electrician or
service person if the grounding
instructions are not completely
understood, or if you have doubts
on whether the appliance is
properly grounded or not .
The incorrect grounding may cause breakdown and
electric shock.
Be sure to use grounded exclusive proper voltage
consent for the power plug.
It becomes the cause of fire.
When the power cord or the power plug is
damaged or the holes of the outlet
are loosed, do not use them.
It may cause electric shock or short circuit
to make fire.
Wait for 5 minutes or longer when
reconnecting the plug.
It may cause the operation of the
freezer to fail.
2. When using the fridge-freezer
Do not cling to the door or the shelves of the door
or the home bar of the freezer or the cool chamber.
It may make the fridge-freezer fallen
down or damage the hands. Especially,
do not allow the children to do the
above.
Do not place the heavy object or the dangerous
object (container with liquid) on the fridge-freezer.
It may be dropped to cause injury, fire
or electric shock when opening or
closing the door.
Copper
Flat
Ground
Wire
More than
30 inches
After
5minutes

Introduction
Important Safety Instruction
120
Opening and closing the door of the refrigerator
vigorously may cause the stored food in the
refrigerator basket to fall by shock and hurt the
foot, so take precautions.
Do not install the fridge-freezer in the wet place or
the place which water or rain splashes.
Deterioration of insulation of electric parts
may cause electric leakage.
Do not use or store inflammable materials ether,
benzene, alcohol, medicine, LP gas, spray or
cosmetics near or in the fridge-freezer.
It may cause explosion or fire.
Do not place the lit candle within the fridge-freezer
to deodorize. Do not use drier to
dry the inside, nor light a candle to
remove odor.
It may cause explosion or fire.
Prevent children from entering the product.
It may endanger the life of a child if the
child enters the refrigerator.

Introduction
Important Safety Instruction
121
Do not store the medicine or the academic materials
at the fridge-freezer.
When the material with the strict
temperature control is stored, it may be
deteriorated or it may make an
unexpected reaction to cause any risk.
Avoid the heating devices. Install
in places away from the fire such
as the place where flammable gas
is leaked.
It may cause fire.
Do not use the combustible spray near the fridge-
freezer.
It may cause fire.
Do not place flower vase, cup, cosmetics, medicine
or any container with water on the fridge-freezer.
It may cause fire, electric shock or
injury by dropping down.
In case of thunder and lightning, or not in use for a
long period of time, detach the
power plug.
There is a danger of electric shock or
fire.

Introduction
Important Safety Instruction
122
Do not spray water at the outside or the inside of
the fridge-freezer or do not clean it
with benzene or thinner.
Deterioration of insulation of electric
parts may cause electric shock or fire.
When gas is leaked, do not touch the fridge-freezer
or the outlet and ventilate the room immediately.
•The explosion by spark may cause
fire or burn.
•Because this fridge-freezer uses
natural gas (isobutene, R600a) as
the environment-friendly
refrigerant, even a small amount (80~90g) is
combustible. When the gas is leaked by the severe
damage during delivering, installing or using the fridge-
freezer, any spark may cause fire or burn.
When any strange smell or smoke is detected from
the fridge-freezer, disconnect the power plug
immediately and contact to the service center.
It may cause fire.
Use the submerged fridge-freezer after checking it.
It may cause electric shock or fire.
Service
Center

Introduction
Important Safety Instruction
123
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Do not allow any person except the qualified
engineer to disassemble, repair or alter the fridge-
freezer.
It may cause injury, electric shock or
fire.
Do not use the fridge-freezer for non-domestic
purpose (storing medicine or testing material, using
at the ship, etc.).
It may cause an unexpected risk such
as fire, electric shock, deterioration of
stored material or chemical reaction.
When disposing the fridge-freezer, remove the
packing materials from the door.
It may cause to lock out the child.
Children should be supervised to ensure that they
do not play with the appliance.

Introduction
Important Safety Instruction
124
Do not insert the hands or the metal stick into the
exit of cool air, the cover, the bottom of the fridge-
freezer, the heatproof grill (exhaust hole) at the
backside.
It may cause electric shock or
injury.
Do not place the food in disorder inside the
refrigerator.
The food may fall during opening and closing the door
of the refrigerator and hurt people.
Do not touch food or containers at
the freezer with wet hands.
It may cause frostbite.
Violating this direction may cause injury or damage
house or furniture. Always be careful, please.
CAUTION
Install the fridge-freezer on the solid and level floor.
Installing it on the unstable place may
cause death by falling down the
fridge-freezer when opening or
closing the door.

Introduction
Important Safety Instruction
125
Do not insert the hands into the bottom of the
fridge-freezer.
The iron plate of the bottom may cause
injury.
Do not put bottle in the freezer.
It may freeze the contents to break the
bottle to cause injury.
Carry the fridge-freezer with the handle bar at the
bottom of the front and the top of the rear.
Otherwise, your hands may be slipped
to cause injury. Because the product is
heavy, carrying it alone may hurt
people or accidents may occur.
Because opening or closing the door or the home
bar of the fridge-freezer may cause injury to the
person around it, be careful,
please.
Opening or closing the door may
cause feet or hands to be caught in
the chink in door or the child to be get
hurt by the corner.
Do not put any living animal in the
fridge-freezer.

Introduction
126
Important Safety Instruction
Warning
• This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
• Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
• After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Precaution

127
Introduction
Accessibility of
Supply Plug
Supply Cord
Replacement
Danger
Don't store
Grounding
(Earthing)
The supply plug of the refrigerator-freezer should be
placed in easy accessible position for quick disconnection
in emergency.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Don't store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
In the event of an electric short circuit, grounding
(earthing) reduces the risk of electric shock by providing
an escape wire for the electric current. In order to prevent
possible electric shock, this appliance must be grounded.
Improper use of the grounding plug can result in an
electric shock.
Important Safety Instruction
Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not
easily climb inside.

Introduction
128
Warning
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite or
cause an eye injury. If a leak is detected, avoid any
naked flames or potential sources of ignition and air
the room in which the appliance is standing for
several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used. The room must be
1m2in size for every 8g of R600a refrigerant inside the
appliance. The amount of refrigerant in your particular
appliance is shown on the identification plate inside the
appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Important Safety Instruction
Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the
appliance require special disposal procedures. When
disposal, please consult with service agent or a
similarly qualified person.

129
Introduction
Important Safety Instruction
Caution
Warning
• If the wall socket is loose, do not insert the power
plug.
It may cause electric shock or fire.
• Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull it
straight out from the outlet.
You may disconnect a wire and cause a short circuit.
• Do not use a wet or damp cloth when cleaning
the plug. Remove any foreign matter from the
power plug pins.
Otherwise, there is a risk of fire.
• After unplugging the appliance, wait for at least
five minutes before plugging it again to the wall
socket.
Abnormal operation of the freezer may cause material
damage.
• If the appliance is not to be used for a long time,
pull out the power plug.
Any deterioration in the insulation may cause fire.
• Do not let children touch or play with the control
panel on the front of the appliance.
• The refrigerant used in fridge/freezer and the
gases in the insulation material require special
disposal procedures. Ensure that none of the pipes
on the back of the appliances are damaged prior
to disposal.
Please do not use a dishwasher to clean the lower
drawers; the high temperature may cause damage
to the baskets which make them unusable.

Introduction
130
Identification of Parts
If you find some parts missing from your unit, they
may be parts only used in other models.
Note
Utility Corner
Removable
Glass Shelf
Multi-air Flow Duct
Vegetable Drawer
Ice Tray
Freezer
Compartment
Leveling Screw
Handle
Display
Removable
Plinth
Basket Door
Egg Tray
2 Bottle
Basket Door
Used to keep fruits
and vegetables, etc.
fresh and crisp.

131
Installation
1. Select a good location.
Place your fridge-freezer where it is easy to use.
2. Avoid placing the unit near heat sources,
direct sunlight or moisture.
3. To ensure proper air circulation around the fridge -
freezer, please maintain sufficient space on both the
sides as well as top and maintain at least 2 inches (5
cm) from the rear wall.
4. To avoid vibration, the unit must be leveled.
If required, adjust the leveling screws to compensate
for the uneven floor.
The front should be slightly higher than the rear to aid
in door closing.
Leveling screws can be turned easily by tipping the
cabinet slightly.
Turn the leveling screws counterclockwise( ) to
raise the unit, clockwise( ) to lower it.
5. Clean your fridge-freezer thoroughly and wipe off all
dust accumulated during shipping.
6. Install accessories such as ice cube box, etc., in their
proper places. They are packed together to prevent
possible damage during shipment.
7. Connect the power supply cord (or plug) to the outlet.
Don't double up with other appliances on the same
outlet.
Installation
When your fridge-freezer is installed, allow it 2-3 hours to
stabilize at normal operating temperature prior to filling
it with fresh or frozen foods.
If power plug is disconnected, allow 5 minutes delay
before restarting.
Your fridge-freezer is now ready for use.
Starting
INSTALL KICK PLATE
• Take the Kick Plate out of the refrigerator.
• Using a screwdriver, secure the kick plate with the
screws provided.
screw screw

Operation
132
• Your fridge-freezer has controls that let you regulate
the temperature in the fridge and freezer
compartments. These controls are on the top of the
fridge-freezer.
• The initial Temperature of the Freezer and Refrigerator
Compartment is -20°C and 3°C respectively.
You can now adjust the temperature of the
compartments as you want.
Temperature Control
Refrigerator
Freezer

133
Operation
• This function makes the fridge-freezer work
in a power saving mode which is useful
when you are away on holiday, by reducing
energy consumption as much as possible.
Pressing ‘VACATION’ starts operation with
lamp ON and pressing it again stops the
operation.
• This function is used when you want to
freeze the foods quickly. Press the EXTRA
FREEZING button once, and then the quick
freeze operation starts with the lamp it.
• The EXTRA FREEZING operation takes about 3 hours.
When its operation ends, it automatically returns to the
normal state. If you want to stop the quick freeze
operation, press the EXTRA FREEZING. button once
more, the lamp goes out, and the EXTRA FREEZING
operation stops and the refrigerator returns to the
normal state.
Vacation
EXTRA FREEZING
