Smeg FAB32RWH3UK User manual

Contents
3
EN
1 Instructions 4
1.1 General safety instructions 4
1.2 Manufacturer liability 6
1.3 Appliance purpose 6
1.4 Disposal 7
1.5 Identification plate 7
1.6 This user manual 7
1.7 How to read the user manual 8
2 Description 9
2.1 General Description 9
2.2 Description of parts 10
2.3 Control panel 10
2.4 Available accessories 11
3 Use 13
3.1 Instructions 13
3.2 Preliminary operations 13
3.3 First use 13
3.4 Using the accessories 15
3.5 Ventilation 16
3.6 Using the refrigerator compartment 16
3.7 Using the freezer compartment 17
3.8 Noises during operation 18
3.9 Heated front surface 18
3.10Turning the appliance off 18
3.11Food storage advice 19
4 Cleaning and maintenance 20
4.1 Instructions 20
4.2 Cleaning the appliance 20
4.3 Defrosting 20
4.4 Interior lighting 21
4.5 What to do if... 21
5 Installation 23
5.1 Electrical connection 23
5.2 Positioning 23
We advise you to read this manual carefully, as it contains all the instructions for maintaining
the appliance’s aesthetic and functional qualities.
For further information on the product: www.smeg.com

Instructions
4
1 Instructions
1.1 General safety instructions
Risk of personal injury
• Never touch the heating elements
during use.
• Keep children under the age of
eight at a safe distance unless they
are constantly supervised and
make sure that they do not play
with the appliance.
• According to the current
regulations, children between 3
and 8 years of age can take or
load food from the appliance, but
it is strongly advised against
allowing children under 8 years of
age to perform these operations
and in general to use the
appliance.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the flames
with a fire blanket.
• Cleaning and maintenance that
should be performed by the user
must not be carried out by
unsupervised children.
• Have qualified personnel carry
out installation and assistance
interventions according to the
standards in force.
• Do not modify this appliance.
• Do not insert pointed metal
objects (cutlery or utensils) into the
slots in the appliance.
• Do not try to repair the appliance
yourself or without the intervention
of a qualified technician.
• Do not touch (especially with wet
hands) frozen products or put
them in your mouth directly.
• Do not store inflammable,
explosive or volatile substances.
• Do not keep explosive substances,
such as spray bottles with
flammable propellants in the
appliance.
• Bottles containing strong alcoholic
drinks must be tightly closed and
stored vertically.
• If the power supply cable is
damaged, contact technical
support immediately and they will
replace it, so as to prevent any
risk.
Risk of damaging the appliance
• WARNING: When positioning
the appliance, ensure the supply
cord is not trapped or damaged.
• WARNING: Do not locate
multiple portable socket-outlets or
portable power supplies at the
rear of the appliance.
•Do not use plug adapter.
• Never rest sharp metal objects
such as knives, forks, spoons and
lids on the appliance during use.

Instructions
5
EN
• Do not use abrasive or corrosive
detergents (e.g. scouring
products, stain removers and
metallic sponges) on glass parts.
• Do not sit on the appliance.
• Do not prize on the door or
handle to move the appliance.
• Do not use steam jets to clean the
appliance.
• Do not use the appliance to cool
rooms for any reason.
• Always unplug the appliance in
the event of a fault or when
performing cleaning or
maintenance.
• Do not keep liquids in tins or glass
containers in the freezer.
• Do not use sharp metal objects to
remove excess ice build-up in the
freezer compartment.
• To prevent instability of the
appliance, install and secure it
correctly as indicated in the
instructions provided in this
manual.
• Do not place heavy objects on
the top of the appliance.
• If installed near another
refrigerator or freezer, keep it at a
minimum distance of 2 cm.
• Do not install/use the appliance
outdoors.
For this appliance
•WARNING: risk of fire /
flammable materials.
• The appliance may only be used
by children aged 8 years and
over, and by people of reduced
physical, sensory or mental
capacity, or lacking in experience
and knowledge in the use of the
appliance, provided that they
instructed on safe use of the
appliance and the risks connected
to it by adults who are responsible
for their safety.
• Children must be supervised to
ensure that they do not play with
the appliance.
• Do not rest any weight or sit on the
open door of the appliance.
• Take care that no objects are stuck
in the doors.
• The appliance contains a small
quantity of isobutane (R600a),
make sure not to damage the
cooling circuit during transport,
installation and cleaning.

Instructions
6
• Keep the ventilation openings
surrounding the appliance or in the
nearby area free from any
obstructions.
• Do not use mechanical, electrical
or chemical products other than
those recommended by the
manufacturer to speed up the
defrosting process.
• Do not damage the cooling circuit
(if it can be accessed).
• Do not use electrical appliances
inside food storage compartments
unless these are of the type
recommended by the
manufacturer.
• In the event of damage to the
cooling circuit, avoid the use of
naked flames and ventilate the
area properly.
• Do not use the appliance or parts
of it in ways other than those
specified in this manual.
• Opening the door for long
periods can cause a significant
increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can
come in contact with food and
accessible drainage systems.
• Store raw meat and fish in suitable
containers in the refrigerator, so
that it is not in contact with or drip
onto other food.
• If the refrigerating appliance is left
empty for long periods, switch off,
defrost, clean, dry, and leave the
door open to prevent mould
developing within the appliance.
1.2 Manufacturer liability
The manufacturer declines all liability
for damage to persons or property
caused by:
• use of the appliance other than
that specified;
• failure to comply with the
instructions in the user manual;
• tampering with any part of the
appliance;
• use of non-original spare parts.
1.3 Appliance purpose
The appliance is designed for use in
a domestic or similar environment, for
instance:
• staff kitchen areas in shops, offices
and other working environments;
• farm houses and by guests in
hotels, motels and other residential
type environments;
• bed and breakfast establishments;
• catering and similar non-retail
applications.
• The appliance is not designed for
professional and commercial use.
• This appliance is for refrigeration
and conservation of fresh and
frozen foods in the home. Every

Instructions
7
EN
other use is considered
inappropriate.
• The appliance is not designed to
operate with external timers or with
remote-control systems.
1.4 Disposal
This appliance must be disposed of
separately from other waste
(Directives 2002/95/EC,
2002/96/EC, 2003/108/EC).
The appliance does not contain substances
in quantities sufficient to be considered
hazardous to health and the environment, in
accordance with current European
directives.
To dispose of the appliance:
• Cut the power supply cable and remove
it along with the plug.
• Deliver the appliance to the appropriate
recycling centre for electrical and
electronic equipment waste, or return it to
the retailer when purchasing an
equivalent product, on a one for one
basis.
• If the appliance is replaced, remove the
door and leave the shelves in their
positions, in order to prevent children
from being trapped inside.
Our appliances are packaged in non-
polluting and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
1.5 Identification plate
The identification plate bears the technical
data, serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
1.6 This user manual
This user manual is an integral part of the
appliance and must therefore be kept in its
entirety and within the user’s reach for the
whole working life of the appliance.
Read this user manual carefully before using
the appliance.
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part
of it unattended.
• Do not let children play with the plastic
bags.

Instructions
8
1.7 How to read the user manual
This user manual uses the following reading
conventions:
1. Sequence of instructions for use.
• Standalone instruction.
Instructions
General information on this user
manual, on safety and final
disposal.
Description
Description of the appliance and its
accessories.
Use
Information on the use of the
appliance and its accessories, food
storage advice.
Cleaning and maintenance
Information for proper cleaning and
maintenance of the appliance.
Installation
Information for the qualified
technician: Installation, operation
and inspection.
Safety instructions
Information
Advice

Description
9
EN
2 Description
2.1 General Description
1 Control panel
2 Fan
3 Interior lighting
4 Refrigerator compartment
5 Quick freeze drawer
6 Freezer compartment
7 Fridge door
8 Freezer door

Description
10
2.2 Description of parts
Control panel
For setting the temperature inside the
refrigerator and freezer compartments.
Fan
Distributes the temperature and reduces
condensation on the shelves and other
surfaces.
Interior lighting
The interior of the appliance is lit when the
door is opened.
Refrigerator compartment
For storing fresh foods.
Quick freeze drawer
For quickly freezing fresh food.
Freezer compartment
For storing frozen foods, freezing fresh
foods and producing ice cubes.
2.3 Control panel
1 Turning ON/OFF the appliance
2 Refrigerator compartment supercold
function ON/OFF button; Vacation
function (long press)
3 Refrigerator compartment temperature
setting button
4 Freezer compartment temperature setting
button
5 Freezer compartment supercold function
ON/OFF button; “ECO” function (long
press)
6 Alarm deactivation button.
7 Appliance off indicator.
8 Refrigerator compartment supercold
function indicator.
9 Refrigerator compartment temperature
display.
10 Vacation function indicator.
11 Alarm warning indicator.
12 Freezer compartment temperature
display.
13 “Eco” function ON/OFF indicator.
14 Freezer compartment supercold function
indicator.

Description
11
EN
2.4 Available accessories
Shelves
For optimising fridge space and placing
foodstuffs inside the refrigerator
compartment.
Fruit and vegetable drawer
For storing fruit and vegetables, maintaining
a constant humidity level.
Supercold drawer
Can be used for maintaining freshness and
flavour of delicate food such as meat, fish
and lightly frozen foods for a longer time
period, since temperature is kept constantly
between −2°C and +3°C.
Freezer drawers
For storing frozen or deep-frozen food.
Door balconies and shelves
Not all accessories are available
on some models.
Do not place food to be frozen or
trays to make ice in the super-cold
compartment.

Description
12
For storing foodstuffs in small containers.
The shelf in the lower part of the door is
useful for storing bottles.
Ice packs
The device contains two ice packs, to pre-
serve low temperatures inside the freezer
cell in case of power failure.
The accessories intended to come
into contact with food are made of
materials that comply with the
provisions of current legislation.
Supplied and optional accessories
can be requested to Authorised
Service Centres. Use only original
accessories supplied by the
manufacturer.

Use
13
EN
3 Use
3.1 Instructions
3.2 Preliminary operations
1. Remove any protective film from the
outside or inside of the appliance,
including accessories.
2. Remove any labels (apart from the
technical data plate) from the
accessories and shelves.
3. Remove and wash all the appliance's
accessories (see 4 Cleaning and
maintenance).
3.3 First use
1. Keep the ON/OFF button on the
control panel pressed for 3
seconds to switch on the appliance.
Temperature setting
1. To set the refrigerator temperature,
press the button; press the
button for the freezer.
2. The set temperature will be shown on
the relevant display.
Improper use
Risk of damage to the appliance
• Do not use sharp objects when
removing ice and frost in order not to
damage the appliance's walls.
• Do not sit or lean on the door or any
open drawers.
• Do not touch the heating elements on
the outside of the appliance.
• Do not store inflammable, explosive or
volatile substances.
• Do not keep explosive substances, such
as spray bottles with flammable
propellants in the appliance.
• Organic compounds, acids and
essential oils can corrode the seals and
plastic surfaces if left in contact with them
for extended periods.
• Bottles containing strong alcoholic drinks
must be tightly closed and stored
vertically.
After installing or repositioning the
appliance, wait at least two hours
before activating it.
After a power failure, the
appliance will automatically switch
on with the previously selected
settings.
The appliance is set by default to
+5°C for the fridge and -18°C for
the freezer.
The refrigerator temperature can
be set between +1°C and +8°C.
The freezer temperature can be set
between -18°C and -24°C.

Use
14
Refrigerator supercold function
1. Press the button to activate/
deactivate the supercold function, the
relevant indicator turns on.
2. After 1 hour the supercold function is
switched off automatically. The
refrigerator compartment returns to its
previous setting.
Vacation function
Useful during periods of prolonged
absence; the Vacation function allows you
to turn off the refrigerator compartment
while keeping the freezer active.
1. To activate/deactivate the Vacation
function, keep the button pressed
for 3 seconds.
2. The indicator will turn on in the
display, and the temperature will not be
shown .
ECO mode
1. To activate/deactivate the ECO mode,
keep the button pressed for 3
seconds.
2. The indicator will turn on in the
display.
3. The appliance will reduce power
consumption after 6 hours since the
activation of the ECO mode.
Alarm for door open
When the refrigerator compartment door
remains open for a long time, the appliance
sounds to warn the user that door should be
closed; press the button to deactivate
the alarm.
High temperature alarm
If the temperature in the compartment is high
due to prolonged power failure or to a fault
of the appliance, an alarm will sound and
the indicator will turn on in the display.
Check food inside the refrigerator
compartment and press the button to
deactivate the alarm.
The refrigerator supercold function
is used for quick cooling of large
quantities of food.
Remove the stored products from
the refrigerator compartment.
To prevent the formation of
unpleasant odours, a temperature
of about 15°C will be kept inside
the refrigerator compartment.
The ECO mode is deactivated
after a power failure or when the
appliance is switched off.
Activation of the supercold function
(refrigerator/freezer) deactivates
the ECO mode.

Use
15
EN
3.4 Using the accessories
Shelves
These can be positioned at different heights
on the guides according to requirements.
Each shelf has a safety fitting to prevent it
from being accidentally removed. To extract
them fully, lift up the rear part (1) and
remove them (2).
Door balconies and shelves
Suitable for storing eggs, butter, dairy
products, conserves and other small food
packages/containers. The lower part of the
door has a shelf for bottles. Avoid placing
excessively heavy bottles on the shelf and
do not let them drop onto the bottom when
inserting them.
Fruit and vegetable drawer
Located at the bottom of the refrigerator
compartment, which is fitted with a glass
shelf to cover fresh foods that require
constant humidity for optimum storage.
Freezer drawers
For storing frozen foods and foods to be
frozen. To remove them, pull them towards
you and lift the front part of each drawer.
Perishable foods should be placed
on the rear part of the shelves
where the temperature is lower.
Storing vegetables with high
content of water can generate
condensation on the glass shelf.
This is a natural phenomenon
which does not affect the
appliance’s operation in any way.

Use
16
Ice packs
The use of ice packs guarantees reduced
freezing times and improved freezer
autonomy in case of power failure. The ice
packs are removable and can be used
safely in the picnic fridge or in the cooler
bag.
3.5 Ventilation
The forced recirculation air in the appliance
is free of humidity and quickly dries the food
inside.
The inner ventilation system cools food
more rapidly and keeps refrigeration
homogeneous inside the appliance.
3.6 Using the refrigerator
compartment
Arranging food
Arrange food on the various shelves,
making sure that they wrapped and
covered hermetically. This precaution
ensures that:
• the flavour, moisture and freshness of the
foods is preserved;
• any contamination of foods with odours
or tastes from other foods can be
avoided;
• the humidity level inside the refrigerator is
prevented from becoming too high as a
result of the normal transpiration of food
(especially fresh fruit and vegetables). In
some operating conditions (rise in
ambient temperature and humidity, more
frequent opening of the door) this might
cause condensation to form on the
shelves.
Storage life table
Before introducing food into the
appliance, seal it thoroughly.
Always allow hot foods and drinks
to cool to room temperature
before putting them in the
appliance.
Foodstuff Time
Eggs, smoked meats,
marinated foods, cheese max 10 days
Root vegetables max 8 days
Butter max 7 days
Pastries, fruit, ready meals,
fresh meat max 2 days
Fish, minced meat, seafood max 1 day

Use
17
EN
3.7 Using the freezer compartment
To keep and freeze foods properly:
• pack fruit and vegetables in portions of
no more than 1 kg and meat and fish in
portions of up to 2 kg.
• small packages freeze quickly which
means that the foods' nutritional
properties are preserved better,
including after defrosting/preparation.
• package foods in hermetically sealed
packages, expelling air as much as
possible.
• Do not use paper bags or shopping
bags, use the suitable freezer bags/
containers.
Frozen foods storage life table
Defrosted foods
Food must be consumed as soon as
possible once defrosted. Freezing foods
preserves them, but it does not destroy any
micro-organisms, which are activated after
thawing, damaging the foods.
Partial defrosting lowers the nutritional value
of the foodstuffs, particularly of fruit,
vegetables and ready meals.
Always allow hot foods and drinks
to cool to room temperature
before putting them in the
appliance.
Foodstuff Time
Fruit, beef max 10-12 months
vegetables, veal, poultry max 8-10 months
Game max 6-8 months
Pork max 4-6 months
Mince max 4 months
Bread, desserts, cooked foods,
oily fish max 3 months
Offal max 2 months
Sausages, lean fish max 1 month

Use
18
3.8 Noises during operation
The refrigerator and freezer compartments
are cooled by means of a compression
system. In order to maintain the preset
temperature inside the refrigerator and
freezer compartments, the compressor
comes into operation in response to the
level of cooling required, and may operate
continuously if necessary. When the
compressor starts to function, it creates a
buzzing noise which generally diminishes in
intensity after a few minutes.
Another normal operating noise of the
appliance is a gurgling due to the coolant
flowing through the pipes in the circuit. This
noise is normal and does not indicate an
appliance malfunction. If it becomes too
loud, this may mean that there are other
causes. Checks must then be made to
ensure that:
• The refrigerator is properly levelled on
the floor and does not vibrate when the
compressor is in operation: if this is not
the case, adjust the appliance's feet until
it is level;
• The drawers, shelves and trays on the
door are correctly positioned in their
holders: if they are not, put them in
correctly;
• Bottles and containers on the various
shelves are stable and not touching each
other: otherwise, the vibration resulting
from compressor operation could
generate noise;
• Do not place the fridge in such a way
that it is in contact with furniture or other
household appliances.
3.9 Heated front surface
There is a front surface heating system
inside the cabinet to limit the formation of
condensation around the door seal.
3.10 Turning the appliance off
Whenever the appliance is to remain
unused for long periods, it should be
switched off.
1. Keep the ON/OFF button on the
control panel pressed for 3 seconds.
The symbols are displayed on the
refrigerator and freezer temperature
displays.
2. Unplug the appliance from the wall
socket.
3. Empty the compartments.
4. Once the freezer has fully defrosted, dry
any residual accumulated moisture with
a tea towel.
Leave the door ajar to ensure that
moisture and stagnant air do not
cause unpleasant odours.

Use
19
EN
3.11 Food storage advice
Practical energy saving advice
• Correct use of the appliance, correct
packaging of foodstuffs, a constant
temperature and food hygiene have
significant effects on the quality of
storage.
• Reduce the number of times that the
doors are opened and the length of time
they remain open to prevent the
compartments from heating up
excessively.
• Clean the condenser (rear of the
appliance) periodically to prevent the
appliance from losing efficiency.
• Defrost frozen food in the refrigerator
compartment in order to make use of the
cold stored in the frozen foods.
General advice
• Always check the expiry date on the
food packaging.
• The foodstuffs must be stored in closed or
pre-packaged containers and must not
be able to emit or absorb moisture and
odours.
• Remove perishable products from the
appliance if you are going away for a
long period.
Refrigerator compartment door
• Keep eggs, butter, cheese etc. in the
upper and central parts.
• Keep drinks, bottles, cans etc. in the
lower part.
Refrigerator compartment
• Keep dairy products, ready meals,
pastries, fruit juices, beer etc. in the
central part.
• Keep meats, cold cuts etc. in the lower
part.
• Keep fresh and tropical fruit, vegetables,
root vegetables, onions, etc. in the fruit
and vegetable drawer.
Freezer compartment
• The type of food, quantity and date of
freezing should be marked on the
container/packaging.
• Use small containers, if possible already
cold.
• The quantity of fresh foods which can be
frozen at the same time is listed on the
nameplate inside the refrigerator
compartment.
• Use suitable freezer bags, tinfoil, cling-
film for use with food, and freezer
containers.
• Do not use paper bags, cellophane for
non-food use, shopping bags or
pre-used freezer bags.
• Avoid frozen food coming into contact
with fresh food to be frozen.
• Keep bagged frozen vegetables, ice,
ice cream etc.

Cleaning and maintenance
20
4 Cleaning and maintenance
4.1 Instructions
4.2 Cleaning the appliance
A special antibacterial protection on the
appliance's interior walls prevents bacterial
growth and keeps them clean. They must
nevertheless be cleaned regularly in order
to keep them in good condition.
Cleaning the outside of the appliance
• The appliance may be cleaned with
water or alcohol-based liquid detergents
(e.g. window cleaning products).
• Avoid aggressive detergents and rough
sponges in order not to damage the
surfaces.
• Use a soft brush to remove dust and fume
deposits from the condenser on the rear
of the appliance.
• Clean the tank above the compressor.
Cleaning the inside of the appliance
• Clean the inside of the appliance with
diluted liquid detergent and warm water,
adding a little bit of vinegar.
• Door balconies and shelves can be
removed.
• Do not use sharp objects or spray
products.
4.3 Defrosting
Improper use
Risk of damage to surfaces
• Do not use steam jets to clean the
appliance.
• Do not use cleaning products containing
chlorine, ammonia or bleach on parts
made of steel or that have metallic
surface finishes (e.g. anodizing, nickel-
or chromium-plating).
• Do not use abrasive or corrosive
detergents (e.g. scouring products, stain
removers and metallic sponges) on
glass parts.
• Do not use rough or abrasive materials
or sharp metal scrapers.
Power voltage
Danger of electrocution
• Turn off the appliance and unplug it from
the mains before cleaning or
maintenance
• Do not pull the cable to remove the plug.
Occasional presence of frost
inside the freezer compartment is
normal.
Do not use electrical appliances
(e.g. hair dryers) or sprays for
defrosting, the plastic parts could
be damaged.

Cleaning and maintenance
21
EN
Defrosting the refrigerator/freezer
compartments
The refrigerator/freezer compartment does
not require defrosting, as any ice which
forms on the refrigeration plate will melt
when the compressor is switched off. The
defrosting process is automatic.
Defrost water is channelled directly into the
dedicated pan on the back of the
appliance, which lets it evaporate by
means of the heat generated by the
compressor.
4.4 Interior lighting
Interior lighting, if damaged, must be
repaired by Technical Service only.
4.5 What to do if...
The appliance does not work:
• Make sure that the appliance is plugged
in and that the main switch is turned on.
The compressor starts to function too often
or functions continuously:
• The room temperature is too high.
• The door is being opened too often or
for too long.
• The door is not closing/sealing properly.
• The freezer is loaded with too many fresh
foods.
• Check that sufficient air can circulate
around the sensor on the right-hand side
of the refrigerator compartment.
• Check that the back of the freezer is
properly ventilated and that the
condenser is not too dirty.
Excessive ice or condensation has built up
inside the refrigerator compartment:
• The door is being opened too often or
for too long.
• Hot foods have been placed inside the
refrigerator compartment.
• The foodstuffs or containers are in
contact with the rear wall.
• The door seal is damaged or dirty.
Clean or replace it.

Cleaning and maintenance
22
The refrigerator compartment is not
sufficiently cold:
• The thermostat is set at too high a
temperature.
• The door is being opened too often or
for too long.
• The door is not closing/sealing properly.
• The room temperature is too high.
The temperature inside the refrigerator
compartment is too cold and the foodstuffs
are freezing:
• The thermostat is set at too low a
temperature.
• Food not contained in suitable containers
or bags.
• Fruit and vegetables might be too wet.
• Foodstuffs placed against the rear wall
of the refrigerator compartment.
Temperature inside freezer compartment
not low enough to freeze foods properly:
• The thermostat is set at too high a
temperature.
• The door is being opened too often or
for too long.
• The door is not closing/sealing properly.
• The door seal is damaged or dirty.
Clean or replace it.
• The food to be frozen contains large
quantities of sugar.
Excessive ice has built up inside the freezer
compartment:
• The thermostat is set at too low a
temperature.
• The room temperature is too high.
• The door is being opened too often or
for too long.
• The door is not closing/sealing properly.
• The door seal is damaged or dirty.
Clean or replace it.
• Hot foods have been placed inside the
freezer compartment.
Doors are hard to open just after closing:
• If you attempt to open the door again just
after closing it (especially the freezer
door), considerable strength is required.
This is due to the vacuum created by the
cooling of the warm air which has
entered the freezer.
The doors are misaligned:
• Check that the appliance is level.
• Level the appliance using its feet.
