Smeg FD84EN4HX User manual

Freezer - Fridge / User ManualEN
FD84EN4HX
FD84EN4HM
Kühl-Gefrierkombination / BedienungsanleitungDE
Congélateur - Réfrigérateur / Guide D’utilisationFR
Vriezer - Koelkast / HandleidingNL
Congelatore - Frigorifero / Manuale per l’usoIT
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Smeg FD84EN4H Inox o
cerca il tuo prodotto tra le migliori offerte di Frigoriferi e Congelatori

EN - 2
Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this
book for future reference.
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly

EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS ................................................................................. 4
1.1 General Safety Warnings ...............................................................................................4
1.2 Installation warnings.......................................................................................................8
1.3 During Usage..................................................................................................................9
2 DESCRIPTION OF THE APPLIANCE ............................................................. 10
2.1 Dimensions...................................................................................................................11
3 USING THE APPLIANCE ................................................................................ 12
3.1 Information about New Generation Cooling Technology ..............................................12
3.2 Display and Control Panel............................................................................................12
3.3 Operating Your Fridge Freezer.....................................................................................13
3.3.1 Super Freeze Mode...................................................................................................13
3.3.2 Super Cool Mode ......................................................................................................13
3.3.3 Economy Mode..........................................................................................................13
3.3.4 Holiday Mode.............................................................................................................14
3.3.5 Drink Cool Mode........................................................................................................14
3.3.6 Screen Saver Mode...................................................................................................14
3.3.7 The Child Lock Function............................................................................................15
3.4 Temperature Settings ...................................................................................................15
3.4.1 Freezer Temperature Settings...................................................................................15
3.4.2 Cooler Temperature Settings.....................................................................................16
3.4.3 Door Open Alarm Function........................................................................................16
3.5 Temperature Adjustment Warnings...............................................................................16
3.6 Accessories ..................................................................................................................17
3.6.1 The Icematic ..............................................................................................................17
3.6.2 The Chiller Shelf........................................................................................................17
3.6.3 The Fresh Dial...........................................................................................................18
3.6.4 Adjustable Door Shelf................................................................................................18
4 FOOD STORAGE ............................................................................................ 19
4.1 Refrigerator Compartment............................................................................................19
4.2 Freezer Compartment ..................................................................................................20
5 CLEANING AND MAINTENANCE .................................................................. 23
6 SHIPMENT AND REPOSITIONING................................................................. 24
6.1 Transportation and Changing Positioning ....................................................................24
6.2 Repositioning the Door.................................................................................................24
7 BEFORE CALLING AFTER-SALES SERVICE............................................... 25
8 TIPS FOR SAVING ENERGY .......................................................................... 27
9 TECHNICAL DATA .......................................................................................... 28
10 INFORMATION FOR TEST INSTITUTES...................................................... 28
11 CUSTOMER CARE AND SERVICE............................................................... 29

EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the instructions.
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and

EN - 5
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
–staff kitchen areas in shops, ofces and other
working environments.
–farm houses and by clients in hotels, motels and
other residential type environments.
–bed and breakfast type environments;
–catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 16 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.

EN - 6
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are
not expected to use appliances safely unless
continuous supervision is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.

EN - 7
To avoid contamination of food, please respect the
following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in the
compartments of the appliance.
• Clean regularly surfaces that can come in contact
with food and accessible drainage systems
• Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip
onto other food.
• Two-star frozen-food compartments are suitable for
storing pre-frozen food, storing or making ice cream
and making ice cubes.
• One-, two- and three-star compartments are not
suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for long
periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the
appliance.

EN - 8
1.2 Installation warnings
Before using your fridge freezer for the rst
time, please pay attention to the following
points:
• The operating voltage for your fridge
freezer is 220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your fridge freezer may have an odour
when it is operated for the rst time. This
is normal and the odour will fade when
your fridge freezer starts to cool.
• Before connecting your fridge freezer,
ensure that the information on the data
plate (voltage and connected load)
matches that of the mains electricity
supply. If in doubt, consult a qualied
electrician.
• Insert the plug into a socket with an
efcient ground connection. If the socket
has no ground contact or the plug does
not match, we recommend you consult a
qualied electrician for assistance.
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located on
the inside left of the appliance).
• We do not accept responsibility for any
damages that occur due to ungrounded
usage.
• Place your fridge freezer where it will not
be exposed to direct sunlight.
• Your fridge freezer must never be used
outdoors or exposed to rain.
• Your appliance must be at least 50 cm
away from stoves, gas ovens and heater
cores, and at least 5 cm away from
electrical ovens.
• If your fridge freezer is placed next to a
deep freezer, there must be at least 2
cm between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of fridge
freezer with lace. This will affect the
performance of your fridge freezer.
• Clearance of at least 150 mm is required
at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your fridge freezer, wipe all
parts with a solution of warm water and
a teaspoon of sodium bicarbonate. Then,
rinse with clean water and dry. Return all
parts to the fridge freezer after cleaning.
• Use the adjustable front legs to make
sure your appliance is level and stable.
You can adjust the legs by turning them
in either direction. This must be done
before placing food in the appliance.
If your refrigerator includes a fan
condenser
-The bottom cabinet cover is the
plastic
The condenser of your fridge is located
at the bottom of the cabinet. As a result,
the ttings which control the distance
between the refrigerator and the wall
behind your fridge are located on the
cover of the bottom of the cabinet. You
can move your fridge toward the back
wall until this point.
Plastic for distance setting
-The bottom cabinet cover is the
metal
The condenser of your fridge is placed
at the bottom of cabinet. As a result
of that, assemble the spacer by xing
it to holes on the cover bottom panel
and turn 90° that’s shown below gure
for arranging the distance between the

EN - 9
refrigerator and the back wall at where
you place the fridge. You can move the
fridge towards the back wall until that
point.
Plastic for distance setting
The distance between the appliance and
back wall must be a maximum of 75 mm.
1.3 During Usage
• Do not connect your fridge freezer to
the mains electricity supply using an
extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play with
the appliance or hang off the door.
• Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
• Do not place glass bottles or cans in the
ice-making compartment as they will
burst when the contents freeze.
• Do not place explosive or ammable
material in your fridge. Place drinks with
high alcohol content vertically in the
fridge compartment and make sure their
tops are tightly closed.
• When removing ice from the ice-making
compartment, do not touch it. Ice may
cause frost burns and/or cuts.
• Do not touch frozen goods with wet
hands. Do not eat ice-cream or ice cubes
immediately after they are removed from
the ice-making compartment.
• Do not re-freeze thawed frozen food. This
may cause health issues such as food
poisoning.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause an
accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of your old appliance
The symbol on the product or on
its packaging indicates that this
product may not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling
of this product. For more detailed
information about recycling of this product,
please contact your local city ofce, your
household waste disposal service or the
shop where you purchased the product.
Packaging and the Environment
Packaging materials protect
your machine from damage that
may occur during transportation.
The packaging materials are
environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.

EN - 10
Notes:
• Please read the instruction manual
carefully before installing and using your
appliance. We are not responsible for the
damage occurred due to misuse.
• Follow all instructions on your appliance
and instruction manual, and keep this
manual in a safe place to resolve the
problems that may occur in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specied purposes. It is not suitable for
commercial or common use. Such use
will cause the guarantee of the appliance
to be cancelled and our company will not
be responsible for any losses incurred.
• This appliance is produced to be used
in houses and it is only suitable for
cooling / storing foods. It is not suitable
for commercial or common use and/or
for storing substances except for food.
Our company is not responsible for any
losses incurred by inappropriate usage of
the appliance.
2 DESCRIPTION OF THE
APPLIANCE
This appliance is not intended to be used
as a built-in appliance.
1A B
2
3
4
5
6
7
8
9
10
11
12
13 14
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
A) Freezer compartment
B) Refrigerator compartment
1) Freezer shelf
2) Icemaker *
3) Turbo fan *
4) Wine rack *
5) Refrigerator shelves
6) Chiller *
7) Crisper cover
8) Crisper
9) Bottle shelf
10) Adjustable door shelf * / door shelf
11) Door shelves
12) Freezer door shelves *
13) Egg holder
14) Ice box tray *
* In some models
General notes:
Fresh Food Compartment (Fridge): Most
efcient use of energy is ensured in the
conguration with the drawers in the bottom
part of the appliance, and shelves evenly
distributed, position of door bins does not
affect energy consumption.
Freezer Compartment (Freezer): Most
Efcient use of energy is ensured in the
conguration with the drawers and bins are
on stock position.

EN - 11
2.1 Dimensions
W2
D2
W1
D1
W3
D3
90o
Space required in use 2
H2 mm 2010,0
W2 mm 940,0
D2 mm 815,7
2the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air.
Overall space required in use 3
W3 mm 1535,2
D3 mm 1547,5
3the height, width and depth of the
appliance including the handle,
plus the space necessary for free
circulation of the cooling air, plus
the space necessary to allow door
opening to the minimum angle
permitting removal of all internal
equipment.
Overall dimensions 1
H1 mm 1860,0
W1 mm 840,0
D1 mm 750,0
1the height, width and depth of the
appliance without the handle.
H1
H2

EN - 12
3 USING THE APPLIANCE
3.1 Information about New Generation
Cooling Technology
Fridges with new-generation cooling
technology have a
different operating
system to static
fridges. Other (static)
fridges may
experience a build up
of ice in the freezer
compartment due to
door openings and
humidity in the food.
In such fridges,
regular defrosting is
required; the fridge
must be switched off,
the frozen food moved
to a suitable container
and the ice which has
formed in the freezer
compartment
removed.
In fridges with new-generation cooling
technology, a fan blows dry cold air
evenly throughout the fridge and freezer
compartments. The cold air cools your food
evenly and uniformly, preventing humidity
and ice build-up.
In the refrigerator compartment, air
blown by the fan, located at the top of
the refrigerator compartment, is cooled
while passing through the gap behind
the air duct. At the same time, the air is
blown out through the holes in the air duct,
evenly spreading cool air throughout the
refrigerator compartment.
There is no air passage between the
freezer and refrigerator compartments,
therefore preventing the mixing of odours.
As a result, your fridge, with new-
generation cooling technology, provides
you with ease of use as well as a huge
volume and aesthetic appearance.
3.2 Display and Control Panel
1
2
3
4
5
7
8
9
10
11
6
Using the Control Panel
1. It is super freeze indicator.
2. It is freezer set value screen.
3. It is super cooling indicator.
4. It is cooler set value screen.
5. It is alarm symbol.
6. It is child-lock symbol.
7. It is holiday mode symbol.
8. It is economy mode symbol.
9. It enables the setting value of freezer
to be modied and super freeze mode
to be activated if desired. Freezer may
be set to -16, -18, -20, -22, -24 °C super
freeze.
10. It enables the setting value of cooler to
be modied and super cool mode to be
activated if desired. Cooler maybe set
to 8, 6, 5, 4, 2 °C super cool.
11. It enables the modes (economy,
holiday…) to be activated if desired.

EN - 13
3.3 Operating Your Fridge Freezer
Lighting (If available)
When the product is plugged in for the
rst time, the interior lights may turn on 1
minute late due to opening tests.
3.3.1 Super Freeze Mode
Purpose
• To freeze a large quantity of food that
cannot t on the fast freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain
freshness.
How Would It Be Used?
Press freezer set button
until Super freeze symbol
will be seen on the
screen. Buzzer will sound
beep beep. Mode will be
set.
During This Mode:
• Temperature of cooler
and super cool mode
may be adjusted. In
this case super freeze
mode continues.
• Economy and Holiday
mode can not be selected.
• Super freeze mode can be cancelled by
the same operation of selecting.
Notes:
• The maximum amount of fresh food (in
kilograms) that can be frozen within 24
hours is shown on the appliance label.
• For optimal appliance performance in
maximum freezer capacity, activate SF
mode 3 hours before you put fresh food
into the freezer.
• At the end of this period, the fridge will
sound an audible alarm notifying that it is
ready.
Super freeze mode will automatically
cancel after 24 hours, depending on
the environmental temperature or when the
freezer sensor reaches a sufciently low
temperature.
3.3.2 Super Cool Mode
Purpose
• To cool and store a large quantity of food
in the fridge compartment.
• To quickly cool drinks.
How Would It Be Used?
Press cooler set button
until super cool symbol
will be seen on the
screen. Buzzer will sound
beep beep. Mode will be
set.
During This Mode:
• Temperature of freezer
and super freeze mode
may be adjusted. In
this case super cool
mode continues.
• Economy and holiday
mode can not be
selected.
• Super cool mode can be cancelled by the
same operation of selecting.
3.3.3 Economy Mode
Purpose
Energy savings. During periods of less
frequent use (door opening) or absence
from home, such as a holiday, Eco program
can provide optimum temperature whilst
saving power.
How Would It Be Used?
• Push "MODE" button
until eco symbol
appears.
• If no button is pressed
for 1 second. Mode will
be set. Eco symbol will
blink 3 times. When
mode is set, buzzer will
sound beep beep.
• Freezer and refrigerator
temperature segments
will show "E".
• Economy symbol and
E will light till mode
nishes.

EN - 14
During This Mode:
• Freezer may be adjusted. When
economy mode will be cancelled, the
selected setting values will proceed.
• Cooler may be adjusted. When economy
mode will be cancelled, the selected
setting values will proceed.
• Super cool and super freeze modes
can be selected. Economy mode is
automatically cancelled and the selected
mode is activated.
• Holiday mode can be selected after
cancelling the economy mode. Then the
selected mode is activated.
• To cancel, you will just need to press on
mode button.
3.3.4 Holiday Mode
How Would It Be Used?
• Push "MODE" button
until holiday symbol
appears
• If no button is pressed
for 1 second. Mode will
be set. Holiday symbol
will blink 3 times. When
mode is set, buzzer will
sound beep beep.
• Cooler temperature
segment will show "--".
• Holiday symbol and
"--" will light till mode
nishes.
During This Mode:
• Freezer may be adjusted. When holiday
mode will be cancelled, the selected
setting values will proceed.
• Cooler may be adjusted. When holiday
mode will be cancelled, the selected
setting values will proceed.
• Super cool and super freeze modes
can be selected. Holiday mode is
automatically cancelled and the selected
mode is activated.
• Economy mode can be selected after
cancelling the holiday mode. Then the
selected mode is activated.
• To cancel, you will just need to press on
mode button.
3.3.5 Drink Cool Mode
Purpose
This mode is used to cool drinks within an
adjustable time frame.
How Would It Be Used?
• Press freezer button for 3 seconds.
• Special animation will
start on freezer set
value screen and 05
will blink on cooler set
value screen.
• Press cooler button to
adjust the time (05 -
10 - 15 - 20 - 25 - 30
minutes).
• When you select the
time the numbers will
blink 3 times on screen
and sound beep beep.
• If no button is pressed
within 2 seconds the time will be set.
• The countdown starts from the adjusted
time minute by minute.
• Remaining time will blink on the screen.
• To cancel this mode press freezer set
button for 3 seconds.
3.3.6 Screen Saver Mode
Purpose
This mode saves energy by switching off all
control panel lighting when the panel is left
inactive.
How to Use?
• Screen saver mode
will be activated
automatically after 30
seconds.
• If you press any key
while the lighting of
the control panel is off,
the current machine
settings will reappear
on the display to let you
make any change you
wish.
• If you do not cancel the
screen saving mode or
press any key for 30

EN - 15
seconds, control panel will remain off.
To deactivate the screen saving mode,
• To cancel the screen saving mode, rst of
all, you need to press any key to activate
the keys and then press and hold the
Mode button for 3 seconds.
• To reactivate screen saving mode, press
and hold the mode button for 3 seconds.
Notes:
• When screen saver mode is active you
can also activate child lock.
• If no button is pressed within 5 seconds
after child lock is activated, the lights of
the control panel will turn off. You can see
latest status of settings or modes after
you pres any button. While control panel
‘s light is on, you can cancel child lock as
described in the instruction of this mode.
3.3.7 The Child Lock Function
Purpose
Child lock can be activated to prevent any
accidental or unintentional changes being
made to the appliance settings.
Activating Child Lock
Press on
freezer and
cooler buttons
simultaneously for
5 seconds.
Deactivating
Child Lock
Press on
freezer and
cooler buttons
simultaneously for
5 seconds.
Child lock
will also be
deactivated if electricity is interrupted or the
fridge is unplugged.
3.4 Temperature Settings
3.4.1 Freezer Temperature Settings
• The initial temperature value for the
freezer setting indicator is -18 °C.
• Press the set freezer
button once.
• When you rst push
this button, the last set
value will blink on the
screen.
• Whenever you press
this button, a lower
temperature will be set
(-16 °C, -18 °C, -20 °C,
-22 °C, -24 °C, super
freeze).
• When you push the
set freezer button until the super freeze
symbol appears, and if you do not push
any other button within 1 second, super
freeze will ash.
• If you continue to press it, it will restart
from -16 °C.
• The temperature value selected before
holiday mode, super freeze mode,
super cool mode or economy mode
is activated and will remain the same
when the mode is over or cancelled. The
appliance continues to operate with this
temperature value.

EN - 16
3.4.2 Cooler Temperature Settings
• Initial temperature value for the cooler
setting indicator is +4 °C.
• Press the cooler button
once.
• When you rst push
this button, the last
value will appear
on the cooler setting
indicator.
• Whenever you press
this button, a lower
temperature will be set.
(+8 °C, +6 °C, +5 °C,
+4 °C, +2 °C, super
cool)
• When you push the
cooler set button until the super cool
symbol appears, and if you do not push
any button within 1 second, super cool
will ash.
• If you continue to press the button, it will
restart from +8 °C.
• The temperature value selected before
holiday mode, super freeze mode,
super cool mode or economy mode
is activated and will remain the same
when the mode is over or cancelled. The
appliance continues to operate with this
temperature value.
Recommended Settings for the Freezer
and Cooler Compartment Temperature
Freezer
Compartment
Cooler
Compartment Remarks
-18 oC 4 oC
For regular
use and best
performance.
-20 oC, -22 oC
or -24 oC4 oC
Recommended
when
environmental
temperature
exceeds 30 °C.
Super Freeze 4 oC
Must be used
when you wish
to freeze food in
a short period of
time.
Freezer
Compartment
Cooler
Compartment Remarks
-18 oC, -20 oC,
-22 oC or
-24 oC
2 oC
These
temperature
settings must be
used when the
environmental
temperature is
high or if you think
the refrigerator
compartment is
not cool enough
becuse the door
is being opened
frequently.
-18 oC, -20 oC,
-22 oC or
-24 oC
Super Cool
Must be used
when the
refrigerator
compartment is
overloaded with
food or when
food needs to be
cooled quickly.
3.4.3 Door Open Alarm Function
If fridge door is opened more than 2
minutes, appliance sounds ‘beep beep’.
3.5 Temperature Adjustment Warnings
• It is not recommended that you operate
your fridge in environments colder than
10°C in terms of its efciency.
• Do not start another adjustment while you
are already making an adjustment.
• Temperature adjustments should be
made according to the frequency of door
openings, the quantity of food kept inside
the fridge and the ambient temperature in
the location of your fridge.
• In order to allow your fridge to reach
the operating temperature after being
connected to mains, do not open the
doors frequently or place large quantities
of food in the fridge. Please note that,
depending on the ambient temperature,
it may take 24 hours for your fridge to
reach the operating temperature.
• A 5 minute delay function is applied
to prevent damage to the compressor
of your fridge when connecting or
disconnecting to mains, or when an
energy breakdown occurs. Your fridge
will begin to operate normally after 5
minutes.

EN - 17
• Your appliance is designed to operate in
the ambient temperature (T/SN = 10°C
- 43°C) intervals stated in the standards,
according to the climate class displayed
on the information label. We do not
recommend operating your appliance out
of the stated temperature limits in terms
of cooling effectiveness.
Climate class and meaning:
T (tropical): This refrigerating appliance
is intended to be used at ambient
temperatures ranging from 16 °C to 43 °C.
ST (subtropical): This refrigerating
appliance is intended to be used at ambient
temperatures ranging from 16 °C to 38 °C.
N (temperate): This refrigerating appliance
is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C.
SN (extended temperate): This
refrigerating appliance is intended to be
used at ambient temperatures ranging from
10 °C to 32 °C.
3.6 Accessories
Visual and text descriptions in the
accessories section may vary according
to the model of your appliance.
3.6.1 The Icematic
• Pull the lever towards you and remove
the ice maker tray
• Fill with water to the marked level
• Hold the left end of the lever and set the
ice-tray on the icebox
• When ice cubes have formed, twist
the lever to drop the ice cubes into the
icebox.
Note:
Do not ll the icebox with water in
order to make ice. It can be broken.
The movement of the ice maker may
be difcult while the refrigerator is
running. In such a case should be cleaned
by removing the glass shelves.
Removing the icemaker
• Take out of the freezer glass shelves
• Remove the icemaker by dragging left or
right on the shelf.
You can remove the icemaker to use a
larger volume of the freezer compartment.
3.6.2 The Chiller Shelf
Chiller shelf
Keeping food in the Chiller compartment,
instead of the freezer or refrigerator
compartments, allows food to retain
freshness and avour for longer, while
preserving its fresh appearance. When the
Chiller tray becomes dirty, remove it and
wash with water.
(Water freezes at 0°C, but food containing
salt or sugar freezes at temperatures lower
than this).
The Chiller compartment is usually used
for storing foods such as raw sh, lightly
pickled food, rice, and so on.
Do not put food you want to freeze
or ice trays (to make ice) in the
Chiller compartment.

EN - 18
To remove the Chiller Shelf:
• Pull the chiller shelf towards you by
sliding it on the rails.
• Pull the chiller shelf up from the rail and
remove it from the fridge.
After the chiller shelf is removed, there
will be space for up to 20kg of food to
be placed in the fridge.
3.6.3 The Fresh Dial
Fresh dial
If the crisper is full, the fresh dial located
in front of the crisper should be opened.
This allows the air in the crisper and the
humidity rate to be controlled, to increase
the life of food within.
The dial, located behind the shelf, must be
opened if any condensation is seen on the
glass shelf.
3.6.4 Adjustable Door Shelf
Five different height adjustments can be
made to provide storage
areas that you need by
adjustable door shelf.
To change the position of
adjustable door shelf;
Lift up front of the shelf
(1) and move up or
down adjustable door
shelf (2) with both hands
(Pict. 1)
Before releasing the door shelf make sure
the door shelf is located at door positions.
12
Pict. 1

EN - 19
4 FOOD STORAGE
4.1 Refrigerator Compartment
For normal operating conditions, set the
temperature of the cooler compartment to
+4 or +6 oC.
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers in the
refrigerator. Frost tends to concentrate in
the coldest parts of the evaporating liquid
and, in time, your appliance will require
more frequent defrosting.
• Never place warm food in the
refrigerator. Warm food should be
allowed to cool at room temperature
and should be arranged to ensure
adequate air circulation in the refrigerator
compartment.
• Make sure no items are in direct contact
with the rear wall of the appliance as
frost will develop and packaging will stick
to it. Do not open the refrigerator door
frequently.
• We recommend that meat and clean sh
are loosely wrapped and stored on the
glass shelf just above the vegetable bin
where the air is cooler, as this provides
the best storage conditions.
• Store loose fruit and vegetable items in
the crisper containers.
• Store loose fruit and vegetables in the
crisper.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being affected by ethylene-
releaser fruits (banana, peach, apricot,
g etc.).
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products
depends on the initial quality of the food
and an uninterrupted refrigeration cycle
before refrigerator storage.
• To avoid cross-contamination do not
store meat products with fruit and
vegetables. Water leaking from meat
may contaminate other products in the
refrigerator. You should package meat
products and clean any leakages on the
shelves.
• Do not put food in front of the air ow
passage.
• Consume packaged foods before the
recommended expiry date.
NOTE: Potatoes, onions and garlic
should not be stored in the refrigerator.
• For normal working conditions, it will
be sufcient to adjust the temperature
setting of your refrigerator to +4 °C.
• The temperature of the fridge
compartment should be in the range
of 0-8 °C, fresh foods below 0 °C are
iced and rotted, bacterial load increases
above 8 °C, and spoils.
• Do not put hot food in the refrigerator
immediately, wait for the temperature
to pass outside. Hot foods increase the
degree of your refrigerator and cause
food poisoning and unnecessary spoiling
of the food.
• Meat, sh, etc. should be store in the
chiller compartment of the food, and the
vegetable compartment is preferred for
vegetables. (if available)
• To prevent cross contamination, meat
products and fruit vegetables are not
stored together.
• Foods should be placed in the refrigerator
in closed containers or covered to
prevent moisture and odors.
IMPORTANT NOTES:
Potatoes, onions and garlic should not
be stored in the refrigerator.
Cooked dishes must remain covered
when they are kept in the fridge. Place
them in the fridge when they are cool,
otherwise the temperature/humidity inside
the fridge will increases, reducing the
fridge’s efciency. Covering food and drink
also preserves their avour and aroma.

EN - 20
Do not allow food to come into contact
with the temperature sensor, which is
located in the refrigerator compartment, in
order to keep the refrigerator compartment
at optimum temperature.
Temperature sensor area
The table below is a quick guide to show
you the most efcient way to store the
major food groups in your refrigerator
compartment.
Food Maximum
storage time
How and where to
store
Vegetables
and fruits 1 week Vegetable bin
Meat and
sh 2 - 3 days
Wrap in plastic foil,
bags, or in a meat
container and store
on the glass shelf
Fresh
cheese 3 - 4 days On the designated door shelf
Butter and
margarine 1 week On the designated door shelf
Bottled
products
e.g. milk
and
yoghurt
Until the
expiry date
recommended
by the
producer
On the designated
door shelf
Eggs 1 month On the designated
egg shelf
Cooked
food 2 days All shelves
4.2 Freezer Compartment
For normal operating conditions, set the
temperature of the freezer compartment to
-18 or -20 oC.
• The freezer is used for storing frozen
food, freezing fresh food, and making ice
cubes.
• For freezing fresh food; wrap and seal
fresh food properly, that is the packaging
should be air tight and shouldn’t leak.
Special freezer bags, aluminum foil
polythene bags and plastic containers
are ideal.
• Do not store fresh food next to frozen
food as it can thaw the frozen food.
• Before freezing fresh food, divide it into
portions that can be consumed in one
sitting.
• Consume thawed frozen food within a
short period of time after defrosting
• Never place warm food in the freezer
compartment as it will thaw the frozen
food.
• Always follow the manufacturer's
instructions on food packaging when
storing frozen food. If no information is
provided food, should not be stored for
more than 3 months from the date of
purchase.
• When purchasing frozen food, make sure
that it has been stored under appropriate
conditions and that the packaging is not
damaged.
• Frozen food should be transported in
appropriate containers and placed in the
freezer as soon as possible.
• Do not purchase frozen food if the
packaging shows signs of humidity
and abnormal swelling. It is probable
that it has been stored at an unsuitable
temperature and that the contents have
deteriorated.
• The storage life of frozen food depends
on the room temperature, the thermostat
setting, how often the door is opened,
the type of food, and the length of time
required to transport the product from
the shop to your home. Always follow the
instructions printed on the packaging and
never exceed the maximum storage life
indicated.
• The maximum amount of fresh food (in
kg) that can be frozen in 24 hours is
indicated on the appliance label.
• To freeze fresh food, ensure that as much
