Snapper GT23540 User manual

Parts Manual fo
r
Revision 1,
GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
McDonough, GA, 30253 U.S.A.
TP 400-5063-1-TC-N
5/22/2007 Manual No. 7006456
HYDRO DRIVE RMO
Copyright © 2007
Briggs & Startton Yard Power Products Group
Milwaukee, WI USA. All Rights Reserved
Briggs & Startton Corporation
MODEL
GT23540
(
1694621
)
GT23540
(
2690258
)

Table Of Content
s
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 3
PAGE GROUP
4Wheels & Tires Group
6Hood, Grille & Dash Group
8Steering Group - Power Steering with Tilt
10 Frame Group - Manual Steering
14 Controls Group
18 Cruise Control Group
20 Transmission Group
24 Transmission SERVICE PARTS - Tuff Torq K-71E without Diff Lock
32 Seat & Seat Deck Group
34 Engine & Electric Clutch Group - 23HP Kohler
36 Lift Group - Hydraulic Lift with Power Steering
40 54" Mower Deck - Belt, Idler Arm & Hitch Group
42 54" Mower Deck - Height Adjustment & Roller Bar Group
46 54" Mower Deck - Housing, Arbors & Blades Group
50 Decals Group
52 Electrical Group

Wheels & Tires Group
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
4

Wheels & Tires Group
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 5
Part No Descri
p
tionItem Qt
y
Note
1 1722305 2 WHEEL & TIRE ASSEMBLY, Front (Includes Ref. 2, 3, 4, 5 & 6)
2 1722833 1 TIRE, 16 x 6-1/2, 8 Super Turf, Front
3 2164247 1 TUBE, Tire 16 x 6 1/2 - 8, Front
4 1717056 2 BEARING, Ball
5 1722834 1 WHEEL, 5-3/8 x 7-15/16, Front
6 2172353 2 VALVE STEM & CAP ASSEMBLY, Air
7 1919394 4 WASHER, 1
8 1722726A 8 WASHER, Special, 1 x 2-1/2
9 2932577 6 RING, Shaft
10 1722676 4 CAP, Hub Grey
11 2105337 2 KEY, HI PRO, 1/4 x 2
12 1719172 2 WASHER, Axle Seal “L”, 2-1/2 x 2-17/32
13 2960200 4 WASHER, 1
14 1721400 2 PLATE & HUB ASSEMBLY, Rear Wheel
15 1726489 2 WHEEL & TIRE ASSEMBLY, Rear 24” (Includes Ref. 6, 16, 17 &
1
16 1727146 1 TIRE, 24 x 12 - 12 Super Turf, Rear
17 2157638 1 TUBE, Tire 24 x 12 - 12, Rear
18 1726490 1 WHEEL, 8-1/2 x 12, Rear
19 2177725 10 NUT, Hex, 7/16-20, For Wheel Bolt

Hood, Grille & Dash Group
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
6

Hood, Grille & Dash Group
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 7
Part No Descri
p
tionItem Qt
y
Note
1 1728031D 1 HOOD, W/Scoop
4 1721804D 1 PANEL, R.H. Side
5 1721803D 1 PANEL, L.H. Side
6 1721810 1 HEADLIGHT ASSEMBLY (Includes Ref. Nos. 22, 23 & 24)
7 1721802D 1 GRILLE
8 1930641 12 NUT, Hex Flange 1/4-20 Whiz Lock
9 1726827 1 DASHBOARD (Used only on YT & LT models)
10 1726894 1 DASHBOARD, W/Hydraulic Lift Slot (Used only on GT models)
12 1721808A 1 HINGE, Hood L.H.
13 1721809A 1 HINGE, Hood R.H.
14 1723123 1 ROD, Dash Support
15 1933896 1 NUT, Hex Lock 10-24 w/Nylon Insert
16 1960392 1 SCREW, Pan Head Phillips #10-24 x 1
17 1960295 12 SCREW, Hex Whiz Lock Flange 1/4-20 x 5/8
18 1733457A 1 DUCT, Air Inlet
19 1726895 1 DASHBOARD, w/Buzzer Hole (Used only on Barons models)
20 1722285 1 COVER, Dash (Used only on Barons models)
21 1722607 1 SCREW, Pan Head Torx #8-16 x 1/2 Plastite (Used only on Barons models)
22 1677371 4 BULB, Headlight
23 1723451 4 SOCKET ASSEMBLY, Seal
24 1722902 1 REFLECTOR, Headlight

Steering Group - Power Steering with Tilt
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
8

Steering Group - Power Steering with Tilt
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 9
Part No Descri
p
tionItem Qt
y
Note
1 1724368 1 BOOT, Tilt Steering Unit
2 1722318 1 STEERING WHEEL, Straight Shaft
3 1960540 1 ROLL PIN
4 1723898A 2 SPACER
5 1725024 1 CAP, Steering Wheel, Plain
6 1721736A 1 MOUNTING PLATE
7 1724161 1 TILT STEERING UNIT Applies to Serial Number Units
1999 & Below.
8 1726026 1 TILT STEERING UNIT Applies to Serial Number Units
2000 & Above.
8 2928372 4 NUT, Hex KEPS, 1/4-20
9 1722923 1 ADAPTER, 2-13/16 Long
10 1721677 2 COUPLER, 2-3/8 Long
11 1919438 2 NUT, Hex Lock, ESNA Light, 5/16-18
12 1922127 2 CAPSCREW, Hex Head 5/16-18 x 1-3/4
13 1960518 4 NUT, Push
14 1931320 4 CARRIAGE BOLT, 1/4-20 x 1-1/4
15 2176440 1 BUSHING, Nylon
16 1960114 5 WASHER, 3/4
17 1722385 1 GEAR &, Shaft ASSEMBLY, Steering
18 1960032 1 CAPSCREW, Hex Head, 3/8-16 x 1-1/4
19 1930645 1 NUT, Hex Flange Two-Way Lock, 3/8-16
20 1664847 2 CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/4
21 1721628 1 SHAFT & PINION ASSEMBLY, Steering Power wtih Tilt
22 1611710 1 RING, Clipring Extension
23 1722459 1 BEARING, 3/4 x 1-11/16
24 1722461 1 SPACER, 3/8” Long
25 1931211 2 NUT, Hex Flange Whiz Lock, 3/8-16, Small
26 1931348 2 CARRIAGE BOLT, 3/8-16 x 3/4
27 1718832 1 GENERATOR, Torque, Power Steering Unit
28 1917356 3 LOCKWASHER, Spring, 5/16
29 1921332 3 CAPSCREW, Hex Head, 5/16-18 x 3/4

Frame Group - Manual Steering
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
10

Frame Group - Manual Steering
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 11
Part No Descri
p
tionItem Qt
y
Note
1 1724081A 1 TOWER & SUPPORT ASSEMBLY
2 1923683 4 CAPSCREW, Hex Washer Head Taptite, 3/8-16 x 3/4
3 1960541 4 CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/4
4 1723528A 1 SUPPORT, Seat Deck
5 1928352 2 NUT, Hex Flange 3/8-16 Whiz Lock, Large
6 1930644 2 NUT, Hex Flange Two-Way Lock, 1/2-13
7 1722602A 1 BACKPLATE
8 1923114 2 CAPSCREW, Hex Head 1/2-13 x 1, Black
9 1921210 2 CAPSCREW, Hex Head 3/8-16 x 1, Black
10 1726989A 1 FRAME ASSEMBLY, Front & Rear
11 1930645 7 NUT, Hex Flange Two-Way Lock, 3/8-16
12 1922755 1 WASHER, 3/8, Black
13 1960103 2 WASHER, 3/8, Black
14 1722541 1 LINK, Drag
15 1919262 1 NUT, Hex Jam 1/2-20
16 1702779A 1 JOINT, Ball
17 1708236 1 SPACER, 3/8 x 1/2 x 5/8
18 1931350 2 CARRIAGE BOLT, 3/8-16 x 1
19 1722626A 1 ROD, Tie
20 1722200A 1 AXLE ASSEMBLY w/LH Spindle (Includes Ref. Nos. 22, 24, 41)
21 1611705 2 SPACER, 25/64 x 5/8 x 5/16, Powder Metal
22 1721682 6 BUSHING, 31/32 x 1-1/4 x 3/4, Powder Metal
23 1930650 2 NUT, Hex Flange Two-Way Lock, 7/16-14
24 1704314 3 FITTING, Lube
25 1686985 1 SPINDLE REPLACEMENT KIT, LH (Includes Ref. Nos. 22, 26, 27)
26 2823485 1 CAPSCREW, 3/8-16 x 7/8, GR8
27 1663151 1 WASHER, Spring, 3/8
28 1725112 1 HUB & ARM ASSEMBLY
29 2830671 1 KEY, Woodruff
30 1724264 1 SPINDLE, LH
31 1931352 1 CARRIAGE BOLT, 3/8-16 x 1-1/2
32 1721752 1 SPACER, 11/16 x 21/32 x 2 3/32
33 1927531 2 CAPSCREW, Hex Head, 7/16-14 x 2 G8
34 1721918A 1 HOOK, “J”
35 1721805A 1 BUMPER, Black
35 1723502 1 BUMPER, Chrome
36 1960086 4 SCREW, Truss Head Torque Drive, 5/16-18 x 7/8

Frame Group - Manual Steering
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
12

Frame Group - Manual Steering
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 13
Part No Descri
p
tionItem Qt
y
Note
37 1930591 2 CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/4
38 1724801A 1 PLATE, Axle Wear
39 1931277 2 NUT, Hex Flange Whix Lick, 5/16-18
40 1722199 1 SPINDLE, RH
41 1919394 1 WASHER
42 2932577 1 RETAINING RING
43 1933260 4 CAPSCREW, Hex Flange Whiz Lock, 3/8-16 x 3/4
44 2921133 2 FITTING, Grease for Wear Plate
45 1960035 2 WASHER, 5/8
46 2960645 1 CAPSCREW, Hex Head, 5/8-11 x 3-1/2
47 2960646 1 NUT, Hex Flange Two-Way Lock, 5/8-11
48 1722212A 1 PLATE, Axle

Controls Group
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
14

Controls Group
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 15
Part No Descri
p
tionItem Qt
y
Note
1 1721353 1 ROD, Brake Lock
2 1721891 1 KNOB, Push On, Red Plastic “P”
3 1930591 1 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4
4 1919326 2 WASHER, 5/16, Black
5 1721476 1 ROD, Brake
6 1931353 2 CARRIAGE BOLT, 3/8-16 x 1 3/4
7 1663114 2 BUSHING, 5/8 x 3/4 x 3/4, Nylon
8 2921133 1 FITTING, Lube, 1/4
9 1725250 1 SPRING, Extension
10 1722460 3 PIN, Quick
11 1724917 1 ARM & HUB ASSEMBLY, Idler
12 1960020 1 WASHER, 5/8
13 1704420 1 RING, Clipring Extension
14 1721134 1 PULLEY, w/Bearing
15 1924940 3 WASHER, 3/8
16 1919439 2 NUT, Hex Lock ESNA Light, 3/8-16
17 1721133 1 PULLEY, Idler
18 1723237 2 BUSHING, 1 x 1-1/8 x 5/8, Nylon
19 1722513 1 ARM, Brake
20 1726763 1 PEDAL ASSEMBLY, Foot
21 1931320 1 CARRIAGE BOLT, 1/4-20 x 1-1/4
22 1918447 1 PIN, Cotter, Black
23 1721354A 1 LATCH, Brake
24 1664847 3 CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/4
25 1919438 1 NUT, Hex Lock ESNA Light, 5/16-18
26 1919381 1 WASHER, 5/16, Black
27 1927557 2 NUT, Hex Flange Whiz Lock Large, 5/16-18
28 1722535A 1 PEDAL, Brake
29 1721577 1 PAD, Brake Pedal
30 1931334 4 CARRIAGE BOLT, 5/16-18 x 7/8
31 1921333 2 CAPSCREW, 5/16-18 x 1
32 1722083A 1 ACTUATOR, Switch 2.53” Long
33 1923683 1 CAPSCREW, Hex Washer Head Taptite, 3/8-16 x 3/4
34 1722070A 1 PEDAL, Forward
35 1960636 4 NUT, Hex KEPS, 5/16-18
36 1721675 1 PAD, Foot Pedal Forward
37 1722071A 1 PEDAL, Reverse

Controls Group
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
16

Controls Group
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 17
Part No Descri
p
tionItem Qt
y
Note
38 1721674 1 PAD, Foot Pedal Reverse
39 1920397 1 NUT, Hex Lock ESNA Light, 1/4-20
40 1686612 1 CAM, Roller
41 1721995 1 SPRING, Extension

Cruise Control Group
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
18

Cruise Control Group
Footnotes:
TP 400-5063-1-TC-N
Manual No. 7006456GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0 19
Part No Descri
p
tionItem Qt
y
Note
1 1722314 1 COVER, w/Cruise Icon
2 1960666 1 SCREW, Torque Head Plus Socket Head, 1/4-20 x 7/8
3 1722303 1 KNOB, Cruise
4 1920397 1 NUT, Hex Lock ESNA Light, 1/4-20
5 1722003 1 LEVER & BRACKET ASSEMBLY, Cruise
6 1960103 2 WASHER, 3/8, Black
7 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4
8 1924361 2 WASHER, 1/2
9 1709043 1 SPACER, w/Flange, 11/32 x 15/32 x 3/4
10 1931342 1 CARRIAGE BOLT, 5/16-18 x 2-3/4
11 1960273 1 CARRIAGE BOLT, 5/16-18 x 2-1/4
12 1722460 2 PIN, Quick
13 1722117 1 ROD, Cruise
14 1722481 1 ROD, Return
15 2159106 1 SPRING, Cruise Return to Frame
16 1960636 2 NUT, Hex KEPS, 5/16-18
17 1960001 2 CAPSCREW, Hex Washer Head Plastite, 10-14 x 5/8
18 1717050 1 SWITCH, Push, Neutral Start, Gray
19 1722080 1 SPACER, 11/32 x 5/8 x 1-13/32
20 1919326 1 WASHER, 5/16, Black
21 1919381 1 WASHER, 5/16, Black
22 1919438 1 NUT, Hex Lock ESNA Light, 5/16-18
23 1677746 1 SPRING, Compression
24 1918447 1 PIN, Cotter

Transmission Group
TP 400-5063-1-TC-N
Manual No. 7006456 GARDEN TRACTOR ELECTRIC CLUTCH
SERIES 0
20
