Snapper LT160H42HBV User manual

Parts Manual fo
r
Revision 6,
LAWN TRACTORS ELECTRIC CLUTCH
SERIES H &
I
COPYRIGHT
©
2006
McDonough, GA, 30253 U.S.A.
TP 400-5015-6-TC-N
2/20/2006 Manual No. 7006449
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
HYDRO DRIV
E
MODEL
LT160H42HB
V
LT160H42HBV2
LT160H42IB
V
LT180H42IB
V
LT180H42IBV
2
LT180H48HBV2
LT200H42IBV
2
LT200H48IBV
2
WLT160H42HBV
2
WLT180H42IBV
2
WLT180H48HBV
2
WLT200H48IBV
2

Table Of Content
s
TP 400-5015-6-TC-N
Manual No. 7006449LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I 3
PAGE GROUP
4WHEELS, FRONT & REAR
6HOOD, BUMPER, HEADLIGHTS & COMPONENTS
10 STEERING WHEEL, CONSOLE, FUEL TANK
14 SEAT, REAR FENDER & COMPONENTS
18 FRONT AXLE
20 FRAME, CLUTCH, BRAKE & STEERING COMPONENTS
26 TRANSMISSION GROUP (Hydro Drive)
28 HYDRO RESERVOIR ASSEMBLY
30 BLADE ENGAGEMENT & TRANSMISSION CONTROLS
34 IMPLEMENT LIFT PARTS
36 ENGINE COMPONENTS, PT.1 (Model LT160H42HBV)
38 ENGINE COMPONENTS, PT.2 (Model LT160H42HBV2)
40 ENGINE COMPONENTS, PT.3 (Model LT18H Models)
44 ENGINE COMPONENTS, PT.4 (Model LT200H Models)
48 ENGINE COMPONENTS, PT.5 (Model LT160H42IBV)
50 42" CUTTING DECK ASSEMBLY
54 BELT, BLADE BRAKE- 42" CUTTING DECK
56 SPINDLE ASSEMBLY- 42" CUTTING DECK
58 48" CUTTING DECK ASSEMBLY (Series "H") PT.1
60 48" CUTTING DECK ASSEMBLY (Series "H") PT.2
64 48" CUTTING DECK ASSEMBLY (Series "I") PT.1
66 48" CUTTING DECK ASSEMBLY (Series "I") PT.2
70 48" DECK IDLER ASSEMBLIES
72 48" DECK SPINDLE ASSEMBLY- Series "H"
74 48" DECK SPINDLE ASSEMBLY- Series "I"
76 DECALS PT. 1
78 DECALS PT. 2
80 ELECTRICAL COMPONENTS
82 ELECTRICAL SCHEMATIC (All Series "I" except LT160H42IBV)
84 ELECTRICAL SCHEMATIC (LT160H42IBV)
86 ELECTRICAL SCHEMATIC (LT160H42HBV & WLT160H42HBV)
88 ELECTRICAL SCHEMATIC (LT160H42HBV2, LT180H48HBV2)

WHEELS, FRONT & REAR
TP 400-5015-6-TC-N
Manual No. 7006449 LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I
4

WHEELS, FRONT & REAR
Footnotes:
TP 400-5015-6-TC-N
Manual No. 7006449LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I 5
Part No Descri
p
tionItem Qt
y
Note
1 7058517 2 ASSEMBLY, Front Tire & Rim (Incl. items 2, 3, 4, 5 & 6) used on 42” Series “H” & 42”
Series “I”
-- 7058521 2 ASSEMBLY, Front Tire & Rim (Incl. items 2, 3A, 4A, 5 & 6) used on 48” Series “H” & 48”
Series “I”
2 7072704 1 TIRE, 15 x 6.00-6 K500 Tread Kenda per front tire assembly
3 7022772 1 RIM, 6.00 x 3.50, Grey per front tire assembly
3A 7071966 1 RIM, 6.00 x 4.00, Grey per front tire assembly
4 7014483 2 BEARING, Wheel PM per front tire assembly
4A 7028722 2 BALL BEARING, Wheel (Heim) per front tire assembly
5 7012234 1 VALVE STEM, Air per front tire assembly
6 7076998 1 FITTING, Lube 1/4-28 Tapered Thread Was 13876, per front tire
assembly
7 7010935 1 WASHER, 5/32 x 25/32” I.D. x 1-1/2” O.D. Flat per front tire assembly
8 7029618 1 WASHER, Hub-Cap Retaining per rear tire assembly
9 7029617 2 WASHER, 3/4 x 1-5/16 x 1/16” per rear tire assembly
10 7011022 1 HUB CAP per rear tire assembly
11 7091516 1 PIN, 5/32 x 1” Cotter per front tire assembly
12 7010746 1 RING, 3/4” External Retaining Was 29738, per rear tire
assembly
13 7058519 2 ASSEMBLY, Rear Tire & Rim (Includes items 5, 14 & 15A) used on Models LT160H42HBV
& LT160H42IBV
-- 7058520 2 ASSEMBLY, Rear Tire & Rim (Includes items 5, 14 & 15B) used on Models
LT160H42HBV2,
LT180H48HBV2 & all Series “I”
14 7024454 1 RIM, 8 x 7.00 Keyed Hub Grey per rear tire assembly
15A 7072706 1 TIRE, 18 x 9.50-8 K500 Tread Kenda per rear tire assembly
15B 7072707 1 TIRE, 20 x 10.00-8 K500 Tread Kenda per rear tire assembly
16 7031038 1 DUST CAP per front tire assembly

HOOD, BUMPER, HEADLIGHTS & COMPONENTS
TP 400-5015-6-TC-N
Manual No. 7006449 LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I
6

HOOD, BUMPER, HEADLIGHTS & COMPONENTS
Footnotes:
TP 400-5015-6-TC-N
Manual No. 7006449LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I 7
Part No Descri
p
tionItem Qt
y
Note
1A 7063298 1 HOOD, Mozart-Scoop-Red Was 26406 or 61383, used on
Models LT160H42HBV2,
LT180H48HBV2 & all Series “I”
1B 7024471 1 HOOD, Mozart used on Model LT160H42HBV
2 7016766 1 ROD, Hood Support
3 7024718 1 CLIP, Spring-Latch
4 7090999 2 SCREW, 1/4-20 x 5/8 Pan Head Self-Tap (Torx)
5 7076978 6 NUT, 1/4-20 Hex Nyloc
6 7073905 2 DECAL, Snapper- Hood- 3D
7 7090803 4 BOLT, 1/4-20 x 5/8” Flat Head Square Neck, GR 2
8 7029572 1 PANEL, Hood, Left Hand, Black
9 7029571 1 PANEL, Hood, Right Hand, Black
10 7029020 1 DECAL, Hood (Right Hand) used on Model LT160H42HBV
-- 7029019 1 DECAL, Hood (Left Hand) used on Model LT160H42HBV
-- 7027820 1 DECAL, LX1642H RH- Mozart Hood used on Model LT160H42HBV2
-- 7027821 1 DECAL, LX1642H LH- Mozart Hood used on Model LT160H42HBV2
-- 7046756 1 DECAL, Hood (Right Hand) used on Model LT180H48HBV2
-- 7046757 1 DECAL, Hood (Left Hand) used on Model LT180H48HBV2
-- 7075002 1 DECAL, Hood (Right Hand) used on 42” Series “I” Models
-- 7075003 1 DECAL, Hood (Left Hand) used on 42” Series “I” Models
-- 7075390 1 DECAL, Hood (Right Hand) used on Model LT160H42IBV
-- 7075391 1 DECAL, Hood (Left Hand) used on Model LT160H42IBV
-- 7075004 1 DECAL, Hood (Right Hand) used on 48” Series “I” Models
-- 7075005 1 DECAL, Hood (Left Hand) used on 48” Series “I” Models
-- 7075391 1 DECAL, Hood (Right Hand) used on Model LT180H42IBV
-- 7075390 1 DECAL, Hood (Left Hand) used on Model LT180H42IBV
-- 7078058 1 DECAL, Hood (Right Hand) used on Model LT200H42IBV2
-- 7078059 1 DECAL, Hood (Left Hand) used on Model LT200H42IBV2
11 7091095 8 POP RIVET, 1/8 x 3/8”
12 7092098 1 SCREW, 1/4-20 x 1-1/4” Hex Head Cap w/Locking Patch
13 7091106 5 SCREW, M4.8 x 1.59 x 16mm HXCRHD Sems Special
14 7029570 1 GRILL, Sloped, Black
15 7026482 1 CLIP, “J” Open Type .4 Bundle Dia., .281 Dia. Hole
16 7026377 1 DECAL, Molded Medallion Was 71544 (used on Series “H”
Models)
17 7029602 1 LENS, Rippled, Sloped
18 7026180 1 DECAL, Lens/Reflector-LH Sloped Grill
19 7026179 1 DECAL, Lens/Reflector-RH Sloped Grill
20 7073446 1 LANYARD, Hood, 14-3/4” long used on Model LT160H42HBV
-- 7073445 1 LANYARD, Hood, 16-13/32” long used on Models
LT160H42HBV2 &
LT180H48HBV2

HOOD, BUMPER, HEADLIGHTS & COMPONENTS
TP 400-5015-6-TC-N
Manual No. 7006449 LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I
8

HOOD, BUMPER, HEADLIGHTS & COMPONENTS
Footnotes:
TP 400-5015-6-TC-N
Manual No. 7006449LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I 9
Part No Descri
p
tionItem Qt
y
Note
-- 7075068 1 LANYARD, Hood 14-3/4” long used on Model LT160H42IBV &
LT180H42IBV
-- 7075069 1 LANYARD, Hood, 16” long used on Series “I” Models
21 7090858 4 SCREW, 5/16-18 x 1/2” Hex Washer Self-Tap
22 7024061 2 SHOULDER BOLT, 3/8-16 thread
23 7034324 1 BRACE. Hood Support/Stop
24 7011791 1 RETAINER, 5/16” Bolt
25 7026172 2 LAMP 1141
26 7024709 2 SOCKET, Headlight Snap-In
27 7026171 1 HARNESS, Headlight M&G Sockets
28A 7028764 1 PLENUM used on Models
LT160H42HBV2 &
LT180H48HBV2 only
28B 7074966 1 PLENUM used on Series “I” Models
29A 7026844 1 FOAM, 2 x 2 x 3.5” used on Models
LT160H42HBV2 &
LT180H48HBV2 only
29B 7072355 1 FOAM, 1 x 1 x 10” used on Series “I” Models
30A 7026803 1 FOAM, 1/2 x 3/4 x 14.25” used on Models
LT160H42HBV2 &
LT180H48HBV2 only
30B 7072354 1 FOAM, 3/4 x 3/4 x 10-3/4” used on Series “I” Models

STEERING WHEEL, CONSOLE, FUEL TANK
TP 400-5015-6-TC-N
Manual No. 7006449 LAWN TRACTORS ELECTRIC CLUTCH
SERIES H & I
10
