snug The Cloud Sundae User manual

thanks for opening the box!
IT WAS SO DARK IN THERE...
I’M HAPPY TO BE HOME!
I’VE BEEN WAITING FOR YOU FOR SOME TIME, SO MY FABRIC COULD BE WRINKLED, PLEASE GIVE ME A COUPLE OF DAYS TO HEAL.
IF YOU NEED ANY HELP, call us: 020 3095 6555 OR email us: [email protected]
THE
sofa
IS MADE
UP OF: 1 X BASE 1 X BACK REST
1 X RIGHT ARM
1 X LEFT ARM
We suggest two people assemble me – it just makes things easier! Align the metal bits on my base unit and my back rest.
Apply pressure and push down until they are completely fixed.
1
SEAT BASE
BACK REST
1 X SEAT CUSHION
1 X BACK CUSHION
On my arms, there are metal Snugfit clips and thumb screws protected by a cardboard cover. To remove this card you need to remove
my thumb screws. Take the thumb screws off by turning them anti-clockwise. Keep these in a safe place! You will need them later.
When I am delivered my Snugfit clips are in the downward lock position. Pull up, rotate my clips to the upward lock position and then
pull up into the stop lock position before moving onto step 3.
2
DOWNWARD
LOCK POSITION
SNUG FIT CLIPS - UPWARD LOCK POSITION
Pull up, rotate 180 degrees and pull up into stop/lock position.

IF YOU NEED ANY HELP, call us: 020 3095 6555 OR email us: [email protected]
RIGHT ARM
LEFT SIDE OF
SEAT BASE
Take my right arm and locate my crocodile clip that is on
the base. Turn the clip so it is facing outwards. I might be
a little stiff! Do the same with my seat base. The clip is
located on the left hand side on the bottom.
3I have small metal triangles on the right hand side of the
bottom of my seat base, and the bottom of my left arm.
Go ahead take a feel! There are also stickers to help you
locate them. The clip that looks like a crocodile mouth
attaches to these metal triangles. Line my arm with my sofa
base and push my arm inwards. It makes things a lot easier
if someone holds me steady while the arms are fitted
4
RIGHT ARM
LEFT ARM RIGHT SIDE OF
SEAT BASE
SEAT BASE
5My Snugfit clips need to be rotated into the downwards lock position to keep arms secure. Start with the front clip first! This
makes it easier for you. Apply moderate inward pressure to outside arm when locking the Snugfit clip into it’s downwards lock
position. Push down, rotate 180 degrees, push down again so the front sungfit clip is hook onto my seat base. My Snugfit clips
should line up with the pre drilled holes on the inside of my base. If they don’t, give my arm a tap forwards or backwards. Do step
6 before rotating the rear Sungfit clip.
SNUG FIT CLIPS - DOWNWARD LOCK POSITION
Push down and rotate 180 degrees, push down again into stop/lock position
thanks for opening the box!
IT WAS SO DARK IN THERE...
I’M HAPPY TO BE HOME!
I’VE BEEN WAITING FOR YOU FOR SOME TIME, SO MY FABRIC COULD BE WRINKLED, PLEASE GIVE ME A COUPLE OF DAYS TO HEAL.
THE
sofa
IS MADE
UP OF: 1 X BASE 1 X BACK REST
1 X RIGHT ARM
1 X LEFT ARM
1 X SEAT CUSHION
1 X BACK CUSHION

Finally put the cushions on. I look great, right?
You can also find assembly videos at
www.snugsofa.com/assembly
7
IF YOU NEED ANY HELP, call us: 020 3095 6555 OR email us: [email protected]
thanks for opening the box!
IT WAS SO DARK IN THERE...
I’M HAPPY TO BE HOME!
I’VE BEEN WAITING FOR YOU FOR SOME TIME, SO MY FABRIC COULD BE WRINKLED, PLEASE GIVE ME A COUPLE OF DAYS TO HEAL.
THE
sofa
IS MADE
UP OF: 1 X BASE 1 X BACK REST
1 X RIGHT ARM
1 X LEFT ARM
1 X SEAT CUSHION
1 X BACK CUSHION
Disassembling me is just as easy as putting me together. Firstly you need to remove my cushions.
1
To scure the Snugfit clip into position insert the thumb
screw and turn clockwise to hand tighten. Once this has
been done repeat step 5 and 6 for my rear Snugfit clip.
do this for both of my arms.
6

IF YOU NEED ANY HELP, call us: 020 3095 6555 OR email us: [email protected]
thanks for opening the box!
IT WAS SO DARK IN THERE...
I’M HAPPY TO BE HOME!
I’VE BEEN WAITING FOR YOU FOR SOME TIME, SO MY FABRIC COULD BE WRINKLED, PLEASE GIVE ME A COUPLE OF DAYS TO HEAL.
THE
sofa
IS MADE
UP OF: 1 X BASE 1 X BACK REST
1 X RIGHT ARM
1 X LEFT ARM
1 X SEAT CUSHION
1 X BACK CUSHION
SNUG FIT CLIPS - UPWARD LOCK POSITION
Pull up, rotate 180 degrees and pull up into stop/lock position.
To remove my arm, we need to turn my sung fit clips into the upwards lock position, so they unclip from my base.
Apply moderate inwards pressure to the outside arm, Pull up, rotate my clips to the upward lock position and
pull up into the stop lock position.
3
Untighten my thumb screws by turning anti-clockwise. Do this for both of my arms. Keep my thumb screws
together in a safe place, as you will need them to reassemble me.
2

Remove my left hand facing arm first. Place your
hand under the base of my arm and lift upwards
to release my arm from the crocodile clip. It makes
things a lot easier if someone holds me steady while
you remove my arm.
4
Remove my back rest by applying weighted pressure to my base. Place your hand under the base of my back
rest and lift upwards.
6
My right hand facing arm is a little different.
Get someone to apply weighted pressure to the top of
the arm. Place your hand under my base unit and lift up.
This will release my base from my arms crocodile clip.
5
IF YOU NEED ANY HELP, call us: 020 3095 6555 OR email us: [email protected]
