JSI Bourne User manual

Installation Instructions
Package Contents
Page 1 of 3Bourne
Wood Table Assembly
#2 & #3 Phillips
Screw Driver
Recommended Tools
Top
Legs
(Qty. 2)
#2 & #3 Phillips
Head Bit
Screw Gun
Level
Wood Rails
(Qty. 2)
Hardware Used
Step 1
Assemble H-Frame
• Attach the four metal plates
to foot rails using 1/4-20 x 1/2 ”
flat head bolts.
• Insert Cross Bar into Side
Rail brackets and attach using
1/4-20 x 1/2 ”flat head bolts.
Metal Plates
(Qty. 4)
H-Frame Rails
& Cross Bar
(Qty. 3)
#10 x 1”Flat Head Screws
(Zinc or Black)
#8 x 1 3/4 ”Pan Head Screws
#10 x 1”Flat Head Screws
(Black)
1/4-20 x 1/2”Flat Head Bolts
#8 x 2 1/4 ”Pan Head Screws
H-Frame
Foot Rail
Metal Plate
1/4-20 x 1/2 ”Bolts
Cross Bar
Side Rail Bracket
1/4-20 x 1/2 ”
Bolts
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-BU003
5/1/16

Installation Instructions
Page 2 of 3Bourne
Step 3
Position Legs in Place on Top
• Flip top upside down and lay on a flat
smooth surface.
• Position Legs on the Top. Align holes
in leg plates to pre-bored holes in Top
as shown.
Step 4
Position Wood Rails in
Place Between Legs
• Slide Wood Rails into slots in Legs as
shown below.
• DO NOT fasten to Legs down at this point.
Wood Table Assembly
(continued)
Wood Legs
Step 5
Attached H-Frame to Legs
• Fasten Metal Rails to Legs using
#10 x 1”flat head screws. Screws
will either be zinc or black pending
color of H-Frame.
Step 6
Fasten Legs to Top
• Align holes in leg plates to pre-bored
holes in Top.
• Fasten all four Legs to Top using
#10 x 1”flat head screws.
#10 x 1 ”flat head
(Color to match H-Frame)
#10 x 1 ”flat head
(Black)
Notice To Installers: Failure to comply with installation instructions will compromise the safety, durability and performance of this product, which may risk injury to the user of this
product and/or diminish the product life cycle. Jasper Group assumes no liability in these instances.
jsifurniture.com
800.457.4511
812.482.3204 O
812.482.1548 F
225 Clay Street / PO Box 231
Jasper, Indiana 47546
Form No. INST-BU003
5/1/16

Installation Instructions
Page 3 of 3Bourne
Wood Table Assembly
(continued)
Step 8
Fasten Wood Rails to Legs
• Attach Wood Rails to Legs using
#8 x 2 1/4”pan head screws.
Step 7
Fasten Wood Rails to Top
• Attach Wood Rails to Top using
#8 x 1 3/4”pan head screws.
Step 9
Level Table
• Carefully flip table upright.
• Level table front-to-back and side-to-side
by rotating adjustable glides.
#8 x 1 3/4”pan head #8 x 2 1/4”pan head
