Installation manual
Room separator LIGHT
The room separator LIGHT is made of lightweight polypropylene twin wall sheets and consists of two parts:
a wall panel and a foot-stand. Due to the smart design, the room separator will be set up in only a few
steps – easy, fast and without the use of tools. With special bayonet locks the wall panels can also be
connected to each other in no time.
Step 1: Set-up and positioning of the food-stand
Step 2: Set-up of room separator
1.1 Flap both sides of the foot-stand
upwards.
1.2 Fasten the sides using the
support elements. The support
elements need to be plugged
into the base panel.
1.3 Place and position the foot-
stand. The stand can also be
fixed to the floor using hook
and loop fastener.
2.1 Put the wall panel from above
into the foot-stand.
2.2 Push the wall panel completely
down the food-stand till it
reaches the floor.
2.3 The room separator is set up.

Söhner Kunststofftechnik GmbH
Seite 2 / 2
Industriestraße 29
D-74193 Schwaigern
T [phone]
F [phone]
[e-mail]
www.soehner.de
Version 01
04/2020
Step 3: Connecting room separators
Step 4: Using corner walls
With the room separator LIGHT we facilitate the installation of temporary spaces, such as cabins or corridors,
and the screening off individual areas. Stay healthy.
If you have questions regarding the installation of the room separators or if you need further wall panels or
foot-stands, please do not hesitate – call us at [phone] an or write us a mail to [email protected].
3.1 To connect two wall panels you
need two bayonet locks.
3.2 Fit two wall panels together
till the openings accurately
positioned on top of each other.
3.3 Put the bayonet locks in and turn
them. The room separators are
connected.
4.2 Connect the corner wall with a
room separator using two
bayonet locks (as described in
step 3).
4.1 Fold a wall panel in the middle
and put it without a foot-stand
on the floor.
4.3 After that, add another room
separator on the other side of
the corner wall.
