SCP-PCS718-010-06H Description and Features
PCS-718 List 1 January 6, 2003 1
OVERVIEW
The ADC®PG-Plus®19-inch Central Office Terminal (COT) shelf, PCS-718 List 1, supports a common
management or alarm unit, two multiplexer units and up to twelve universal or integrated PG-Plus Central Office
Line Units (COLUs) or up to six PG-Plus Integrated Central Office Line Units (FICOLUs).
DESCRIPTION AND FEATURES
The PCS-718 provides convenient mounting of a PG-Plus Alarm Unit (PAU) or PG-Plus Management Unit
(PMU), PG-Plus Multiplexer Units (PMXs) and Central Office Line Units (COLUs). Termination points for
subscriber circuits, alarm, power, and metallic test access are located on the backplane at the rear of the COT shelf.
All circuit boards are installed from the front of the COT shelf. The PCS-718 COT shelf accommodates the
following units (see Figure 1):
•12 COLUs or 6 FICOLUs
•Two PMXs
•One PAU or one PMU
Figure 1. Front View of the PCS-718 COT Shelf
The PCS-718 COT shelf features include:
•Universal mounting brackets for installation into a 19-inch or 23-inch equipment rack
•Wire-wrap connections for HDSL, alarm cutoff, and alarm relays
•Screw terminal connections for frame ground and Central Office (CO) battery
•DB-25 connector for network communications
•BNC connector for inter-shelf communications
•50-pin Telco connector for four-wire service connections
•50-pin Telco connectors for two-wire service connections
PAU/PMU
Slot (J1)
J1 J2 J3 J4 J5 J6 J7 J8 J9 J10 J11 J12 J13 J14 J15
Central Office Line Unit Slots
(J4-J15)
PMX
Slots
(J2-J3)

Composite Clock Signals SCP-PCS718-010-06H
2 January 6, 2003 PCS-718 List 1
COMPOSITE CLOCK SIGNALS
Composite clock signals are a 64 kHz bipolar clock with 8 kHz bipolar violations, that define the bit and byte
boundaries of DDS data as it is transferred within a CO. In support of DDS interfaces, PG-Plus defines two
composite clock interfaces at the PAU/PMU card slot. The PAU/PMU selects the clock and translates it into bit
and byte clocks, which it then distributes to the COLUs. Wire-wrap pins on the backplane allow the composite
clock source to be terminated or daisy-chained to another shelf.
BACKPLANE CONNECTIONS
Each shelf supports the connection of up to twelve COLUs or six FICOLUs, two PMX units, and one PAU or
PMU. The backplane of the PCS-718 List 1 contains the connectors shown in Figure 2 and Table 1. Wiring
external to the COT shelf should follow the provisions of the current edition of the National Electrical Code and
applicable local codes.
Figure 2. PCS-718 Shelf Backplane
Information in Tables 2 through 17 can be used for diagnostic and troubleshooting procedures under the
direction of an authorized ADC technical support representative.
P3
J4-J15
P2 J3 P1
TB1J22 P5 J20 J2HDSL pins J21
Test tip, ring &
EXT ACO pins
Composite
clock pins
Alarm relay
pins
J1

SCP-PCS718-010-06H Backplane Connections
PCS-718 List 1 January 6, 2003 3
The following sections identify each connector by type and function.
Power
The COT shelf backplane has a seven-position power terminal strip (TB1) that provides connections for dual
–48 Vdc, common battery return, and frame ground by way of screw terminals. The COT shelf can be wired for
redundant powering, split-powering, or single-source powering depending upon requirements.
HDSL
Each COLU slot is equipped with four wire-wrap pins for xDSL interfaces.
Two-Wire Subscriber Circuits
A total of 72 two-wire subscriber pairs terminate at the Telco connectors (P1, P2,and P3) on the COT shelf
backplane. Six pairs route to each of the twelve COLU slots. See Tables 24 through 26 for the connector pinouts.
Four-Wire Subscriber Circuits
The COT shelf provides a total of twelve four-wire data interfaces that are separate from the two-wire pairs. One
four-wire connection is provided for each of the twelve COLU slots. See Table 27 on page 39 for the connector
pinouts.
COLU Edge Card Connectors
Tables 2 through 13 show the backplane connector pinouts for each COLU slot.
Table 1. PCS-718 Backplane Connectors
Connector Description
J1 PAU or PMU connector
J2 PMX 1 connector
J3 PMX 2 connector
J4 - J15 COLU HDSL connectors.
The wire-wrap posts are for the HDSL.
J20 DB-25 (RS-232) connector
J21 10Base2 LAN connector
J22 Frame Ground
P1 - P3 Telco connectors
P5 Telco connector
TB1 Seven-position power terminal strip

Backplane Connections SCP-PCS718-010-06H
4 January 6, 2003 PCS-718 List 1
Table 2. COLU #1 (J4) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP1 RING1 50
47 TIP2 RING2 48
45 TIP3 RING3 46
43 TIP4 RING4 44
41 TIP5 RING5 42
39 TIP6 RING6 40
37 <BURN IN> - 38
35 CC8KA CC64KA 36
33 INTRPT1- SCB1 34
31 RDATA1 RDATB1 32
29 CLKA1 CLKB1 30
27 RSIGA1 RSIGB1 28
25 FSYNCA1 FSYNCB1 26
23 TDATA1 TDATB1 24
21 TSIGA1 TSIGB1 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_L BATA_L 16
13 BATB_L BATB_L 14
11 – – 12
9HTIPA1 HTIPB1 10
7HRINGA1 HRINGB1 8
5FGND FGND 6
34WRXT1 4WRXR1 4
14WTXT1 4WTXR1 2

SCP-PCS718-010-06H Backplane Connections
PCS-718 List 1 January 6, 2003 5
Table 3. COLU #2 (J5) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP7 RING7 50
47 TIP8 RING8 48
45 TIP9 RING9 46
43 TIP10 RING10 44
41 TIP11 RING11 42
39 TIP12 RING12 40
37 <BURN IN> – 38
35 CC8KA CC64KA 36
33 INTRPT2- SCB2 34
31 RDATA2 RDATB2 32
29 CLKA2 CLKB2 30
27 RSIGA2 RSIGB2 28
25 FSYNCA2 FSYNCB2 26
23 TDATA2 TDATB2 24
21 TSIGA2 TSIGB2 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_L BATA_L 16
13 BATB_L BATB_L 14
11 – – 12
9HTIPA2 HTIPB2 10
7HRINGA2 HRINGB2 8
5FGND FGND 6
34WRXT2 4WRXR2 4
14WTXT2 4WTXR2 2

Backplane Connections SCP-PCS718-010-06H
6 January 6, 2003 PCS-718 List 1
Table 4. COLU #3 (J6) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP13 RING13 50
47 TIP14 RING14 48
45 TIP15 RING15 46
43 TIP16 RING16 44
41 TIP17 RING17 42
39 TIP18 RING18 40
37 <BURN IN> – 38
35 CC8KA CC64KA 36
33 INTRPT3- SCB3 34
31 RDATA3 RDATB3 32
29 CLKA3 CLKB3 30
27 RSIGA3 RSIGB3 28
25 FSYNCA3 FSYNCB3 26
23 TDATA3 TDATB3 24
21 TSIGA3 TSIGB3 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_L BATA_L 16
13 BATB_L BATB_L 14
11 – – 12
9HTIPA3 HTIPB3 10
7HRINGA3 HRINGB3 8
5FGND FGND 6
34WRXT3 4WRXR3 4
14WTXT3 4WTXR3 2

SCP-PCS718-010-06H Backplane Connections
PCS-718 List 1 January 6, 2003 7
Table 5. COLU #4 (J7) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP19 RING19 50
47 TIP20 RING20 48
45 TIP21 RING21 46
43 TIP22 RING22 44
41 TIP23 RING23 42
39 TIP24 RING24 40
37 <BURN IN> – 38
35 CC8KA CC64KA 36
33 INTRPT4- SCB4 34
31 RDATA4 RDATB4 32
29 CLKA4 CLKB4 30
27 RSIGA4 RSIGB4 28
25 FSYNCA4 FSYNCB4 26
23 TDATA4 TDATB4 24
21 TSIGA4 TSIGB4 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_L BATA_L 16
13 BATB_L BATB_L 14
11 – – 12
9HTIPA4 HTIPB4 10
7HRINGA4 HRINGB4 8
5FGND FGND 6
34WRXT4 4WRXR4 4
14WTXT4 4WTXR4 2

Backplane Connections SCP-PCS718-010-06H
8 January 6, 2003 PCS-718 List 1
Table 6. COLU #5 (J8) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP25 RING25 50
47 TIP26 RING26 48
45 TIP27 RING27 46
43 TIP28 RING28 44
41 TIP29 RING29 42
39 TIP30 RING30 40
37 <BURN IN> – 38
35 CC8KA CC64KA 36
33 INTRPT5- SCB5 34
31 RDATA5 RDATB5 32
29 CLKA5 CLKB5 30
27 RSIGA5 RSIGB5 28
25 FSYNCA5 FSYNCB5 26
23 TDATA5 TDATB5 24
21 TSIGA5 TSIGB5 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_L BATA_L 16
13 BATB_L BATB_L 14
11 – – 12
9HTIPA5 HTIPB5 10
7HRINGA5 HRINGB5 8
5FGND FGND 6
34WRXT5 4WRXR5 4
14WTXT5 4WTXR5 2

SCP-PCS718-010-06H Backplane Connections
PCS-718 List 1 January 6, 2003 9
Table 7. COLU #6 (J9) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP31 RING31 50
47 TIP32 RING32 48
45 TIP33 RING33 46
43 TIP34 RING34 44
41 TIP35 RING35 42
39 TIP36 RING36 40
37 <BURN IN> – 38
35 CC8KA CC64KA 36
33 INTRPT6- SCB6 34
31 RDATA6 RDATB6 32
29 CLKA6 CLKB6 30
27 RSIGA6 RSIGB6 28
25 FSYNCA6 FSYNCB6 26
23 TDATA6 TDATB6 24
21 TSIGA6 TSIGB6 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_L BATA_L 16
13 BATB_L BATB_L 14
11 – – 12
9HTIPA6 HTIPB6 10
7HRINGA6 HRINGB6 8
5FGND FGND 6
34WRXT6 4WRXR6 4
14WTXT6 4WTXR6 2

Backplane Connections SCP-PCS718-010-06H
10 January 6, 2003 PCS-718 List 1
Table 8. COLU #7 (J10) Connector Pinouts
Pin # Assignment Assignment Pin #
49 TIP37 RING37 50
47 TIP38 RING38 48
45 TIP39 RING39 46
43 TIP40 RING40 44
41 TIP41 RING41 42
39 TIP42 RING42 40
37 <BURN IN> – 38
35 CC8KA CC64KA 36
33 INTRPT7- SCB7 34
31 RDATA7 RDATB7 32
29 CLKA7 CLKB7 30
27 RSIGA7 RSIGB7 28
25 FSYNCA7 FSYNCB7 26
23 TDATA7 TDATB7 24
21 TSIGA7 TSIGB7 22
19 TSTTIP TSTRING 20
17 GND GND 18
15 BATA_H BATA_H 16
13 BATB_H BATB_H 14
11 – – 12
9HTIPA7 HTIPB7 10
7HRINGA7 HRINGB7 8
5FGND FGND 6
34WRXT7 4WRXR7 4
14WTXT7 4WTXR7 2
