Solaris BLSA3 Technical manual

INTRODUCTION
1
Thank you for purchasing this machine.
Before using this machine, carefully read the “IMPORTANT SAFETY INSTRUCTIONS”, and then study
this manual for the correct operation of the various functions. In addition, after you have finished reading
this manual, keep it where it can quickly be accessed for future reference.
Please read these safety instructions before attempting to use the machine.
DANGER - To reduce the risk of electric shock
1Always unplug the machine from the electrical outlet immediately after using, when
cleaning, making any user servicing adjustments mentioned in this manual, or if you
are leaving the machine unattended.
WARNING - To reduce the risk of burns, fire, electrical shock, or injury to
persons.
2Always unplug the machine from the electrical outlet when making any adjustments mentioned in the instruction
manual.
• To unplug the machine, switch the machine to the symbol “O” position to turn it off, then grasp the plug and pull
it out of the electrical outlet. Do not pull on the cord.
• Plug the machine directly into the electrical outlet. Do not use an extension cord.
• Always unplug your machine if there is a power failure.
3Electrical Hazards:
• This machine should be connected to an AC power source within the range indicated on the rating label. Do not
connect it to a DC power source or inverter. If you are not sure what kind of power source you have, contact a
qualified electrician.
• This machine is approved for use in the country of purchase only.
4Never operate this machine if it has a damaged cord or plug, if it is not working properly, it has been dropped or
damaged, or water is spilled on the unit. Return the machine to the nearest authorized Baby Lock retailer for
examination, repair, electrical or mechanical adjustment.
• While the machine is stored or in use if you notice anything unusual, such as an odor, heat, discoloration or
deformation, stop using the machine immediately and unplug the power cord.
• When transporting the machine, be sure to carry it by its handle. Lifting the machine by any other part may
damage the machine or result in the machine falling, which could cause injuries.
• When lifting the machine, be careful not to make any sudden or careless movements, which may cause a
personal injury.
INTRODUCTION
IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS
2
5Always keep your work area clear:
• Never operate the machine with any air openings blocked. Keep ventilation openings of the machine and foot
controller free from the build up of lint, dust, and loose cloth.
• Do not store objects on the foot controller.
• Never drop or insert foreign objects into any opening.
• Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
• Do not use the machine near a heat source, such as a stove or iron; otherwise, the machine, power cord or
garment being sewn may ignite, resulting in fire or an electric shock.
• Do not place this machine on an unstable surface, such as an unsteady or slanted table, otherwise the machine
may fall, resulting in injuries.
6Special care is required when sewing:
• Always pay close attention to the needle. Do not use bent or damaged needles.
• Keep fingers away from all moving parts. Special care is required around the machine needle.
• Switch the machine to the symbol “O” position to turn it off when making any adjustments in the needle area.
• Do not use a damaged or incorrect needle plate, as it could cause the needle to break.
• Do not push or pull the fabric when sewing, and follow careful instruction when free motion stitching so that
you do not deflect the needle and cause it to break.
7This machine is not a toy:
• Your close attention is necessary when the machine is used by or near children.
• This product contains small parts. Keep the product out of the reach of children to prevent accidental ingestion
of small parts.
• The plastic bag that this machine was supplied in should be kept out of the reach of children or disposed of.
Never allow children to play with the bag due to the danger of suffocation.
• Do not use the seam ripper in any other way than how it is intended.
• Do not use outdoors.
8For a longer service life:
• When using and storing this machine, avoid direct sunlight and high humidity locations. Do not use or store the
machine near a space heater, iron, halogen lamp, or other hot objects.
• Do not use cleansers or organic solvents, such as thinner, petroleum ether or alcohol, to clean the machine.
Otherwise, the finish may peel off or become scratched.
• Do not oil the machine by yourself to prevent damaging it.
• Always consult the Instruction and Reference Guide when replacing or installing any assemblies, the presser feet,
needle, or other parts to assure correct installation.
9For repair or adjustment:
• If the light unit is damaged, it must be replaced by an authorized Baby Lock retailer.
• In the event a malfunction occurs or adjustment is required, first follow the troubleshooting table in the back of
the Instruction and Reference Guide to inspect and adjust the machine yourself. If the problem persists, please
consult your local authorized Baby Lock retailer.
Use this machine only for its intended use as described in the manual.
Use accessories recommended by the manufacturer as contained in this manual.
The contents of this manual and specifications of this product are subject to change without notice.
For additional product information and updates, visit our website at www.babylock.com

IMPORTANT SAFETY INSTRUCTIONS
3
SAVE THESE INSTRUCTIONS
This machine is intended for household use.
FOR USERS IN COUNTRIES EXCEPT EUROPEAN COUNTRIES
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised
to ensure that they do not play with the appliance.
FOR USERS IN EUROPEAN COUNTRIES
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
FOR USERS IN THE UK, EIRE, MALTA AND CYPRUS
ONLY
IMPORTANT
• In the event of replacing the plug fuse, use a fuse approved by ASTA to BS 1362, i.e. carrying the mark,
rating as marked on plug.
• Always replace the fuse cover. Never use plugs with the fuse cover omitted.
• If the available electrical outlet is not suitable for the plug supplied with this equipment, you should contact your
authorized Baby Lock retailer to obtain the correct lead.

IMPORTANT SAFETY INSTRUCTIONS
4
Federal Communications Commission (FCC) Supplier's
Declaration of Conformity (For U.S.A. Only)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the authorized Baby Lock retailer or an experienced radio/TV technician for help.
• This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Important
Changes or modifications not expressly approved by Tacony Corporation could void the user's authority to operate
the equipment.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.
Responsible Party: Tacony Corporation
1760 Gilsinn Lane, Fenton, Missouri 63026 U.S.A.
declares that the product
Product Name:
Model Number:
Baby Lock Sewing Machine
BLSA3

IMPORTANT SAFETY INSTRUCTIONS
5
For Users in Canada
This device complies with Industry Canada's licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC
radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be
installed and operated keeping the radiator at least 20cm or more away from person's body.
For Users in Mexico
The operation of this equipment is subject to the following two conditions:
(1) it is possible that this equipment or device may not cause harmful interference, and
(2) this equipment or device must accept any interference, including interference that may cause undesired operation.
La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y
(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada.
Legal limitations for copying
(United States/Canada)
Observe all copyright laws when using this product.
Color reproductions of certain documents are illegal and may result in either criminal or civil liability. This
memorandum is intended to be a guide rather than a complete listing of every possible prohibition. In case of doubt,
we suggest that you check with counsel as to any particular questionable documents.
The following documents issued by the United States/Canadian Government or any of its Agencies may not be
copied:
•Money
• Bonds or other certificates of indebtedness
• Certificates of Deposit
• Internal Revenue Stamps (canceled or uncanceled)
• Selective Service or draft papers
•Passports
• United States/Canadian Postage Stamps (canceled or uncanceled)
• Food Stamps
• Immigration Papers
• Checks or drafts drawn by Governmental agencies
• Identifying badges or insignias
Copyrighted works cannot be copied. Sections of a copyrighted work can be copied for ‘fair use’.
Multiple copies would indicate improper use.
Works of art should be considered the equivalent of copyrighted works.

WARNING SIGN
6
Unlawful Use of Scanning Equipment
(Other countries except United States/Canada)
It is an offence to make reproductions of certain items or documents with the intent to commit fraud. The following
is a non-exhaustive list of documents which it may be unlawful to produce copies of. We suggest you check with
your legal adviser and/or the relevant legal authorities if in doubt about a particular item or document:
• Currency
• Bonds or other certificates of debt
• Certificates of Deposit
• Armed forces service or draft papers
•Passports
• Postage stamps (cancelled or uncancelled)
• Immigration papers
• Welfare documents
• Cheques or drafts drawn by governmental agencies
• Identifying badges or insignias
Copyrighted works cannot be copied lawfully, subject to the “fair dealing” exception relating to sections of a
copyrighted work. Multiple copies would indicate improper use. Works of art should be considered the equivalent
of copyrighted works.
■Spool Stand
The warning label is attached to the bottom.
This product contains magnets.
aBe careful not to pinch your fingers or any objects between the spool stand and the upper cover of the machine.
bBe sure to keep the magnets away from precision electronics, computer disks, credit cards with a magnetic stripe,
etc.
cDo not use the spool stand if you have a pacemaker.
■Side Cutter (Sold Separately)
The following warning label pertains to the side cutter. Do not touch the knives or operation lever of the side
cutter while sewing to avoid equipment damage or injury. For details, refer to “Overcasting Using the Side
Cutter (Sold Separately)” on page 113.
WARNING SIGN
abc

TRADEMARKS
7
This product includes software developed by the following vendor: ©2008 Devicescape Software, Inc.
Make sure you use a router or firewall when connecting your machine to the Internet to protect it against
unauthorized access from the Internet.
TRADEMARKS
IMPORTANT:
READ BEFORE DOWNLOADING, COPYING, INSTALLING OR USING.
By downloading, copying, installing or using the software you agree to this license. If you do not agree
to this license, do not download, install, copy or use the software.
Intel License Agreement For Open Source Computer Vision Library
Copyright © 2000, Intel Corporation, all rights reserved. Third party copyrights are property of their respective owners.
Redistribution and use in source and binary forms, with or without modification, are permitted provided that the
following conditions are met:
• Redistribution’s of source code must retain the above copyright notice, this list of conditions and the following
disclaimer.
• Redistribution’s in binary form must reproduce the above copyright notice, this list of conditions and the
following disclaimer in the documentation and/or other materials provided with the distribution.
• The name of Intel Corporation may not be used to endorse or promote products derived from this software
without specific prior written permission.
This software is provided by the copyright holders and contributors “as is” and any express or implied warranties,
including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose are
disclaimed. In no event shall Intel or contributors be liable for any direct, indirect, incidental, special, exemplary,
or consequential damages (including, but not limited to, procurement of substitute goods or services; loss of use,
data, or profits; or business interruption) however caused and on any theory of liability, whether in contract, strict
liability, or tort (including negligence or otherwise) arising in any way out of the use of this software, even if
advised of the possibility of such damage.
All information provided related to future Intel products and plans is preliminary and subject to change at any time, without notice.
SD is a trademark of SD-3C, LLC.
WPA™ and WPA2™ are trademarks of Wi-Fi Alliance®.
Any trade names and product names of companies appearing on Baby Lock products, related documents and any
other materials are all trademarks or registered trademarks of those respective companies.
COPYRIGHT AND LICENSE
PRECAUTION FOR WIRELESS CONNECTION

8
HOW TO USE THIS MANUAL
The Instruction and Reference Guides for this machine consist of the Instruction and Reference Guide
(Sewing) and the Instruction and Reference Guide (Embroidery). Refer to the appropriate Instruction and
Reference Guide according to your needs. For basic information about, for example, the included
accessories or the settings screen, refer to chapter 1 of the Instruction and Reference Guide (Sewing).
In the screens appearing in the step-by-step instructions, the parts referred to in the operations are marked
with . Compare the screen in the directions with the actual screen, and carry out the operation.
If, while using the machine, you experience something you do not understand, or there is a function you
would like to know more about, refer to the index at the back of the Instruction and Reference Guide in
conjunction with the table of contents to find the section of the manual you should refer to.
HOW TO USE THIS MANUAL

CONTENTS
9
1
2
3
4
5
INTRODUCTION................................................. 1
IMPORTANT SAFETY INSTRUCTIONS ................ 1
WARNING SIGN.................................................. 6
TRADEMARKS ...................................................... 7
COPYRIGHT AND LICENSE................................. 7
PRECAUTION FOR WIRELESS CONNECTION .... 7
HOW TO USE THIS MANUAL ............................. 8
Chapter 1 Getting Ready 11
NAMES OF MACHINE PARTS AND THEIR
FUNCTIONS ...................................................... 12
ACCESSORIES .................................................... 15
Included Accessories ........................................................... 15
Options................................................................................ 19
Using the Accessory Case .................................................... 21
Using the Flat Bed Attachment............................................. 21
Using Fine Tipped Stylus Pen............................................... 22
Using the Multi-purpose Screwdriver ................................... 22
Assembling the Spool Stand ................................................. 23
TURNING THE MACHINE ON/OFF .................. 24
Setting Your Machine for the First Time ............................... 25
LCD SCREEN ...................................................... 26
Using the Machine Setting Mode Key .................................. 27
Sewing Settings .................................................................... 27
General Settings................................................................... 28
Embroidery Settings ............................................................. 30
Wireless LAN settings .......................................................... 31
Setting Functions.................................................................. 31
Using the Machine Help Key ............................................... 35
Using the Operation Guide Function ................................... 36
Using the Sewing Guide Function........................................ 37
Playing a Tutorial Video....................................................... 38
Playing MPEG-4 (MP4) Videos............................................. 39
Using the Stitch Pattern Explanation Function ...................... 39
Viewing the Instruction and Reference Guide (PDF File) on
the Machine......................................................................... 40
WIRELESS NETWORK CONNECTION
FUNCTIONS ...................................................... 41
Operations Available with a Wireless Network
Connection .......................................................................... 41
Specifying Wireless Network Connection Settings................ 41
Using the Wizard to Set Up the Wireless Network
Connection .......................................................................... 42
CONNECTING THE ACCESSORY TO THE
MACHINE .......................................................... 44
Using USB Media/SD Card (Sold Separately)........................ 44
Using a USB Mouse ............................................................. 44
Chapter 2 Sewing Basics 45
LOWER THREADING......................................... 46
Winding the Bobbin............................................................. 46
Setting the Bobbin................................................................ 50
Pulling Up the Bobbin Thread.............................................. 52
UPPER THREADING .......................................... 53
Upper Threading.................................................................. 53
Using the Twin Needle Mode .............................................. 56
Using the Spool Stand.......................................................... 58
CHANGING THE NEEDLE.................................. 60
Fabric/Thread/Needle Combinations.................................... 62
CHANGING THE PRESSER FOOT ...................... 63
Removing the Presser Foot ................................................... 63
Attaching the Presser Foot.................................................... 63
Attaching the Presser Foot with the Included Adapter .......... 64
Using the Compact Digital Dual Feed Foot .......................... 65
SEWING ............................................................. 68
Sewing a Stitch..................................................................... 68
Using Advanced Multi-Function Foot Controller .................. 69
Sewing Reverse/Reinforcement Stitches................................ 72
Automatic Reinforcement Stitching ...................................... 72
Automatic Presser Foot Lowering Function and Thread
Cutting Function................................................................... 74
Automatic Presser Foot Raising Function .............................. 74
Sewing Curves...................................................................... 75
Changing Sewing Direction.................................................. 75
Sewing Heavyweight Fabrics................................................ 75
Sewing Hook-and-Loop Fastener Tape ................................. 76
Sewing Lightweight Fabrics .................................................. 77
Sewing Stretch Fabrics.......................................................... 77
Sewing Leathers or Vinyl Fabrics .......................................... 77
Sewing Cylindrical Pieces .................................................... 77
STITCH SETTINGS ............................................. 78
Setting the Stitch Width ........................................................ 78
Setting the Stitch Length ....................................................... 79
Setting the [L/R Shift] ............................................................ 79
Setting the Thread Tension ................................................... 80
USEFUL FUNCTIONS ........................................ 81
Automatic Thread Cutting .................................................... 81
Pivoting................................................................................ 82
Using the Knee Lifter ............................................................ 83
Automatic Fabric Sensor System (Automatic Presser Foot
Pressure)............................................................................... 84
Needle Position - Stitch Placement....................................... 84
Checking the Needle Location in the Screen ........................ 85
USING THE PROJECTOR................................... 86
Convenient Sewing Features by Using the Projector ............. 86
About the Dual Purpose Stylus ............................................. 86
Installing a Battery in the Dual Purpose Stylus ...................... 86
Operating the Projector with the Dual Purpose Stylus .......... 87
Using the Dual Purpose Stylus Holder.................................. 87
PROJECTOR FUNCTIONS (UTILITY STITCHES
AND CHARACTER/DECORATIVE STITCHES).... 88
Projection Area of Projector ................................................. 88
Projecting the Stitch Pattern with the Projector ..................... 88
Selecting a Stitch Pattern with the Dual Purpose Stylus......... 89
Editing a Stitch Pattern Selected with the Dual Purpose
Stylus ................................................................................... 89
Projecting the Guidelines with the Projector......................... 90
Specifying the Sewing End Point........................................... 92
Chapter 3 Utility Stitches 95
SELECTING UTILITY STITCHES ......................... 96
Selecting a Stitch ................................................................ 100
Saving Your Stitch Settings ................................................. 102
SEWING THE STITCHES .................................. 103
Straight Stitches .................................................................. 103
Dart Seam .......................................................................... 107
Gathering ........................................................................... 108
Flat Fell Seam..................................................................... 108
Pintuck............................................................................... 109
Zigzag Stitches ................................................................... 110
Elastic Zigzag Stitches ........................................................ 111
Overcasting........................................................................ 112
Quilting.............................................................................. 115
Hand-Look Quilting ........................................................... 124
Blind Hem Stitches............................................................. 125
Appliqué ............................................................................ 127
Shelltuck Stitches ............................................................... 128
Scallop Stitches .................................................................. 128
Crazy Quilting.................................................................... 129
Smocking Stitches .............................................................. 129
Fagoting ............................................................................. 130
Tape or Elastic Attaching .................................................... 131
Heirloom............................................................................ 132
CONTENTS

CONTENTS
10
Basting ............................................................................... 133
Zigzag Couching ................................................................ 134
One-Step Buttonholes ........................................................ 137
Four-Step Buttonholes ........................................................ 141
Bar Tacks ........................................................................... 143
Button Sewing .................................................................... 144
Eyelet ................................................................................. 146
Multi-directional Sewing (Straight Stitch and Zigzag
Stitch)................................................................................. 146
Zipper Insertion.................................................................. 147
Changing the Start and End Angles of the Stitch Pattern (Stitch
Tapering Function) ............................................................. 150
Chapter 4 Character/Decorative Stitches 155
SELECTING STITCH PATTERNS........................ 156
Selecting Decorative Stitch Patterns.................................... 158
Selecting Character Stitch Patterns...................................... 158
SEWING STITCH PATTERNS ............................ 160
Sewing Attractive Finishes .................................................. 160
Basic Sewing ...................................................................... 160
Making Adjustments........................................................... 161
EDITING STITCH PATTERNS ........................... 163
Changing the Size .............................................................. 166
Changing the Length (for 7mm Satin Stitch Patterns
Only).................................................................................. 166
Creating a Vertical Mirror Image ........................................ 166
Creating a Horizontal Mirror Image.................................... 166
Sewing a Stitch Pattern Continuously ................................. 166
Changing Thread Density (for Large Satin Only) ................. 167
COMBINING STITCH PATTERNS .................... 168
Combining Various Stitch Patterns...................................... 168
Combining Large and Small Stitch Patterns......................... 169
Combining Horizontal Mirror Image Stitch Patterns............ 169
Combining Stitch Patterns of Different Length .................... 170
Making Step Stitch Patterns ................................................ 171
USING THE MEMORY FUNCTION.................. 173
Saving Stitch Patterns ......................................................... 173
Retrieving Stitch Patterns .................................................... 174
Managing Saved File .......................................................... 175
Chapter 5 Appendix 177
CARE AND MAINTENANCE............................. 178
Restrictions on Oiling......................................................... 178
Precautions on Storing the Machine ................................... 178
Cleaning the LCD Screen ................................................... 178
Cleaning the Machine Casing............................................. 178
Cleaning the Race .............................................................. 178
Cleaning the Bobbin Case .................................................. 180
Cleaning the Cutter in the Bobbin Case Area...................... 180
About the Maintenance Message........................................ 181
TROUBLESHOOTING ...................................... 182
Frequent Troubleshooting Topics ....................................... 182
Upper Thread Is Too Tight.................................................. 182
Tangled Thread on Wrong Side of Fabric ........................... 183
Incorrect Thread Tension.................................................... 184
Fabric Is Caught in the Machine and Cannot be
Removed............................................................................ 185
If the Thread Becomes Tangled Under the Bobbin Winder
Seat .................................................................................... 186
List of Symptoms ................................................................ 187
ERROR MESSAGES ........................................... 192
How Can I Find the Wireless Security Information (SSID and
Network Key) ..................................................................... 194
SPECIFICATIONS ............................................. 195
UPDATING YOUR MACHINE’S SOFTWARE ... 197
Update Procedure Using USB Media.................................. 197
Update Procedure Using Wireless LAN Connection ........... 198
STITCH SETTING CHART................................. 199
INDEX .............................................................. 210

Chapter 1
Getting Ready
Be sure to install the latest software.
Refer to “UPDATING YOUR MACHINE’S SOFTWARE” on page 197.

NAMES OF MACHINE PARTS AND THEIR FUNCTIONS
12
■Front View
* Camera and projector (built-in)
aTop cover
Open the top cover when threading the machine or winding the
bobbin.
bPretension disk
Pass the thread around the pretension disk when winding the
bobbin thread. (page 46)
cThread guide for bobbin winding
Pass the thread through this thread guide when winding the
bobbin thread. (page 46)
dSpool pin
Place a spool of thread on the spool pin. (page 53)
eSpool cap
Use the spool cap to hold the spool of thread in place.
(page 53)
fSupplemental spool pin
Use this spool pin to wind the bobbin thread, or to sew with the
twin needle. (page 46, page 56)
gBobbin winder
Use the bobbin winder when winding the bobbin. (page 46)
hBobbin winding slider
Adjust the amount of thread wound onto the bobbin. (page 48)
iLCD (liquid crystal display)
Settings for the selected stitch and error messages appear in
the LCD. (page 26)
jSpeaker
kKnee lifter
Use the knee lifter to raise and lower the presser foot. (page 83)
lKnee lifter slot
Insert the knee lifter into the slot. (page 83)
mOperation buttons (7 buttons) and sewing speed
controller
Use these buttons and the slide to operate the machine.
(page 14)
nNeedle plate lever
Slide the lever toward you to remove the needle plate.
(page 178)
oFlat bed attachment with accessory compartment
Store presser feet and bobbins in the accessory compartment
of the flat bed attachment. When sewing cylindrical pieces,
remove the flat bed attachment. (page 21)
pThread cutter
Pass the threads through the thread cutter to cut them.
(page 55)
qThread guide plate
Pass the thread around the thread guide plate when threading
upper thread. (page 53)
■Right-side/Rear View
aConnector for the presser foot
Connect the compact digital dual feed foot or embroidery foot
with LED pointer (sold separately). (page 65)
bHandle
Carry the machine by its handle when transporting the
machine.
cPresser foot lever
Raise and lower the presser foot lever to raise and lower the
presser foot. (page 63)
dAir vent
The air vent allows the air surrounding the motor to circulate.
Do not cover the air vent while the machine is being used.
eMain power switch
Use the main power switch to turn the machine ON and OFF.
(page 24)
fAdvanced multi-function foot controller
Use the advanced multi-function foot controller to operate the
machine. (page 69)
gPower cord receptacle
Insert the power cord into the machine receptacle. (page 24)
hDual purpose stylus holder connector
Connect the included dual purpose stylus holder. (page 87)
iFoot controller jack
Insert the foot controller plug into its jack on the machine.
(page 70)
jUSB port
In order to send stitch patterns and embroidery patterns from/
to USB media, plug the USB media directly into the USB port.
kSD card slot
Insert an SD card into the SD card slot in order to import/export
stitch patterns and embroidery patterns.
lHandwheel
Rotate the handwheel toward you (counterclockwise) to raise
and lower the needle. The wheel should be turned toward the
front of the machine.
NAMES OF MACHINE PARTS AND THEIR FUNCTIONS
IMPORTANT
• Do not place any object weighing 1 kg (2.2 lb)
or more on the top cover, otherwise the cover
may be damaged.
• Do not touch the camera or projector.
Otherwise, it will not display properly.
a
b
c
d
ef gh
o
p
i
j
l
m
nk
q
*
a
b
c
d
e
f
g
h
i
j
k
l

NAMES OF MACHINE PARTS AND THEIR FUNCTIONS
Getting Ready
13
1
■Needle and Presser Foot Section
aPresser foot holder screw
Use the presser foot holder screw to hold the presser foot
holder in place. (page 64)
bPresser foot holder
The presser foot is attached to the presser foot holder.
(page 63)
cPresser foot
The presser foot consistently applies pressure to the fabric as
sewing takes place. Attach the appropriate presser foot for the
selected stitch. (page 63)
dFeed dogs
The feed dogs feed the fabric in the sewing direction.
eBobbin cover
Open the bobbin cover to set the bobbin. (page 50, page 111)
fNeedle plate
The needle plate is marked with guides to help sew straight
seams. (page 105)
Remove the needle plate to clean the race. (page 178)
gNeedle bar thread guide
Pass the upper thread through the needle bar thread guide.
(page 53)
hNeedle clamp screw
Use the needle clamp screw to hold the needle in place.
(page 60)
Measurements on the needle plate and the bobbin
cover (with mark)
The measurements on the bobbin cover and
needle plate are references for stitch patterns with
a left or middle (center) needle position.
aFor stitches with a middle (center) needle position
bFor stitches with a left needle position
cLeft needle position on the needle plate <inch>
dLeft needle position on the needle plate <cm>
eMiddle (center) needle position on the bobbin cover
(with mark) <inch>
fMiddle (center) needle position on the needle plate
<inch>
■Embroidery Unit
aCarriage
The carriage moves the embroidery frame automatically when
embroidering.
bRelease lever (located under the embroidery unit)
Press the release lever to remove the embroidery unit.
cEmbroidery frame holder
Insert the embroidery frame into the embroidery frame holder
to hold the frame in place.
dFrame-securing lever
Press the frame-securing lever down to secure the embroidery
frame.
eEmbroidery unit connection
Insert the embroidery unit connection into the connection port
of the machine (with the machine powered off) when attaching
the embroidery unit.
a
b
c
d
g
h
e
f
a
b
c
d
e
f
b
a
b
c
d
e

NAMES OF MACHINE PARTS AND THEIR FUNCTIONS
14
■Operation Buttons
a“Start/Stop” button
Press this button and the machine will sew a few stitches at a
slow speed and then begin sewing at the speed set by the
sewing speed controller. Press the button again to stop the
machine. Hold the button in to sew at the machine’s slowest
speed. The button changes color according to the machine’s
operation mode.
b“Reverse Stitch” button
For straight, zigzag, and elastic zigzag stitch patterns that take
reverse stitches, the machine will sew reverse stitches at low
speed only while holding down the “Reverse Stitch” button.
The stitches are sewn in the opposite position.
For other stitches, use this button to sew reinforcement
stitches at the beginning and end of sewing. Press and hold
this button, and the machine sews 3 stitches in the same spot
and stops automatically. (page 72)
c“Reinforcement Stitch” button
Use this button to sew a single stitch repeatedly and tie-off.
For character/decorative stitches, press this button to end with
a full stitch instead of at a mid-point. The LED light beside this
button lights up while the machine is sewing a full motif, and
automatically turns off when the sewing is stopped. (page 72)
In addition, use this button to sew reinforcement stitches
before cutting the thread when changing the bobbin thread in
embroidery mode. This will prevent stitches from unraveling.
d“Needle Position” button
Use this button when changing sewing direction or for detailed
sewing in small areas. Press this button to raise or lower the
needle position. With this button, you can lower and raise the
needle to sew a single stitch.
e“Thread Cutter” button
Press this button after sewing to automatically trim the excess
thread.
f“Presser Foot Lifter” button
Press this button to lower the presser foot and apply pressure
to the fabric. Press this button again to raise the presser foot.
gSewing Speed controller
Use this controller to adjust the sewing speed. Move the slide
to the left to sew at slower speeds. Move the slide to the right
to sew at higher speeds.
h“Automatic Threading” button
Use this button to automatically thread the needle.
Green: The machine is ready to sew or is sewing.
Red: The machine cannot sew.
a
b
c
d
ef g h

ACCESSORIES
Getting Ready
15
1
Included Accessories
After opening the box, check that the following
accessories are included. If any item is missing or
damaged, contact your authorized Baby Lock
retailer.
ACCESSORIES
Part Name
Part Code
1.
Zigzag foot “J” (on machine)
XF3022-001
2.
Advanced monogramming foot “N+”
FA17
3.
Overcasting foot “G”
XC3098-051
4.
Zipper foot “I”
X59370-051
5.
Buttonhole foot “A+”
XH2665-101
6.
Buttonhole foot stabilizer
XH1726-201
7.
Blind stitch foot “R”
X56409-051
8.
Button fitting foot “M”
130489-001
J
N+
G
I
A+
R
M
9.
Compact digital dual feed foot
BLSA-DDF
10. Regular sole for digital dual feed foot (on
compact digital dual feed foot)
XF4419-101
11.
Straight stitch foot
XD0826-051
12.
Free motion quilting foot “C”
XF4737-001
13. Free motion echo quilting foot “E”
* Attach the included adapter to use this
product.
XE0766-001
14.
Free motion open toe quilting foot “O”
XF4873-001
15.
Embroidery foot “W”
XF4012-101
16.
1/4" Quilting foot with guide
ESG-QGF
17.
Adapter
XF3613-001
Part Name
Part Code
C
E
E
O
O
W

ACCESSORIES
16
18.
Screw (small)
XA4813-051
19. Needle set
75/11 2 needles
90/14 2 needles
90/14 2 needles: Ball point needle (gold
colored)
XE4962-001
20. Twin needle
2/11 needle
XE4963-001
21. Ball point needle set
75/11 2 needles:
Ball point needle for embroidery
HAX130EBBR
XD0705-151
22.
Bobbin × 10 (One bobbin is on machine.)
X52800-150
23.
Seam ripper
XF4967-001
24.
Scissors
XF2052-001
25.
Cleaning brush
X59476-051
26.
Eyelet punch
XG7791-001
27.
Screwdriver (small)
X55468-051
Part Name
Part Code
28.
Screwdriver (large)
XC4237-021
29.
Multi-purpose screwdriver
BLMPD
30.
Spool cap (small)
130013-157
31. Spool cap (medium) × 2 (One spool cap is on
machine.)
X55260-156
32.
Spool cap (large)
130012-057
33.
Thread spool insert (mini king thread spool)
XA5752-121
34.
Spool stand
XH1607-001
35.
Spool cap (XL) × 2
XE0779-001
36.
Spool holder × 2
XA0679-050
37.
Spool cap base × 2
XE0780-001
Part Name
Part Code

ACCESSORIES
Getting Ready
17
1
38.
Spool felt × 2
XC7134-051
39.
Ring × 4
026030-136
40.
Spool felt (on machine)
X57045-051
41.
Spool net × 2
XA5523-050
42.
Embroidery needle plate cover
XE5131-001
43.
Knee lifter
XE4713-001
44.
Alternate bobbin case (no color on the screw)
XC8167-651
45. Standard bobbin case (green marking on the
screw) (on machine)
XE5342-101
46.
Straight stitch needle plate
XH2513-001
47.
Cord guide bobbin cover (with single hole)
XE5992-001
Part Name
Part Code
48.
Bobbin cover (with mark) (on machine)
XH3126-001
49.
Bobbin cover (on straight stitch needle plate)
XE8878-001
50. Embroidery frame H 100 mm × W 100 mm (H 4
inches × W 4 inches)
EF74
51. Embroidery frame H 180 mm × W 130 mm (H 7
inches × W 5 inches)
EF75
52. Embroidery frame H 272 mm × W 272 mm (H
10-5/8 inches × W 10-5/8 inches)
EF101
53. Embroidery frame H 408 mm × W 272 mm (H
16 inches × W 10-5/8 inches)
EF99
54.
Scanning frame
XF9321-001
55.
Magnet × 6
XF9325-001
56.
Embroidery bobbin thread
BBT-W
57.
Embroidery positioning sticker sheets × 2
XE4912-501
Part Name
Part Code

ACCESSORIES
18
Following documents can be downloaded.
• Instruction and Reference Guide (Sewing)
• Instruction and Reference Guide (Embroidery)
• Embroidery Design Guide
www.babylock.com/
58.
White calibration stickers (solid)
XE7916-001
59.
Stabilizer material
Contact your authorized Baby Lock retailer.
60.
Chalk pencil
XE8568-001
61.
Dual purpose stylus
XH2515-001
62.
Dual purpose stylus holder
XH1805-001
63.
Accessory case
D02CD0-001
64. Advanced multi-function foot controller
- Main foot controller
- Side pedal
-Mountingplate
-Mountingscrew×2
Contact your authorized Baby Lock retailer.
65.
Bobbin center pin and instruction sheet
XF5048-001
66.
Power cord
XC6052-151
67.
Couching sole for digital dual feed foot
XF9332-101
Part Name
Part Code
68.
Yarn guide for sewing couching
XG0786-101
69.
Embroidery couching foot “Y”
XH1815-101
70.
Yarn guide for embroidery couching
XH3803-001
71.
Yarn threader
XF7187-001
72. End point stickers
(4 sheets, 243 stickers per sheet)
D01HBC-001
73.
Fine tipped stylus pen
Contact your authorized Baby Lock retailer.
74.
Quick Reference Guide
D02A9V-001
75.
Product Safety Guide
D02A9X-001
Memo
• Always use accessories recommended for
this machine.
• The screw for the presser foot holder is
available through your authorized Baby Lock
retailer (Part code XA5904-051).
Part Name
Part Code
Y
