SONIQ CSA100K-AU User manual

Alarm clock radio
with bluetooth
CSA100K-AU

Congratulations on your purchase of this quality product.
Before installation, please read this manual carefully to avoid
electrical shock, personal injury, and damage to the product.
The technical specifications are subject to change without
notice.
Welcome

1. Product Features ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1
2. What’s included ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙1
3. Specification ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙2
4. LCD Display & Buttons ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙3
5. Operating Instruction ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6
5.1 Power ON ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6
5.2 Set Time ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6
5.3 Set Alarm Time ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙6
5.4 Alarm Function ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7
6. SLEEP Function under ON Mode ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7
7. Play Music from Mobile via Bluetooth ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7
7.1 Operation ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙7
7.2 Answer the Phone ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙8
7.3 Hang up ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙8
7.4 Play Music ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙8
8. FM Radio Operation ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙8
9. Play Music from Aux Jack ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙9
10. Back-up Button Battery ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙9
Contents
Operation Guide

1. Product Features
- Elegant and fashionable design
- Bluetooth speakerphone for conference calls
- 3.2 inch LCD display screen
- FM Digital radio
- 3.5mm Audio jack for connecting other audio sources
- Stereo speaker, providing superior quality sound
- USB Charging port for compatible device
- Dual Alarms
2. What’s included
CSA100K Unit 1 PC
Power Adaptor 1 PC
User Manual 1 PC
Audio Cable 1 PC
Remote Controller 1 PC
Cell Button 1 PC
Warrranty Card 1 PC
-1-
Operation Guide

3. Specification
- Bluetooth Version: V2.1+EDR
- Bluetooth Profiles: A2DP, AVRCP, HFP, HSP
- Receiver range: Up to 10 metres
- Power Adaptor: AC 100-240V 50/60Hz DC 5V 2.5A
- Output Power: 3W + 3W
- Driver Unit: 4Ω 3W 2 in
- Frequency Response: 60Hz~20KHz
- S/N Ratio: >65dB
- Distortion Rate: <1%
- FM Frequency Range: 87.5 ~ 108MHz
- USB Port: DC 5V 2.1A
- Product Net Weight: 0.69kg
- Product Size: 138*138*100mm
-2-
Operation Guide

4. LCD Display and Buttons
-3-
⑨USB Charging Port ⑩AUX IN Jack
Time Setting Adjusting Clock Time Down
Adjusting Clock Time Up FM Antenna
DC 5V
12
13
11
14
15
①② ③ ④⑤ ⑥ ⑦ ⑧
HOUR MINUTE
①AUX IN ②Bluetooth
③FM ④ Alarm 1
⑤Alarm 2 ⑥PM
⑦SLEEP ⑧SNOOZE
AUX IN TIME DC 5V
⑨ ⑩ 12 13 14 15 11
Operation Guide

-4-
Operation Guide
Function
Power ON/OFF
SNOOZE 90-80-70-60-50-40-30-20-10-00 Minute
Switch Modes; Alarm Time Confirmation
Time Setting of Alarm1
Time Setting of Alarm 2
Volume Down/ Adjusting Alarm Time Down
Skip Backwards to Previous Song
Bluetooth, Play/Pause, Answer the Phone and Hang up/Auto
Scan FM Station
Skip Forwards to next Song
Volume Up/ Adjusting Alarm Time Up
SNOOZE, Display Brightness Level (3Levels: 1-2-3)
Button

Function
Power on/off
Mode selection
Time setting
Sleep time setting
3 levels of LCD screen brightness can be
chosen
Fast backward to previous song; To
previous station under FM radio mode
Fast forward to next song; To next station
under FM radio mode
Play/Pause
Alarm 1 setting
Alarm 2 setting
Scan the station by hands; Long press to
auto-scan
Scan the station by hands; Long press to
auto-scan
Volume up/Adjusting clock time up/
Adjusting alarm time up
Volume down/Adjusting clock time down/
Adjusting alarm time down
Snooze
Auto-scan FM station
Mute
Button
-5-
Operation Guide
Remote Control

-6-
5. Operating Instruction
5.1 Power ON
Connect the power adaptor into the jack on the back of CSA100K
labeled “DC”, and then plug the power adaptor into the wall outlet.
The LCD display turns on. Press to turn on the unit.
5.2 Set Time
Under any mode, press “Time” to set time. Press “+” or “-” on the
backside of the unit to switch the Hour mode between 12-Hour and
24-Hour. Press “Time” to confirm it. Then Hour figure and MINUTE
figure begin to flash. Press “+” or “-” to adjust the HOUR and press
“Time” to confirm it, then press “+” or “-” to adjust the MINUTE and
press “Time” to confirm the setting. It exits the setting in 10seconds if
no operation on any key.
5.3 Set Alarm Time
Under any mode, press to enter alarm time setting, icon displays
in the LCD. Press some times to display OFF/BU. (OFF- non
alarm is selected). When BU icon appears, press “SET/MODE” to
enter alarm time setting. The HOUR figure begins to flash, then
press “+” or “-” on the top side of the unit to adjust the figure; Press
“SET/MODE”, the MINUTE figure begins to flash. Press “+” or “-” on
the unit to adjust the figure; then press "SET/MODE" to confirm.It will
exit the setting in 5 seconds if no operation on any key.
Operation Guide

-7-
5.4 Alarm Function
1) When alarm1 is on, icon is flashing in the LCD and the alarm
ring tone is becoming larger and larger. Press “SNOOZE” to activate
the Snooze function. SNOOZE icon appears in the LCD. Alarm will
be on again in 9-minute snooze. The alarm can last for 30minutes at
most if no button is pressed (including snooze time).
2) To stop alarm, press or . Alarm 1 is one-off alarm.
3) Setting Alarm is the same as setting Alarm . Alarm works
everyday. To turn it off completely, switch to OFF mode.
6. SLEEP Function under ON Mode
Press “SLEEP” to set timing shutdown time from 90-80-70…….OFF.
Choose the time, it will store it automatically in 3 seconds and exit
the setting. To see the remaining sleep time, press “SLEEP”.
7. Play Music from Mobile via Bluetooth
7.1 Operation
Press “MODE” to choose Bluetooth mode. Go to mobile settings,
turn on Bluetooth and search Bluetooth devices. Connect “CSA100K ”.
When it is successfully paired, you will hear a sound of “DU”. Play
Alarm Ring Source - BUZZ Alarm OFF
Operation Guide

-8-
music from your mobile now. (When Bluetooth is connected, press
“Mode” to switch it to other mode, Bluetooth will be OFF automatically
and get disconnected with mobile. When switching it to Bluetooth
mode again, connect “ CSA100K ” manually or automatically.)
7.2 Answer the Phone
When a phone call is coming, press to answer the phone.
7.3 Hang up
Press to hang up when having a phone call.
7.4 Play Music
When playing music, press to pause the music. Press to
skip backwards to previous song; Press to skip forwards to next
song.
8. FM Radio Operation
Switch the unit to FM mode, Press and Hold /SCAN to auto
scan radio station and store the scanned stations accordingly. The
frequency starts from 87.5MHz to 108MHz and skips at every 0.1
MHz in scanning process. Once catching a station, it stops a second
and store it, then continues the auto-scanning. When it scans from
87.5MHz to 108MHz or stores 20 stations, it will stop scan
automactically. Press or to select the station.
Operation Guide

-9-
9. Play Music from Aux Jack
Plug in the 3.5mm audio cable into the AUX IN jack, then press
"MODE" to switch the mode to AUX IN. Play music now.
10. Back-up Button Battery
The 3V button battery is to retain the alarm/clock setting in case of a
power failture. It can not display the alarm/clock time.
AUX IN TIME
DC 5V
