Sony 64 User manual

3-859-616-71 (1)
Video Camera
Recorder
Operating Instructions
Before operating the unit, please read this manual thoroughly,
and retain it for future reference.
©1997 by Sony Corporation
CCD-TRV64E

2
Welcome!
Congratulations on your purchase of this Sony HandycamVision™ camcorder. With your
Handycam Vision you can capture life’s precious moments with superior picture and sound
quality.
Your Handycam Vision is loaded with advanced features, but at the same time it is very easy to
use. You will soon be producing home video that you can enjoy for years to come.
WARNING
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
To avoid electrical shock, do not open the cabinet.
Refer servicing to qualified personnel only.

3
Table of contents
Before you begin
Using this manual ................................... 4
Checking supplied accessories.............. 5
Getting started
Charging and installing the battery
pack .................................................... 6
Inserting a cassette .................................. 9
Basic operations
Camera recording ................................. 10
Using the zoom feature ................. 13
Selecting the START/STOP mode
.................................................... 14
Shooting with the LCD screen...... 15
Letting the subject monitor the shot... 16
Hints for better shooting ...................... 17
Checking the recorded picture............ 19
Playing back a tape ............................... 20
Searching for the end of the picture ... 23
Advanced operations
Using alternative power sources ........ 24
Using the mains .............................. 24
Changing the mode settings................ 26
Fade-in and fade-out ............................ 30
Using the wide mode function............ 31
Enjoying picture effect ......................... 33
Focusing manually................................ 35
Using the PROGRAM AE function .... 37
Shooting with backlighting ................. 39
Adjusting the exposure ........................ 40
Releasing the STEADY SHOT function
........................................................... 41
Superimposing a title ........................... 42
Making your own titles ........................ 44
Recording with the date/time ............ 45
Optimizing the recording condition .. 46
Watching on a TV screen ..................... 47
Editing onto another tape .................... 48
Recording from a VCR or TV .............. 50
Additional information
Changing the lithium battery in the
camcorder ........................................ 51
Resetting the date and time ................. 53
Usable cassettes and playback modes
........................................................... 54
Tips for using the battery pack ........... 55
Maintenance information and
precautions ...................................... 58
Using your camcorder abroad ............ 63
Trouble check ........................................ 64
Self-diagnosis function .................. 68
Specifications ......................................... 69
Identifying the parts ............................. 70
Warning indicators ............................... 77
Index ....................................................... 78

4
As you read through this manual, buttons and settings on the camcorder are shown in
capital letters.
e.g. Set the POWER switch to CAMERA.
As indicated with ≥in the illustrations, you can hear the beep sound to confirm your
operation.
Note on TV colour systems
TV colour systems differ from country to country. To view your recordings on a TV,
you need a PAL system-based TV.
Precaution on copyright
Television programmes, films, video tapes, and other materials may be copyrighted.
Unauthorized recording of such materials may be contrary to the provision of the
copyright laws.
Precautions on camcorder care
•The LCD screen and/or the colour viewfinder are manufactured using high-
precision technology. However, there may be some tiny black points and/or
bright points (red, blue or green in colour) that constantly appear on the LCD
screen and/or in the viewfinder. These points are normal in the manufacturing
process and do not affect the recorded picture in any way. Over 99.99% are
operational for effective use.
• Do not let the camcorder get wet. Keep the camcorder away from rain and sea water.
Letting the camcorder get wet may cause the unit to malfunction, and sometimes this
malfunction cannot be repaired [a].
• Never leave the camcorder exposed to temperatures above 60°C (140°F ), such as in a
car parked in the sun or under direct sunlight [b].
[a] [b]
Before you begin
Using this manual
Contents of the recording cannot be compensated if recording or playback is not
made due to a malfunction of the camcorder, video tape, etc.

5
Checking supplied accessories
Check that the following accessories are supplied with your camcorder.
1Wireless Remote Commander (1)
(p. 74)
2AC-V316 AC power adaptor (1)
(p. 6,24)
3NP-F530 Battery pack (1) (p. 6,24)
4CR2025 Lithium Battery (1) (p. 51)
The lithium battery is already installed
in your camcorder.
Before you begin
134
567
2
5R6 (size AA) battery for Remote
Commander (2) (p. 74)
6A/V connecting cable (1) (p. 47,50)
7Shoulder strap (1) (p. 75)

6
Charging time
Battery pack NP-F530 (supplied) NP-F730 NP-F930
Charging time* (min.) 170 (110) 250 (190) 330 (270)
Before using your camcorder, you first need to charge and install the battery pack. To
charge the battery pack, use the supplied AC power adaptor.
This camcorder operates with the “InfoLITHIUM“ battery. If you use any other battery
to operate your camcorder, the camcorder may not operate or the battery life may be
shortened.
“InfoLITHIUM“ is a trademark of Sony Corporation.
Charging the battery pack
Charge the battery pack on a flat surface without vibration.
(1)Connect the mains lead to mains.
(2)Align the surface of the battery pack indicated by the zmark with the edge of
the terminal shutter of the AC power adaptor. Then fit and slide the battery
pack in the direction of the arrow. The CHARGE lamp (orange) lights up.
Charging begins.
When the CHARGE lamp goes out, normal charge is completed. For full charge, which
allows you to use the battery longer than usual, leave the battery pack in place for
approximately one hour. Unplug the unit from the mains, then remove the battery pack
and install it into the camcorder. You can also use the battery pack before it is
completely charged.
Getting started
Charging and installing the battery pack
12
The time required for a normal charge is indicated in parentheses.
* Approximate minutes to charge an empty battery pack using the supplied AC power
adaptor. (Lower temperatures require a longer charging time.)

7
Getting started
NP-F530 (supplied)
150 (135)
110 (100)
85 (75)
60 (55)
110 (100)
NP-F730
305 (275)
255 (230)
175 (155)
145 (130)
255 (230)
Battery pack
Continuous recording time*
Typical recording time**
Playing time on LCD
Battery life
Upper numbers are the time when recording with the viewfinder. Lower numbers are
the time when recording with the LCD screen. Using both will further reduce recording
time.
Charging and installing the battery pack
Numbers in parentheses indicate the time when you use a normally charged battery.
Battery life will be shorter if you use the camcorder in a cold environment.
* Approximate continuous recording time indoors.
** Approximate minutes when recording while you repeat recording start/stop,
zooming and turning the power on/off. The actual battery life may be shorter.
Notes on remaining battery time indication during recording
• Remaining battery time is displayed in the viewfinder or on the LCD screen.
However, the indication may not be displayed properly, depending on using
conditions and circumstances.
• When you close the LCD panel and open it again, it takes about 1 minute for the
correct remaining time to be displayed.
To remove the battery pack
Slide the battery pack in the direction of the arrow.
Notes on charging the battery pack
• The CHARGE lamp will remain lit for a while even if the battery pack is removed
and the mains lead is unplugged after charging the battery pack. This is normal.
• If the CHARGE lamp does not light, disconnect the mains lead. After about one
minute, reconnect the mains lead again.
• You cannot operate the camcorder using the AC power adaptor while charging the
battery pack.
• When a fully charged battery pack is installed, the CHARGE lamp will light once,
then go out.
NP-F930
480 (435)
400 (360)
275 (250)
230 (205)
400 (360)

8
BATT RELEASE
(PUSH)
Charging and installing the battery pack
Installing the battery pack
Align the grooves of the battery pack with the receptacles of the camcorder and slide
the battery pack down until it catches on the battery release lever and clicks.
Attach the battery pack to the camcorder securely.
Note on installing the NP-F930 battery pack
Use the camcorder while lifting up the viewfinder slightly.
Note on the battery pack
Do not carry the camcorder by grasping the battery pack.
To remove the battery pack
While pressing BATT RELEASE (PUSH), slide the battery pack in the direction of the
arrow.
You can look at the demonstration of the functions available with this camcorder (p. 28).

9
Getting started
EJECT
Inserting a cassette
Make sure that the power source is installed. When you want to record in the Hi8
system, use Hi8 video cassette H.
(1)While pressing the small blue button on the EJECT switch, slide it in the
direction of the arrow. The cassette compartment automatically lifts up and
opens.
(2)Insert a cassette with the window facing out.
(3)Close the cassette compartment by pressing the “PUSH” mark on the cassette
compartment. The cassette compartment automatically goes down.
1 2 3
To eject the cassette
While pressing the small blue button on the EJECT switch, slide it in the direction of the
arrow.
To prevent accidental erasure
Slide the tab on the cassette to expose the red mark. If you insert the cassette with the
red mark exposed and close the cassette compartment, the beeps sound for a while. If
you try to record with the red mark exposed, the and 6indicators flash, and you
cannot record.
To re-record on this tape, slide the tab back out covering the red mark.
PUSH

10
2
3
1
CAMERA
POWER
OFF
VTR
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
HSTBY
0:00:00
40 min.
40 min.
AUTO DATE
REC
0:00:01
SP
Basic operations
Camera recording
Make sure that the power source is installed and a cassette is inserted and that the
START/STOP MODE switch inside the LCD panel is set to . Before you record one-
time events, you may want to make a trial recording to make sure that the camcorder is
working correctly.
When you use the camcorder for the first time, power on it and reset the date and time
to your time before you start recording (p. 53).
The date is automatically recorded for 10 seconds after you start recording (AUTO
DATE feature).
(1)While pressing the small green button on the POWER switch, set it to
CAMERA.
(2)Turn STANDBY up to STANDBY.
(3)Press START/STOP. The camcorder starts recording. The “REC” indicator
appears and the red lamp lights up in the viewfinder. The camera recording/
battery lamp located on the front of the camcorder also lights up.
You can also select Recording mode, SP (standard mode) or LP (long play) mode.
Set REC MODE in the menu system according to the length of your planned recording
before you start.

11
Basic operations
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
To stop recording momentarily [a]
Press START/STOP again. The “STBY” indicator appears in the viewfinder (Standby
mode).
To finish recording [b]
Press START/STOP again. Turn STANDBY down to LOCK and set the POWER switch
to OFF. Then, eject the cassette and remove the battery pack.
To focus the viewfinder lens
If you cannot see the indicators in the viewfinder clearly, or after someone else has used
the camcorder, focus the viewfinder lens. Turn the viewfinder lens adjustment ring so
that the indicators in the viewfinder come into sharp focus.
Camera recording
[a] [b]
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
STBY
0:35:20
Note on Standby mode
If you leave the camcorder in Standby mode for 5 minutes while the cassette is inserted,
the camcorder turns off automatically. This prevents wearing down the battery and
wearing out the tape. To resume Standby mode, turn STANDBY down and up again.
To start recording, press START/STOP.

12
Camera recording
Notes on recording mode
• This camcorder records and plays back in SP (standard play) mode and in LP (long
play) mode. The playback quality in LP mode, however, will not be as good as that in
SP mode.
• When a tape recorded on this camcorder in LP mode is played back on other types of
8mm camcorders or VCRs, the playback quality may not be as good as that on this
camcorder.
Note on recording
When you record from the beginning of a tape, run the tape for about 15 seconds before
starting the actual recording. This will ensure that you won’t miss any start-up scenes
when you play back the tape.
Notes on the tape counter
• The tape counter indicates the recording or playback time. Use it as a guide. There
will be a time lag of several seconds from the actual time. To set the counter to zero,
press COUNTER RESET.
• If the tape is recorded in SP and LP modes mixed, the tape counter shows incorrect
recording time. When you intend to edit the tape using the tape counter as a guide,
record in same (SP or LP) mode.
Note on the beep sound
As indicated with ≥in the illustration, a beep sounds when you turn the power on or
when you start recording, and two beeps sound when you stop recording, confirming
the operation. Several beeps also sound as a warning of any unusual condition of the
camcorder.
Note that the beep sound is not recorded on the tape. If you do not want to hear the
beep sound, select “OFF” in the menu system.
Note on the AUTO DATE feature
The clock is set at the factory to Sydney time for Australia and New Zealand models, to
Tokyo time for the models sold in Japan, and to Hong Kong time for other models. You
can reset the clock in the menu system. You can change the AUTO DATE settings by
selecting ON or OFF in the menu system. The AUTO DATE feature shows the date
automatically once a day.
However, the date may automatically appear more than once a day when:
– you reset the date and time.
– you eject and insert the tape again.
– you stop recording within 10 seconds.
– you set AUTO DATE to OFF once and set it to ON again in the menu system.
When moving from indoors to outdoors (or vice versa)
Turn STANDBY up and point the camcorder at a white object for about 15 seconds so
that the white balance is properly adjusted.

13
Basic operations
WT
T
WT W
Using the zoom feature
Zooming is a recording technique that lets you change the size of the subject in the
scene.
For more professional-looking recordings, use the zoom function sparingly.
“T” side: for telephoto (subject appears closer)
“W” side:for wide-angle (subject appears farther away)
Camera recording
Zooming speed (Variable speed zooming)
Move the power zoom lever a little for a slower zoom, move it further for a faster zoom.
When you shoot a subject using a telephoto zoom
If you cannot get a sharp focus while in extreme telephoto zoom, move the power zoom
lever to the “W” side until the focus is sharp. You can shoot a subject that is at least
about 80 cm (about 2 5/8 feet) away from the lens surface in the telephoto position, or
about 1 cm (about 1/2 inch) away in the wide-angle position.
Notes on digital zoom
• More than 15x zoom is performed digitally, and the picture quality deteriorates as
you go toward the “T” side. If you do not want to use the digital zoom, set the D
ZOOM function to OFF in the menu system.
• The right side [a]of the power zoom indicator shows the digital zooming zone, and
the left side [b]shows the optical zooming zone. If you set the D ZOOM function to
OFF, the [a]zone disappears.
T
W
T
W
[a][b]

14
Camera recording
To extend the recording time in 5SEC mode
Press START/STOP again before all the dots disappear. Recording continues for about
5 seconds from the moment you press START/STOP.
Notes on START/STOP mode
• If you have turned off the indicators on the LCD screen, the dots do not appear.
• You cannot use FADER in 5SEC or mode.
2
1
3
STBY
0:00:00 REC
• • • • •
REC
•
5SEC
START/STOP
MODE
ANTI GROUND
SHOOTING
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
Selecting the START/STOP mode
Your camcorder has two modes besides normal start/stop mode. These modes enable
you to take a series of quick shots resulting in a lively video.
(1)While pressing OPEN, open the LCD panel.
(2)Set START/STOP MODE to the desired mode.
: Recording starts when you press START/STOP, and stops when you
press it again (normal mode).
ANTI GROUND SHOOTING : The camcorder records only while you
press down START/STOP so that you can avoid recording unnecessary scenes.
5SEC: When you press START/STOP, the camcorder records for 5 seconds and
then stops automatically.
(3)Turn STANDBY up to STANDBY and press START/STOP. Recording starts.
If you selected 5SEC, the remaining tape indicator disappears and five dots appear. The
dots disappear at a rate of one per second as illustrated below.

15
Basic operations
21
12
Backlighting the LCD screen
If the LCD screen is insufficiently illuminated even after adjusting LCD BRIGHT, select
LCD B. L. in the menu system and set to BRIGHT. You can select LCD B. L. only while
using the battery pack as a power source.
Notes on the LCD panel
• When closing the LCD panel, turn it vertically until it clicks [a].
• When turning the LCD panel, turn it always vertically; otherwise, the camcorder
body may be damaged or the LCD panel may not close properly [b].
• Close the LCD panel completely when not in use.
Shooting with the LCD screen
You can also record the picture while looking at the LCD screen.
When using the LCD screen, the viewfinder turns off automatically. You cannot
monitor the sound from the speaker during recording.
(1)While pressing OPEN, open the LCD panel.
(2)Adjust the angle of the LCD panel.
The LCD panel moves about 90 degrees to this side and about 210 degrees to
the other side.
To adjust the brightness of the LCD screen, press LCD BRIGHT.
+ side: to brighten the LCD screen
– side: to dim the LCD screen
The battery life is longer when the LCD panel is closed. Use the viewfinder instead of
the LCD screen to save the battery power.
Camera recording
210°
90°
90°
LCD
BRIGHT
[a] [b]
1
2

16
Letting the subject monitor the shot
You can turn the LCD panel over so that it faces the other way and you can let the
subject monitor the shot while shooting with the viewfinder.
Turn the LCD panel vertically first until it clicks, then turn it over. The indicator
appears on the LCD screen (Mirror mode) and the date and remaining tape indicators
disappear.
To Cancel Mirror Mode
Turn the LCD panel back toward the viewfinder.
Notes on mirror mode
• When you turn the LCD panel about 135 degrees to 210 degrees, the camcorder
enters mirror mode.
• Using the mirror mode, you can record yourself while watching yourself on the LCD
[a].
• The picture on the LCD looks as a mirror-image while recording in mirror mode [b].
The STBY indicator appears as rP and REC as r. The other indicators may not
appear in mirror mode.
• While recording in mirror mode, you cannot operate the following buttons: TITLE,
DATE, TIME and MENU.
• The date appears in reverse when the AUTO DATE feature is turned on. When
recorded it will be normal.
1
2
[a] [b]

17
Basic operations
Hints for better shooting
2
1
3
• Place your right elbow against your side.
• Place your left hand under the camcorder to support it. Be sure to not touch the
built-in microphone.
• Place your eye firmly against the viewfinder eyecup.
• Use the viewfinder frame as a guide to determine the horizontal plane.
• You can also record in a low position to get an interesting angle. Lift the viewfinder
up for recording from a low position [a].
• You can also record in a low position or even in a high position using the LCD panel
[b].
• When you use the LCD screen outdoors in direct sunlight, the LCD screen may be
difficult to see. If this happens, we recommend that you use the viewfinder.
For hand-held shots, you’ll get better results by holding the camcorder according to the
following suggestions:
• Hold the camcorder firmly and secure it with the grip strap so that you can easily
manipulate the controls with your thumb.
[a] [b]
Place the camcorder on a flat surface or use a tripod
Try placing the camcorder on a table top or any other flat surface of suitable height. If
you have a tripod for a still camera, you can also use it with the camcorder.
When attaching a non-Sony tripod, make sure that the length of the tripod screw is less
than 6.5 mm (9/32 inch). Otherwise, you cannot attach the tripod securely and the
screw may damage the camcorder.

18
Cautions on the viewfinder and the LCD
• Do not pick up the camcorder by the viewfinder or by the LCD panel [c].
• Do not place the camcorder so as to point the viewfinder or the LCD screen toward
the sun. The inside of the viewfinder may be damaged. Be careful when placing the
camcorder under sunlight or by a window [d].
Hints for better shooting
[c] [d]

19
Basic operations
EDITSEARCH
2
CAMERA
POWER
OFF
VTR
START/STOP
L
O
C
K
S
T
A
N
D
B
Y
EDITSEARCH
1
EDITSEARCH
3
Checking the recorded picture
Using EDITSEARCH, you can review the last recorded scene or check the recorded
picture in the viewfinder or on the LCD screen.
(1)While pressing the small green button on the POWER switch, set it to
CAMERA.
(2)Turn STANDBY up to STANDBY.
(3)Press the – (Œ) side of EDITSEARCH momentarily; the last few seconds of the
recorded portion play back (Rec Review).
You can monitor the sound from the speaker or headphones.
Hold down the – side of EDITSEARCH until the camcorder goes back to the
scene you want. The last recorded portion is played back. To go forward, hold
down the + side (Edit Search).
To stop playback
Release EDITSEARCH.
To go back to the last recorded point after edit search
Press END SEARCH. The last recorded point is played back for about 5 seconds (10
seconds in LP mode) and stops. Note that this function does not work once you eject the
cassette after you recorded on the tape.
To begin re-recording
Press START/STOP. Re-recording begins from the point you released EDITSEARCH.
Provided you do not eject the cassette, the transition between the last scene you recorded
and the next scene you record will be smooth.

20
12
3
4
5
CAMERA
POWER
OFF
VTR
VOLUME
STOP REW FF PAUSE RECPLAY
Playing back a tape
You can monitor the playback picture on the LCD screen.
(1)While pressing the small green button on the POWER switch, set it to VTR.
The video control buttons light up.
(2)Insert the recorded tape with the window facing out.
(3)While pressing OPEN, open the LCD panel. Adjust the angle of the LCD panel
or the brightness of the LCD screen if necessary.
(4)Press ·to start playback.
(5)Adjust the volume using VOLUME.
You can also monitor the picture on a TV screen, after connecting the camcorder to a TV
or VCR.
To stop playback, press π.
To rewind the tape, press 0.
To fast-forward the tape rapidly, press ).
