Canon XF400 User manual

4K Camcorder
Instruction Manual
NTSC
PUB. DIE-0516-000A
Firmware ver. 1.0.1.0

161
Specifications
Specifications
XF405 / XF400
Camcorder
— Values given are approximate figures.
System
•RecordingSystem
MP4 clips:
Video format: MPEG-4 AVC/H.264
Audio format: MPEG-4 AAC-LC, 16 bit, 48 kHz, 2 channels
Linear PCM, 16 bit, 48 kHz, 4 channels
File format: MP4
XF-AVC clips:
Video compression: MPEG-4 AVC/H.264
Audio compression: Linear PCM, 24 bit, 48 kHz, 4 channels
File format: MXF (XF-AVC)
Photos:
DCF (Design rule for Camera File system), compatible with Exif Ver. 2.31, JPEG compression
1This camcorder supports Exif 2.3 (also called “Exif Print”). Exif Print is a standard for enhancing the communication between
camcorders and printers. By connecting to an Exif Print-compliant printer, the camcorder’s image data at the time of shooting
is used and optimized, yielding extremely high quality prints.
• Video Configuration (recording/playback)
MP4 clips:
Bit rate: 150 Mbps, 35 Mbps, 17 Mbps, 8 Mbps, 4 Mbps
Resolution: 3840x2160, 1920x1080, 1280x720
Color sampling: 4:2:0, 8 bit
Frame rate: 59.94P, 29.97P, 23.98P
XF-AVC clips:
Bit rate: 160 Mbps, 45 Mbps
Resolution: 3840x2160, 1920x1080
Color sampling: 4:2:0, 8 bit
Frame rate: 59.94P, 59.94i, 29.97P, 23.98P
• Recording Media (not included)
For approximate recording times, refer to the Reference Tables (A164)
SD, SDHC (SD High Capacity) or SDXC (SD eXtended Capacity) card (2 slots)
•ImageSensor
1.0-inch single-plate CMOS sensor
Effective pixels: 8,290,000 pixels(3840x2160)
•LCDTouchScreen
3.5 in. color LCD, 16:9 aspect ratio, 1,560,000 dots, 100% coverage, capacitive touch screen operation
• Viewfinder: 0.24 in., equivalent to 1,560,000 dots, 100% coverage
•Microphone:Stereo electret condenser microphone
•Lens
f=8.3 – 124.5 mm, F/2.8 – 4.5, 15x optical zoom, 9-blade iris diaphragm
35mm equivalent focal length: 28.3 - 424.6 mm(using Dynamic IS)
25.5 - 382.5 mm(using other IS modes)
•LensConfiguration
18 elements in 14 groups (2 aspheric elements)

Specifications
162
• Filter Diameter: 58 mm
• Focus
Manual focus, AF-boosted MF, continuous AF
AF type: Dual Pixel CMOS AF, contrast-detection AF
Minimum focusing distance: 60 cm (2 ft.); 1 cm (0.39 in.) at full wide angle
• White Balance
Automatic white balance (AWB); 2 preset settings (daylight, tungsten lamp); color temperature setting; custom
white balance (2 sets)
• Minimum Illumination
0.1 lx (shooting mode [NLow Light], shutter speed 1/2)
1.7 lx (59.94P, shooting mode [’Programmed AE], auto slow shutter [On], shutter speed 1/30)
•ImageStabilization
Optical-shift image stabilizer + digital compensation (Standard IS, Dynamic IS, Powered IS)
•Size of Photos:3840x2160, 1920x1080, 1280x720
Wi-Fi
•Wireless Standard: IEEE802.11b/g/n (2.4 GHz band), IEEE802.11a/n (5 GHz band)
• Connection Methods
Infrastructure (Wi-Fi Protected Setup (WPS), search for access points, manual), Camera Access Point
• Authentication Methods: Open, shared key, WPA-PSK, WPA2-PSK
• Encryption Methods: WEP-64, WEP-128, TKIP, AES
• Available Wi-Fi Channels
2.4 GHz band: CH1 to CH11
5 GHz band: CH56 to CH64 (Infrastructure only), CH149 to CH161 (Infrastructure/Camera Access Point)
Terminals
•mSDI OUT Terminal
BNC jack, output only, 0.8 Vp-p / 75 Ω, unbalanced
3G-SDI: SMPTE 424, SMPTE 425, SMPTE ST 299-2
HD-SDI: SMPTE 292, SMPTE ST 299-1
Embedded audio, time code (VITC/LTC)
• HDMI OUT Terminal: HDMI mini connector, output only
•USB Terminal: mini-B receptacle, Hi-Speed USB, output only
•MICTerminal
∅3.5 mm stereo mini-jack (unbalanced)
–65 dBV (auto volume, full scale –12 dB) / 5 kΩor more
Microphone attenuator: 20 dB
• INPUT Terminals(on the handle unit)
XLR jack (pin1: shield, pin2: hot, pin3: cold), 2 sets (balanced)
Sensitivity:
For microphone input: –60 dBu (manual volume center, full scale –18 dB) / 600 Ω
For line input: 4 dBu (manual volume center, full scale –18 dB) / 10 kΩ
Microphone attenuator: 20 dB
•×(headphone) Terminal
∅3.5 mm stereo mini-jack (unbalanced)
–29 dBV (16 Ωload, Max volume) / 100 Ω

163
Specifications
• REMOTE Terminal: ∅2.5 mm stereo sub-mini jack, input only
• (Ethernet) Terminal: Ethernet, 1000BASE-T compatible
Power/Others
•PowerSupply (rated)
7.4 V DC (battery pack), 8.4 V DC (AC adapter)
•PowerConsumption
Recording video configuration: 3840x2160, 150 Mbps(MP4 clips)/160 Mbps(XF-AVC clips), 59.94P,
autofocusactivated, screen backlight [Normal]
Using only the LCD screen: m9.0 W, n8.8 W
Using only the viewfinder: m8.4 W, n8.2 W
• Operating Temperature: 0 – 40 °C (32 – 104 °F)
•Dimensions[W x H x D] (excluding the grip belt)
Camcorder only: 135 x 97 x 214 mm (5.3 x 3.8 x 8.4 in.)
Camcorder with the lens hood attached: 150 x 97 x 267 mm (5.9 x 3.8 x 10.5 in.)
Camcorder with the lens hood and handle unit attached: 150 x 216 x 267 mm (5.9 x 8.5 x 10.5 in.)
•Weight

Camcorder body only (including the grip belt): m1,150 g (2.5 lb.), n1,145 g (2.5 lb.)
Typical recording configuration*: m1,670 g (3.7 lb.), n1,665 g (3.7 lb.)
* Camcorder with lens hood, handle unit and microphone holder, BP-828 battery pack and one SD card.
CA-946 AC Adapter
•RatedInput:100 – 240 V AC, 50/60 Hz
•RatedOutput:65 VA (100 V AC) - 85 VA (240 V AC)
• Operating Temperature: 0 – 40 °C (32 – 104 °F)
•Dimensions: 73 x 40 x 139 mm (2.9 x 1.6 x 5.5 in.)
•Weight
: 465 g (1.0 lb.)
BP-828 Battery Pack
• Battery Type
Rechargeable lithium ion battery, compatible with Intelligent System
• Nominal Voltage: 7.4 V DC
• Nominal Capacity: 2,670 mAh
• Rated Capacity (minimum): 19 Wh / 2,550 mAh
• Operating Temperature: 0 – 40 °C (32 – 104 °F)
•Dimensions: 30.7 x 55.7 x 40.2 mm (1.2 x 2.2 x 1.6 in.)
•Weight
: 121 g (4.3 oz.)
Weight and dimensions are approximate. Errors and omissions excepted.

Reference Tables
164
Reference Tables
Charging Times
Charging times are approximate and vary according to charging conditions and initial charge of the battery pack.
Approximate Recording Time on an SD Card
Approximate times, for reference only, based on a single recording that continues until the card is full.
Battery pack→
BP-820 BP-828
Charging conditions↓
Using the camcorder and supplied CA-946 AC adpater 230 min. 350 min.
Using the CG-800 Battery Charger 190 min. 260 min.
Resolution
SD card capacity
8 GB 16 GB 32 GB 64 GB 128 GB
MP4 clips
3840x2160 (150 Mbps) 5 min. 10 min. 25 min. 55 min. 1 h. 50 min.
1920x1080 (35 Mbps) 25 min. 55 min. 1 h. 55 min. 4 h. 8 h. 5 min.
1920x1080 (17 Mbps) 55 min. 2 h. 4 h. 5 min. 8 h. 15 min. 16 h. 35 min.
1280x720 (8 Mbps) 2 h. 4 h. 15 min. 8 h. 40 min. 17 h. 35 min. 35 h. 20 min.
1280x720 (4 Mbps) 4 h. 5 min. 8 h. 35 min. 17 h. 25 min. 35 h. 15 min. 70 h. 45 min.
XF-AVC clips
3840x2160 (160 Mbps) 5 min. 10 min. 25 min. 50 min. 1 h. 45 min.
1920x1080 (45 Mbps) 20 min. 45 min. 1 h. 30 min. 3 h. 5 min. 6 h. 15 min.

165
Reference Tables
Approximate Recording Times with a Fully Charged Battery Pack
The usage times in the following tables are approximate and were measured under the following conditions.
Actual times may vary.
- Only the LCD screen was used.
- “Typical recording” times measure recording times with repeated operations such as start/stop recording,
zooming and turning on/off the camcorder.
The effective usage time of the battery pack may decrease when using a bright screen setting, when recording in
cold surroundings, etc.
m
Video configuration Usage conditions Battery pack
Resolution (bit rate) Frame rate BP-820 (optional) BP-828 (supplied)
MP4 clips
3840x2160 (150 Mbps)
59.94P
Recording (maximum) 75 min. 115 min.
Recording (typical) 35 min. 60 min.
Playback 105 min. 165 min.
29.97P
Recording (maximum) 90 min. 140 min.
Recording (typical) 45 min. 70 min.
Playback 125 min. 190 min.
1920x1080 (35 Mbps)
59.94P
Recording (maximum) 85 min. 130 min.
Recording (typical) 40 min. 65 min.
Playback 130 min. 200 min.
29.97P
Recording (maximum) 100 min. 155 min.
Recording (typical) 50 min. 75 min.
Playback 135 min. 210 min.
1280x720 (8 Mbps)59.94P
Recording (maximum) 90 min. 135 min.
Recording (typical) 40 min. 65 min.
Playback 135 min. 210 min.
1280x720 (4 Mbps)29.97P
Recording (maximum) 105 min. 165 min.
Recording (typical) 50 min. 80 min.
Playback 140 min. 215 min.
XF-AVC clips
3840x2160 (160 Mbps)
59.94P
Recording (maximum) 75 min. 115 min.
Recording (typical) 35 min. 60 min.
Playback 105 min. 165 min.
29.97P
Recording (maximum) 90 min. 140 min.
Recording (typical) 45 min. 70 min.
Playback 125 min. 190 min.
1920x1080 (45 Mbps)
59.94P
Recording (maximum) 85 min. 130 min.
Recording (typical) 40 min. 65 min.
Playback 130 min. 200 min.
29.97P
Recording (maximum) 100 min. 155 min.
Recording (typical) 50 min. 75 min.
Playback 135 min. 210 min.

Reference Tables
166
n
Video configuration Usage conditions Battery pack
Resolution (bit rate) Frame rate BP-820 (optional) BP-828 (supplied)
MP4 clips
3840x2160 (150 Mbps)
59.94P
Recording (maximum) 75 min. 120 min.
Recording (typical) 35 min. 60 min.
Playback 110 min. 165 min.
29.97P
Recording (maximum) 95 min. 145 min.
Recording (typical) 45 min. 70 min.
Playback 125 min. 195 min.
1920x1080 (35 Mbps)
59.94P
Recording (maximum) 85 min. 135 min.
Recording (typical) 40 min. 65 min.
Playback 135 min. 205 min.
29.97P
Recording (maximum) 105 min. 160 min.
Recording (typical) 50 min. 75 min.
Playback 140 min. 215 min.
1280x720 (8 Mbps)59.94P
Recording (maximum) 90 min. 140 min.
Recording (typical) 45 min. 70 min.
Playback 140 min. 215 min.
1280x720 (4 Mbps)29.97P
Recording (maximum) 105 min. 165 min.
Recording (typical) 50 min. 80 min.
Playback 145 min. 220 min.
XF-AVC clips
3840x2160 (160 Mbps)
59.94P
Recording (maximum) 75 min. 120 min.
Recording (typical) 35 min. 60 min.
Playback 110 min. 165 min.
29.97P
Recording (maximum) 95 min. 145 min.
Recording (typical) 45 min. 70 min.
Playback 125 min. 195 min.
1920x1080 (45 Mbps)
59.94P
Recording (maximum) 85 min. 135 min.
Recording (typical) 40 min. 65 min.
Playback 135 min. 205 min.
29.97P
Recording (maximum) 105 min. 160 min.
Recording (typical) 50 min. 75 min.
Playback 140 min. 215 min.
