Sony Hyper HAD SSC-MX34 User manual

SONY
Black and White
Video Camera
Operating Instructions
Before operating the unit, please read these instructions
thoroughly and retain them for future reference.
Mode d’empioi
Avant de faire fonctionner cet appareil, lisez attentivement le
present mode d’empioi et conservez-le pour toute reference
ulterieure.
Manual de instrucciones
Antes de utilizar la unidad, lea las instrucciones con atencion y
conservelas para su consulta en el futuro.
Hyper H AD.
SSC-MX34
Sony Corporation © 1 998 Printed in Japan

-Kv'K- i '.’V v’.S
Cautions for installing the camera
If installing the camera on the ceiling, be sure it is secure. If not
securely installed, the camera may fall and injury may occur.
If the camera is installed on the ceiling using equipment such as a
bracket, housing and motored swivel base (pan/tilt), do the following:
• Use tripod screws and securely tighten them with a driver. Order the
tripod screws (Sony Part No. 3-174-693-01) from your nearest Sony
dealer.
• Install the tripod adapter on a flat surface.
Connections
Connect the camera to a power outlet, only after all connections have
been completed.
Using an internal synchronization
(D Set the SYNC switch to INT (internal synchronization).
(D 75-ohm coaxial cable
(D Connect with VIDEO IN connector on a video monitor, etc.
© to power supply (AC 24 V)
© Power cord
When using the LINE LOCK mode, set the SYNC switch © to L.L (line
lock) and make connections as above.
When zoom, focus and the iris are controlled externally
© To lens control terminal
© Custom cable supplied with camera
© To external control device

Cautions
• When controlling the iris externally, set the auto iris ON/OFF switch
<D to “OFF”. Iris control using this connector will not work if the auto
iris is ON.
• If you control the lens using external control device, the shortest
subject distance is fixed at 800 mm regardless of the zoom position.
© VIDEO OUT connector (BNC)
© Ground terminal
© AC 24 V input terminals
© 12V/6V switch
When using the lens control connector © to control the focus, zoom,
and iris from an external source, set this switch to match the input
voltage (±12 V or ± 6 V).
© NORM/REV switch
Use this switch whether the external input voltage is + or to change
the direction of the focus, zoom and iris movement. Use the following
table for reference.
—__Function
Zoom
Focus
Iris
\Voltage
Switch \
position \
+
—
+
— +
—
NORM Wide
Tele
Far
Near
Close
Open
REV
Tele
Wide
Near
Far
Open
Close

Phase Adjustment
When using more than one camera, connect to a camera switcher and
set the vertical phase range as follows:
© Camera switcher
© Monitor
© Vertical phase
© Adjustable range
The picture may roll vertically if the vertical phase is not set. To adjust
the vertical phase, turn the V PHASE screw at the back of the camera.

---
To control the lens (focus, zoom, and iris) externally, connect the cable
supplied with the camera to this connector.
The pin numbers of this connector, the color-coding of the cable, and
the corresponding input/output signals are as shown in the below table.
Identify the colored conductors of the cable prior to connecting them to
each of the external control device terminals. (Refer to Illustration
for pin positions.)
Pin No.
Cable colors
—
In/output signal
1
Red
Preset voltage input (+)
2
White
Preset voltage input (-)
3
Black
Zoom position voltage output*
4
Yellow GND
5 Blue
Focus position voltage output*
6 Green
Focus control voltage input
7
Brown
Zoom control voltage input
8
Gray
Iris control voltage input
* When the zoom position is moved to the “W (wide-angle)” side, the
positional output voltage increases; when it is moved to the “T
(telephoto)” side, the voltage decreases.
When the focus position is moved to the “F (far)” side, the positional
output voltage increases; when it is moved to the “N (near)” side, the
voltage decreases.

Specifications
Image device
Effective pixels
Signal system
Signal process
Synchronization system
Horizontal resolution
Built-in lens
Angle of view
Shortest subject distance
Focus
Lens control
Control voltage polarity
Minimum illumination
Video output
Video S/N
Automatic gain control (AGC)
Iris
BLC
Aperture
Power requirements
Power consumption
Operating temperature
Operating humidity
Storage temperature
Storage humidity
Shock resistance
Mass
Dimensions
Supplied Accessories
1/3" interline transfer type CCD
768 (H) x 494 (V)
EIA standard
Digital signal processor
Internal/line-lock
570 TV lines
x12 zoom lens
f = 5.4 mm to 64.8 mm, FI .8 to F2.7
H: 48.8 degrees (wide end) to 4.3 degrees
(tele end)
V: 37.6 degrees (wide end) to 3.3 degrees
(tele end)
10 mm (wide end), 800 mm (tele end)
Manual (One-push AF available)
DC voltage control: ± 6 V /± 12 V
(switchable)
Preset voltage input: 5 Vp-p to 12 Vp-p
(Zoom/focus preset function by the external
control device)
Normal/Reverse (switchable)
0.4 lux (FI . 8 , 50 IRE, AGC: ON, TURBO:
ON)
1 Vp-p, 75 Q, Sync.: Negative
50 dB (Weight ON)
Switchable: ON (TURBO)/ON (NORM)/OFF
Auto/manual
Switchable: ON (FULL)/ON (SPOT)/OFF
Switchable: NORM/SHARP
24 VAC
5.1 W
-10°C to +50°C (14°F to 122°F)
20% to 80%
-40°C to +60°C (-40°F to +140°F)
20% to 95%
70 G
Approx. 520 g (1 lb 2 oz)
60 x 60 x 129.5 mm
(2 3 / 8 x 2 3 / 8 x 5 V 8 inches) (w/h/d)
(Excluding protruding parts)
Tripod adaptor (1)
Custom cable (1)
Operating Instruction (1)
Design and specifications are subject to change without notice.
