Sony PlayStation 5 User manual

CFI-2018
PlayStation®5
Quick Start Guide
快速參考指南 •快捷参考指南 •빠른 시작 가이드

2
2 Connect the HDMI cable and the AC power
cord.
Use the included cables.
Make all connections before plugging the AC power cord
into an electrical outlet.
The following illustrations all show the console with the disc
drive installed.
HDMI IN port HDMI OUT port
HDMI™ cable
To an electrical outlet
AC IN connector
AC power cord
Rear view
Let’s get started
1 Insert the horizontal stand feet into the hole
in the grooves of the PlayStation®5 console.
Always attach the feet to your PS5® console before use.
Place your console on a soft cloth spread over a flat
surface before attaching the feet.
Console with disc drive installed
Console without disc drive installed
If you want to set your PS5 console in the vertical position, you’ll
need to use the vertical stand (sold separately).
Bottom view
Bottom view

3
Let’s get started
EN
5 Turn on your PS5 console by pressing the
(power) button.
The power indicator blinks blue, and then turns white.
If you leave the console idle for 60 seconds after you turn it on,
the screen reader turns on. You can listen to on-screen text and
other important information read aloud to help you accomplish
what you want to do.
Screen reader is available only in certain languages.
Front view
Power indicator
(power) button
3 Connect the LAN cable.
For a wired connection to the internet, use a LAN cable
(not included).
If you’re going to use Wi-Fi®, don’t connect a LAN cable
and skip to the next step.
4 Turn on your TV and set the input
to HDMI.
Rear view
LAN port

4
Let’s get started
6 Connect your DualSense™ wireless
controller to your console and press the
(PS) button.
To pair your controller, connect it with a USB cable to
the USB port on your console. When you press the
(PS) button, the controller turns on.
USB Type-C® port USB port
(PS) button
USB cable
Front view
7 Make it your own.
You’re almost done! Follow the on-screen instructions to
complete the initial setup.
• Set up your account
Make a new account or sign in with an existing account.
By signing in with your existing account, you can access
your PlayStation®Plus subscription, as well as friends,
trophies, and other account information.
• Transfer data from another console
If you have a PlayStation®4 console or another PS5
console, you can transfer data to your new console by
signing in with an existing account.
You’ll know that setup is complete when Welcome to
PlayStation 5 appears on your screen.
Will a child be using your PS5 console? See also “Parental
controls” (page 5).
• The setup options that you see are tailored to your needs,
based on information such as your network environment and
the account that you’re signed into.
• You can go back and change any of your settings by selecting
Settings from the home screen.

5
EN
Parental controls
You can manage settings for children who use your PS5
console. Parental controls let you set restrictions on the
games children can play, when and how long they play,
whether or not they can chat, and more.
Each adult ( ) and child ( ) will need their own separate
accounts. When you create an account for a child, it’s
automatically linked to your account, creating a family. You
can set parental controls only for children in your family.
You can use an existing account, such as one you created on a PS4™
console, for your PS5 console. Your family and parental control settings
will carry over to your PS5 console.
Create an account for a child
You can create a child account and set parental controls at
the same time.
Press the (PS) button to open the control center. Select
your profile picture, then select Switch User. From the user
selection screen, select Add User to create an account.
Review and change your parental control settings
We recommend that you check the child’s parental controls
regularly. You can review or update them by selecting
Settings > Family and Parental Controls from the home
screen.
Game rating icons
Each game comes with a game rating icon that helps you
determine whether it’s age-appropriate for the child.
Singapore
Player’s Age 0 and above 16 and above 18 and above
Game Age Rating
Find out more about parental control features and setup in the User’s
Guide (page 11).

6
What’s on the screen
Home screen
From the home screen, you can go to two types of content: games or media.
In the games home, you’ll find your games, PlayStation™Store, and other game-related apps.
In the media home, you’ll find music, video, and other non-game related apps.
Switch home screens
Switch between games and media.
Search, change your settings, and edit your
profile.
Hub
Learn more about the game or app you
selected, and find related information.
• On the PS5 console, the button confirms selected items.
• To return to the home screen while your game or app is running, select Home from
the control center, or press and hold the (PS) button on your controller.

7
What’s on the screen
EN
Control center
Press the (PS) button to open the control center.
You can access a variety of features without leaving your game or app.
Cards
Cards show you features and activities related
to your games and apps that are available
depending on what you’re doing at that
moment. Select a card to learn more, or jump
to the next card.
Controls
Select Home to return to your home screen,
and Power to turn off your PS5 console.
Perform other basic functions here, too.
Get quick access to the functions and settings
you use most during gameplay.

8
Let’s play
Play a digital game
You can play a game that you downloaded from
PlayStation Store .
You’ll get a notification when the game is downloaded and
ready to play.
Select the game from your games home.
To purchase and download games, you’ll need to connect your
console to the internet and sign in with your account.
Play a game from a disc
(Only for consoles with disc drive installed)
Insert the disc.
Game data begins to install, and you’ll receive a notification
when the game is ready to play.
Select the game from your games home.
Eject the disc
Press the (eject) button to eject the disc.
Front view
(eject) button

9
EN
Use your controller
Charge your controller
With your PS5 console turned on or in rest mode, use a USB
cable to connect your controller to the console. When your
console is in rest mode, the light bar on your controller slowly
blinks orange. After charging is complete, the light bar turns
off.
To charge your controller while your console is in rest mode, go to
Settings > System > Power Saving > Features Available in Rest
Mode > Supply Power to USB Ports, and select an option other than
Off.
Mute your microphone
Each time you press the mute button, your mic switches
between muted (button lit) and unmuted (button off).
Press and hold the mute button to mute your mic and to
turn off sound output from the speakers on your controller
and TV. Press the mute button again to return to the original
state.
Mute button
Microphones
Lit : Mic is muted
O : Mic is unmuted
Blinking : Mic and sound output are
muted
Use multiple controllers
You can use up to 4 controllers at once. Press the (PS)
button to assign numbers to your controllers. The player
indicator lights turn on accordingly. Numbers are assigned
in order from 1, and you can determine your controller’s
number by the number of lights that turn on.
• You’ll need to pair your controller when you use it for the first time
(page 4).
• When you play a PS4 game, your controller’s light bar glows
blue, red, green, or pink based on the order that the controller is
connected. This is separate from the player indicator.
Turn on your PS5 console with a controller
Press the (PS) button on a controller that has finished
pairing to turn on your PS5 console.
(PS) button
Player indicator
Light bar

10
Shutting down
Caution
Disconnect the AC power cord from the electrical outlet only when
the power indicator is off. If you disconnect it while the power
indicator is on solidly or blinking, data might be lost or become
corrupted, and you might damage your console.
Put your console in rest mode
In rest mode, your console stays on, but at a lower power
consumption. You can do things like charge your controller,
automatically update your system software, and keep your
game or app suspended in rest mode.
For some features, you’ll need to enable their settings to use them.
Go to Settings > System > Power Saving > Features Available in
Rest Mode.
Select Power from the control center, and then select
Enter Rest Mode. The power indicator blinks white, and then
turns orange. To exit rest mode, press the (PS) button.
Turn o your console completely
Select Power from the control center, and then select
Turn Off PS5. The power indicator blinks white, and then the
console turns off.
Power indicator
White Console is on.
Orange Console is in rest mode.
Off Console is off.

11
EN
Further information
Safety Guide
Learn how to use your PS5 console safely with the supplied
Safety Guide. This printed manual also contains product
warranty terms and information about specifications. Be sure
to read it before using your console.
User’s Guide
Find out about everything your PS5 console can do. Learn
how to configure settings and how to use each function.
From your PS5 console’s home screen, go to Settings >
User’s Guide, Health & Safety, and Other Information >
User’s Guide.
Customer Support Website
Find online support information such as step by step
troubleshooting and frequently asked questions by visiting
playstation.com/help/.
“ ”, “PlayStation”, “ ”, “PS5”, “PS4”, “DualSense” and “PlayStation Shapes Logo” are
registered trademarks or trademarks of Sony Interactive Entertainment Inc.
“SONY” and “ ” are registered trademarks or trademarks of Sony Group Corporation.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the
HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
USB-IF SuperSpeed USB Trident logo is a registered trademark of USB Implementers Forum,
Inc.
USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
Wi-Fi® is a registered trademark of Wi-Fi Alliance®.
Design and specifications are subject to change without notice.
Information about system functionality and images published in this document may vary
from those for your console, depending on the system software version in use. Also, the
illustrations and screen images used in this guide may vary from the actual product.

12
2 連接HDMI連接線與交流電源線。
請使用隨附的連接線。
完成所有連接後，再將交流電源線的插頭插上電源插座。
以下插圖皆以裝有光碟機的主機為例。
HDMI IN連接埠 HDMI OUT連接埠
HDMI™連接線
至電源插座
AC IN端子
交流電源線
背面
立即開始
1 將水平式支架腳座插入PlayStation®5主機上凹
槽的孔中。
使用前請一律將腳座裝設至PS5®主機。請先在平坦表面上鋪一
塊軟布，將主機置於上面，然後再裝設腳座。
裝有光碟機的主機
未裝光碟機的主機
如果您想要直立式放置PS5主機，則必須使用直立架（另售）。
底視圖
底視圖

13
立即開始
CT
5 按下PS5主機的 （電源）按鈕以啟動電源。
電源指示燈閃爍藍色後會亮白色。
若主機在電源啟動後處於閒置狀態60秒，則螢幕助讀程式將開啟。
畫面上文字及其他重要資訊將被大聲念出，以協助您完成想要執行
的動作。
螢幕助讀程式僅支援特定語言。
正面
電源指示燈
（電源）按鈕
3 連接LAN連接線。
要以有線與網際網路連線時，請使用LAN連接線（未隨附）。
若希望使用Wi-Fi®，請勿連接LAN連接線，直接跳至下一步。
4 啟動電視機的電源，將影像輸入切換為
HDMI。
背面
LAN連接埠

14
立即開始
6 連接DualSense™無線控制器與主機後，按下
（PS）按鈕。
若要為控制器進行配置，請使用USB連接線將其與主機上的
USB連接埠連接。按下 （PS）按鈕時，會啟動控制器的電
源。
USB Type-C®連接埠 USB連接埠
（PS）按鈕
USB連接線
正面
7 按需要調整設定。
設定步驟就快完成了！請跟隨畫面指示完成初始設定。
•設定帳戶
建立新帳戶或以現有帳戶登入。透過現有帳戶登入，您可以
存取您的PlayStation®Plus定期服務，還可以查看好友、獎盃
及其他帳戶資料。
•從另一台主機傳輸資料
若您擁有PlayStation®4主機或另一台PS5主機，您可以透過現
有帳戶登入將資料傳輸到新主機。
當畫面上顯示［歡迎使用PlayStation 5］時，即表示設定已經
完成。
會有小孩使用這台PS5主機嗎？另請參閱「家長監控」（第15
頁）。
•根據您使用的網路環境及登入帳戶等資訊，會針對您的需求調整
設定選項。
•您可以返回並從主頁畫面選擇 ［設定］來變更任何設定。

15
CT
家長監控
您可以為使用PS5主機的小孩管理設定。家長監控可以限制小孩可
遊玩的遊戲、設定他們可遊玩的時間與時長、是否能與他人聊天等
等。
每位成人（ ）與小孩（ ）都必須擁有自己的個人帳戶。當您為
小孩建立帳戶時，該帳戶會自動連結至您的帳戶，以建立家庭。您
只能為自己家庭的小孩設定家長監控。
您可以使用現有帳戶登入PS5主機，例如在PS4™主機上建立的帳戶。
PS5主機會原樣保留家庭及家長監控設定。
為小孩建立帳戶
您可以同時建立小孩帳戶並設定家長監控。
按下 （PS）按鈕開啟控制中心。選擇您的個人資料相片，接著
選擇［切換使用者］。從使用者選擇畫面選擇［新增使用者］以建
立帳戶。
檢視並變更家長監控設定
建議您定期檢查小孩的家長監控。您可以從主頁畫面選擇 ［設
定］＞［家庭及家長監控］來檢視或更新設定。
遊戲分級圖示
每款遊戲都帶有遊戲分級圖示，以便您確定該款遊戲是否適合您小
孩的年齡。
對象年齡 0歲以上 6歲以上 12歲以上 15歲以上 18歲以上
遊戲分級
關於家長監控機能與設定的進一步資訊，請參閱用戶指南（第21頁）。

16
畫面瀏覽
主頁畫面
在主頁畫面可以前往兩種內容：遊戲或媒體。
您可在遊戲主頁找到遊戲、PlayStation™Store及其他遊戲相關應用程式。
可在媒體主頁找到音樂、影片及其他非遊戲相關應用程式。
切換主頁畫面
來回切換遊戲與媒體。
搜尋、變更設定，以及編輯您的個人資料。
內容中心
進一步了解所選遊戲或應用程式的詳情，並尋找相
關資訊。
•在PS5主機上， 按鈕用於確認選擇的項目。
•若要在遊戲或應用程式正在執行的同時返回主頁畫面，請從控制中心選擇 ［主頁］，
或按住控制器上的 （PS）按鈕不放。

17
畫面瀏覽
CT
控制中心
按下 （PS）按鈕開啟控制中心。
可在不離開遊戲或應用程式的情況下存取各種機能。
分頁卡
根據您當時執行的動作而定，分頁卡會顯示與遊戲
及應用程式相關的可用機能與行動。選擇分頁卡了
解詳情，或跳轉至下一個分頁卡。
控制項
選擇 ［主頁］可返回主頁畫面，選擇 ［電源］
可關閉PS5主機的電源。亦可在這裡執行其他基本
功能。
可以在遊玩過程中快速存取您最常使用的功能與設
定。

18
我們來玩吧
遊玩數位遊戲
您可以遊玩您在 ［PlayStation Store］下載的遊戲。
當遊戲下載完成並可以開始遊玩時，您會收到通知。
從遊戲主頁選擇遊戲。
若要購買及下載遊戲，需要將主機與網際網路連線並使用您的帳戶登
入。
遊玩光碟遊戲
（僅限裝有光碟機的主機）
插入光碟。
將會開始安裝遊戲資料，當遊戲可以開始遊玩時，您會收到通知。
從遊戲主頁選擇遊戲。
退出光碟
按下 （退出）按鈕，退出光碟。
正面
（退出）按鈕

19
CT
使用您的控制器
為控制器充電
在PS5主機電源啟動的狀態或處於待命模式時，使用USB連接線連接
控制器與主機。主機處於待命模式時，控制器的光條會緩慢閃爍橘
色。充電完成後，光條會熄燈。
若要在主機處於待命模式時為控制器充電，請進入 ［設定］＞［主
機］＞［省電］＞［待命模式中的機能］＞［為USB連接埠供電］，選
擇為［關］以外的選項。
將麥克風設為靜音
每按一次靜音按鈕，麥克風會切換為靜音（按鈕亮燈）或解除靜音
（按鈕熄燈）。
按住靜音按鈕不放可將麥克風靜音，並且關閉控制器的喇叭與電視
機的聲音輸出。再次按下靜音按鈕返回原始狀態。
靜音按鈕
麥克風
亮燈：麥克風靜音
熄燈：麥克風解除靜音
閃爍： 麥克風和聲音輸出靜音
使用多台控制器
您最多可同時使用4台控制器。按下 （PS）按鈕，可為控制器分
配編號。玩家指示燈會隨之亮燈。編號從1開始依序分配，您可以
依照亮燈數量來確定控制器編號。
•第一次使用控制器時，需先為控制器進行配置（第14頁）。
•遊玩PS4遊戲時，控制器的光條會依控制器連接的先後順序，亮藍
色、紅色、綠色或粉紅色的燈。這與玩家指示燈有所不同。
使用控制器啟動PS5主機電源
按下已完成配置之控制器的 （PS）按鈕，即可啟動PS5主機電
源。
（PS）按鈕
玩家指示燈
光條

20
關閉電源
注意
請在電源指示燈熄滅後，再拔除交流電源線的插頭。在電源指示燈亮
燈或閃爍時拔除交流電源線，可能會導致資料毀損、消失，以及主機
故障。
讓主機處於待命模式
處於待命模式時，主機會保持開啟但耗電量降低。您可以執行主機
處於待命模式時為控制器充電、自動更新系統軟體、使遊戲或應用
程式暫停等動作。
某些機能必須啟用其設定後才能使用。進入 ［設定］＞［主機］＞
［省電］＞［待命模式中的機能］。
在控制中心選擇 ［電源］，接著選擇［進入待命模式］。電
源指示燈在閃爍白色後會亮橘色。若要解除待命模式，請按下
（PS）按鈕。
完全關閉主機電源
在控制中心選擇 ［電源］，接著選擇［關閉PS5的電源］。電源
指示燈閃爍白色後，主機的電源便會關閉。
電源指示燈
白色 主機已啟動。
橘色 主機處於待命模式。
熄燈 主機已關閉。
