Sony PS5 CFI-1018A User manual

CFI-1018A
PlayStation®5
Quick Start Guide
快速參考指南 •快捷参考指南 •빠른 시작 가이드

2
1Place the console with the rear side facing up, and
then remove the screw hole cap.
2Attach the screw hole cap to the bottom of the base.
3Remove the screw from the bottom of the base.
3
2
4Attach the base, and then secure with a screw. Use a
coin or similarly shaped object to tighten the screw.
Bottom of
base
Let's get started
1 Attach the base.
Always attach the base to the console, whether it's in the
vertical or horizontal position.
Place your console on a flat surface when attaching the
base.
You'll need to reconfigure the base for the position
of your console. Rotate the top and bottom part of
the base in opposite directions. Keep rotating until
you hear a "click".
For the vertical position
With the base attached
Hook
Make sure the hook is in the position
as illustrated below before attaching
the base to the console.

3
Let's get started
EN
2 Connect the HDMI cable and the AC
power cord.
Use the included cables.
Make all connections before plugging the AC power cord
into an electrical outlet.
HDMI OUT port HDMI IN port
HDMI™ cable
To an electrical outlet
AC IN
connector
AC power cord
Rear view
For the horizontal position
With the base attached
Make sure the hook is in the position
as illustrated below before attaching
the base to the console.
Hook
1Place the console with the rear side facing up. Align
the base with the marked area on the console, and
press the base in firmly.

4
Let's get started
3 Connect the LAN cable.
For a wired connection to the internet, use a LAN cable
(not included).
If you're going to use Wi-Fi®, don't connect a LAN cable
and skip to the next step.
4 Turn on your TV and set the input
to HDMI.
Rear view
LAN port
5 Turn on your PlayStation®5 console by
pressing the (power) button.
The power indicator blinks blue, and then turns white.
If you leave the console idle for 60 seconds after you turn it on,
the screen reader feature turns on. You can listen to on-screen
text and other important information read aloud to help you
accomplish what you want to do.
Screen reader is only available in certain languages.
Front view
Power indicator
(power) button

5
Let's get started
EN
6 Connect your wireless controller to your
console using a USB cable, and then
press the (PS) button.
To pair your controller, connect it with a USB cable to
the USB port on your console. When you press the
(PS) button, the controller turns on.
USB Type-A port USB port
(PS) button
USB cable
Front view
7 Make it your own.
You're almost done! Follow the on-screen instructions to
• Set up your console
Select your language, configure your internet connection
settings, and manage your power save settings.
Select Optimized Experience in Power Options for Rest Mode
to charge your controller during rest mode or to enable your
update files to install automatically (page 12).
• Set up your account
Create a new account or sign in with an existing
account, such as one you created on a PlayStation®4
console. See also "For PS4 users" (page 6).
• Download your content
Download purchased PS5™ games and media apps. If
you have a PS4™ console, you can transfer the data to
your PS5 console.
You'll know that setup is complete when Welcome to
PlayStation 5 appears on your screen.
Will a child be using your PS5 console? See also "Parental
controls" (page 6).
• The setup options that you see are tailored to your needs,
based on information such as your network environment and
the account that you're signed into.
• You can go back and change any of your settings by selecting
Settings from the home screen.

6
Parental controls
You can manage settings for children who use your PS5
console. Parental controls let you set restrictions on the
games children can play, when and how long they play, who
they communicate with, and more.
Each adult ( ) and child ( ) will need their own separate
accounts. When you create an account for a child, it's
automatically linked to your account, creating a family. You
can set parental controls only for children in your family.
You can use an existing account, such as one you created on a PS4
console, for your PS5 console. Your family and parental control settings
will carry over to your PS5 console.
For PS4 users
Play some PS4 games on your PS5 console
Enjoy supported PS4 games*on your PS5 console.
* Some functionalities available on the PS4 console may be absent
when played on the PS5 console. You must update to the latest system
software version. Internet connection required.
Transfer data from a PS4 console to your
PS5 console
Connect your PS4 console and
PS5 console to the same network
to transfer data such as game
save data, user information, and
downloaded content.
If you have a USB drive that you've
been using as extended storage for
your PS4 console, you can continue
using it by simply connecting it to
your PS5 console.
Use the same account you
created on a PS4 console
There's no need to create a new
account for your PS5 console. Just
sign in with your existing account
and your game history, trophies,
profile, and any exchanges you've
had with friends will transfer to your
PS5 console.

7
Parental controls
EN
Create an account for a child
You can create a child account and set parental controls at
the same time.
Press the (PS) button to open the control center. Select
your avatar, then select Switch User. From the user selection
screen, select Add User to create an account.
Review and change your parental control settings
We recommend that you check the child's parental controls
regularly. You can review or update them by selecting
Settings > Family and Parental Controls from the home
screen.
Game rating icons
Each game comes with a game rating icon that helps you
determine whether it's age-appropriate for the child.
Singapore
Player's Age 16 and above 18 and above
Game Age Rating
Find out more about parental control features and setup in the User's
Guide (page 13).

8
What's on the screen
Home screen
From the home screen, you can go to two types of content: games or media.
In the games home, you'll find your games, PlayStation™Store, and other game-related apps.
In the media home, you'll find music, video, and other non-game related apps.
Switch home screens
Switch between games and media.
Change your settings, and edit your profile.
Hub
Learn more about the game or app you
selected, and find related information.
• On the PS5 console, the button confirms selected items.
• To return to the home screen while your game or app is running, select Home from
the control center, or press and hold the (PS) button on your controller.

9
What's on the screen
EN
Control center
Press the (PS) button to open the control center.
You can access a variety of features without leaving your game or app.
Cards
Cards show you features and activities related
to your games and apps that are available
depending on what you're doing at that
moment. Select a card to learn more, or jump
to the next card.
Controls
Select Home to return to your home screen,
and Power to turn off your PS5 console.
Perform other basic functions here, too.
Get quick access to the functions and settings
you use most during gameplay.

10
Let's play
Play a game from a disc
Insert the disc.
Game data will start copying, and you'll get a notification
when the game is ready to play.
Select the game from your games home.
Eject the disc
Press the (eject) button to eject the disc.
Front view
(eject) button
Play a digital game
You can play a game that you downloaded from
PlayStation Store .
You'll get a notification when the game is downloaded and
ready to play.
Select the game from your games home.
To purchase and download games, you'll need to connect your
console to the internet and sign in to your account.

11
EN
Use your controller
Charge your controller
With your PS5 console turned on or in rest mode, use a USB
cable to connect your controller to the console. When your
console is in rest mode, the light bar on your controller slowly
blinks orange. After charging is complete, the light bar turns
off.
To charge your controller while your console is in rest mode, go to
Settings > System > Power Saving > Features Available in Rest
Mode > Supply Power to USB Ports, and select an option other than
Off.
Mute your microphone
Each time you press the mute button, your mic switches
between muted (button lit) and unmuted (button off).
Press and hold the mute button to mute your mic and to
turn off sound output from the speakers on your controller
and TV. Press the mute button again to return to the original
state.
Mute button
Microphones
Lit : Mic is muted
O : Mic is unmuted
Blinking : Mic and sound output are
muted
Use multiple controllers
You can use up to 4 controllers at once. Press the (PS)
button to assign numbers to your controllers. The player
indicator lights turn on accordingly. Numbers are assigned
in order from 1, and you can determine your controller's
number by the number of lights that turn on.
Light bar
Player indicator
(PS) button
• You'll need to pair your controller when you use it for the first time
(page 5).
• When you play a PS4 game, your controller's light bar glows
blue, red, green, or pink based on the order that the controller is
connected. This is separate from the player indicator.
Turn on your PS5 console with a controller
Press the (PS) button on a controller that has finished
pairing to turn on your PS5 console.

12
Shutting down
Caution
Disconnect the AC power cord from the electrical outlet only when
the power indicator is off. If you disconnect it while the power
indicator is on solidly or blinking, data might be lost or become
corrupted, and you might damage your console.
Put your console in rest mode
In rest mode, your console stays on, but at a lower power
consumption. You can do things like charge your controller,
automatically update your system software, and keep your
game or app suspended in rest mode.
For some features, you'll need to enable their settings to use them.
Go to Settings > System > Power Saving > Features Available in
Rest Mode.
Select Power from the control center, and then select
Enter Rest Mode. The power indicator blinks white, and then
turns orange. To exit rest mode, press the (PS) button.
Turn o your console completely
Select Power from the control center, and then select
Turn Off PS5. The power indicator blinks white, and then the
console turns off.
Power indicator
White Console is on.
Orange Console is in rest mode.
Off Console is off.

13
EN
Further information
Safety Guide
Learn how to use your PS5 console safely with the supplied
Safety Guide. This printed manual also contains product
warranty terms and information about specifications. Be sure
to read it before using your console.
User's Guide
Find out about everything your PS5 console can do. Learn
how to configure settings and how to use each function.
From your PS5 console's home screen, go to Settings >
User's Guide, Health & Safety, and Other Information >
User's Guide.
Customer Support Website
Find online support information such as step by step
troubleshooting and frequently asked questions by visiting
playstation.com/help.
" ", "PlayStation", " ", "PS5" and "PS4" are registered trademarks or trademarks of
Sony Interactive Entertainment Inc.
"SONY" and " " are registered trademarks or trademarks of Sony Corporation.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
Wi-Fi® is a registered trademark of Wi-Fi Alliance®.
Design and specifications are subject to change without notice.
Information about system functionality and images published in this document may vary
from those for your console, depending on the system software version in use. Also, the
illustrations and screen images used in this guide may vary from the actual product.

14
1以背面朝上的方向放置主機，接著取下螺絲孔蓋帽。
2將螺絲孔蓋帽裝設至底座的底部。
3從底座的底部卸下螺絲。
3
2
4裝設底座，接著用螺絲固定。使用硬幣或類似形狀的物體來旋
緊螺絲。
底座的底部
立即開始
1 裝設底座。
請一律將底座裝設至主機，無論是直立位置還是水平位置。
裝設底座時，請將主機放在平坦表面上。
您需要針對主機的位置重新設定底座。以相反方向旋
轉底座的頂部與底部部分。持續旋轉直至聽到「卡
嗒」一聲為止。
直立位置
裝好底座的狀態
掛鉤
將底座裝設至主機之前，請確保掛鉤
處於下圖所示的位置。

15
立即開始
CT
2 連接HDMI連接線與交流電源線。
請使用隨附的連接線。
完成所有連接後，再將交流電源線的插頭插上電源插座。
HDMIOUT連接埠 HDMIIN連接埠
HDMI™連接線
至電源插座
ACIN端子
背面
交流電源線
水平位置
裝好底座的狀態
將底座裝設至主機之前，請確保掛鉤
處於下圖所示的位置。
掛鉤
1以背面朝上的方向放置主機。將底座對準主機上的標記區域，牢固
地嵌入底座。

16
立即開始
3 連接LAN連接線。
要以有線與網際網路連線時，請使用LAN連接線（未隨附）。
若希望使用Wi-Fi®，請勿連接LAN連接線，直接跳至下一步。
4 啟動電視機的電源，將影像輸入切換為
HDMI。
背面
LAN連接埠
5 按下PlayStation®5主機的 （電源）按鈕以啟
動電源。
電源指示燈閃爍藍色後會亮白色。
若主機在電源啟動後處於閒置狀態60秒，則螢幕助讀程式將開啟。
畫面上文字及其他重要資訊將被大聲念出，以協助您完成想要執行
的動作。
螢幕助讀程式僅支援特定語言。
正面
電源指示燈
（電源）按鈕

17
立即開始
CT
6 使用USB連接線連接無線控制器與主機後，按
下 （PS）按鈕。
若要為控制器進行配置，請使用USB連接線將其與主機上的
USB連接埠連接。按下 （PS）按鈕時，會啟動控制器的電
源。
USBType-A連接埠 USB連接埠
（PS）按鈕
USB連接線
正面
7 按需要調整設定。
設定步驟就快完成了！請跟隨畫面指示進行設定。
•設定主機
選擇您的語言、設定網際網路連線以及管理省電設定。
在［待命模式下的電源選項］中選擇［最佳體驗］，可在待命模
式期間為控制器充電或自動安裝更新檔案（第24頁）。
•設定帳戶
建立新帳戶或以現有帳戶登入，例如使用您在PlayStation®4
主機上建立的帳戶。另請參閱「PS4使用者」（第18頁）。
•下載內容
下載已購買的PS5™遊戲與媒體應用程式。若您擁有PS4™主
機，可以將資料傳送到PS5主機。
當畫面上顯示［歡迎使用PlayStation5］時，即表示設定已經
完成。
會有小孩使用這台PS5主機嗎？另請參閱「家長監控」（第18
頁）。
•根據您使用的網路環境及登入帳戶等資訊，會針對您的需求調整
設定選項。
•您可以返回並從主頁畫面選擇 ［設定］來變更任何設定。

18
家長監控
您可以為使用PS5主機的小孩管理設定。家長監控可以限制小孩可
遊玩的遊戲、設定他們可遊玩的時間與時長、可以與誰互通訊息等
等。
每位成人（ ）與小孩（ ）都必須擁有自己的個人帳戶。當您為
小孩建立帳戶時，該帳戶會自動連結至您的帳戶，以建立家庭。您
只能為自己家庭的小孩設定家長監控。
您可以使用現有帳戶登入PS5主機，例如在PS4主機上建立的帳戶。PS5
主機會原樣保留家庭及家長監控設定。
PS4使用者
在PS5主機上遊玩某些PS4遊戲
在PS5主機上暢玩支援的PS4遊戲*。
*部分遊戲機能僅可在PS4主機上使用，可能不適用於PS5主機。系統軟件必
須更新至最新版本。需要網際網路連線。
將資料從PS4主機傳送到PS5主機
將PS4主機與PS5主機連線至相同網路，
可傳送遊戲保存資料、使用者資訊及下
載內容等資料。
若您的PS4主機有使用USB硬碟做為擴充
儲存空間，可以直接將其連接到PS5主機
以繼續使用。
使用在PS4主機上建立的相同帳戶
您不必為PS5主機建立新帳戶。只需登
入現有帳戶，即可將遊戲歷史記錄、獎
盃、個人資料以及與好友之間的所有交
換訊息傳送到PS5主機。

19
家長監控
CT
為小孩建立帳戶
您可以同時建立小孩帳戶並設定家長監控。
按下 （PS）按鈕開啟控制中心。選擇個人造型，接著選擇［切
換使用者］。從使用者選擇畫面選擇［新增使用者］以建立帳戶。
檢視並變更家長監控設定
建議您定期檢查小孩的家長監控。您可以從主頁畫面選擇 ［設
定］＞［家庭及家長監控］來檢視或更新設定。
遊戲分級圖示
每款遊戲都帶有遊戲分級圖示，以便您確定該款遊戲是否適合您小
孩的年齡。
對象年齡 0歲以上 6歲以上 12歲以上 15歲以上 18歲以上
遊戲分級
關於家長監控機能與設定的進一步資訊，請參閱用戶指南（第25頁）。

20
畫面瀏覽
主頁畫面
在主頁畫面可以前往兩種內容：遊戲或媒體。
您可在遊戲主頁找到遊戲、PlayStation™Store及其他遊戲相關應用程式。
可在媒體主頁找到音樂、影片及其他非遊戲相關應用程式。
切換主頁畫面
來回切換遊戲與媒體。
變更設定、編輯您的個人資料。
內容中心
進一步了解所選遊戲或應用程式的詳情，並尋找相
關資訊。
•在PS5主機上， 按鈕用於確認選擇的項目。
•若要在遊戲或應用程式正在執行的同時返回主頁畫面，請從控制中心選擇 ［主頁］，
或按住控制器上的 （PS）按鈕不放。
