KDL- 46EX400
46" BRAVIA® EX Series HDTV
Key Features
Full HD 1080p Resolution
Ambient Sensor adjusts color based on room light
LightSensor ™adjusts backlight with room light
BRAVIA Engine ™2 fully digital video processor
USB port for photos, music & video playback
BRAVIA® Sync ™ controls compatible devices w/ one remote
1
7 HD Inputs (4 HDMI, 2 Component, 1 PC)
Key Technologies
Full HD 1080p Resolution Experience Full HD 1080p picture quality, the highest at - home resolution,
and take full advantage of HD sources like a Blu - ray Disc™Player or PlayStation ® 3 gaming console
via the 16:9 wide screen panel (1920 x 1080).
2
Ambient Sensor Get a natural looking picture whether you are watching movies late at night or
playing video games during the day with an Ambient Sensor that automatically adjusts the picture
color based on a room's lighting.
LightSensor ™Technology Automatically increase or decrease the level of brightness of your TV's
backlight based on a room's lighting conditions with the integrated LightSensor™technology. Dim
the lights to watch a movie and the sensor dims the backlight, which also helps reduce
unnecessary power consumption.
BRAVIA Engine ™2 Enjoy sharp, vibrant, life - like images while optimizing color & contrast and
significantly reducing noise with the BRAVIA Engine™2 fully digital processor.
USB Input Share your photos on the big screen or listen to your favorite music. Simply connect your
digital camera, USB - enabled MP3 player, or USB storage device directly to your HDTV's USB input.
BRAVIA® Sync ™Compatible Conveniently operate and control other BRAVIA ® Sync™compatible
devices - including BRAVIA ® HDTVs, Blu - ray Disc™Players, surround sound systems, Handycam ®
camcorders and Cyber - shot ® digital still cameras, all with one remote control.
3
7 HD Inputs Get versatile HD connection options with seven HD inputs, including four HDMI™inputs
to connect a Blu - ray Disc™player, PlayStation ® 3 gaming console or any other HDMI - capable
equipment. Two HD component inputs provide added HD - capable connectivity in addition a PC
input (HD - 15 pin) lets you use your HDTV as a computer monitor.
4

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 10/27/2010
KDL- 46EX400
46" BRAVIA® EX Series HDTV
Please visit the Dealer Source for current
information at www.sony.com/dealersource
Features
General
Closed Captions (CC): Analog, Digital
Finish (Surface Color): PianoBlack
HDMI™InstaPort: Yes
Start Up Sony Logo Display: Yes
Display
Backlight Type: CCFL
Display Device: LCD
Video
Video Processing: BRAVIA Engine 2 ™Technology
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Wide Mode: Normal, Zoom, Wide Zoom, Full (Full1-2 for
PC)
3D Comb Filter: Yes
MPEG Noise Reduction: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema™Technology: Yes
Picture Mode: Vivid, Standard, Custom
Advanced Contrast Enhancer (ACE): Yes
Cinema Mode: Yes
Live Color™Technology: Yes
Audio
Auto SAP: 20FM/10AM
Auto Mute (on no signal): Yes
Steady Sound® Automatic Volume Control: Yes
Audio Out: Fixed
Stereo System: MTS
Dolby ®: Dolby ® Digital
Alternate Audio (Digital): yes
Surround Effect: Cinema, Music, Live Sports, Game
5.1 Channel Audio Out: Yes
Sound Mode: Dynamic, Standard, Clear Voice, Custom
5.1ch Through Out (Handycam): Yes
Clear Voice: Yes
Invisible Speaker (w/Sound Elevation): Yes
Convenience
Channel Jump: Yes
Multiple Language Display: English, French, Spanish
Info Banner: PSIP, XDS
Sleep Timer: Yes
Input Skip: Manual
Channel Surf: Yes
Channel Block (with password): Yes
Edit Channel Labels: Yes
Label Inputs: Yes
ID-1 Detection: Yes
USB Application(s): Photo Viewer (jpeg), Music Player
(mp3), Video Player (mpeg1), Video Player (mpeg2
TS)
Theatre Mode (Theatre Button): Yes
Show/Hide Channels: Yes
Auto Shut-off: Yes
BRAVIA® Sync™: Yes
Parental Control: Yes
BRAVIA® Sync™Menu Button: Yes (on Remote
Control)
On-Screen Display for External Input: Yes
PIP (Picture in Picture): PC Input(HD15/HDMI) & TV
Channel/CVBS/(HDMI)/(Component)
Channel Labels: Yes
Program Block: Yes
Control for HDMI™(HDMI™CEC): Yes
Short Banner: Yes
Auto Photo Mode: via USB
Picture Adjustments Lock: Yes
White Balance: RGB Gain/Bias
Auto Picture Setting w/HDMI™: Cinema, Photo,
Graphics, Game
Scene Select: Auto, Cinema, Sports, Photo, Music,
Game, Graphics, General
Favorites (Simple UI): Yes
Ambient Sensor: Yes
Picture Frame Mode: Yes
Start Up Sony Logo Display: Yes
USB Player: Yes
Sensing
Ambient Sensor: Yes
Specifications
Display
Viewing Angle (Right/Left): 178(89/89)
Viewing Angle (Up/Down): 178(89/89)
Dynamic Contrast Ratio: 140,000:1
Screen Size (measured diagonally): 46"
Display Resolution: Full HD 1080(1920x1080)
Aspect Ratio: 16:9
Refresh Rate: 60Hz
TV System
Tuner (Cable): QAM
Tuner (Terrestrial): ATSC™ / NTSC
Channel Coverage: VHF: 2- 13ch
UHF: 14 - 69ch
CATV (analog): 1- 135ch
CATV (digital) : 1- 135ch
TV System (Analog): M
Number of Tuners (Analog): 1(Hybrid)
Number of Tuners (Digital): 1(Hybrid)
TV System (Digital): ATSC
Color System: NTSC
Video
Video Signal: 1080/60p (HDMI ™ / COMPONENT), 1080/60i,
1080/24p (HDMI ™ ONLY), 720/60p, 480/60p, 480/60i
Audio
Audio Power Output: 20W (10W x 2)
Speakers (Total): 2
Speaker Configuration: 2
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear) (1
fixed/1 selectable)
Composite Video Input(s): 2 (1 Side/1 Rear)
Digital Audio Output(s): Optical Digital Output -1 (Rear)
RF Connection Input(s): 1 (Rear)
Analog Audio Input(s) (Total): 4 (1 Side / 3 Rear)
Audio Out: 1(Rear)
HDMI™Connection(s) (Total): 4 (2 Side/2 Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1(Rear)
( common with HDMI 1) (stereo Mini)
USB 2.0: 1(Side)
HDMI™PC Input: Yes
AC Power Input: 1 (Rear) AC Socket
Power
Power Consumption (in Standby): Less than 0.23W
(AC120V), Less than 0.4W (AC240V)
Power Requirements (voltage): AC 120V
Power Requirements (frequency): 60Hz
Power Consumption (in Operation) max.: 245W Max
Regulation And Standards Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: 300x300(46")
Service and Warranty Information
Limited Warranty Term: 1 Year Labor / 1 Year Parts
Energy Saving & Efficiency
Power Saving Modes: Yes
Eco Settings: Yes
Dynamic Backlight Control: Yes
Backlight Off Mode: Yes
Estimated Annual Energy Consumption (kWh): 215.0
kWh
Idle TV Standby: Yes
Power Consumption (On Mode) for Energy Star: 116.8W
Power Consumption (Standby Mode) for Energy Star:
0.23W
Recycled & Recyclable Materials
Product Materials: Recycled Carton (more than 40%)
Packaging Materials: Recycled Carton (more than 20%)
Printed Materials: FSC Certified
Weights and Measurements
Weight (Approx.): 45 lbs. (20.4kg) with pedestal; 39.9 lbs.
(18.1kg) without pedestal
Dimensions (Approx.): 44 3/8 x 28 x 11 5/8" (1127 x 711 x
294mm) with pedestal; 44 3/8 x 26 5/8 x 4 1/8" (1127 x
674 x 102mm) without pedestal
Supplied Accessories
Remote Control (RM- YD035)
Batteries (Type AAA x2)
AC Power Cord (attached)
Table Top Stand (separate, pre-assembled)
Optional Accessories
Wallmount Bracket (SU-WL500)
UPC Code: 027242785045
1.WorkswithotherBRAVIA®SyncorTheatreSync™ labeledhome
audio/videoproducts when connected via HDMI ™ interface.
2. HDMI cable required, sold separately.
3.DevicesmustbeconnectedviaHDMI™ interface.
4.Limitedtoresolutionssupportedbyboth the PC and the Sony TV. See
SonyTV user ’ smanualandPCdocumentationforsupported
resolutions.
©2010Sony Electronics Inc. Allrightsreserved.Reproduction in whole or
inpart without written permissionisprohibited. Sony, BRAVIA, Sync,
Motionflow,BRAVIA Engine, LightSensor, Cyber - shot,24p True Cinema,
XrossMedia Bar, make.believe, and the Sony logo, FullHD 1080p logo and
BRAVIAlogo are trademarks of Sony.PlayStationis a trademark of Sony
ComputerEntertainment.Blu - rayDisc is atrademark.HDMI, the HDMI
logo and High - DefinitionMultimedia Interfacearetrademarks of HDMI
LicensingLLC. All other trademarksaretrademarks of their respective
owners.Featuresand specifications are subject to change without notice.
Non - metricweights and measures are approximate andmay vary.
