SXRD PROJECTION TELEVISION
SERVICE MANUAL SP-4 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-759-04
KDS-50A3000 RM-YD016 US/CND
KDS-55A3000 RM-YD016 US/CND
KDS-60A3000 RM-YD016 US/CND
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 8/2007
☛
: UPDATED ITEM
REVISION DATE SUBJECT
8/2007 No revisions or updates are applicable at this time.
8/2007 Added Optional Colored Speaker Grille P/N’s information. Replaced Page 115.
9/2007 Updated Self-Diagnostic information. Replaced page 8-9.
Corrected information in Disassembly section, Replace pages 10 -16.
Corrected PN for Power Supply and added PN for Plug Holder. Replaced page 67.
10/2007 Updated TOC to add Appendix C: HV Cable Removal. Replaced page 3.
Updated Disassembly section to include HV Cable Removal instructions. Replaced page 13.
Updated illustration to show HV Plug Holder. Replaced page 67.
Added Appendix C: HV Cable Removal.

SXRD PROJECTION TELEVISION
SERVICE MANUAL SP-4 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-759-04
KDS-50A3000 RM-YD016 US/CND
KDS-55A3000 RM-YD016 US/CND
KDS-60A3000 RM-YD016 US/CND
Self Diagnosis
Supported model
KDS-60A3000 RM-YD016

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
3
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 4
Warnings and Cautions .................................................................. 6
Safety Check-Out ........................................................................... 7
Self-Diagnostic Function................................................................. 8
SECTION 1: DISASSEMBLY............................................................... 10
1-1. Lamp Removal ..................................................................... 10
1-2. Screen Frame Assembly and Speaker Grille Assembly
Removal ............................................................................... 10
1-3. Rear Cover Removal and H1 Board Bracket Removal .........11
1-3-1. Side Cover Removal (KDS-50A3000 Only)..............11
1-4. H2 Board, Speaker, and Separator Removal....................... 12
1-5. Front Bracket Removal ........................................................ 12
1-6. Optics Block Assembly and Lamp Duct Removal ................ 13
1-6-1. Lamp Duct Block Disassmbly .................................. 13
1-7. Chassis Removal ................................................................. 14
1-8. Diffusion Plates (Screens) Removal .................................... 15
1-9. Mirror Removal..................................................................... 16
SECTION 2: CIRCUIT ADJUSTMENTS.............................................. 17
2-1. Using the Remote Commander for Electrical Adjustments .. 17
2-2. Accessing Service Adjustment Mode ................................... 17
2-3. Viewing the Service Menus.................................................. 17
2-4. Using the Remote Commander to View Service Data ......... 18
2-5. Adjusting H/V Center............................................................ 18
2-6. Exiting Service Mode ........................................................... 18
SECTION 3: DIAGRAMS..................................................................... 19
3-1. Circuit Boards Location ........................................................ 19
3-2. Printed Wiring Boards and
Schematic Diagrams Information ......................................... 19
3-3. Block Diagram...................................................................... 21
3-4. Schematics and Supporting Information .............................. 22
A Board Schematic Diagram ................................................ 22
BC Board Schematic Diagram ............................................. 24
F Board Schematic Diagram ................................................ 26
FB1A Board Schematic Diagram (1 of 17) ........................... 28
FB1A Board Schematic Diagram (2 of 17) ........................... 29
FB1A Board Schematic Diagram (3 of 17) ........................... 30
FB1A Board Schematic Diagram (4 of 17) ........................... 31
FB1A Board Schematic Diagram (5 of 17) ........................... 32
FB1A Board Schematic Diagram (6 of 17) ........................... 33
FB1A Board Schematic Diagram (7 of 17) ........................... 34
FB1A Board Schematic Diagram (8 of 17) ........................... 35
FB1A Board Schematic Diagram (9 of 17) ........................... 36
FB1A Board Schematic Diagram (10 of 17) ......................... 37
FB1A Board Schematic Diagram (11 of 17) ......................... 38
FB1A Board Schematic Diagram (12 of 17) ......................... 39
FB1A Board Schematic Diagram (13 of 17) ......................... 40
FB1A Board Schematic Diagram (14 of 17) ......................... 41
FB1A Board Schematic Diagram (15 of 17) ......................... 42
FB1A Board Schematic Diagram (16 of 17) ......................... 43
FB1A Board Schematic Diagram (17 of 17) ......................... 44
G Board Schematic Diagram (1 of 2) ................................... 46
G Board Schematic Diagram (2 of 2) ................................... 47
H1 Board Schematic Diagram.............................................. 49
H2 Board Schematic Diagram.............................................. 51
S2 Board Schematic Diagram.............................................. 53
T Board Schematic Diagram ................................................ 55
TUU2 Board Schematic Diagram (1 of 2) ........................... 57
TUU2 Board Schematic Diagram (2 of 2) ........................... 58
U Board Schematic Diagram (1 of 4) ................................... 60
U Board Schematic Diagram (2 of 4) ................................... 61
U Board Schematic Diagram (3 of 4) ................................... 62
U Board Schematic Diagram (4 of 4) ................................... 63
3-5. Semiconductors ................................................................... 65
SECTION 4: EXPLODED VIEWS ........................................................ 66
4-1. Screen Frame Assembly and Mirror..................................... 66
4-2. Optics Block Assembly......................................................... 67
4-3. Chassis ................................................................................ 68
4-4. Connectors........................................................................... 69
SECTION 5: ELECTRICAL PARTS LIST............................................ 70
APPENDIX A: ENCRYPTION KEY COMPONENTS ..........................A-1
APPENDIX B: REPLACING THE LAMP............................................B-1
APPENDIX C: HV CABLE REMOVAL ...............................................C-1

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
4
SPECIFICATIONS
Design and specifications are subject to change without notice.
120V, 60Hz
240W
Less than 0.4W
HDMI IN 1/2/3
Video - 480i, 480p, 720p, 1080i, 1080p, 1080/24p
Audio - Two channel linear PCM 32, 44.1 and 48 kHz,
16, 20, and 24 bit, Dolby Digital
Audio - (HDMI IN 1 only) 500 mVrms
(100% modulation) Impedance:47 kilo ohms
Video (IN) 1/2/3
Video
1 total Y: 1.0 Vp-p, 75ohms unbalanced,
sync negative
S Video (IN)
1 total (4-pin mini DIN)
Y: 1Vp-p, 75ohms unbalanced, sync negative
C: 0.286Vp-p (Burst signal), 75ohms
Audio (IN)
500 mVrms (100% modulation)
Impedance:47 kilo ohms
Power Requirements
Power Consumption (W)
In Use (Max)
In Standby
Inputs/Outputs Component In 1/2
(Y, PB/RR) (Component Video)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
PB
:
0.7 Vp-p, 75 ohms;
PR: 0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i, 1080p
Audio (IN)
500 mVrms (100% modulation)
Impedance:47 kilo ohms
Audio Out
500 mVrms (100% modulation)
1 Vrms at the maximum volume setting
(Varies with input level)
Digital Audio Optical Output (PCM/Dolby Digital)
Optical Digital Audio Output
PC In
D-sub 15-pin, analog RGV, 0.7 Vp-p, 75 ohms,
positive
PC Audio Input
Stereo mini jack, 500mVrms, 47 kilohm
Trademark Information
As an ENERGY STAR®Partner, Sony
Corporation has determined that this product
meets the ENERGY STAR®guidelines for
energy efficiency.
ENERGY STAR®is a U.S. registered mark.
This TV incorporates High-
Definition Multimedia Interface
(HDMI™) technology. HDMI, the HDMI logo and High-
Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
This TV is manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
SXRD “BRAVIA” and , BRAVIA ENGINE EX, “XMB”
and “XrossMediaBar”, S-Force, BRAVIA Theatre Sync, , DMx,
BRAVIA Internet Video Link Ready and “PS3” are trademarks
or registered marks of Sony Corporation and/or
Sony Computer Entertainment Inc.

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
5
KDS-50A3000 KDS-55A3000 KDS-60A3000
S
p
eaker Out
p
ut
(
W
)
S
p
eaker Dimension
mm
in
Dimensions (W x H x D)
mm 1150 x 850 x 365 mm 1260 x 920 x 395 mm 1370 x 985 x 425 mm
in 45 3/8 x 33 1/2 x 14 3/8 in 49 5/8 x 36 1/4 x 15 5/8 in 54 x 38 7/8 x 16 3/4 in
Mass
kg 34 kg 37 kg 41 kg
lbs 75 lbs 81.10 lbs 90.7 lbs
12W + 12W
27/8 x 5 1/8 in
70 x 130 mm
All measurements are approximations
Television system
American TV standard, NTSC
ATSC Compliant 8VSB, ATSC (8VSB terrestrial)
ANSI/SCTE 07 2000, QAM on cable
Channel coverage
Terrestrial 2-69/ Cable TV: 1-125 (analog)
Terrestrial 2-69/ Cable TV: 1-135 (digital)
Screen Size (measured diagonally)
KDS-50A3000 - approximately 50 inches
KDS-55A3000 - approximately 55 inches
KDS-60A3000 - approximately 60 inches
Antenna
75-ohm external antenna terminal for VHF/UHF
Projection System
3 SXRD Panels, 1 lens projection system
SXRD Panel System
High Frame Rate Compatible 0.61 inch panel Ful HD SXRD device
Projection Lens
High Performance, large diameter hybrid lens F2.5
Lamp
120W, XL-5200 Ultra High Pressure Lamp
Supplied Accessories
Remote Commander RM-YD016
Two Size AA (R6) Batteries
Operating Instructions
Quick Setup Guide
Warranty Card
Online Registration Card
Optional Accessories
Lamp
XL-5200 Ultra High Pressure Lamp
TV Stand
SU-RS12X

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
6
WARNINGS AND CAUTIONS
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualified to do so.
CARRYING THE TV
Carrying the TV requires at least two people. Do not hold
by the pedestal or the front panel of the TV. Doing so may
cause these parts to break off.
If you have connected cables and cords, be sure to
unplug them before moving the TV. When moving the TV,
KDS-50A3000 KDS-55A3000/ KDS-60A3000
place one hand in the hole
on the lower portion of the
TV while grasping the top
with the other hand.
place one hand to the
lower portion of the front
cabinet while grasping the
top with the other hand.
Do not grasp the
pedestal or the front
panel of the TV.
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this receiver is
directly connected to the AC power line.
!SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace
these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that
are critical for safe operation are identified in this manual. Follow these procedures whenever critical components are replaced or improper operation is
suspected.
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifié seulement. Pour prévenir le risque de choc électrique, ne pas faire
l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifié faire ainsi.
TRANSPORTER LE TÉLÉVISEUR
Le transport du téléviseur doit être effectué par au
moins deux personnes. Ne tenez pas le téléviseur
par son socle ni par le panneau avant. Ces pièces
risqueraient de se détacher.
Si vous avez branché les câbles et les cordons d’alimentatio
n
veillez à les débrancher avant de déplacer le téléviseur.
Lorsque vous déplacez le téléviseur,
Ne saisissez pas le
téléviseur par son socle
ni par le panneau avant.
KDS-50A3000 KDS-55A3000/ KDS-60A3000
placez une main dans l’orifice
de la partie inférieure du boîti
e
arrière tout en maintenant la
partie supérieure de l’autre m
a
placez une main sur la partie
inférieure du boîtier avant
tout en maintenant la partie
supérieure de l’autre main.
Afin d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage. Le
chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
!ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une
importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le
present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement
sont identifies dans le present manuel. Suivre ces procedures lors de chaque remplacement de composants critiques, ou lorsqu’un mauvais
fonctionnement suspecte.

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
7
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the B+ and HV to see if they are specified values. Make sure
your instruments are accurate; be suspicious of your HV meter if sets
always have low HV.
8. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 μF
Earth Ground
AC
Voltmeter
(0.75V)
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
8
SELF-DIAGNOSTIC FUNCTION
Self Diagnosis
Supported model
The units in this manual contain a self-diagnostic function. If an error occurs, the POWER LED will automatically begin to flash. The number of times
the LED flashes translates to a probable source of the problem. A definition of the POWER LED flash indicators is listed in the instruction manual for
the user’s knowledge and reference. If an error symptom is difficult to reproduced use the Remote Commander to display the record that is stored at
the internal NVM to specify the cause of the failure.
Diagnostic Test Indicators
When an error occurs, the POWER LED will flash a set number of times to indicate the possible cause of the problem. If there is more than one
error, the POWER LED will identify the first of the problem areas. If the errors occur simultaneously, the one that corresponds to the fewest flashes is
identified first.
Results for all of the following diagnostic items are displayed on screen. (No error has occurred if the screen displays a “0”.)
NUMBER OF TIMES
LED BLINKS
SELF
CHECK
CODE
DIAGNOSIS ITEM POSSIBLE CAUSE POSSIBLE SOLUTION
2 times POW_OVP Power OVP 7V is over voltage Check CN6903 on G Board
3 times POW_ERR1 Power Error 12V is not supplied Check CN6903 on G Board
5 times LAMP_DRV Lamp Driver Problem with the
lamp driver
Check Power Supply (Ballast)
400V (CN6501 on G Board)
Check IC4001 on FB1A Board
6 times COVER Lamp Cover Lamp cover is not securely
attached
Secure Lamp Door.
Verify harness is connected
to T Board.
7 times TEMP_ERR Temperature Over Inner temperature is too high Remove dust from fan and
ventilation is clear.
8 times AUD_PROT Audio Protect Error Short in speaker line Check A Board or replace speaker
9 times FAN_ERR Fan Error
Fan is not getting power.
Fan connector is not securely
attached.
Secure harness to fan.
Check CN4001 or CN5602 on FB1A
Board.
Check CN6900 on G Board.
10 times DTT_ERR Microprocessor Error
DTT_WDT
(Watch Dog Timer) Check FB1A Board
11 times DEV_ERR Device Error I2C Communication Error Check S2, H2, and C Boad and all
connection to the FB1A Board
LAMP-LED flashes Lamp Error Lamp needs to be replaced. Change the lamp.
DISPLAY OF POWER LED OR LAMP LED FLASH COUNT
TIMER
LAMP POWER
Screen
☛

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
9
-Example
Diagnosis Number of times LED Flashes
3 times
Lamp Cover 6 times
LED ON : 0.3sec
LED OFF : 0.3sec LED OFF
3.0sec
LED OFF
3.0sec
Power Error
NOTE: 4 Flashes is not used for self-diagnosis
RELEASING THE POWER LED LASH
Unplug the power cord from the outlet to temporarily stop the POWER LED lamp from flashing.
Self-Diagnostic Screen Display
For failures that are difficult to reproduce, or accompany occasional power off and/or picture mute, the Self-Diagnostic Self Check screen display is
useful to specify the cause.
VIEWING THE SELF-DIAGNOSTIC SELF CHECK SCREEN
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a second of each other:
DISPLAY Channel
5 Volume -
POWER
NOTE: This differs from the method of accessing service mode which is Volume +
Sample Self-Diagnostic Screen Display
alpsiDDEL
y
nmuloCrotacidnInoitamrofnI
PVO_WOP:20000
1RRE_WOP:300 ------------------------------------ 00
VRD_PMAL:500 ------------------------------------ 00
REVOC:600 ------------------------------------ detcetedsawrorrenasetacidni110
RRE_PMET:700
528111113043211321401180121050
detcetedsawrorreonsetacidni000
TORP_DUA:800 ------------------------------------ 00
RRE_NAF:900 ------------------------------------ 00
RRE_TTD:010 ------------------------------------ 00
RRE_VED:110 ------------------------------------ 00
:310 ------------------------------------ 00
TDW_TTD:101 ------------------------------------ 00 sremiTgoDhctaW-TDW*
TDW_MVT:201 ------------------------------------ sremiTgoDhctaW(*00
TDW_MEB:301 ------------------------------------ kcartotdesuera00
,srossecorporcim00RRE_PMAL:552
).srorredrocerotton
emitnoitarepodnatnuoctooB
KCEHCFLES
21000-21000-82000-31000
------------------------------------
Displays Time of last 3 events
Total hours of operations
(max 65535)
Total Panel hours
(max 65535)
Boot count (max 65535) Total lamp hours
NOTE: To refresh the Self Check menu when all the items are not displayed, press JUMP on the Remote Commander.
CLEARING THE SELF-DIAGNOSTIC SCREEN
The self-diagnostic results displayed on the screen are not cleared automatically, therefore you should always check the self-diagnostic screen during
repairs. When you have completed the repairs, clear the self-diagnostic screen to reset the results to “0”.
Note: The self-diagnostic function will not be able to detect any subsequent faults after completion of the repairs unless the Self-Diagnostic
result display is cleared to reset the results to “0”.
1. If the Self-Diagnostic screen is already displayed, proceed to step 3. If not, Power off (Set to Standby mode).
2. Press DISPLAY Channel
5 Volume -
POWER
3. Press Channel 8
0 The status resets to 0.
4. To exit the Self-Diagnostic screen, turn the power off.
☛

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
10
SECTION 1: DISASSEMBLY
1-1. LAMP REMOVAL
1Remove the Lamp Cover and the Lamp Door Assembly.
2Gently pull out Lamp Block assembly from the TV.
1-2. SCREEN FRAME ASSEMBLY AND SPEAKER GRILLE ASSEMBLY REMOVAL
1Loosen the 2 Ornamental Screws (one from each side).
2Pull off the Speaker Grille Assembly from the
Screen Frame Assembly.
3Remove 2 screws from the Screen Frame Assembly,
+BVTP2 4x16
For detailed instructions refer to Appendix B: Replacing the Lamp, at the back of this manual.
Lamp
Lamp Cover
Lamp Door Assembly
1
2
2
1
3
Speaker Grille Assembly
Screen Frame Assembly
Rear Cabinet
Ornamental Screw
☛

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
11
1-3. REAR COVER REMOVAL AND H1 BOARD BRACKET REMOVAL
1-3-1. SIDE COVER REMOVAL (KDS-50A3000 ONLY)
1Remove 12 screws from the Rear Cabinet,
+BVTP2 4x16
2Remove 2 screws from the Side Control Bracket,
+BVTP2 4x16
3Remove 1 screws from the H1 Board,
+BVTP 3x12 TYPE2 IT-3
4Release one connector.
1Remove 4 screws from the Side Covers (2 from each side),
+BVTP2 4x16
Screen Frame Assembly
Rear Cabinet
Side Control
Bracket
H1 Board
1
2
3
4
Rear Cabinet
1
1
Side Cover (R)
Side Cover (L)
☛

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
12
1-4. H2 BOARD, SPEAKER, AND SEPARATOR REMOVAL
1-5. FRONT BRACKET REMOVAL
1Disconnect joint connector from the H2 board.
2Remove 2 screws for H2 board removal,
+BVTP 3x12 TYPE2 IT-3
3Disconnect joint connector from the Speakers.
4Remove 4 screws from the Speakers, +BWTP2 4x16
5Remove 6 screws from the Separator, +BVTP2 4x16
6Lift two tabs and slide out the Separator unit.
1Release all connector wire from Clamps on the Front Bracket.
2Remove 2 screws from the Duct and the TUU2 Shield,
+BVST 3x6
3Remove 2 screws from the Chassis block,
+BVTP2 4x16
6
4
3
2
1
5
Rear Cabinet
Separater
Speaker
Speaker
H2 Board
1
3
2
Duct (Front)
FB1 Shield (Bottom)
TUU2 Shield
Front Bracket
☛
☛

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
13
1-6. OPTICS BLOCK ASSEMBLY AND LAMP DUCT REMOVAL
1-6-1. LAMP DUCT BLOCK DISASSMBLY
1Remove 1 screw from the Adjuster Cover,
+PVTP2 4x16
2Remove 2 screws from the Adjuster Block and
the Supporter, +PWHTP2 4x25
3Remove 2 screws from the Lamp Duct, +PVTP2
4x16
4Gently pull out Optics Block from cabinet.
Caution: When replacing the Optics Unit Block
Assembly be sure to remove any dust particles.
1Remove 1 screw from the Upper Duct,
+BVTP2 4x16
2Disconnect 2 connectors from the Power
Supply (Ballast Unit).
3Remove 1 screw from the Power Supply,
+BVTP2 4x16
4Remove 1 screw from the
Power Supply, +BVTP2 4x16
5Using caution not to damage the
HV wires, push the HV Cable through
the Plug Holder.
(See Appendix C for illustrations.)
Note: To remove each duct, gently lift the tabs to
release from the hooks.
6Carefully detach from the Optics Block.
7Remove 1 screw from the T board,
+BVTP 3x12 TYPE2 IT-3
8Disconnect 1 connector from the T board.
9Disconnect 1 connector from the S2 board.
10 Remove 2 screws from the Fuse Holder,
+BVTP 3x12 TYPE2 IT-3
3
4
1
2
Lamp Duct Unit
Adjuster Cover
Adjuster Supporter (V)
Adjuster
Block (V)
Adjuster Plate (H)
Optics Block
D.C. Fan (80x80)
Turn Rivet
Optics Block
Note:The D.C. Fan is secured to the Optics Block Assembly with Turn Rivet screws.
To remove these screws use a screw driver to unscrew the screw until it lifts slightly
above the rivet then pull the screw and the rivet out from the fan.
(Refer to the illustration to the left.)
☛
☛
2
1
3
9
10
4
5
68
7
Exhaust Duct (L)
Fan (DC Motor)
Fan Cushion
Power Supply
(Ballast Unit)
Fuse Holder
S2 Board
Fuse Sheet
Fuse Plate
2P Connector
(Thermal Fuse)
Intake Duct (F)
Lamp Duct (F)
Plug Holder
HV Cable (Ballast Plug)
Lamp Duct (R)
T Board
Exhaust Duct (U)
Optics Block

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
14
1-7. CHASSIS REMOVAL
2
1
FB1A Block Assembly
AC Bracket
(F Board Bracket)
Chassis Block
1Remove 2 screws from the Rear Cabinet and the
AC Bracket, +BVTP 3x12 TYPE2 IT-3
2Remove 2 screws from the FB1A Block Assembly,
+BVTP2 4x16
7
8
9
13
14
6
4
3
5
10
11
12
Fan Bracket
G Board
A Board
D.C. Fan (60x60)
Turn Rivet
Terminal Bracket
U Board
G Bracket
AU Shield
BC Board
BC Shield
FB1 Block
TUU2 Block
F Board
3G Board – Disconnect 6 connectors then remove 6 screws, +BVTP 3x12 TYPE2 IT-3
4Fan Bracket – Disconnect 1 Connector then remove 2 screws, +BVTP2 4x16
5Turn Rivet – Unscrew and carefully pull out from the fan to release it from the shield.
Note: The fan is secured to the Chassis Assembly with Turn Rivet screws. To remove these screws use a screw driver to unscrew the
screw until it lifts slightly above the rivet then pull the screw and the rivet out from the fan.
6A Board – Disconnect 2 connectors then remove 3 screws, +BVST3x6, and pull out from the FB1A Block Assembly connector
7F Board – Disconnect 2 connectors then remove 2 screws, +BVST 3x6
8TUU2 Block – Release the RF connector
9FB1A Block Assembly – Disconnect 6 connectors
10 BC Board – Disconnect 2 connectors then remove 2 screws, +BVST 3x6
11 BC Shield – Remove 3 screws, +BVST 3x6
12 G Bracket – Remove 6 screws, +BVST 3x6, then remove the AU Shield by removing 1 screw, +BVST 3x6
13 U Board – Disconnect 1 connector, remove 2 screws +BVST 3x6, and pull out from FB1A Block Assembly connector
14 Terminal Bracket - Remove 3 screws, +PSW M3x8, 5 screws, + BVTP 3x12 TYPE2 IT-3, and 1 Hex Nut and 1 Washer
Caution: When replacing any part of the chassis be sure to remove any dust particles and clean the mirror.

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
15
1-8. DIFFUSION PLATES (SCREENS) REMOVAL
1Remove a total of 12 screws, +BVTP2 4x16
2 screws from the Top Holder,
8 screws from the Bottom Holder and
1 screw from each of the side holders.
2Gently pull the screens from the Screen Frame Assembly
to dislodge from the double sided tape.
CAUTION:
The screens are adhered to the Screen Frame Assembly with double sided tape (3-275-118-21). After removing the screens, use rubbing
alcohol to gently clean the area to remove any excess tape. The double sided tape must be replaced before mounting the screens to the
Screen Frame Assembly to ensure that they are securely attached. The illustration below indicates the approximate location of the double
-side tape. For complete details, refer to the Sony Electronics Service Information website.
Diffusion Plate
(Lenticular - Front side)
TAPE, PE 100
(3-275-116-01)
1 piece on each corner area Diffusion Plate
(Frensnel - Rear side)
Note:
The following diagram illustrate the taping method when replacing the diffusion Plates.
For Part Numbers refer to the Explode view section of this manual.
Screen Holders
Diffusion Plates
Screen Frame Assembly
Double Sided Tape
(10mm x 100mm)
Double Sided Tape
(2 pieces, 1 piece on each side)
2 x (10mm x 500mm) (KDS-50A3000 Only)
2 x (10mm x 550mm) (KDS-55A3000/60A3000 Only)
1
2

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
16
1-9. MIRROR REMOVAL
Rear Cabinet
Mirror
Mirror Edge Guard
Mirror Edge Guard
Mirror Edge Guard
Mirror Holder
1
1Remove 6 screws (KDS-50/55A3000 Only),
8 screws (KDS-60A3000 Only), +BVTP2 4x16
NOTE: Order the same part number to replace Top & Side Mirror Edge Guards.
Refer to the Exploded View section of this manual for part number information.
Caution:
- Holder screws should be tightened from the center to the outer screw positions.
☛

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
17
2-1. USING THE REMOTE COMMANDER
FOR ELECTRICAL ADJUSTMENTS
To adjust various set features, use the Remote Commander to put the
set into service mode to display the service menus and categories.
Equipment Needed:
Pattern Generator (with component outputs)
Oscilloscope
Digital multimeter
2-2. ACCESSING SERVICE ADJUSTMENT
MODE
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a
second of each other:
DISPLAY Channel
5Volume
+
POWER .
Displays
Service Menus
DISPLAY
VOLUME (+)
TV POWER
JUMP
RM-YD016
Onscreen cursor
and select button
5
The first service menu (TV) displays.
SECTION 2: CIRCUIT ADJUSTMENTS
2-3. VIEWING THE SERVICE MENUS
Use the Remote Commander to view the BE and Digital service menus
options.
1. To display the Service Menu that contains the Category you want to
adjust, press JUMP on the Remote Commander.
(For a complete list of the service Categories refer to Service Menus)
CHASSIS SERVICE
000 GR
000 GRMD 0
SUB SERVICE
000 VERS
000 MODEL
MODEL ID: XXXXXXXXXX
Press JUMP
BEM SERVICE
BOOT: 1. 001W00AU
MAIN: 1. 010W00AU
DATA: 1. 011A00SUA
NVM: 1. 011
Press JUMP
Press JUMP
DIGITAL
001 OP 000000 VERS
<SUB><DIGITAL> SM1. 009W00AADM1. 103A00SA SD1. 003W00AADD0. 000A00LU SB1. 002W00AA
<BE>
BM1. 010W00AU
BD1. 011A00SUA
BB1. 001W00AU
M2. 001C
Press JUMP
SERVICE
Sample Service Menu

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
18
2-4. USING THE REMOTE COMMANDER TO
VIEW SERVICE DATA
Use the buttons on the Remote Commander to access the service menu
items and adjust the data values.
VCENT
BEM SERVICE
0003 6
0016 TG
DIFF 1
Service
Menu
Category
Adjustment
Item
Item
Numbers Data Value
RM-YD016
Display
Next Category
Display
Previous Item
Increase
Data Value
Decrease
Data Value
Display
Previous
Category
Display
Next Item
Displays
Service Menus
MUTING
JUMP
Saves data
Writes data
into memory
Read data
9
0
5
6
3
1
2
4
2-5. ADJUSTING H/V CENTER
Check the picture horizontal/vertical center after replacing the Optics
Unit Block or Rear Cover.
1. Check the H/V center using a 480i monoscope signal with the TV in
“FULL’ model.
2. If the center is shifted, proceed to step 3.
3. Access the Service Menu by pressing the following buttons on the
Remote Commander within a second:
DISPLAY Channel
5Volume
+
TV POWER .
The service menu displays.
4. Press the JUMP button until the BEM micro service menu displays.
BEM SERVICE
BOOT: 1. 001W00AU
MAIN: 1. 010W00AU
DATA: 1. 011A00SUA
NVM: 1. 011
5. Press 2until the 0016 TG category displays.
BEM SERVICE
0001 0
0016 TG
DIFF 1
6. Press 1until the 0003 VCENT item displays.
VCENT
BEM SERVICE
0003 6
0016 TG
DIFF 1
7. Press 3to increase (shift VCENT up), or press 6to decrease the
value (shift VCENT down) until the correct adjustment is set.
8. Press 1until the 0004 HCENT item displays.
0004 5HCENT
BEM SERVICE
0016 TG
DIFF 1
9. Press 3to increase (shift HCENT right), or press 6to decrease the
value (shift HCENT left) until the correct adjustment is set.
10.To write into memory, press MUTING then 0on the Remote
Commander.
2-6. EXITING SERVICE MODE
After completing the changes, exit service mode.
1. To exit service mode, turn the power off by pressing POWER .
Wait 2 minutes before restarting the set to allow the fans to
completely shut down or the Service Menu will appear on the screen.

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
19
SECTION 3: DIAGRAMS
3-1. CIRCUIT BOARDS LOCATION
3-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS INFORMATION
All voltages are in V.
S : Measurement impossibility.
: B+line.
: B-line. (Actual measured value may be different).
: signal path. (RF)
Circled numbers are waveform references.
The components identified by shading and
!
symbol are critical for safety. Replace
only with part number specified.
The symbol indicates a fast operating fuse and is displayed on the component
side of the board. Replace only with fuse of the same rating as marked.
Les composants identifies per un trame et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une piece portant le numero specifie.
Le symbole indique une fusible a action rapide. Doit etre remplace par une
fusible de meme yaleur, comme maque.
NOTE: The components identified by a red outline and a mark contain confidential
information. Specific instructions must be adhered to whenever these components
are repaired and/or replaced.
See Appendix A: Encryption Key Components in the back of this manual.
All capacitors are in μF unless otherwise noted. pF : μμF 50WV or
less are not indicated except for electrolytics and tantalums.
All electrolytics are in 50V unless otherwise specified.
All resistors are in ohms. kΩ=1000Ω, MΩ=1000kΩ
Indication of resistance, which does not have one for rating
electrical power, is as follows: Pitch : 5mm
Rating electrical power :
1/4 W
1/4 W in resistance, 1/10 W and 1/16 W in chip resistance.
: nonflammable resistor
: fusible resistor
: internal component
: panel designation and adjustment for repair
: earth ground
: earth-chassis
All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
Readings are taken with a color-bar signal input.
Readings are taken with a 10MΩdigital multimeter.
Voltages are DC with respect to ground unless otherwise noted.
Voltage variations may be noted due to normal production
tolerances.
OPTICS BLOCK ASSEMBLY
(Includes the C Board)
T
S2
H2
BC
F
A
U
G
FB1A
TUU2
H1

KDS-50A3000/55A3000/60A3000
KDS-50A3000/55A3000/60A3000
20
REFERENCE INFORMATION
RESISTOR
: RN METAL FILM
: RC SOLID
: FPRD NONFLAMMABLE CARBON
: FUSE NONFLAMMABLE FUSIBLE
: RW NONFLAMMABLE WIREWOUND
: RS NONFLAMMABLE METAL OXIDE
: RB NONFLAMMABLE CEMENT
: ADJUSTMENT RESISTOR
COIL
: LF-8L MICRO INDUCTOR
CAPACITOR
: TA TANTALUM
: PS STYROL
: PP POLYPROPYLENE
: PT MYLAR
: MPS METALIZED POLYESTER
: MPP METALIZED POLYPROPYLENE
: ALB BIPOLAR
: ALT HIGH TEMPERATURE
: ALR HIGH RIPPLE
G
D
S
B1 E1C2
B2 C1
E2
2
3
4
5
6
7
8
9
0
qa
qs
qf
qh
qj
qk
–
1
G
D
S
B2 E2C1
B1 C2
E1
B2 E2
C1
B1 C2E1
B2 E2
C1
B1 C2E1
ql
B1 E1
E2
C1(B2)C2
w;
B1
E2
C1
C2
ws
wd
(B2)
E1
(B2)
E1
E2
B1
C2C1
wa
B1
E1
C2
B2
C1
E2
G
SS
D
G
D
B1
E1
C2
B2
C1
E2
B1
E2
C2C1(B2)
E2
B1
C1
C2E1(B2)
C2
B1
C1
E2E1(B2)
C2
B1
C1
E2
B2
E1
C2
Ver.1.5
Transistor
(FET)
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Transistor
Discrete semiconductot
(
Chip semiconductors that are not actuall
y
used are included.
)
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Diode
Source
Source
Anode Anode
(NC)
(NC)
Cathode
Anode
Cathode
Common
Cathode Cathode
Common
Cathode Cathode
Common
Common
Common
Common
Cathode
Anode
Base Emitter
Collector
Base Emitter
Collector
Drain
Gate
Gate
Drain
Device Printed symbol Terminal name Circuit
Terminal name of semiconductors in silk screen
printed circuit ( )
Anode
Anode
Anode Cathode
Anode Anode
Cathode
qd
Transistor
(FET)
Transistor
(FET)
qg
Emitter
Collector
Base
Transistor
Source
Gate
Drain
Cathode
Anode
Anode Cathode
Anode
Anode
*
