KDS-R60XBR2
60" Class SXRD XBR Rear Projection Television (59.5" diagonal)
Key Features
Full HD(1920 x 1080) Picture Resolution with SXRD Panel
3 SXRD Panels(R/G/B), over 2 Million Pixels Each
Contrast Ratio up to 10000:1 with Advanced Iris
1080p Input, HDMI™x3 (1080p) & Front Component (1080p)
Full Digital Signal Processing with WEGA Engine ™HD.
HDMI In x2 (1080p); Component In; (1080i) PC In
Full HD 1080 (1920 x 1080/0.61 ” SXRD chip) Picture Resolution
WEGA Engine ™HD System
DRC MF-V2.5
Contrast Ratio up to 10000:1 with Advanced Iris function
Key Technologies
Cinema Black Pro The Advanced Iris function is a special Sony function designed to improve contrast expression
especially in darker scenes. The Advanced Iris function is enabled by using either one of two modes, Auto and Manual.
The Auto Mode has two settings designed to work best with video content such as movies that vary between bright
scenes and dark scenes. Auto 1 is for programs that have a wide range of brightness from scene to scene. Auto 2 is for
programs that have less variation between brightness levels from scene to scene.
HDMI™and PC Inputs Designed for maximum versatility, Sony ’ s Grand WEGA™XBR ® line is equipped with a
comprehensive range of input interfaces. The HDMI (High - Definition Multimedia Interface) is the first industry -
supported, uncompressed, all - digital audio/video interface. HDMI technology supports enhanced or High Definition
video, together with multi - channel digital audio to provide matchless image and sound reproduction. The PC input (D -
Sub 15) offers easy connection to your PC, allowing you to use your high resolution Grand WEGA XBR TV as a computer
monitor.
SXRD™Panels Experience what a high - end Full HD 1080p experience is like. A blistering 5ms total panel response
time (rise + fall) renders fast action , the three - panel SXRD design exceeds the demands of even the most rapidly
moving high definition images for a remarkably smooth, film - like image.
WEGA Engine™HD Get unparalleled picture quality from any video source. Sony ’ s unique Digital Reality Creation
Multifunction picture enhancement circuit (DRC - MFv2.5) converts standard video to high definition quality. WEGA
Engine ™HD also reduces unwanted digital artifacts, maximizes picture performance and enhances color
performance. The result: crisp details, bold contrast, and eye - popping colors for a picture so real it ’ s like you ’ re there.
Advanced Iris Deep blacks and excellent brightness are very important elements in achieving good picture quality.
Sony ’ s special Advanced Iris function plays an important role in helping achieve it. This function dynamically adjusts
the iris to optimize contrast levels. It works with any video content under a variety of viewing environments.
HDMI™and PC Connectivity Maximum versatility from a comprehensive range of input interfaces. HDMI (High -
Definition Multimedia Interface) input supports enhanced or high definition video along with multi - channel digital
audio for excellent image and sound reproduction. PC input (HD - 15 - pin) offers easy connection to your PC, so you can
use your high resolution TV as a computer monitor .
5
Changeable Designer Color Bezels (sold separately) Add a touch of personalstyle with these designer
accessories. Choose from five colors and complement any dé cor.

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 800.222.7669 • www.sony.com
Last Updated: 05/23/2008
KDS-R60XBR2
60" Class SXRD XBR Rear Projection Television (59.5" diagonal)
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
ChannelFix: Yes
VideoLabel: Yes
Closed Captions (CC): Yes
Video
VideoProcessing: Yes (WEGA Engine™HD
System)
ColorTemperature: Cool, Neutral, Warm
NoiseReduction: Yes
BlackCorrector: High, Medium, Low, Off
ClearWhite: On, Off
GammaCompensation: High, Medium,
Low, Off
CineMotion ® Reverse 3:2 Pulldown
Technology: Yes
Direct Digital II Circuitry: Yes
AdvancedIris: Yes
Display Mode for PC Input: Video, Text
DRC ® MultiFunctionCircuitry: Yes (DRC MF
V2.5)
DRC ® Mode: Mode 1, Mode 2, CineMotion ®
Technology
DRC ® PalettePresets: Custom 1, Custom
2, Custom 3
DirectMode: On, Off
GameMode: On/Off
Advanced Video Menu: Yes
PictureModes: Vivid, Standard, Pro
DetailEnhancer: High, Medium, Low, Off
ColorSystem: ATSC, NTSC
DisplayTechnology: SXRD™Technology
HighDefinition: Yes (Full HD 1080)
3D Comb Filter: Yes
Live Color Creation™ Technology: Yes
Audio
MTS Stereo Decoder: Yes
AudioMute: Yes
SimulatedSurround: Yes
AutoSAP: Yes
Steady Sound ® AutomaticVolume
Control: Yes
Dolby ® : Dolby ® Digital (AC3/ATSC only)
Convenience
FavoriteChannel: Yes
Speed Surf™ChannelSelection: Yes
Program Guide Access: Yes
Parental Control (V - Chip): Yes
InfoBanner: Yes
ProgrammableTimer: Yes
SleepTimer: 15, 30, 45, 60, 90, Off
TimerEvents: Timer 1, Timer 2
Power Save Mode: Standard, Reduced,
Picture Off
Twin - View™ Technology: Yes
RemoteControl: Yes
ID - 1Detection: Yes
Specifications
General
AspectRatio: 16:9
TelevisionType: Micro Display HDTV
Display
Screen Size (measured diagonally): 60"
class (59.5")
NativeResolution: 1920 x 1080
DisplayResolution: 1920 x 1080p (Full HD)
TV System
Tuner(Cable): Clear QAM, CableCARD™
QAM
Tuner(Terrestrial): NTSC, ATSC (8 VSB)
Video
Display Response Time: 2.5ms (rise and
fall)
VerticalSize: Yes
VerticalCenter: Yes
HorizontalCenter: Yes
Audio
Audio Power Output: 30W (15W x2)
Inputs and Outputs
CableCARD™ Slot: 1 (Rear)
Component Video (Y/Pb/Pr ) Input(s): 2
(Rear)
Composite Video Input(s): 3 (1 Front/2
Rear)
Control - SInput(s): 1 (Rear)
Control - SOutput(s): 1 (Rear)
Digital Audio Output(s): 1 (Rear) Dolby ®
Digital Optical Output
RF Connection Input(s): 2 (Rear)
S- VideoInput(s): 1 (Rear)
PC Audio Input(s): 1 (Rear)
PC Video Input(s): 1 (Rear)
Analog Audio Input(s) (Total): 5 (1
Front/4 Rear)
AudioOut: 1 (Rear)
HDMI™Connection(s)(Total): 3 (2 Rear/1
Side)
HDMI™Connection(s) (w/ Analog Audio
In): 1 rear input included L/R audio inputs
Power
Power Consumption (in Operation): 285W
Power Consumption (in Standby): 0.2W
(without CableCARD)
PowerManagement: Yes
Power Requirements (voltage): AC 120V,
60Hz
Regulation and Standard
Compliance
Energy Star ® Compliant: Yes
5
5
Service and Warranty Information
LimitedWarranty: 1 Year Parts / 1 Year
Labor
Dimensions
Weight: 112.44lbs (51kg)
Supplied Accessories
Remote Control (RM - Y009)
XL - 5300 (extra lamp included)
Operating Instructions
Quick Start Guide
Batteries (AA x2)
Limited Warranty
Product Registration Card
Optional Accessories
SU - RS51U (AV Stand)
XL - 5300 (180W Replacement Lamp)
UPC Code: 027242697805
1.WithAdvancedIrisON
2.Dependingon usage, the lamp will require periodic replacement to
maintainoptimumpicturequality.Itisrecommendedthatthelamp
be exchanged after 8,000 hours of use.
3.Screen Size measured diagonally
4.Foradditionalwarrantytermsandinformationpleaserefertothe
LimitedWarrantyCardincludedwiththisproduct or visit
http://esupport.sony.com
5.Limitedtoresolutionssupportedbyboth the PC and the Sony TV. See
SonyTVusersmanualandPC documentation for supported
resolutions
©2006SonyElectronicsInc.Allrightsreserved.
Sony,Grand WEGA, Steady Sound,WEGAEngineHD, Speed Surf, SXRD,
CineMotionandDRCaretrademarks of Sony. In the United States, TV
GuideandotherrelatedmarksareregisteredmarksofGemstar - TVGuide
International,Inc.and/or one of its affiliates. CableCARD is atrademarkof
CableTelevisionLaboratories,Inc. SRS and the SRS symbol, and
TruSurroundare trademarks of SRS Labs, Inc. This TV incorporatesHigh -
DefinitionMultimediaInterface(HDMI™ ) technology.HDMI,theHDMI
logo and High - DefinitionMultimedia Interfacearetrademarks or
registeredtrademarks of HDMI LicensingLLC.Allother trademarks are
propertyoftheirrespectiveowners.
Features and specifications are subject to change without notice. Non -
metricweights and measures are approximate.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddue to environmental considerations. For disposal or
recyclinginformation,pleasecontact your local authorities or the
ElectronicIndustries Alliance (www.eiae.org)
