Sony KP-44PX2 User manual

- 1 -
KP-44PX2/44PX2U
RM-938
SERVICE MANUAL AE-6X CHASSIS
MODEL COMMANDER DEST CHASSIS NO.
KP-44PX2 RM-938 AEP SCC-Q85C-A
MODEL COMMANDER DEST CHASSIS NO.
PROJECTION TV
RM-938
KP-44PX2U RM-938 UK SCC-Q84G-A
KP-44PX2

- 2 -
KP-44PX2/44PX2U
RM-938
TABLE OF CONTENTS
Section Title Page Section Title Page
Specifications ...................................................... 3
Connectors .......................................................... 4
1. SELF DIAGNOSIS FUNCTION
1-1. AE-6X Self Diagnostic Software ....................... 5
2. GENERAL ................................................................... 6
3. DISASSEMBLY
3-1. Rear Board Removal .......................................... 15
3-2. Main Bracket Block Removal ............................ 15
3-3. Service Position ................................................. 15
3-4. Front Panel Removal ......................................... 15
3-5. Resistor Assembly (Focus Pack) Removal ....... 16
3-6. H1 and H3 Board Removal ................................ 16
3-7. Beznet Block Removal ....................................... 17
3-8. High Voltage Cable Removal and Installation .... 17
3-9. AP and D Board Removal .................................. 17
3-10. Terminal Board Removal .................................... 18
3-11. G Board Removal ............................................... 18
3-12. A Board Removal ............................................... 19
3-13. Chassis Block Removal ...................................... 19
3-14. Picture Tube Removal ......................................... 19
4. SET-UP ADJUSTMENTS
4-1. Screen Voltage Adjustment
(Rough Alignment) ............................................ 20
4-2. Screen (G2) Adjustment .................................... 20
4-3. Focus Rough Adjustment .................................. 20
4-4. Deflection Yoke Tilt Adjustment ........................ 20
4-5. 2-Pole Magnet Adjustment ................................. 21
4-6. 4-Pole Magnet Adjustment ................................. 21
4-7. Green, Red and Blue Focus Adjustment ............ 21
5. SAFETY RELATED ADJUSTMENT
5-1. HV Hold-Down Adjustment ............................. 22
6. ELECTRICAL ADJUSTMENTS
6-1. Adjustments with Commander ........................... 23
6-1-1. How to Select Each Mode .............................. 23
6-1-2. Programming the Remote Commander
for Operation in Service Mode ....................... 23
6-1-3. Setting the TV into Service Mode .................. 23
6-1-4. Screen Display for Service Menu .................. 24
6-1-5. Service List (Projector Engine) ...................... 25
6-2. Registration Adjustment ................................................ 27
6-2-1. Setup for Adjustment ..................................... 27
6-2-2. Main Deflection Adjustment .......................... 27
6-2-3. Operation Method for
Projector Engine Mode ................................... 28
6-2-4. Projector Engine Adjustment
(Sub Deflection Adjustment) .......................... 29
6-3. Auto Convergence Offset ................................... 31
6-4. White Balance Adjustment .................................. 31
6-5. Sub Bright Adjustment ....................................... 31
6-6. Sub Color Adjustment ........................................ 31
6-7. Auto Convergence Error Code List .................... 32
6-8. Test-Test Mode ................................................... 33
7. DIAGRAMS
7-1. Block Diagrams .................................................. 35
7-2. Circuit Boards Location ...................................... 40
7-3. Schematic Diagrams and Printed Wiring
Boards ................................................................. 40
A Board Schematic Diagram (1/2) .................... 41
A Board Schematic Diagram (2/2) ................... 42
A Printed Wiring Board .................................... 43
AP Board Schematic Diagram ............................ 45
AP Printed Wiring Board ................................. 49
D Board Schematic Diagram .............................. 46
D Printed Wiring Board .................................... 50
G Board Schematic Diagram .............................. 52
G Printed Wiring Board .................................... 51
M2 Board Schematic Diagram ............................ 53
M2 Printed Wiring Board ................................. 54
CB, ZB, H1 and H3 Board
Schematic Diagrams ........................................... 55
CB, ZB, H1 and H3 Printed Wiring Boards .... 54
CG, ZG and H2 Board Schematic Diagrams ..... 56
CG, ZG and H2 Printed Wiring Boards ........... 57
CR and ZR Board Schematic Diagrams ............. 58
CR and ZR Printed Wiring Boards ................... 57
7-5. Semiconductors .................................................. 59
7-6. IC Block Diagrams ............................................. 62
8. EXPLODED VIEWS
8-1. Screen and Cover Block ................................... 65
8-2. Control Panel and Cabinet Block ........................ 66
8-3. Main Bracket Block ............................................ 67
8-4. Picture Tube Block ............................................. 68
9. ELECTRICAL PARTS LIST .................................. 69
SAFETY-RELATED COMPONENT WARNING !!
COMPONENTS IDENTIFIED BY SHADING AND MARKED ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE
PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND THE
ANODE CAP TO THE METAL CHASSIS, CRT SHIELD, OR THE
CARBON PAINTED ON THE CRT, AFTER REMOVAL OF THE
ANODE CAP.
WARNING !!
AN ISOLATION TRANSFORMER SHOULD BE USED DURING
ANY SERVICE WORK TO AVOID POSSIBLE SHOCK HAZARD
DUE TO LIVE CHASSIS, THE CHASSIS OF THIS RECEIVER IS
DIRECTLY CONNECTED TO THE POWER LINE.

- 3 -
KP-44PX2/44PX2U
RM-938
LEDOMMETI metsySnoisiveleT metsySoeretS egarevoClennahC metsySroloC
AL,I,K/D,H/G/B MACIN/NAMREG
oeretS
21-10R,21-20E:FHV
Q-B,01-20F:L
21-1R:K/D
96-12E:FHU
96-210:L
96-12R:K/D
96-12B:I
02S-1S:VTELBAC
14S-12S:REPYH
MACES,LAP
85.3CSTN,34.4CSTN
)NIOEDIV(
UI oeretSMACIN96-12B
MACES,LAP
85.3CSTN,34.4CSTN
)NIOEDIV(
eziSerutciPdetcejorP
)sehcni44(mc011xorppA
derusaemerutcipmc011xorppA(
)yllanogaid
tuptuodnuoS
rekaepstfeLdnathgiR)SMR(W51x2)rewoPcisuM(W03x2
]RAER[slanimreTtuptuO/tupnI snoitacificepSlareneG
rotcennocoruEnip-12:1
)dradnatsCELENEC(
.slangisoediVdnaoiduArofstupnI
.BGRrofstupnI
oiduAdnaoediVVTfostuptuO
.slangis
stnemeriuqeRrewoPV042-022
noitpmusnoCrewoPW522
rotcennocoruEnip-12:2
.slangisoediVdnaoiduArofstupnI
.BGRrofstupnI
.slangisoiduAdnaoediVVTfostuptuO
)tuOrotinoM(
snoisnemiDmm645x1611x7901xorppA
thgieWgk46xorppA
rotcennocoruEnip-12:3
.slangisoediVdnaoiduArofstupnI
)elbatceleS(
.oediVSrofstupnI
kniLVA
seirosseccAdeilppuS )1(rednammoCetomeR839-MR
)2(yrettab6RdetangisedCEI
skcaJonohPoiduArofelbairavsrotcennoCtuptuO
slangiS
serutaeFrehtO
esioNotuA,RND,FCD,sulPlatigiDzH001
,ezeerFerutciP,txeteleT,PIP,noitcudeR
PSD,EBB,ybloDlautriV
]EDIS[slanimreTtuptuO/tupnI lortnoCderarfnI:metsySlortnoCetomeR
kcajenohpdaeHkcajinimoerets
stnemeriuqerrewoP
cdV3
noitangisedCEIseirettab2
)AAezis(6R
stupnioiduAskcajonohp
stupnioediVskcajonohp
tupnioediVSNIDnip4
.ecitontuohtiwegnahcottcejbuserasnoitacificepsdnangiseD
WARNING (UK Models only)
The flexible mains lead is supplied connected to a B.S. 1363 fused
plug having a fuse of 5 AMP rating. Should the fuse need to be
replaced, use a 5 AMP FUSE approved by ASTA to BS 1362, ie one
that carries the ASA
Tmark.
IF THE PLUG SUPPLIED WITH THIS APPLIANCE IS NOT SUIT-
ABLE FOR THE OUTLET SOCKETS IN YOUR HOME, IT SHOULD
BE CUT OFF AND AN APPROPRIATE PLUG FITTED. THE PLUG
SEVERED FROM THE MAINS LEAD MUST BE DESTROYED AS A
PLUG WITH BARED WIRES IS DANGEROUS IF ENGAGED IN A
LIVE SOCKET.
When an alternative type of plug is used, it should be fitted with a
5 AMP FUSE, otherwise the circuit should be protected by a 5 AMP
FUSE at the distribution board.
How to replace the fuse.
Open the fuse compartment with
a screwdriver blade and replace
the fuse.
FUSE
emaNledoM
metI 2XP44-PK U2XP44-PK
bmoClaPFFOFFO
PIPFFOFFO
ytiroirPBGRNONO
xoBrefooWFFOFFO
1tracSNONO
2tracSNONO
3tracSNONO
)4(nitnorFNONO
4tracSFFOFFO
rotcejorPNONO
G/BmroNNOFFO
ImroNNONO
K/DmroNNOFFO
SUAmroNFFOFFO
LmroNNOFFO
TASmroNFFOFFO
MmroNFFOFFO
txeteleTNONO
oeretSmaciNNONO

- 4 -
KP-44PX2/44PX2U
RM-938
Connected Not Connected (open) * at 20Hz - 20kHz
Pin No 124 Signal Signal level
1Audio output B
(right)
Standard level : 0.5V rms
Output impedence : Less than 1kohm*
2
Audio input B
(right)
Standard level : 0.5V rms
Output impedence : More than 10kohm*
3
Audio output A
(left)
Standard level : 0.5V rms
Output impedence : Less than 1kohm*
4Ground (audio)
5Ground (blue)
6Audio input A
(left)
Standard level : 0.5V rms
Output impedence : More than 10kohm*
7Blue input 0.7 +/- 3dB, 75 ohms positive
8Function select
(AV control)
High state (9.5-12V) : Part mode
Low state (0-2V) : TV mode
Input impedence : More than 10K ohms
Input capacitance : Less than 2nF
9Ground (green)
10 Open
11 Green Green signal : 0.7 +/- 3dB, 75 ohms,
positive
12 Open
13 Ground (red)
14 Ground (blanking)
15
_ _ Red input 0.7 +/- 3dB, 75 ohms, positive
_ (S signal Chroma
input)
0.3 +/- 3dB, 75 ohms, positive
16 Blanking input
(Ys signal)
High state (1-3V) Low state (0-0.4V)
Input impedence : 75 ohms
17 Ground (video
output)
18 Ground (video
input)
19 Video output 1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
20
_ _ Video input 1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
_ Video input
Y (S signal)
1V +/- 3dB, 75ohms, positive sync 0.3V
(-3+10dB)
21 Common ground
(plug, shield)
21 pin connector
19
17
15
13
11
9
7
5
3
1
20
18
16
14
12
10
8
6
4
2
21
Rear Connection Panel Front Connection Panel
noitarugifnocniptekcosoediVS
niP
oN
langiS leveLlangiS
1dnuorG-
2dnuorG-
3tupni)langisS(Y,mho57Bd3-/+V1
V3.0.cnySevitisop
Bd01+3-
4tupni)langisS(CBd3-/+V3.0
evitisop,mho57
.cnyS
S-Video
socket
3

- 5 -
KP-44PX2/44PX2U
RM-938
UNEMRORRE
20E
30E
40E
50E
60E
70E
80E
90E
01E
11E
21E
31E
41E
51E
61E
EMITGNIKROW
SRUOH
SETUNIM
PCO
PVO
CNYSV
RKI
CII
MVN
TORPH
RENUT
PDNUOS
-
ETARNACS
CAD
DNEKCAB
-
PIP
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
)552,0(
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
41
7
SECTION 1 SELF DIAGNOSIS FUNCTION
egasseMrorrE DEL
edoC
rorreoN00
devreseR10
)noitcetorPtnerruCrevO(PCO20
noitcetorPegatloVrevO30
cnySlacitreVoN40
norewoptarorrERKI50
norewoptawolsenilatadro/dnakcolcsubCII60
norewoptaegdelwonkcasubCIIonMVN70
noitcetorPlatnoziroH80
norewoptaegdelwonkcaonrenuT90
rorrErossecorPdnuoS01
devreseR11
rorrEetarnacS21
rorrECAD31
rorrEdnekcaB41
rorrEecnegrevnoCcimanyD51
rorrEPIP61
Table 1 How to enter into Table 2
1. Turn on the main power switch of the TV set.
2. Program Remote Commander for Operation in Service
Mode. [See Page 23].
3. Press ‘VIDEO’ ‘VIDEO’ > ‘MENU’ on the Remote
Commander.
4. Using the Remote Commander, Scroll to the ‘Error Menu’
item using the down arrow key, then press the right arrow
key.
5. The following table will be displayed indicating the error
count.
Table 2
Note: To clear the error count data press ‘80’ on the Remote
commander.
Flash Timing Example : e.g. error number 3
StBy LED
ON ON ON
OFF OFF
1-1. AE-6X Self Diagnostic Software
The identification of errors within the AE-6X chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the
event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous
flashing LED) and then communicate with each device in turn to establish if a device is faulty. If a device is found to be faulty the relevant
device number will be displayed through the LED (Series of flashes which must be counted) See table 1, non fatal errors are reported using this
method.
Each time the software detects an error it is stored within the NVM. See Table 2.

– 6 –
9
GB
6After all available channels are captured and stored, the Programme Sorting menu
automatically appears on the screen enabling you to change the order in which the channels appear on the screen.
a) If you wish to keep the broadcast channels in the tuned order, go to step 7. b) If you wish to store the channels in a different order:
1Press the or button to select the programme number with the channel (TV
Broadcast) you wish to rearrange, then press the button.
2Press the or button to select the new programme number position for your
selected channel (TV Broadcast), then press OK.
3Repeat steps b)1 and b)2 if you wish to change the order of the other channels.
7Press the MENU button to remove the menu from the screen.
Programme Sorting
Programme: 01 TVE2 41 TVE 02 TVE 03 ANT3 04 TELE5 05 C+ 06 C44
Select new position Move: OK
MENU
Programme Sorting
Programme: 01 TVE2 02 TVE 03 ANT3 04 TELE5 05 C+ 06 C44
Select Channel Confirm:
Your projection TV is now ready for use.
First Time Operation
8First Time Operation
Switching On the Projection TV and Automatically Tuning
The first time you switch on your TV, a sequence of menu screens appear on the TV enabling you to: 1) choose the language
of the menu screen, 2) choose the country in which you wish to operate the TV, 3) search and store all available channels (TV Broadcast) and 4) change the order in which the channels (TV Broadcast) appear on the screen.
However, if you need to change any of these settings at a later date, you can do that by selecting the appropriate option in
the (Set Up menu) or by pressing the Auto Start Up Button / on the TV set.
1Connect the Projection TV plug to the mains socket (220-240V AC, 50Hz)
The first time that the TV set is connected, it is usually turned on. If the TV is off, press
the on/off button on the TV set to turn on the TV.
The first time you switch on the TV, a Language menu displays automatically on the
TV screen.
2Press the or button on the remote control to select the language, then press the
OK button to confirm your selection. From now on all the menus will appear in the selected language.
3The Country menu appears automatically on the TV screen. Press the or button
to select the country in which you will operate the TV set, then press the OK
button to confirm your selection.
• If the country in which you want to use the TV se does not appear in the list,
select “-” instead of a country.
• In order to avoid wrong teletext characters for Cyrillic languages we
recommendtoselectRussiacountry in thecase that yourown country doesnot appear in the list.
4The Auto Tuning menu appears on the screen. Press the
OK button to select Yes.
5The projection TV starts to automatically search and store all available broadcast
channels for you.
This procedure could take some minutes. Please be patient and do not press
any buttons, otherwise automatic tuning will not be completed.
In some countries the TV Broadcaster installs the channels automatically (ACI
system). In this case, the TV Broadcaster sends a menu in which you can select your city by pressing the or button and OK to store the channels.
If no channels were found during the auto tuning process then a new menu
appears automatically on the screen asking you to connect the aerial. Please connect the aerial (see page 7) and press OK. The auto tuning process will start
again.
Language
English Norge Français Italiano Nederlans
Select Language: Confirm:OK
Language
English Norge Français Italiano Nederlans
SelectLanguage: Confirm: OK
Language
English Norge Français Italiano Nederlans
Select Language: Confirm: OK
Country
Sverige Norge - Italia Schweiz/Suisse/Svizzera
Select Language: Confirm: OK
continued...
Programme: Channel: System
Searching...
1
C 01
B/G
Auto Tuning
Do you want to start
automatic tuning?
Yes
No
No channel found
Please connect aerial
Confirm
The operating instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers of the Operating Instruction Manual remain as in the manual.
SECTION 2 GENERAL

–7 –
10
Auto converge the Red, Green, and Blue Lines 1Press on the mark , on the right side of the projection TV. 2 Press / button.
TheAuto Convergence functionworks for about 10 seconds. When thewhite cross disappears from the screen, your projection TV is ready for use.
The Auto Convergence function does not work when: •no signal is input.
•the input signal is weak. •the screen is exposed to spotlights or direct sunlight. •you watch the teletext broadcast. •you watch NexTView.
Adjusting Colour Registration (Convergence)
Due to the earth’s magnetism, the picture might become undefined and you could see different colours on the outlines of the images. In that case, proceed as follows.
1Press the MENU button to switch the first level menu on. 2•To highlight the desired menu or option, press or .
•To enter the selected menu or option, press . •To return to the last menu or option, press . •To alter the settings of your selected option, press //or. •To confirm and store your selection, press OK.
3Press the MENU button to remove the menu from the screen.
Introducing and Using the Menu system
Your projection TV uses an on-screen menu system to guide you through the operations. Use the following buttons on the
Remote Control to operate the menu system:
First Time Operation - Menu System
MENU
MENU
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
PictureAdjustment
Select: EnterMenu:
PictureMode Contrast Brightness Colour Sharpness Reset NoiseReduction
Personal
AUTO
11
GB
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Sound Adjustment
Select: Enter Menu:
Effect Treble Bass Balance Reset Dual Sound Auto Volume TV Speakers
Natural
Off
Stereo
On
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter Menu:
Off
On
AUTO
AV1
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
On Screen display Menus Guide
Refer to the section "Picture Adjustment”, on page 12. Refer to the section "Sound Adjustment”, on page 12.
Refer to the section "RGB Centring" on page 17.
Menu System
Refer to the section "Sleep Timer" on page 13. Refer to the section "Auto Format" on page 13. Refer to the section "AV3 Output" on page 13. Refer to the section "PIP Input" on page 14. Refer to the section "PIP Position" on page 14. Refer to the section "Language/Country" on page 14. Refer to the section "Auto Tuning" on page 14. Refer to the section "Programme Sorting" on page 15. Refer to the section "Programme Labels" on page 15. Refer to the section "AV Preset" on page 15. Refer to the section "Manual Programme Preset" on page 16.
Sound Adjustment
Select: Enter:
Effect Treble Bass Balance Reset Dual Sound Auto Volume TV Speakers
Natural
Off
Stereo
On
Picture Adjustment
Select: Enter:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter:
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Enter:
Set Up
Select:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Start Auto Tuning:
Set Up
Select:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Enter:
Set Up
Select:
Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up
Enter:
Set Up
Select:
Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up
Enter:
Set Up
Select:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Enter:
Detail Set Up
Select:
RGB Centring 0
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Select:
Enter Menu:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Enter:
Set Up
Select:
Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up

–8 –
12 Menu System
Menu Guide
PICTURE ADJUSTMENT The “Picture Adjustment”menu allows you to alter the picture adjustments. To do this: after selecting the item you want to alter press , then press repeatedly / / or to adjust it and finally press OK to store the new adjustment.
Level 1 Level 2 Level 3 / Function
• This menu also allows you to customise the picture mode based on the programme you are watching:
Picture Mode Live (for live broadcast programmes, DVD and Digital Set Top Box receivers).
Personal (for individual settings). Movie (for films).
•Brightness, Colour and Sharpness can only be altered if “Personal” mode is selected. •Hue is only available for NTSC colour signal (e.g: USA video tapes). •Select Reset and press OK to reset the picture to the factory preset levels.
•The Noise Reduction option is set to AUTO to automatically reduce the picture noise visible in the broadcast signal. To cancel this function,
select “Off” instead of “AUTO”.
SOUND ADJUSTMENT The “Sound Adjustment”menu allows you to alter the sound adjustments. To do this: after selecting the item you want to alter, press . Then press repeatedly / / or to adjust it and finally press OK to store the new adjustment.
Effect Natural: Enhances clarity, detail and presence of sound by using “BBE High Definition Sound system”*.
Dynamic: “BBE High Definition Sound system”*intensifies clarity and presence of sound for better
intelligibility and musical realism.
Dolby**V: Dolby Virtual, simulates the sound effect of “Dolby Surround Pro Logic”. Off: Flat response. Treble Less More
Bass Less More
Balance Left Right Reset Resets the sound to the factory preset levels. Dual Sound • For a stereo broadcast:
Mono. Stereo.
• For a bilingual broadcast:
Mono (for mono channel if available). A(for channel 1). B(for channel 2).
Auto Volume Off: volume level changes according to the broadcast signal.
On: volume level of the channels will stay the same, independent of the broadcast signal
(e.g. in the case of advertisements).
TV Speakers On: to listen to the TV from the set speakers.
Off:to listen to the TV from an external amplifier connected to the audio outputs on the rear of the projection
TV set.
• If you are listening to the TV through headphones, the “Effect” option will automatically be switched to “Off”. • If you select “Dolby Virtual” on the “Effect” option, the “Auto Volume” option will automatically be switched to “Off” and vice versa.
*The “BBE High Definition Sound system” is manufactured by Sony Corporation under license from BBE Sound, Inc. It is covered by
U.S. Patent No. 4,638,258 and No. 4,482,866. The word “BBE” and BBE Symbol are trademarks of BBE Sound, Inc.
** This TV has been designed to create the “Dolby Surround” sound effect by simulating the sound of four speakers with two speakers,
when the broadcast audio signal is Dolby Surround encoded. The sound effect can also be improved by connecting a suitable external amplifier (for details refer to “Connecting to external audio Equipment” on page 21).
**Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby
Laboratories.
K
Picture Adjustment
Select: Enter:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
continued...
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Sound Adjustment
Select: Enter Menu:
Effect Treble Bass Balance Reset Dual Sound Auto Volume TV Speakers
Natural
Off
Stereo
On
Sound Adjustment
Select: Enter:
Effect Treble Bass Balance Reset Dual Sound Auto Volume TV Speakers
Natural
Off
Stereo
On
13
GB
Menu System
Level 1 Level 2 Level 3 / Function
SLEEP TIMER The “Sleep Timer”option in the “Features”menu allows you to select a time period for the TV to switch itself automatically into the standby mode. To do this: after selecting the option press , then press or to set the time period delay (max. of 4 hours).
•While watching the TV, you can press the button on the remote control to display the time remaining. •One minute before the projection TV switches itself into standby mode, the time remaining is displayed on the TV screen automatically.
AUTO FORMAT The “Auto Format”option in the “Features”menu allows you to
automatically change the aspect ratio of the screen.
Todo this:after selectingthe option,press . Thenpress or to
select On (if you wish the TV set to automatically switch the screen format according to the broadcast signal) or Off (if you wish to keep your preference). Finally press OK to store.
Even if you have selected “On”or “Off”in the “Auto Format”option, you can always modify the
format of the screen by pressing repeatedly on the remote control to select one of the following formats:
Smart: Imitation of wide screen effect for 4:3 broadcast. 4:3: Conventional 4:3 picture size, full picture information. 14:9: Compromise between 4:3 and 16:9 picture size. Zoom: Widescreen format for letterbox movies. Wide: For 16:9 broadcast. Full picture information. In “Smart”, “Zoom”and “14:9”modes, parts of the top and bottom of the screen are cut off.
Press or to adjust the position of the image on the screen (e.g. to read subtitles).
AV3 OUTPUT The “AV3 Output”option in the “Features”menu allows you to select the source to be output from the Scart connector 3/3
so that you can record from this Scart any signal coming from the projection TV or from an external equipment connected to the Scart connectors 1/1or 2/2or side connectors 4or
4and 4.
If your VCR supports Smartlink, this procedure is not
necessary.
Todo this:after selectingthe option,press .Thenpress or to select the desired output signal: TV, AV1, AV2, AV4, YC4 or AUTO.
If you select “AUTO”, the output signal will always be the same one that is displayed on the screen. If you have connected a decoder to the Scart 3/3or to a VCR connected to this Scart, please remember to change back
the “AV3 Output”to “AUTO”or “TV”for correct unscrambling.
S
S
S
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter Menu:
Off
On
AUTO
AV1
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter:
Off
On
AUTO
AV1
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter Menu:
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
4:3
Zoom
14:9
Wide
Smart
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter Menu:
Off
On
AUTO
AV1
continued...

–9 –
14 Menu System
Level 1 Level 2 Level 3 / Function
PIP INPUT The “PIP Input”option in the “Features”menu allows you to select
the source you want to watch in the “PIP”screen.
To do this: after selecting the option, press . Then press
repeatedly or to select the desired source AV1, AV2, AV3, AV4 or TV. Finally press OK to store.
To watch the “PIP”screen with the selected source, press the
/ button on the remote control.
You can swap the screens by pressing the / button on the
remote control.
PIP POSITION The “PIP Position”option in the “Features”menu allows you to change the position of the “PIP”screen within the main screen. To do this: after selecting the option press , , or to select the desired position. Finally press OK to store. LANGUAGE/COUNTRY The “Language/Country”option in the “Set Up”menu allows you to select the language that the menus are displayed in. It also allows you to select the country in which you wish to operate the projection TV set. To do this: after selecting the option, press and then proceed in the same way as in steps 2 and 3 of the section “Switching On the Projection TV and Automatically Tuning”on page 8.
AUTO TUNING The “Auto Tuning”option in the “Set Up”menu allows you to automatically search for and store all available TV channels. To do this: after selecting the option, press and then proceed in the same way as in the steps 4 and 5 of the section “Switching On the Projection TV and Automatically Tuning”on page 8.
B
A
A
BB
B
A
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter Menu:
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Select: Enter:
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Off
On
AUTO
AV1
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Features
Sleep Timer Auto Format AV3 Output PIP Input PIP Position
Select: Enter Menu:
Off
On
AUTO
AV1
Enter:
Set Up
Select:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
continued...
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
Start Auto Tuning:
Set Up
Select:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
15
GB
Menu System
Level 1 Level 2 Level 3 / Function
PROGRAMME SORTING The “Programme Sorting”option in the “Set Up”menu allows you
to change the order in which the channels (TV Broadcast) appear on the screen. To do this: after selecting the option, press and then proceed in the same way as in step 6 b) of the section “Switching On the Projection TV and Automatically Tuning”on page 9. PROGRAMME LABELS The “Programme Labels”option in the “Set Up”menu allows you to name a channel using up to five characters (letters or numbers). To do this: 1After selecting the option, press , then press or to select
the programme number with the channel you wish to name.
2Press . With the first element of the Label column highlighted,
press or to select a letter or number (select “-“for a blank), then press to confirm this character. Select the other four characters in the same way. Finally press OK to store.
AV PRESET The “AV Preset”option in the “Set Up”menu allows you to designate a name to the external equipment you have connected to the input sockets of this projection TV. To do this: 1After selecting the option, press , then press or to select
the input source you wish to name (AV1, AV2 and AV3 are for the rear Scarts and AV4 for side connectors). Then press .
2A label automatically appears in the label column:
a) If you want to use one of the 6 predefined label (CABLE,
GAME,CAM, DVD,VIDEO or SAT),press or toselect the desired label and finally press OK to store.
b) If you want to set a different label, select Edit and press .
Then with the first element highlighted, press or to select a letter, number or “-“for a blank, then press to confirm this character. Select the other four characters in the same way and finally press OK to store.
b) If you want to set a different label, select Edit and press .
Then with the first element highlighted, press or to select a letter, number or “-“for a blank, then press to confirm this character. Select the other four characters in the same way and finally press OK to store.
continued...
Enter:
Set Up
Select:
Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
Enter:
Set Up
Select:
Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Enter:
Set Up
Select:
Language/Country Auto Tuning Programme Sorting Programme Labels AV Preset Manual Programme Preset Detail Set Up

–10 –
16 Menu System
Level 1 Level 2 Level 3 / Function
MANUAL PROGRAMME PRESET The “Manual Programme Preset”option in the “Set Up”menu
allows you to:
a)
Preset channels or the VCR channel one by one to the programme order of your choice. To do this:
1After selecting the ”Manual Programme Preset”option, press then with Programme option highlighted press .
Press or to select which programme number you want to preset the channel on (for VCR, select programme number
“0”). Then press .
2The following option is only available depending on the country you have selected in the “Language/Country”menu.
After selecting the System option, press . Then press or to select the TV Broadcast system (B/G for western
European countries, D/K for eastern European countries, Lfor France or Ifor United Kingdom). Then press .
3After selecting the Channel option, press . Then press the number buttons to enter directly the channel number of the
TV Broadcast or the channel of the VCR signal. If you do not know the channel number, press or to search for it. When you tune the desired channel, press OK twice to store.
Repeat all the above steps to tune and store more channels.
b)
Label a channel using up to five characters. To do this: highlighting the Programme option, press the PROG +/- button to select the programme number with the channel
you wish to name. When the programme you want to name appears on the screen, select the Label option and press . Next
press orto select a letter, number or “-“for a blank. Press to confirm this character. Select the other four characters in the same way. After selecting all the characters, press OK twice to store.
c)
Fine tune the broadcast reception. Normally the automatic fine tuning (AFT) will give the best possible picture, however you
can manually fine tune the TV to obtain a better picture reception in case the picture is distorted.
To do this: while watching the channel (TV Broadcast) you wish to fine tune, select the AFT option and press . Next press
or to adjust the fine tuning between -15 and +15. Finally press OK twice to store.
d)
Skip any unwanted programme numbers when they are selected with the PROG +/- buttons. To do this: highlighting the Programme option, press the PROG +/- button to select the programme number you want to skip.
When the programme you want to skip appears on the screen, select the Skipoption and press . Next press or to select
Yes. Finally press OK twice to confirm and store.
To cancel this function afterwards, select “No”instead of “Yes”in the step above.
e)
View and record scrambled channels when using a decoder connected to Scart 3/3directly or through a VCR.
This option is only available depending on the country you have selected in the “Language/Country”menu.
To do this: select the Decoder option and press . Next press or to select On. Finally press OK twice to confirm and
store.
To cancel this function afterwards, select “Off”instead of “On”in the step above.
S
continued...
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Select:
Enter Menu:
Enter:
Set Up
Select:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
17
GB
Menu System
Level 1 Level 2 Level 3 / Function
RGB CENTRING When connecting an RGB source, such as a “PlayStation”, you may need to readjust the horizontal position of the picture. If this is the case, you can adjust it through the “RGB Centring”option in the “Detail Set Up”. To do this: while watching an RGB source select the “RGB Centring” option and press . Then press or to adjust the centre of the picture between –10 and +10. Finally press OK to confirm and store.
Picture Adjustment
Select: Enter Menu:
Picture Mode Contrast Brightness Colour Sharpness Reset Noise Reduction
Personal
AUTO
Enter:
Detail Set Up
Select:
RGB Centring 0
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Auto Tuning Programme Sorting Select NexTView AV Preset Manual Set Up
Select:
Enter Menu:
Set Up
Select:
Enter Menu:
Language/Country Auto Tuning rogramme Sorting rogramme Labels AV reset Manual rogramme reset Detail Set Up

–11 –
18
Teletext
Teletext is an information service transmitted by most TV stations. The index page of the teletext service (usually page 100)
gives you information on how to use the service. To operate teletext, use the remote control buttons as indicated below.
•Teletext errors may occur if you use a channel (TV Broadcast) with a weak signal. •After 5 minutes viewing the same teletext page and without any button being pressed, the brightness level of the picture
automatically decreases notoriously to avoid any damage to the picture tube. Press any button of the remote control to reset the brightness level.
To switch on Teletext :
After selecting the TV channel which carries the teletext service you
wish to view, press .
To select a Teletext page:
Input 3 digits for the page number, using the numbered buttons. •If you make a mistake, retype the correct page number. •If the counter on the screen continues searching, it is because the page is not available.
If this is the case, input another page number
To access the next or preceding page:
Press PROG + ( ) or PROG - ().
To superimpose teletext on to the TV:
Whilst you are viewing teletext, press . Press it again to cancel teletext mode.
To freeze a teletext page:
Press / . Press it again to cancel the freeze.
To reveal concealed information (e.g: answer to a quiz):
Press / . Press it again to conceal the information.
To select a sub page:
A teletext page may consist of several sub pages. In this case the page number that appears on the
upper left corner will change from white to green and one or more arrows will appear next to the page number. Repeatedly press the or buttons on the remote control to watch the desired sub page.
To Switch Off Teletext:
Press .
Fastext
Fastext service lets you access Teletext pages with one button push. When you are in Teletext mode and Fastext is broadcast, a colour coded menu appears at the bottom
of the teletext page. Press the appropriate coloured button (red, green, yellow or blue) to access the page corresponding to your menu choice.
Teletext
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index Programme News Sport Weather
25
153 101
98
TELETEXT
Index rogramme News Sport Weather
25
153
101
98
19
GB
NexTView* *(depending on availability of service).
NexTView is an on-screen electronic programme guide, providing you with programme information for different
broadcasters.
When looking for information you can search by theme (sports, art, etc...) or date. Ifwrong characters appear when viewing NexTView, use the menu system to enter the “Language/Country”menu (see page
14) and select the same language as the NexTView is broadcasted.
Displaying NexTView 1
Select a broadcast channel providing a NexTView service. In this case the indication “NexTView”is displayed as soon as data
is available.
2
To see NexTView service you have two different types of NexTView interface. These depend on the % of available data:
a)
“Programme List”interface:
Whilst you are watching TV, and after the indication “NexTView”(coloured white) is displayed on the screen, press the
button on the remote control to watch the “Programme List”interface (see fig. 1).
b) “Overview”interface:
Whilst you are watching TV, and after more than 50% of NexTView data is available (100% data may not be available
depending on the area) the indication “NexTView”(coloured black) is displayed on the screen. Press the button on the remote control to watch the “Overview”interface (see fig. 2).
As soon as you enter the NexTView service the % of NexTView data available will be shown in the bottom left corner of
the screen. Once you have entered the service, the % of data will not increase.
3
To navigate through NexTView:
•moving to right or left press or . •moving up or downwards, press or . •confirming a selection, press OK.
4
To switch NexTView off, press the button on the remote control.
“Programme List” interface (fig. 1):
Icons for different themes (see the “Icons’key”section below) Date Programme list “Overview” interface (fig. 2): Icons for different themes (see the “Icons’key”section below) Date Overview
*
”Record”and “Remind”options will be shown on the screen as soon as a programme has been selected, but they will not be shown if you
are watching a TV channel which is not a NexTView provider.
*”Record”and “Remind”will not be available if the programme that you have selected has already started.
Icons’ key:
Record*:
This function only works if you have connected a VCR which supports SmartLink and Timer Programming feature.
Ifyou wish to record the selected programme, press the red buttonon the remote control.
NexTView
Remind*: If you wish to be reminded when the selected programme is broadcast, press the green button on the remote control. At the time that the programme should be broadcast a reminder message is displayed on the TV.
01 Mon
TV1 TV2 TV3 TV4 TV5 TV6 TV7 TV8
02 Tue
03 Wed
04 Thu
05 Fri
06 Sat
07 Sun 9 : 15 : 03
9 : 00 9 : 30 10 : 00
Maga ine | Songs from the shows Weather Forecast | Mike's show Euronews | Fantasy film | Star Wars
Home Shopping Europe | Euro Sports News | Arts show | Maga ine Larry King's live | Euro Sports Euro maga ine | Euro Sports Home Shopping Europe | Euronews
Songs from the shows TV1 00:30 - 01:30 Thursday 04 Programme description
Record Remind
Record*:
This function only works if you have connected a VCR which supports SmartLink and Timer Programming feature.
If you wish to record the selected programme, press the red button on the remote control.
Remind*: Ifyou wish to bereminded when the selected programme is broadcast,press the green button on the remote control. At the time that the programme should be broadcast a reminder message is displayed on the TV.
full selection list:
All the programme information is listed by time
and broadcast channels order.
entertainment children arts sports news
movies
music
channel selection:
In case the NexTView provider sends information of more than 8
broadcast channels, you can select 8 of them to create your personal list.
remind list:
shows you the list with all the programmes (maximum 5 programmes)
that you have selected to be reminded about.
01 Mon
TV1 TV2 TV3 TV4 TV5 TV6 TV7 TV8
00 : 30 01 : 30 05 : 30 06 : 30 07 : 30 08 : 30 09 : 30 10 : 30
Songs from the shows Weather forecast informati A1 news maga ine Arts show Oclock news Weather forecast informati A1 news maga ine Arts show
02 Tue
03 Wed
04 Thu
05 Fri
06 Sat
07 Sun 7 : 07 : 01
Songs from the shows TV1 00:30 - 01:30 Thursday 04 Programme description
Record Remind

–12 –
20 Additional Information
Acceptable input signal ANo inputs BAudio/video and RGB signal CAudio/video and RGB signal DAudio/video and S video signal ES Video signal FVideo signal GAudio signal HNo input
Available output signal Audio signal. Video/audio from TV tuner. Video/audio displayed on TV screen (monitor out). Video/audio from selected source. No output. No output. No output. Audio signal to headphones.
Connecting Optional Equipment
Using the following instructions, you can connect a wide range of optional equipment to your projection TV.
VCR
VCR
VCR
Decoder
Hi-fi
DVD
AB
C
D8mm/Hi8/
DVC camcorder
S VHS/Hi8 DVC camcorder
F
E
G
H
To avoid
picture distortion:
Do not
connect
equipment
to Eand F
connectors
at the same time.
continued...
21
GB
Additional Information
Additional Information when connecting equipment Connecting a VCR We recommend you connect your VCR to the Dsocket using a scart lead. If you do not have a scart lead, use the “Manual Programme Preset”section on page 16 to tune in the channel of the VCR test signal to TV programme number “0”. Also refer to your VCR instruction manual to get the VCR test signal. If your video supports SmartLink please refer to the "SmartLink" section of this instruction manual on page 22. If you have connected a decoder to the Scart 3/3Dor through a VCR connected to this Scart: Select the “Manual Programme Preset”option in the “Set Up”menu and after entering in the “Decoder**”option, select “On”(by
using or ). Repeat this option for each scrambled signal. **This option is only available depending on the country you have selected in the “Language/Country”menu. Connecting to external Audio Equipment: Plug in your Hi-Fi equipment to the audio output sockets Aif you wish to amplify the audio output from projection TV. Next , using the menu system, select the “Sound Adjustment”menu and set the “TV Speakers”to “Off”.
Audio level of the external speakers can be modified by pressing the volume buttons on the remote control. Also treble and
bass settings can be modified through the “Sound Adjustment”menu.
To enjoy “Dolby Virtual” sound effect through your Hi-Fi equipment: Place the speakers of your equipment in front of your listening position and beside the projection TV set but keeping a distance of 50 cm between each speaker and the projection TV set. Then by using the menu system, select the menu “Sound Adjustment”. Next select “Dolby V”on the “Effect”option.
Using Optional Equipment
In order to get the input signal of a connected equipment onto the TV screen, you need to select the symbol of the connector to which you have connected the device. e. g. : Your VCR is connected to the connector with the symbol
Y
1/ 1. Press the button on the remote control
repeatedly until you see the symbol 1 on the screen.
1Connect your equipment to the designated projection TV socket, as it is indicated on the previous
page.
2Switch on the connected equipment. 3To watch the picture of the connected equipment, press the button repeatedly until the
correct input symbol appears on the screen.
Symbol Input Signals 1•Audio / video input signal through the Scart connector B
1•RGB input signal through the Scart connector B. This symbol appears only if an RGB
source has been connected.
2•Audio / video input signal through the Scart connector C.
2•RGB input signal through the Scart connector C. This symbol appears only if an RGB
source has been connected.
3•Audio/video input signal through the Scart connector D.
3•S Video Input signal through the Scart connector D. This symbol appears only if an S
Video source has been connected.
4•Video input signal through the phono socket Fand Audio input signal through G.
4•S Video Input signal through the front S Video input jack Eand Audio signal through
G. This symbol appears only if an S Video source has been connected.
4Press button on the remote control to return to the normal TV picture.
For mono equipment Connect the phono plug to the L/G/S/I socket on the side of the TV and select 4or 4input signal using the instructions above. Finally, refer to the “Sound Adjustment”section of this manual and select “Dual Sound”“A”on the sound menu screen.
S
S S
S
Your sitting position
~50°
Right
Hi-Fi
speaker
Left
Hi-Fi
speaker

–13 –
23
GB
Remote Control Configuration for VCR/DVD In it’s default condition this remote control will operate the basic functions of this Sony TV, Sony DVDs and most Sony VCRs. To control VCRs and DVDs of other manufacturers (and some Sony VCR models), please complete the following steps:
•Before you start, look up the 3 digit code for your brand of DVD or VCR from the list below. On those brands that have
more than one code, enter the first code number.
•Sony will endeavour to update the software according to market changes. Therefore, please refer to code table included
with the remote control for latest code set.
1Press the Media Selector button on the remote control repeatedly until the required green light (VCR
or DVD) is lit.
If Media Selector is on TV position, code numbers will not be stored.
2Before the green light goes out, press and hold the yellow button for approximately 6 seconds until the
green light starts flashing.
3Whilst the green light is flashing, enter all three digits of the code for your brand of VCR or DVD using
the number buttons on the remote control.
If your selected code is entered correctly, all three green lights will be lit momentarily.
4Turn on your VCR or DVD and check that the main functions work.
•If your device is not working or some of the functions do not work please check that you entered
the correct code set or try the next code listed against the brand.
•Your brand codes may be lost if weak batteries are not replaced within a few minutes. To reset
your brand of DVD or VCR please repeat the above steps. A small label is added inside the battery door to allow you to record your brand codes.
•Not all brands are covered and not all models of every brand may be covered.
Additional Information
2
1
3
VCR Brand List DVD Brand List Brand Code Brand Code SONY (VHS) 301, 302, 303, 308, 309 SONY 001 SONY (BETA) 303, 307, 310 AIWA 021 SONY (DV) 304, 305, 306 DENON 018, 027, 020, 002 AIWA 325, 331, 351 GRUNDIG 009, 028, 023, 024, 016, 003 AKAI 326, 329, 330 HITACHI 025, 026, 015, 004 DAEWOO 342, 343 JVC 006, 017 GRUNDIG 358, 355, 360, 361, 320, 351 KENWOOD 008 HITACHI 327, 333, 334 LG 015, 014 JVC 314, 315, 322, 344, 352, 353, 354, 348, 349 LOEWE 009, 028, 023, 024, 016, 003 LG 332, 338 MATSUI 013, 016 LOEWE 358, 355, 360, 361, 320, 351 ONKYO 022 MATSUI 356, 357 PANASONIC 018, 027, 020, 002 ORION 328 PHILIPS 009, 028, 023, 024, 016, 003 PANASONIC 321, 323 PIONEER 004 PHILIPS 311, 312, 313, 316, 317, 318, 358, 359 SAMSUNG 011, 014 SAMSUNG 339, 340, 341, 345 SANYO 007 SANYO 335, 336 SHARP 019, 027 SHARP 324 THOMSON 012 THOMSON 319, 350 TOSHIBA 003 TOSHIBA 337 YAMAHA 018, 027, 020, 002
24 Additional Information
Optimum Viewing Area
For the best picture quality, try to position the projection TV so that you can view the screen from within the areas shown
below.
Horizontal viewing area
Vertical viewing area
20º 20º
60º
60º
minimum distance 1.7 m
(Optimum viewing position)
(Optimum viewing position)
minimum distance 1.7 m

–14 –
25
GB
Specifications
Additional Information
TV system: Depending on your country selection: B/G/H, D/K, L, I Colour system: PAL SECAM, NTSC 3.58, 4.43 (only Video In) Channel Coverage: VHF: E2-E12 UHF: E21-E69 CATV: S1-S20 HYPER: S21-S41 D/K: R1-R12, R21-R69 L: F-2F-10, B-Q, F21-F69 I: UHF B21-B69 Projected picture size: 44”(approx. 112 cm. measured diagonally) Rear Terminals
1/121-pin scart connector (CENELEC standard)
including audio/video input, RGB input, TV audio/video output.
2/221-pin Scart connector (CENELEC standard)
including audio / video input, RGB input, monitor audio/video output.
3/321-pin Scart connector (CENELEC standard)
including audio / video input, S video input,
selectable audio / video output and Smartlink
interface.
audio outputs (Left/Right) - phono jacks
Side Terminals
4S Video input –4 pin DIN 4video input –phono jack 4audio input –phono jacks
headphones jack
Sound Output:
2 x 30 W (music power) 2 x 15 W (RMS)
Power Consumption: 225 W Standby Power Consumption: < 0.7 W Dimensions (w x h x d) : approx. 1100 x 1160 x 536 mm. Weight: approx. 61 Kg. Accessories supplied: 1 Remote Control (RM-938) 2 Batteries (IEC designated, AA size) Other features: •Digital Comb Filter (High resolution). •100 Hz picture, Digital Plus. •Teletext, Fastext, TOPtext (250 page
TEXT memory).
•NICAM. •Sleep Timer. •SmartLink (direct link between your
projection TV set and a compatible VCR. For more information on SmartLink, please refer to the Instruction Manual of your VCR).
•TV system autodetection. •Dolby Virtual. •BBE. •PIP. •Auto Format. •ACI (Auto Channel Installation).
S
S
(SMARTLINK)
Design and specifications are subject to change without notice. Ecological Paper - Totally Chlorine Free
26
Troubleshooting
Here are some simple solutions to problems which may affect the picture and sound.
Additional Information
If you continue to experience problems, have your projection TV serviced by qualified personnel.
Never open the casing yourself.
Problem No picture (screen is dark) and no sound. Poor or no picture (screen is dark), but good sound. No picture or no menu information from equipment connected to the Scart connector. Good picture, no sound. No colour on colour programmes. When you switch on the TV the last channel you were watching before switching the TV off does not appear. Undefined picture with different colour on the outlines of the images. Noisy picture when viewing a TV channel. No unscrambling or unstable picture whilst viewing a scrambled channel with a decoder connected through the Scart connector
3/3.
Distorted picture when changing programmes or selecting teletext. Wrong characters appear when viewing teletext. Wrong characters appear when viewing NexTView. Brightness level of the picture is notoriously decreased when viewing a teletext page. Remote control does not function. The standby indicator on the projection TV flashes.
S
Solution •Check the aerial connection. •Plug the TV in and press the button on the front of the projection TV. •If the standby indicator is on, press TV button on the remote control. •Using the menu system, select the “Picture Adjustment”menu and select “Reset”to
return to the factory settings.
•Check that the optional equipment is on and press the button repeatedly on the
remote control until the correct input symbol is displayed on the screen.
•Press the + button on the remote control. •Check that “TV Speakers”is “On”in the “Sound Adjustment”menu. •Check that headphones are not connected. •Using the menu system, select the “Picture Adjustment”menu and select “Reset”to
return to factory settings.
•This is not a malfunction. Press the number buttons on the remote control to select the
desired channel.
•Adjust the colour registration. For more details, please refer to “Adjusting Colour
Registration (Convergence)”section on page 10.
•Using the menu system, select the “Manual Programme Preset”menu and adjust Fine
Tuning (AFT) to obtain better picture reception.
•Using the menu system, select the “Noise Reduction”option in the “Picture
Adjustment”menu and select “Auto”to reduce the noise in the picture.
•Using the menu system, select the “Features”menu. Then enter to “Detail Set Up”
option and set “AV3 Output”to “TV”.
•Check that the Decoder is not connected on the scart 2/2.
•Turn off any equipment connected to the Scart connector on the rear of the projection
TV.
•Using the menu system, enter to the “Language/Country”menu and select the
country in which you operate the projection TV set. For Cyrillic languages, we recommend to select Russia country in the case that your own country does not appear in the list.
•Use the menu system to enter the “Language/Country”menu (see page 14) and select
the same language that NexTView is broadcast in.
•This is not a malfunction. After 5 minutes viewing the same teletext page and without
any button being pressed, the projection TV automatically decreases the brightness level to avoid any damage to the picture tube. To reset the brightness level, press any button of the remote control.
•Check that the Media Selector on the remote control is set to the device you are using
(VCR, TV or DVD).
•If the remote control does not operate the VCR or DVD even when the Media Selector
has been set correctly. Enter the necessary code set as explained in the “Remote Control Configuration for VCR/DVD”chapter on page 23.
•Replace the batteries. •Contact your nearest Sony service centre.

– 15 –
KP-44PX2/44PX2U
RM-938
3-1. REAR BOARD REMOVAL
3-3. SERVICE POSITION
3-2. MAIN BRACKET BLOCK REMOVAL
SECTION 3 DISASSEMBLY
3-4. FRONT PANEL REMOVAL
Rear board
Twelve screws
(Hexagon head)
Two screws
(Hexagon head)
1
2
Main bracket block
Light shield
board
1
2
3
Main bracket block
1
1
2
Front Panel Two screws
(Hexagon head)

– 16 –
KP-44PX2/44PX2U
RM-938
3-5. RESISTOR ASSEMBLY (FOCUS PACK) REMOVAL
3-6. H1 AND H3 BOARD REMOVAL
2Screw
(+BVTP 4x16)
4
31
Four screws
(Hexagon head)
Front board
Resistor assembly
(Focus pack)
32
1 H3 board
Front panel H1 board

– 17 –
KP-44PX2/44PX2U
RM-938
3-7. BEZNET BLOCK REMOVAL
3-9. AP AND D BOARD REMOVAL
2
4
1
3
Beznet block
Five screws
(Hexagon head)
Eleven screws
(+BVTP 4x16)
Four screws
(Hexagon head)
1
2
3
5
4
Three claws
Six screws
(+BVTP 3x12)
Screw
(+BVTP 3x12)
Screw
(+BVTP 3x12)
Printed circuit
board support
4
6 AP board
Claw7
D board
3-8. HIGH-VOLTAGE CABLE REMOVAL AND
INSTALLATION
1
2
1
2
(1) Removal
(2) Installation
3
4
Rubber cap
Rubber cap
HV cable
turn 90
HV cable
Hook
Gutter

– 18 –
KP-44PX2/44PX2U
RM-938
3-10. TERMINAL BOARD REMOVAL
3-11. G BOARD REMOVAL
1
2 G board
Five claws
2
1
Terminal board
Six screws
(BVTP 4x16)

– 19 –
KP-44PX2/44PX2U
RM-938
3-12. A BOARD REMOVAL
1
2A board
Screw
(+BVTP 3x12)
Two claws
3
4
3
1
2
3-14. PICTURE TUBE REMOVAL
6
Four screws
(+BTVP 4x16)
5
7
Removing the arrow-marked screw is strictly inhibited.
If removed, it may cause liquid spill.
Four screws
(+BTVP 4x16)
Lens
CR board
Neck assembly
Deflection yolk
Picture tube
3-13. CHASSIS BLOCK REMOVAL
3
Screw
(Hexagon head)
43
1
2
Screw
(Hexagon head)
Two screws
(Hexagon head)
Three screws
(Hexagon head)
Chassis block

– 20 –
KP-44PX2/44PX2U
RM-938
Fig. 4-1
4-2. SCREEN (G2) ADJUSTMENT
1. Turn on the power of the set.
2. Select VIDEO1 mode without signals.
3. Supply DC 175 ±0.5 V from external power supply to
TP7103 (KR), TP7203 (KG) or TP7303 (KB) of CR board,
CG board and CB board.
4.Adjust red, green and blue screen voltage, with SCREEN
VR on the focus packuntil retraceline disappears .
4-4. DEFLECTION YOKE TILT ADJUSTMENT
1. Receive the Monoscope signal.
2. Place the caps on the red and blue lens so that only the
green color.
3. Loosen the deflection yoke set screw and align the tilt of
the Deflection yoke so that the bars at the center of
the monoscope pattern are horizontal.
4. After aligning the deflection yoke, fasten it securely to
the funnel-shaped portion (neck) of the CRT.
5. The tilt of the deflection yoke for red and blue is aligned
the same as was done for green.
Fig. 4-5
Neck Assy
Make sure deflection yoke is
touching CRT closely.
2-pole magnet
4-pole magnet
Deflection yoke
Anode cap
RG
SCREEN
B
RG
FOCUS
Focus Pack
B
Fig. 4-4
Lens
Fig. 4-3
Fig. 4-2
Test signal
Minimize both A and B.
A
B
5. Rotate the green lens and align to obtain the best lens
focus at the center area.
6. Rotate the green focus VR on the focus pack and align to
obtain the best electrical focus in the top right corner.
7. Perform the same alignment for red and blue lenses and
electric focus.
8. Fix lens screw.
SECTION 4 SET-UP ADJUSTMENTS
4-1. SCREEN VOLTAGE ADJUSTMENT
(ROUGH ALIGNMENT)
1. Receive the Monoscope signal.
2. Set 50% BRIGHTNESS and minimum PICTURE.
3. Turn the red VR on the focus pack all the way to the left
and then gradually turn it to the right until the point where
you can see the retrace line.
4. Next gradually turn it to the left to the position where the
retrace line disappears.
4-3. FOCUS ROUGH ADJUSTMENT
1. Loose the lens screw.
2. Program Remote Commander for operation in Service
mode (See Page 23).
3. Place the caps on the red and blue lens so that only the
green color is shown.
4. Press “VIDEO” “VIDEO” “5” “6” on the remote
commander to enter 'Projector Engine'. Press “6” twice
on the Commander to display the test signal (crosshatch)
on the screen.
