Sony ICD-U70 User manual

ICD-U70
Voice Plus All - In - One DVR Solution
Step - up
New
1GB Built In Memory
3
5
Up to 16 Hours of MP3 Playback
4
Up to 502 Hours of Recording Time (LP Mode)
2
Built-in USB
1
5 Message Folders
HQ Recording Mode -16kHz (19.2Kbps): Up to 115 Hours Recording
Time
2
Add-Recording Function
Function Toggle Button Makes the Unit Easy to Use
Digital VOR (Voice Operated Recording)
Easy -to-Read LCD Display
250mW Speaker Output
Includes; 1 "AAA" Battery, Neck Strap and Stereo Headphones
Compatible with Dragon® NaturallySpeaking ® Preferred Voice to Print
Software
Digital Voice Up ® Recording
Digital Pitch Control
3 Recording Modes (STLP)

ICD-U70
Voice Plus All - In - One DVR Solution
Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com
Last Updated: 03/02/2006
Please visit the Dealer Network for current information at www.sony.com/dn
Features
1GB Flash Memory
uses ahigh capacity IC chip, which may be
recorded over and used again and again, with distortion - free clarity.
3
5
MP3 Playback
provides easy playback of unsecure MP3 files by
dragging and dropping files into the MP3 folder on the device
4
LP Recording Mode Provides Up to 502 Hours Recording Time
Offering a longer recording time while maintaining 2 - channel recording.
2
Built - In USB
allows the device to be plugged directly into a USB port
on a computer or hub, eliminating the need for cables
1
Compatible With Dragon ® NaturallySpeaking ® Preferred
Voice to Print Software
to easily convert your recorded files into text.
Digital Voice Up ® and VOR (Voice Operated Recording)
Functions
increases the volume of the person speaking when recorded
at a distance from the unit.
Digital Pitch Control
allows recordings to be heard at slower than
normal speeds without distortion to facilitate transcribing or editing, or
faster than normal to move quickly to a desired portion.
Slim Style Design
main controls are easy to use
Add - Recording Function
allows you to insert and add additional
information to any message without affecting the original.
Specifications
General
Type of Use: All -In- One Ultra Portable DVR
Recording Media: Built -In Flash Memory 1GB
Recording and Playback Times: HQ: 115 Hr 10 Min.; SP: 307 Hr 15
Min.; LP: 502 Hr 45 Min.
Audio
Recording System: Digital Stereo, Monaural Recording
Microphone: Built - in
Format(s) Supported: MP3 Playback
Convenience
Erase/Protect: 2 Erase Options; Message Protection Feature
Hardware
Display: Full Function Display
Power
Output Power: 250mW
Power Requirements: Powers Though USB
Battery Life (Approx.): Up to 20 Hours Recording, Up to 13 Hours
Playback
Battery Type: "AAA" x 2
Speaker
Type: Built - in
5
4
2
4
Speaker Dimensions: 17/27" (16mm); Built - in
Software
Supplied Software: Digital Voice Editor (CD -ROM)
Operating System Compatibility: Microsoft ® Windows ® 98, 98SE, ME,
2000 Professional, XP Home, XP Professional, XP Media Center Edition
Inputs and Outputs
Microphone Input: 1
DC - In: 3V
Headphone Output(s): 1 (Mini)
USB Port(s): 1
Dimensions
Weight: 2.26 oz. (64 g) with battery
Measurements: 1.10" x 4.72" x 0.54 (28.0 x 120.0 x 13.8mm)
Supplied Accessories
1 "AAA" Battery
Neck Strap
Stereo Headphones
Optional Accessories
AC Power Adaptor (AC-E30HG)
Color: Navy Blue
UPC Code: 027242690851
1. Not all products with USB 2.0 connectors may communicate with each other due to chipset variations.
2. Approximate recording times. Battery life will vary based upon usage conditions.
3. User available memory= 1,005,780,992 bytes, a portion of which is used for data management functions, with
default 5 folders setting. Total available space will be reduced as the number of folders increases.
4. Playback time is dependent on available memory. Calculated on 4 minutes per song.
5. Actual user available memory is approximate. A portion is used for data management.
