Dear client
Dear clientDear client
Dear client
We are proud that you decided yourself for a soulution phono-preamplifier You have
acquired a phono-preamplifier with outstanding sonic performance which you will
enjoy for many years
We understand your eagerness to get started but even though please study this
manual step by step before you integrate the Power Supply Unit 750PSU in your
High Fidelity system This manual contains also useful tips for the optimisation of
your overall HiFi-System
If there are any questions regarding the start-up or operation of your Power Supply
Unit 750PSU please do not hesitate to contact your dealer
Have fun!
Have fun!Have fun!
Have fun!

soulution
nature of sound
Page 2
CE
CECE
CE-
--
-Declaration of Conformity
Declaration of ConformityDeclaration of Conformity
Declaration of Conformity
Spemot AG declares that this product is in conformance with the following direc-
tives and standards:
Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002)
Electromagnetic Compatibility 2004/108/EG (EN 55013:2001, EN 55020:2002,
EN 61000-3-2:2006, EN61000-3-3:1995)
FCC
FCCFCC
FCC-
--
-Notice
NoticeNotice
Notice
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules These limits are de-
signed to provide reasonable protection against harmful interference in a residential
installation This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harm-
ful interference to radio communications However there is no guarantee that inter-
ference will not occur in a particular installation
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
- adjust or relocate the receiving antenna
- increase the separation between the equipment and the receiver
- connect the equipment into a mains outlet on a circuit different from that to
which the receiver is connected
- consult the dealer or an experienced radio/TV technician for help
Disposal
DisposalDisposal
Disposal
According to the Directive 2002/96/EG of the European Parliament used
consumer-electro technical appliances have to be disposed separately
and have to be indicated with the following symbol
In the case of disposal of this component please do so in conformity with legal and
environmental regulations

Power Supply Unit
Power Supply UnitPower Supply Unit
Power Supply Unit 750
750750
750PSU
PSUPSU
PSU
User Manual
Page 3
Table of Content
Table of ContentTable of Content
Table of Content
1
Quick start 5
2 Important security advices: 6
3 Technical Highlights 8
3 1 Layout 8
3 2 Power supply 8
4 Start of operation and handling of the Power Supply Unit 750PSU 9
4 1 Scope of delivery and packing 9
4 2 Optimal positioning of your Power Supply Unit 750PSU 9
4 3 Rear panel of the Power Supply Unit 750PSU 10
5 Protection functions of Power Supply Unit 750PSU 11
6 Trouble shooting 11
6 1 Actions after appearance of an error 11
7 Care and maintenance 12
7 1 Burn-in 12
7 2 Cleaning 12
8 Service 12
9 Specification 12
10 Warranty 13
11 Dimensions 14

Power Supply Unit
Power Supply UnitPower Supply Unit
Power Supply Unit 750
750750
750PSU
PSUPSU
PSU
User Manual
Page 5
1
11
1Quick start
Quick startQuick start
Quick start
Unpacking
UnpackingUnpacking
Unpacking
Unpack the Power Supply Unit 750PSU
and store the packing
for future transportations
Security advice: Your
Power Supply Unit 750PSU
has a top class sur
faces Please take care while installing
it
Positioning
PositioningPositioning
Positioning
Position the Power Supply Unit 750PSU on a stable base
Security advice:
Cooling air must be able to circulate
and escape unrestricted
Cabeli
CabeliCabeli
Cabeling
ngng
ng
Disconnect all components of your HiFi-
system from the mains
supply Connect the DC-input of your Phono-P
reamplifier
750/751 with the Power Supply Unit 750PSU
Security advice: The Power Supply Unit 750PSU
has
to remain turned off while connecting the Phono
-
Preamplifier 750/751
Switch on
Switch onSwitch on
Switch on
Set your (pre) amplifier to minimal volume Switch-on
the
Power Supply Unit 750PSU, then switch-on the Phono
-
Preamplifier 750/751
Security advice: Before you switch on the Phono
-
Preamplifier 750/751 check whether t
he cabling is done
correctly

soulution
nature of sound
Page 6
2
22
2Important security advices:
Important security advices:Important security advices:
Important security advices:
User manual:
User manual:User manual:
User manual:
Read this user manual carefully before you start-up your Power Supply Unit
750PSU and follow all installation and security advices
Please keep this user manual In the case this manual gets lost you have the possi-
bility to download it from the soulution-webpage
Power supply
Power supplyPower supply
Power supply:
::
:
Please use the special DC-cable for the connection between the Power Supply Unit
750PSU and the Phono-Preamplifier 750/751
Cabling:
Cabling:Cabling:
Cabling:
While manipulating with cables the Power Supply Unit 750PSU has to remain dis-
connected Before you (dis)connect the DC-cable the Power Supply Unit 750PSU
needs to be switched off Wrong cabling may cause damages to your Power Supply
Unit 750PSU, Phono-Preamplifier 750/751, (pre)amplifier or to your loudspeakers
Excessive volumes due to inappropriate handling may cause hearing damages
Transport:
Transport:Transport:
Transport:
Use only with the cart, stand, tripod, bracket or table specified by the manufacturer
or sold with the apparatus When a cart is used, use caution when moving
cart/apparatus combination to avoid injury or tip over

Power Supply Unit
Power Supply UnitPower Supply Unit
Power Supply Unit 750
750750
750PSU
PSUPSU
PSU
User Manual
Page 7
Packing:
Packing:Packing:
Packing:
Please keep the original packing for future transports The original packing is opti-
mal protection against potential damages
Operation:
Operation:Operation:
Operation:
Never run your Power Supply Unit 750PSU
- with opened housing
- with closed cooling-slots
- with high ambient temperatures (>40°C)
- close to heat sources like radiators, heatings, ovens or similar appliances dis-
sipating heat
- with extremely high humidity for example in humid cellars or rooms similar
humidity
- close to water (Sink, bathtub, or similar equipment) or with any object con-
taining water residing on top of the product
Cleaning:
Cleaning:Cleaning:
Cleaning:
Use a soft and dry towel We suggest using a non abrasive micro fibre towel Please
do not use any solvents or liquidities
Service:
Service:Service:
Service:
Do not try to repair your Power Supply Unit 750PSU by yourself It needs a service
check by a qualified person in the following cases:
- the mains-cable or the mains connectors are damaged
- foreign substances or liquidity has entered the Power Supply Unit 750PSU
- the Power Supply Unit 750PSU has seen rain
- the Power Supply Unit 750PSU seems to malfunction
- the Power Supply Unit 750PSU has fallen to the floor or the housing is dam-
aged
Serial
SerialSerial
Serial-
--
-Nr :
Nr :Nr :
Nr : 750PSU
750PSU750PSU
750PSU –
––
–

soulution
nature of sound
Page 8
3
33
3Technical
TechnicalTechnical
Technical Highlights
Highlights Highlights
Highlights
3 1
3 13 1
3 1 Layout
LayoutLayout
Layout
The power supplies for the analogue and the digital circuits are strictly separated
Additional filter networks reduce mutual interferences between the analogue and
the digital sections for the phono preamplifier 750/751
3 2
3 23 2
3 2 Power supply
Power supplyPower supply
Power supply
The power supply unit has three separate power supplies on board One power sup-
ply is dedicated to the analogue section of the phono preamplifier 750/751 exclu-
sively another power supply takes care of the relais and the controller unit In
standby operation still another power supply is used
The power supply for the analogue sections guarantees optimal condition for the op-
eration of the phono preamplifier 750/751 It has the following features:
- Extremely stable on irrespective of the load with a maximal deviation for the
+/- 15V supply voltage of 5mV (load regulation)
- Lowest influence to changes in the mains supply voltage (line regulation)
- Nearly not measurable noise of the supply voltage (AC < 2µV
RMS
)
- High current supply for short load changes of max 12A
A multi stage filter network protects the audio circuits from potential interferences
with noise present in the mains

Power Supply Unit
Power Supply UnitPower Supply Unit
Power Supply Unit 750
750750
750PSU
PSUPSU
PSU
User Manual
Page 9
4
44
4Start of operation and handling of the
Start of operation and handling of the Start of operation and handling of the
Start of operation and handling of the Power Supply Unit 750PSU
Power Supply Unit 750PSUPower Supply Unit 750PSU
Power Supply Unit 750PSU
Please take care while installing the Power Supply Unit 750PSU Follow all security
advices!
4 1
4 14 1
4 1 Sc
ScSc
Scope of delivery and packing
ope of delivery and packingope of delivery and packing
ope of delivery and packing
Please check the scope of delivery:
- Power Supply Unit 750PSU
- Mains cable
- User manual
- Cotton gloves
Please store the packing of the Power Supply Unit 750PSU for future transports
Check your Power Supply Unit 750PSU for transport damages In the case your
Power Supply Unit 750PSU is damaged please contact your soulution dealer
Security advice: If your Power Supply Unit 750PSU is still very cold
from the transport, please let it warm within the packing, in order to omit condensa-
tion of water inside your Power Supply Unit 750PSU
4 2
4 24 2
4 2 Optimal positioning of your
Optimal positioning of your Optimal positioning of your
Optimal positioning of your Power Supply Unit 750PSU
Power Supply Unit 750PSUPower Supply Unit 750PSU
Power Supply Unit 750PSU
There are no limitations on where to position your Power Supply Unit 750PSU
Security advice: The Power Supply Unit 750PSU has a high quality
surface Please be careful so that the surface does not get scratched Please use the
enclosed cotton gloves

soulution
nature of sound
Page 10
4 3
4 34 3
4 3 Rear panel of the
Rear panel of the Rear panel of the
Rear panel of the Power Supply Unit 750PSU
Power Supply Unit 750PSUPower Supply Unit 750PSU
Power Supply Unit 750PSU
Rear panel of the Power Supply Unit 750PSU
4 3 1
4 3 14 3 1
4 3 1 Mains
MainsMains
Mains (A)
(A) (A)
(A)
Connect the Power Supply Unit 750PSU with the Phono-preamplifier 750/751 Use
the special DC-cable
The Phono-Preamplifier 750/751 will change to the operating mode OFF (Standby,
red LED on front panel) after switch-on of the Power Supply Unit 750PSU
Security advice: Switch-off the Power Supply Unit 750PSU before you
(dis)connect the DC-cable The high current contacts could get destroyed otherwise
4 3 2
4 3 24 3 2
4 3 2 Label
LabelLabel
Label (F
(F (F
(F)
))
)
Please note the serial number of your Power Supply Unit 750PSU on page 7 of this
user manual This allows you to have the product specific data at hand without re-
moving your Power Supply Unit 750PSU from the HiFi rack

Power Supply Unit
Power Supply UnitPower Supply Unit
Power Supply Unit 750
750750
750PSU
PSUPSU
PSU
User Manual
Page 11
5
55
5Protection functions of
Protection functions ofProtection functions of
Protection functions of Power Supply Unit 750PSU
Power Supply Unit 750PSUPower Supply Unit 750PSU
Power Supply Unit 750PSU
The mains voltage is permanently monitored For too high mains supply voltage the
power supply unit gets shut down
6
66
6Trouble shoot
Trouble shootTrouble shoot
Trouble shooting
inging
ing
Error
ErrorError
Error Action
ActionAction
Action
No music
No musicNo music
No music
Please check
- If the Phono-Preamplifier 750/751 is switched on
- If the Power Supply Unit 750PSU is switched-on
- If the correct input has been selected
- If MUTE is activated
- If the preamplifier is switched-on or in mute
- If the power amplifier is switched-on
-
The cabling to the cartridge and the preamplifier; from
the preamplifier to the power amplifier; from power am-
plifier to the loudspeaker and the LINK-System if con-
nected
6 1
6 16 1
6 1 Actions after appearance of an error
Actions after appearance of an errorActions after appearance of an error
Actions after appearance of an error
If you con not identify the error please disconnect the power supply (before you dis-
connect the Power Supply Unit 750PSU has to be in operating condition OFF) and
contact your soulution dealer

soulution
nature of sound
Page 12
7
77
7Care and maintenance
Care and maintenanceCare and maintenance
Care and maintenance
7 1
7 17 1
7 1 Burn
BurnBurn
Burn-
--
-in
inin
in
The Power Supply Unit 750PSU will play on top level immediately after the first
placing into operation However during the first 50-100 hours of operation you will
notice a further improvement of its sonic qualities
7 2
7 27 2
7 2 Cleaning
CleaningCleaning
Cleaning
Please use a soft towel for the cleaning of your Power Supply Unit 750PSU We
recommend the use of a nonabrasive micro fibre towel Please do not employ any
solvents
Security advice: Liquidity is not allowed to enter the Power Supply Unit
750PSU The electronic may be damaged seriously
8
88
8Service
ServiceService
Service
If your soulution preamplifier needs service please contact your soulution dealer
For further information see www soulution-audio com
9
99
9Specification
SpecificationSpecification
Specification
Specification
SpecificationSpecification
Specification Data
DataData
Data
General
GeneralGeneral
General
Power consumption (OFF, standby) < 0 5 W
Power consumption (ON) 32 W
Dimensions
DimensionsDimensions
Dimensions
Dimensions (WxDxH) 480x450x117 mm
Weight ca 17kg
Technical specifications are subject to change without prior notification

Power Supply Unit
Power Supply UnitPower Supply Unit
Power Supply Unit 750
750750
750PSU
PSUPSU
PSU
User Manual
Page 13
10
1010
10 Warranty
WarrantyWarranty
Warranty
All soulution products are guaranteed against defects in material and workmanship
for five years from date of purchase
The guarantee is void if the Power Supply Unit 750PSU has been subject to misuse
or negligence or has been modified, repaired or opened by a non authorised person
without written authorisation of Spemot AG
For the return transport to our premises please use exclusively the original packag-
ing Transport damages are not subject to this guarantee, repairs will be charged
We recommend effecting transport insurance
If you not posses the original packaging no more please contact your soulution
dealer
Basic repairs may be completed by your soulution dealer Please clarify whether he
is able to do the work before you send the Power Supply Unit 750PSU back to us

soulution
nature of sound
Page 14
11
1111
11 Dimension
DimensionDimension
Dimensions
ss
s

Spemot AG
Industriestrasse 70
CH-4657 Dulliken
www soulution-audio com
info@soulution-audio com
soulution
nature of sound
part no
part nopart no
part no 92140
9214092140
92140
