USER’S GUIDE
±15-V Current-Limited
Power Supply
Model 0901
5215 Hellyer Ave. • San Jose, CA 95138-1001 • USA
phone: [phone] • fax: [phone]
e-mail: [e-mail] • www.newfocus.com
0901 pwr supply rev C.fm Page 1 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Warranty
New Focus, Inc. guarantees its products to be free of defects for one year from
the date of shipment. This is in lieu of all other guarantees, expressed or implied,
and does not cover incidental or consequential loss.
Information in this document is subject to change without notice.
Copyright 2001, New Focus, Inc. All rights reserved.
The symbol and NEW FOCUS, Inc. are registered trademarks
of NEW FOCUS, Inc.
Document Number 090101 Rev. C
0901 pwr supply rev C.fm Page 2 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Model 0901 Power Supply Contents • 3
Contents
Operation 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Characteristics 7
Customer Service 8
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appendices 9
Appendix I: Changing the AC Voltage Selection . . . . . . . . . . 9
Appendix II: Fuses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Appendix III: Pin-Outs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Appendix IV: Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
0901 pwr supply rev C.fm Page 3 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4 • Contents NEW FOCUS, Inc.
0901 pwr supply rev C.fm Page 4 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Model 0901 Power Supply Operation • 5
Operation
Introduction
The New Focus Model 0901 Power Supply is a triple-
output, ±15-V DC power supply. Each of the outputs is
current limited: the banana-jack output to 100 mA and
the two micro-connector outputs to 300 mA. While
the supply can be used as a general-purpose supply, it
is primarily intended for use with those New Focus
products that require a ±15-V power supply.
Figure 1:
Model 0901
front panel
Getting Started
The three ±15-V outputs of the Model 0901 are all
derived from a common, 0.8-A linear supply, but are
independently current limited, as shown in Figure 2.
GND
0.3 A Max 0.3 A Max 0.1 A Max
Power
–+
±15 Volt Current Limited Power Supply
0901
0901 pwr supply rev C.fm Page 5 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6 • Operation NEW FOCUS, Inc.
Since each output is independently limited, the voltage
on each output differs slightly. All three ±15-V outputs
will, however, be within ±3% of ±15 V.
Please refer to “Appendix IV: Cables” on page 12 for
instructions in connecting the Model 0901 to other New Focus
products.
Figure 2:
Block diagram
of the Model
0901 power
supply
Note:
Note:
±15 V
Power
Supply
0.1 A Current
Limit
0.1 A Current
Limit
0.3 A Current
Limit
0.3 A Current
Limit
0.3 A Current
Limit
0.3 A Current
Limit
+15 V
COM
-15 V
+15 V
COM
-15 V
+15 V
COM
-15 V
+15 V
COM
-15 V
Banana
Jack
Microtech
Connector
Microtech
Connector
0901 pwr supply rev C.fm Page 6 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Model 0901 Power Supply Characteristics • 7
Characteristics
Model # 0901
Output Voltages ±15 V (±3%)
Outputs (3 total) Microtech Connector (2)
Banana Jack (1)
Typical Current Limit
(Microtech connector)
300 mA
Typical Current Limit
(banana-jack connector)
100 mA
Output Impedance < 6 Ω
0901 pwr supply rev C.fm Page 7 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8 • Customer Service NEW FOCUS, Inc.
Customer Service
Technical Support
Information and advice about the operation of any
New Focus product is available from our applications
engineers. For quickest response, ask for “Technical
Support” and know the model and serial numbers for
your product.
Hours: 8:00–5:00 PST, Monday through Friday
(excluding holidays).
Toll Free: 1–866–NUFOCUS (1–866–683–6287)
(from the USA & Canada only)
Phone: [phone]
Support is also available by fax and email:
Fax: [phone]
Email: [e-mail]
We typically respond to faxes and email within one
business day.
Service
In the event that your New Focus product malfunc-
tions or becomes damaged, please contact New Focus
for a return authorization number and instructions on
shipping the unit back for evaluation and repair.
0901 pwr supply rev C.fm Page 8 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Model 0901 Power Supply Appendices • 9
Appendices
Appendix I: Changing the AC Voltage Selection
The Model 0901 can operate at 100, 120, 220, or 240 V
AC with AC frequencies of 47–63 Hz. The unit is
configured at the factory for the standard AC voltage in
the purchaser’s country.
To check the voltage setting, look at the voltage
indicator on the AC power module on the back of the
power supply.
Figure 3:
AC power
module &
voltage
indicator
1.
Make sure the power supply is turned off.
2.
Disconnect the AC power cord.
3.
Open the cover of the power module using a
small blade screwdriver or similar tool.
Voltage Indicator
Model #:
Serial #:
Made in U.S.A.
WARNING
For continued protection against fire hazard, replace
only with the same type and rating of fuse.
Input VAC
90 - 120
200 - 250
CAUTION 
Risk of electric shock, do not remove 
cover. Refer servicing to qualified personnel.
10 - 250 VAC
1.2 - 0.5A, 48-66Hz
Fuse
2.0 A T
1.0 A T
0901
XX-XXXX
120Vac
0901 pwr supply rev C.fm Page 9 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10 • Appendices NEW FOCUS, Inc.
Figure 4:
Power module
with the cover
open
4.
Remove the AC-voltage selection wheel from
the unit.
Do not attempt to rotate the wheel while it is still
in the power module; the wheel must be removed,
turned, and then reinserted for proper operation.
5.
Reinsert the wheel in the module so the desired
Ac voltage can be viewed in the power-module
window.
6.
Ensure the proper fuses for the new AC voltage
are installed (see “Appendix II: Fuses”).
7.
Close the power-module cover.
8.
Verify the proper voltage is showing through
the module window.
9.
Reconnect the AC power cord.
Model #:
Serial #:
Made in U.S.A.
WARNING
For continued protection against fire hazard, replace
only with the same type and rating of fuse.
Input VAC
90 - 120
200 - 250
CAUTION 
Risk of electric shock, do not remove 
cover. Refer servicing to qualified personnel.
10 - 250 VAC
1.2 - 0.5A, 48-66Hz
Fuse
2.0 A T
1.0 A T
0901
XX-XXXX
120Vac
~
100Vac
~
220Vac
~
AC-voltage
selection wheel
Fuses &
fuse holders
120Vac
0901 pwr supply rev C.fm Page 10 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Model 0901 Power Supply Appendices • 11
Appendix II: Fuses
The AC power module requires two 5x20-mm, 250-V,
fast fuses. The current ratings of the fuses should be as
follows:
Appendix III: Pin-Outs
The front-panel connector pin-outs are as follows:
Figure 5:
Pin-out of
Microtech
connector (as
viewed from
front panel)
AC Voltage Fuse Rating
100 V 0.5 A
120 V 0.5 A
220 V 0.25 A
240 V 0.25 A
Line Banana Jack Microtech
Connector
+15 V Red Pin 1
COM Green Pin 2
-15 V Black Pin 3
Pin 2
Pin 3 Pin 1
0901 pwr supply rev C.fm Page 11 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

12 • Appendices NEW FOCUS, Inc.
Appendix IV: Cables
New Focus offers two types of cables for use with the
Model 0901:
Connect a Model 0921 cable to one of the 0.3-A
outputs to provide banana-jack outputs for general
laboratory use. This cable should not be used to drive a
New Focus photoreceiver or amplifier from the Model
0901’s 0.1-A banana-jack output since it provides
insufficient current for New Focus products.
The colored male-banana plugs on the Model 0921
cable follow the color-coding convention listed on
page 11 for the Model 0901 banana jacks: red is +15 V,
green is common, and black is -15 V. This cable can
also be used with a power supply other than the Model
0901 to power a New Focus product.
When powering a New Focus product with the Model
0901, use a Model 0922 cable on one of the supply’s
0.3-A Microtech connector outputs.
Model # Description
0921
Cable, 3 banana plugs (male) to Micro-
tech connector female, 1 meter
0922
Cable, Microtech connector female to
Microtech connector female, 1 meter
0901 pwr supply rev C.fm Page 12 Friday, August 10, 2001 2:41 PM
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group is your source for quality
new and certied-used/pre-owned equipment
• FAST SHIPPING AND
DELIVERY
• TENS OF THOUSANDS OF
IN-STOCK ITEMS
• EQUIPMENT DEMOS
• HUNDREDS OF
MANUFACTURERS
SUPPORTED
• LEASING/MONTHLY
RENTALS
• ITAR CERTIFIED
SECURE ASSET SOLUTIONS
SERVICE CENTER REPAIRS
Experienced engineers and technicians on staff
at our full-service, in-house repair center
WE BUY USED EQUIPMENT
Sell your excess, underutilized, and idle used equipment
We also offer credit for buy-backs and trade-ins
www.artisantg.com/WeBuyEquipment
REMOTE INSPECTION
Remotely inspect equipment before purchasing with
our interactive website at www.instraview.com
LOOKING FOR MORE INFORMATION?
Visit us on the web at www.artisantg.com for more
information on price quotations, drivers, technical
specications, manuals, and documentation
Contact us: (888) 88-SOURCE | [e-mail] | www.artisantg.com
SM
View
Instra
