sound crush SC-190 User manual

Bluetooth Speaker
Intended use
The product is intended only for sound reproduction and phone call reception
via Bluetooth. Use the product only as described in this manual.
Components
Accessories
1 x Bluetooth speaker
1 x Micro-USB-cable
1 x User manual
1 x AUX cable
Compatibility
This product is compatible with Bluetooth enabled mobile phones and music
devices. It features Bluetooth version 4.1+EDR. It also works with devices
featuring other Bluetooth versions that support e.g.
Volume-/back
Play/pause/
phone pick
Volume+/next
Bluetooth
Button
On/Off button
Water resistant cover

Wireless Hands-Free communication
HFP (Hands-free Profile)
Wireless stereo listening
A2DP (Advanced Audio Distribution Profile)
Wireless music control
AVRCP
Before first time use
Read this user guide carefully to avoid damages or injuries due to
improper use. Pay special attention to the safety instructions. Keep the
instructions for future reference and include them when transferring the
device to third persons.
The device must be charged before the first use. Please refer to the
chapter“Charging the battery”.
Carefully remove all packaging materials and check the device for
completeness and integrity. Do not use a damaged device.
Pair the speaker with a Bluetooth AV source or Bluetooth mobile phone
first. Please refer to the chapters “Pairing”.
The Bluetooth Speaker ID is EL 161.
Operation
TURNING ON/OFF
To turn on, press and hold the On-Off button for approx. 2 seconds. The
Bluetooth LED flashes up in blue and red. Press the On/Off button for approx.
2 seconds to turn off.
ADJUSTING THE VOLUME
Short press the Volume +/- buttons to adjust the volume.
Charging the battery
1. Connect the USB cable (included) to the speaker.
2. Connect the other end of the USB cable to the USB port of the computer
or a USB-charger.
3. During the battery charging the power LED lights continuously red.

Note
LED turns on continuously:
Battery charging. power LED twinkles: The capacity of the battery is <20%.
Battery must be re-charged.
LED turns off: Battery charging complete.
The speaker can still be used during charging. It will take approx. 4 hours to
fully charge the battery by 5V-1A adapter（not included）.
Pairing
1. Turn on the speaker. The speaker is ready for pairing. The LED twinkles in
red-and-blue and a sound is chimed.
2. Activate the Bluetooth function on the audio device. Connect the
Bluetooth- AV-Source with the Speaker via Bluetooth pairing.
3. When both devices are paired the Bluetooth LED turns on blue
continuously.
4. Unpair at the Bluetooth source to disconnect. A sound indicates that
Bluetooth is deactivated and the LED flashes in blue and red.
Note:
Keep the range of 1 meter when pairing. Before pairing a Bluetooth AV source,
refer to the AV source user guide regarding safety instructions and use with
other devices.
Music playback
Start the music playback on the Bluetooth AV source.
Hold press volume +/- buttons to next/ previous song.
Mobile phone
1. To pick up an incoming call, press key.
2. To end a call press key or end the call on your mobile phone.

Note
Phone calls will always be the top priority. When an incoming/ outgoing
call is being progressed, it actively interrupts the music playback. As soon
as the call has been ended, the music resumes.
External device via AUX connection
1. Connect the stereo cable (included) to the AUX jack.
2. Insert the other end of the cable into the headphone or LINEOUT jack of
the external device.
Note
Disconnect the Bluetooth connection with audio sources before
connecting an external device via AUX IN.
Switch the external player on and turn its volume to zero.
Turn the speaker system on and regulate the volumes of both devices.
Cleaning and care
Switch off the device before cleaning.
Clean the device with a soft, damp cloth and a mild cleaning agent. Finish
by wiping it with a dry cloth.
Do not use alcohol, acetone, benzene, scouring cleansers etc. to clean
the device. Do not use hard brushes or metal objects.
Specification
Power supply :5 V
Speaker unit : 2” x 2 + 2 passive subwoofers
Power consumption :max. 5 W
Operating temperature: Max. 45 °C
Disposal
municipal waste. Return it to a designated collection point for the
recycling of WEEE. By doing so, you will help to conserve resources and
protect the environment. Contact your retailer or local authorities for more
information.
Please dispose of batteries in an environmentally friendly manner. Do not put
batteries into the household waste. Please use the return and collection systems in
your community or contact the dealer where you purchased the product.

FCC Warning:
FCC ID: 2ABPR-SC-190
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter
