Monoprice Harmony XL User manual

Harmony XL Bluetooth® Wireless Speaker
P/N 33826
User's Manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES...............................................................................................................................3
INTRODUCTION....................................................................................................................................................................................... 4
FEATURES..................................................................................................................................................................................................... 4
CUSTOMER SERVICE........................................................................................................................................................................... 4
PACKAGE CONTENTS........................................................................................................................................................................ 4
PRODUCT OVERVIEW........................................................................................................................................................................ 5
Top View................................................................................................................................................................................................. 5
Side Panel .............................................................................................................................................................................................. 6
CHARGING....................................................................................................................................................................................................7
BLUETOOTH PAIRING .........................................................................................................................................................................7
TRUE WIRELESS STEREO (TWS) MODE ...............................................................................................................................7
AUDIO PLAYBACK.................................................................................................................................................................................9
PHONE CALLS............................................................................................................................................................................................9
TECHNICAL SUPPORT...................................................................................................................................................................... 10
SPECIFICATIONS................................................................................................................................................................................... 10
REGULATORY COMPLIANCE.......................................................................................................................................................11
Notice for FCC ...................................................................................................................................................................................11
Radio Notice for FCC ..................................................................................................................................................................12
Notice for Industry Canada...................................................................................................................................................12
Radio Notice for Industry Canada...................................................................................................................................12

3
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying extra attention to these
safety warnings and guidelines. Please keep this manual in a safe place for future
reference.
This device is intended for indoor use only.
Do not expose this device to water or moisture of any kind. Do not place drinks
or other containers with moisture on or near the device. If moisture does get in
or on the device, immediately unplug it from the power outlet and allow it to
fully dry before reapplying power.
Do not touch the device, the power cord, or any other connected cables with
wet hands.
If operating this speaker in a humid environment, ensure that no condensation
occurs. Condensation could cause damage to the speaker cone and could cause
a short in the amplifier, which in turn could cause fire or severe electric shock.
Do not expose this device to excessively high temperatures. Do not place it in,
on, or near heat sources, such as a fireplace, stove, radiator, etc. Do not leave it
in direct sunlight.
Prior to operation, check the unit and power cord for physical damage. Do not
use if physical damage has occurred.
Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
This device contains a Lithium-polymer battery. Dispose of this device only in
accordance with local, state, or federal regulations for electronic waste.
Charge the battery before first use and at least once every three months.
Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
This device has no user serviceable parts. Do not attempt to open, service, or
modify this device.

4
INTRODUCTION
The Monoprice Harmony XL portable Bluetooth® speaker is the perfect speaker for the
home or on the go. Small enough to fit in a backpack or bag, the Harmony XL features
30 watts of power delivered to two DSP tuned 3" drivers, resulting in deep bass and
clear, crisp highs. Utilize the True Wireless Stereo functionality by adding an additional
Harmony XL and enjoy true stereo sound from a pair of portable Bluetooth speakers.
FEATURES
Two DSP tuned 3" drivers powered by two 15-watt amplifiers
50Hz ~ 20kHz frequency response
Built-in 4000mAh rechargeable batteries
Up to 15 hours of audio playback
Bluetooth® 4.2 radio with support for the A2DP, AVRCP, and HFP profiles
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to ensuring that your
ordering, purchasing, and delivery experience is second to none. If you have any
problem with your order, please give us an opportunity to make it right. You can
contact a Monoprice Customer Service representative through the Live Chat link on our
website www.monoprice.com or via email at su[email protected]. Check the
website for support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service
for a replacement.
1x Harmony XL Bluetooth® speaker
1x Micro USB charging station
1x 3.5mm audio cable
1x User's manual

5
PRODUCT OVERVIEW
Top View
: With the speaker powered off, press and hold the button to turn the speaker on.
If it is not already paired, it will also enter Bluetooth® pairing mode. With the
speaker powered on, press and hold the button to turn it off.
: Momentarily press the button to decrease the volume level. Press and hold the
button to skip back to the previous track (Bluetooth playback only).
: Momentarily press the button to increase the volume level. Press and hold the
button to skip forward to the next track (Bluetooth playback only).
: Momentarily press or double press the button to pair the speaker with another
Harmony XL speaker. Press and hold the button to cancel the Bluetooth
connection.
: During Bluetooth audio playback, momentarily press the button to start or pause
playback. When there is an incoming phone call, momentarily press the button
to answer the call. When a phone call is in progress, momentarily press the
button to hang up. When there is an incoming phone call, press and hold the
button to reject the call. When in AUX playback mode, momentarily press the
button to turn audio muting on or off. Note that audio muting does not pause
playback on the source device.

6
: When the speaker is powered on, the four Charge Level LEDs indicate the
charge level of the built-in rechargeable battery. While the battery is being
charged, the Charge Level LEDs will flash blue to indicate that charging is in
progress. When charging is complete, the all four Charge Level LEDs will be
illuminated blue. The single square LED to the right of the four Charge Level LEDs
is the Connection Status LED. The Connection Status LED flashes blue when the
speaker is in Bluetooth® pairing mode, is solid blue when there is a valid
Bluetooth connection, and is red when the AUX input is being used.
Side Panel
: Plug the included micro USB charging cable into the DC 5V port, then plug
the other end into a USB power source.
: To charge a mobile device, plug a USB charging cable into your mobile
device, then plug the other end into the USB port on the speaker.
: Plug the included 3.5mm audio cable into the AUX jack, then plug the other
end into the headphone jack on an audio source device. Note that the AUX
input is disabled when a valid Bluetooth® connection exists.

7
CHARGING
The speaker has a built-in rechargeable battery. To charge the battery, plug one end of
the included micro USB charging cable into the micro USB charging port, then plug the
other end into a USB power source, such as a wall charger. The Charge Level LEDs on
the top panel will flash blue while charging is in progress and all four LEDS will be
illuminated blue when charging is complete. A full charge takes approximately 3-4
hours, if the battery is fully depleted. The battery should be charged before first use and
at least once every three months.
BLUETOOTH PAIRING
Perform the following steps to pair the speaker with a mobile device.
1. With the speaker powered off, press and hold the button to turn it on. The
speaker will emit audio cues. If it is not already paired with a device, the
Connection Status LED will begin flashing blue. If it is solid blue and you want to
pair with a different device, press and hold the button to cancel the
existing Bluetooth® pairing.
2. Open the Bluetooth settings on your device, then scan for nearby Bluetooth
devices.
3. Locate and select the MP33826 entry. The Connection Status LED will stop
flashing, will illuminate solid blue, and the speaker will emit audio cues.
TRUE WIRELESS STEREO (TWS) MODE
If you have two Harmony XL speakers, you can pair them together in TWS mode. When
in TWS mode, each speaker operates in mono, with one playing left channel audio and
the other playing right channel audio. This allows you to separate the two speakers for
a true stereo listening experience. Note that TWS mode only works with Bluetooth®
audio playback and the speakers must be within 15 feet of each other.
Perform the following steps to pair two Harmony XL speakers for TWS operation.
1. Press and hold the button on each speaker to power both speakers on.

8
2. If either speaker is paired with a Bluetooth® device, press and hold the
button on it to cancel the existing Bluetooth pairing.
3. Identify which speaker you want to be the slave speaker. Momentarily press the
button on it.
4. Double press the button on the master speaker. The speaker will emit
audio cues, indicating that two-speaker pairing has begun.
5. Wait about 3-5 seconds for the two speakers to pair. When paired, the
Connection Status LED on the slave speaker will illuminate solid blue and the
LED on the master speaker will blink slowly.
6. Press and hold the button on one of the speakers. Both speakers will
power off.
7. Press and hold the button on the master speaker. Both speakers will power
on, the master speaker will emit audio cues, and the Connection Status LED will
start flashing blue.
8. Open the Bluetooth® settings on your mobile device, then scan for nearby
Bluetooth devices. Locate and select the MP33826 entry. The master speaker will
emit audio cues and the Connection Status LED will start blinking slowly. The
LED on the slave speaker will illuminate solid blue.
Notes:
If you want to disable TWS mode, turn the speakers on, then press the
button on either speaker. The master speaker will emit audio cues.
If the speakers have already been paired for TWS mode, turn them on and wait
for 5 seconds to let the two speakers reconnect. The master speaker will emit
audio cues when the connection is made.

9
AUDIO PLAYBACK
Use the following buttons to control audio playback.
Momentarily press the button to decrease the volume level for both
Bluetooth® and AUX playback.
Press and hold the button to skip back to the previous track (Bluetooth
playback mode only).
Momentarily press the button to increase the volume level for both
Bluetooth and AUX playback.
Press and hold the button to skip forward to the next track (Bluetooth®
playback mode only).
When in Bluetooth playback mode, momentarily press the button to start
or pause audio playback.
When in AUX playback mode, momentarily press the button to turn audio
muting on or off. Note that audio muting does not pause the source device.
PHONE CALLS
If an incoming call is detected while Bluetooth audio playback is in progress, playback
will automatically pause. Momentarily press the button to answer the call. If you
want to reject the call, press and hold the button. When the call is over,
momentarily press the button to hang up.

10
TECHNICAL SUPPORT
Monoprice is pleased to provide free, live, online technical support to assist you with
any questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come
online to talk to one of our friendly and knowledgeable Tech Support Associates.
Technical support is available through the online chat button on our website
www.monoprice.com or through email by sending a message to [email protected]om.
Check the website for support times and links.
SPECIFICATIONS
Model
33826
Bluetooth® Version
v4.2 + EDR
Supported Bluetooth Profiles
A2DP, AVRCP, HFP
Bluetooth Range
≤ 32 feet (10 meters)
Amplifier Power
2x 15 watts
Driver Size
2x 3"
Nominal Impedance
4 ohms
Frequency Response
50Hz ~ 20kHz
Signal-to-Noise Ratio
≥ 75dB
Total Harmonic Distortion
10% THD
USB Charging Power
5 VDC, 2A
Battery Type
Lithium polymer
Battery Capacity
4000mAh
Playback Time
Up to 15 hours at 60% volume
Charging Time
3-4 hours
Dimensions
10.6" x 4.1" x 3.9" (270 x 103 x 99 mm)
Weight
3.7 lbs. (1668g)

11
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the
equipment no longer complying with FCC requirements for Class B digital devices. In
that event, your right to use the equipment may be limited by FCC regulations, and you
may be required to correct any interference to radio or television communications at
your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.

12
Radio Notice for FCC
Caution
This FCC Part 15 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not expressly
approved by Monoprice, including the use of non-approved antennas, could void the
user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Radio Notice for Industry Canada
Caution
This IC RSS-210 radio device operates on a non-interference basis with other devices
operating at this frequency. Any changes or modification to said product not expressly
approved by Monoprice, including the use of non-approved antennas, could void the
user’s authority to operate this device.
This device complies with IC RSS-210. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
The Bluetooth® word mark and logos are registered trademarks of Bluetooth SIG, Inc.
