*Thank you for purchasing our product. Please read all instructions carefully before operation ,to ensure
you complete understanding and to obtain the best possible performance from the unit.
WARNING:
To reduce the risk of electronic shock, do not remove the top cover. No user serviceable parts inside.
Refer all servicing to qualified personnel only. Before replacing any fuse, make sure the set is switched off
and disconnected from the AC mains or any other of power source. Replace a fuse only with another of
exactly same specification.
POWER CORD PROTECTION:
Do not cut, kink, damage or modify the AC power cord supplied with this set. Keep the AC power cord away
from heaters and harmful chemicals. Do not keep any heavy object on the power cord.
OPERATION ON GENERATOR:
When operating this set on a generator , make sure the set is switched off till the generator voltage has
stabilized.
VENTILATION:
This set should be situated so that its location or position does not interfere with its proper ventilation. Do
not cover the ventilation holes/slots. Do not insert or drop anything into the ventilation holes/slots.
STABILITY:
This set must kept in a stable and flat horizontal position , and never in a tilted position. Do not place this set
on an unstable stand, tripod, bracket, or mount, do not use attachments which are not supplied or explicitly
recommended by the manufacturer.
EARTHING:
This set must be earthed properly before use. A wire from the earth terminal on the rear panel must be
connected to electrical earth.
EXPOSURE TO HEAT:
Do not touch the heat sinks while the set is working.
DO NOT DISASSEMBLE THE UNIT SINCE THERE ARE NO USER SERVICEABLE PARTS INSIDE
NOTE:
*THIS SYSTEM IS NOT FOR 2.1, 4.1, OR 5.1 SPEAKERS.
*THE ONLY SPEAKER COMPATIBLE IS BOOKSHELF SPEAKER 2.0, TOWER SPEAKER 2.0,
LOCAL 2.0 SPEAKERS, CEILING SPEAKER WITHOUT TRANSFORMER.
*FOR CEILING SPEAKER WITH TRANSFORMER JUST DISCONNECT THE TRANSFORMER
FROM SPEAKER AND DO THE DIRECT CONNECTION TO THE AMPLIFIER.
FOR ANY TECHNICAL HELP REGARDING INSTALLATION YOU CAN CONTACT THROUGH MAIL
OR WHATSAPP WHICH IS GIVEN BELOW
CAUTIONS AND NOTES
TM
SOUND FOR HOME

TM
SOUND FOR HOME
FEATURES AND SPECIFICATION
1) TV IN & CD IN slot - It's a kind of 2 inputs in form of RCA port. To ON this, press the switch of
PART - A - 9.
2) Fm Arial, open the wire and place at some direction were you feel the signal is good.
3) It's a 2 channel so there is 1 option of connecting speakers. 1)Connect 2 woofer or speaker
of 4ohms -10 or 12 inch.
4) 220-230V corded power supply, before turning it ON. Check the cord is properly stuck in the
socket. No loose connection should be there as it may result damage to amplifier.
5) It’s a Speaker fuse of 3 Ampier for each channel, if any short in speaker the fuse will blow off.
6) Fuse 1000MA(1 Amp) if the main led light is not glowing, it means fuse should be replaced.
*SPECIFICATIONS:
POWER OUTPUT 360Watts RMS for 4ohms 2speaker for 8hms 2speaker 180W
INPUT CHANNELS 2xMic , Aux and 2xRCA
OUTPUT CHANNELS HEADPHONE(AMPLIFIER BASS AND TREBLE WILL WORK)
DIGITAL PLAYER Mp3 Player with Remote Control (Bluetooth, USB, SD & AUX)
FREQUENCY RESPONSE 20Hz - 15000Hz +/- 3dB
CONTROLS Volume , Balance , Bass , Treble , Mic Volume , Echo .
POWER SOURCE AC : 220 - 230V
DIMENSIONS L-38cm x H-10cm x D- 20cm (Product size)
WEIGHT 4.7Kg / 4700 Gram (Product Weight)
DISTORTION <0.1%
BODY Metal powder coated body
TRANSFORMER Square 100% cooper ( 28 - 0 - 28 . 6Amp)
IC OR MOSFET MOSFET - TTA5200 X 2 & TTC1943 X 2
COOLING Heat sink and Ventilation
IDEAL Home, Conference, Classes, Schools, Shop & Showrooms etc.
ORIGIN MADE IN INDIA ( MAHARASHTRA - THANE )
In case of any issue, customer can service it locally or will have 6 MONTH:
to send the product to our center in by local courier or Indian post. THANE
Courier charges for sending the product to us should be borne by customer
and we will borne charges for sending back the product.
MODEL SK 25000 ECHO
WARRANTY
*FEATURES AND SPECIFICATION: PART - C
RED BLK BLK RED
1
6
2
5
FUSE 1AMP
230 V AC
10” OR 12” SPEAKER OR WOOFER
FUSE
3 AMP
MADE IN INDIA
2019
2020
ARIAL
TV IN
CD IN
L R
L R
3 4
FEATURES AND SPECIFICATION
TM
SOUND FOR HOME
PACKAGE CONTENTS: 1) AMPLIFIER
2) REMOTE
3) INSTRUCTION MANUAL
4) AAA BATTERIES FOR REMOTE
*FEATURES AND SPECIFICATION: PART - A
1) Press downwards to Power on and the led light above will Glow.
2) This is loudness switch from which you will get high bass at low volume.
3) This is classic switch from which you will get high treble at low volume.
4) This is master volume knob for adjusting the volume of amplifier.
5) This is a balance knob, keep it in the center so all speaker will work and if you feel
that the bass is not clear then just interchange the 1 channel speaker wire.
6) This is a Bass knob, adjust it according to the master volume as volume increase the
bass may effect so we have to lower the bass accordingly.
7) This is a Treble knob, adjust it according to the master volume as volume increase the
Treble may effect so we have to lower the treble accordingly.
8) There are 2 Mic inputs of 6.3mm were we can use wired and wireless Mic. For better result
don't take Mic closer to the speaker, and reduce the volume of PART - B by remote to
increase Mic output, best experience when we do Karaoke as Mic volume should be high.
9) This is Mic on/off switch, when we press the Mic will work and as this is Karaoke system,
Mic will work with all inputs like BLUETOOTH/ USB/ FM/ AUX/ SD/ CD/ TV.
10) This is CD/TV switch when we press IN the back panel (PART-C-1) RCA slots will work
i.e CD/TV input and when we press OUT switch, the front panel display (PART-B) will be ON.
11) This is Mic volume where we can adjust volume for Mic slot (PART-A-9).
12) This is a Echo control were we an adjust the echo level of microphone.
13) This is HEADPHONE slot for headphones or it can be used as Output option also in this
the Bass and Treble will work.
1 2 3 4 5 6 9 10 13 7
8
ECHO
11 12
*FEATURES AND SPECIFICATION: PART - B
Digital Player
----
PWR
Bluetooth
TF
PREV NEXT >II
MODE
IR
REPEAT
STOP
AUX USB
VOL+
VOL-
1 2 3 4
5
6
7
8
11 10 9
1) Previous song/station will be played.
2) Next song/station will be played.
3) It is to pause the songs.
4) It is a volume key Up(+).
5) It is a volume key Down(-).
6) Mode key to switch the interface
i.e.USB/SD/AUX/BLUETOOTH
7) STOP key.
8) Repeat key
9) USB slot Read upto 32GB Pendrive.
10) AUX slot - You can insert 3.5mm cable to connect Mobile or Laptop or TV.
11) TF slot Read upto 32GB memory card.
