SoundScape®ATS-360GT16
PRODUCT DESCRIPTION
ese Omni-directional outdoor speakers are designed for
applications where smooth coverage, hidden audio is required.
Rugged and built to be buried in any terrain, Mushroom® Speakers
provide a music source that blends into the landscape. e sound
radiates in a complete circle, creating a uniform 360° audio eld
without loud or dead spots.
e ATS-360GT is a high-eciency, high-reliability model suitable
for most low-powered residential and commercial music and paging
applications.
Best installation method is to place the speakers 5-10 ft back from
walkways 15-20 ft spacing in shrubbery and avoid lawn areas.
PART NUMBERS
ATS-360GT16 – Complete Loudspeaker Assembly
ATS-360-SPKR Replacement Speaker without transformer
ATS-360-SPKR T8- Legacy Replacement Speaker with 8W Transformer
ATS-360-SPKR T16 Replacement Speaker with 16W Transformer
ATS-360 G Lid –Green Lid
ATS-360G –ENC – Enclosure Bottom – Green
PRODUCT SPECS
Speaker 8 Inch Full Range Speaker with integral Grill
Enclosure Green , Polyethylene, UV resistant
Connections 10 Ft – Direct Burial Cable Whip, Conduit Fitting
Direct Connection 8 Ohm Via Jumper
70V Amplier Connection 4W,8W,16W Selectable
100V Amplier Connection 8W,16W, 32W Selectable
Sound Power Rating 50 Watts
1 W 1 M Sensitivity @ 1 kHz 85 dB
Maximum Rated Output @ 1 M 103 dB
Frequency Response (-10) 45Hz – 9.5KHz
Loudspeaker Warranty 3 Years in Normal use, Direct water Spray excluded,
avoid placement next to Sprinklers
Enclosure Warranty 10 Years–We have enclosure products installed and
operational for over 30 years
