WALL MOUNT LOUDSPEAKER
NARROW FRONTAL AREA ENCLOSURES
Reduces cabinet diffraction and reflection effects to preserve accurate imaging and natural tonal balance
PORTED BASS SYSTEM DESIGN
Delivers accurate and powerful bass output for music and movie soundtracks
TCC™ WOOFER CONES
Are comprised from a proprietary blend of injection-molded polypropylene, talc, carbon and ceramic materials that have an ideal stiffness-to-
mass ratio for precise detail and powerful bass tones
HYPERBOLIC DOME MIDRANGE DRIVERS
Feature tri-laminate Teteron material and fluid cooling to produce high sound pressure levels with exceptional clarity and natural midrange
tones that blend seamlessly with PHD high frequencies
TETERON TWEETERS
Employ a tri-laminate soft dome and fluid cooling system to deliver smooth and precise treble tones in a uniform pattern over a wide area for
crystal clear highs everywhere in the room
NILES HD HIGH DEFINITION VOICE MATCHING
Ensures compatibility with other Niles HD High Definition in-wall and ceiling mount models to accommodate a wide variety of system designs
PHD60
Stock Number
FG01148 - Silver
FG01288 - Black
Details
PHD High Definition Wall Mount Loudspeakers
WOOFER TECHNOLOGY
nPatent pending, Cone Forward™ design positions the woofer cone at the front of the baffle and allows sound to
radiate freely into the room
nFour 5-1/4" injection-molded TCC™ (talc, carbon, and ceramic-filled) polypropylene woofers are extremely rigid to
reduce breakup and lower distortion
nButyl rubber woofer surround damps resonance and provides exceptional durability
nHigh BL magnet structure insures powerful bass response
nLong-throw coil/magnet structure reproduces dynamic program material without distortion
nPorted bass system design delivers accurate and powerful bass output for music and movie soundtracks
MIDRANGE TECHNOLOGY
nPatent pending, Cone Forward™ design positions the woofer cone at the front of the baffle for natural sounding
bass and clear, open midrange
nQuadruple 5-1/4" injection-molded TCC™ (talc, carbon, and ceramic-filled) polypropylene woofers offer extreme
rigidity to reduce breakup and lower distortion
n1-1/2" Teteron hyperbolic dome midrange driver is fluid-cooled and provides high sound pressures to reproduce
critical mid frequencies with exceptional accuracy
TWEETER TECHNOLOGY
n1" fluid cooled Teteron dome tweeter delivers ultra-wide dispersion to reproduce clear and detailed high frequencies
AUDIOPHILE FEATURES
nAdjustable, dispersion-controlling, midrange/tweeter pod enables precise imaging regardless of placement and
accommodates vertical or horizontal installations
nBass-reflex design enhances low frequency response and dynamic impact
n4-way loudspeaker design provides exceptional detail over a wide listening area
nRigid extruded aluminum enclosure delivers accurate bass response with low distortion
nContemporary finish matches popular flat panel displays
TONE CONTROLS
nVariable (+3dB to -3dB) midrange and treble controls adjust from the front baffle and enable fine-tuning after
installation
INSTALLATION
nIntegrated wall mount bracket makes installation quick and easy
SPECIFICATIONS
nImpedance: 4 ohm; Frequency response: 55Hz – 21kHz +/-3dB
nRecommended amplifier power: 10W to 250W
nSensitivity: 90dB with 2.83V pink noise input, measured at 1 meter on axis
nDimensions: 6.2" Wide x 34.7" High x 5.6" Deep (including wall bracket)
Warranty: Five-year limited
