SP Audio SP HM Midrange Series User manual

Owner’sManual
SP AUDIO S.r.l.
P. IVA: 03191510126
Via Sardegna, 50
20020 Magnago (MI) Italia
Ufficio: [phone]
Mobile: [phone]
www.spaudio.it - [email protected]
SP10HMMidrange
SP 8HM Midrange

High Quality SP Series Midrange Speaker
Features Of SP Series Midrange Speaker
Thiele Small Parameter
General Specification
High Quality SP Series Midrange Speaker
SPEC TSP
Fo
Revc
Qts
Qes
Qms
Vas
Xmax
Sd
Cms
Mms
Bl
No
Nominal Diameter
Rated Impedance
Minimum Impedance
Rated Power(RMS)
Peak Power
Sencitivity
Frequency Range
VC Diameter(mm/in)
Winding Mateiral
Suspension
Cone
■ 102 dB SPL 1W/1M
■ 2.5” CCAW VC
■ 400 W RMS Power
■ Al Solid Phaseplug
■ 4 Ohms Impedance
■ 180g N38H Magnet
■ 102.5 dB SPL 1W/1M
■ 3” CCAW VC
■ 500 W RMS Power
■ Al Solid Phaseplug
■ 4 Ohms Impedance
■ 286g N38H Magnet
Applications:
SP HM Midrange Series is a professional line for loud car music
SP 10HM
100 Hz
3.3 Ohm
0.473
0.498
9.171
19.55 L
2.0 mm
380 cm²
95.27 um/N
29.33 g
10.94 TL
3.28%
SP 8HM
145 Hz
3.0 Ohm
0.671
0.719
10.093
5.28 L
2.0 mm
243 cm²
62.76 um/N
19.22 g
8.55 TL
2.16%
220℃ Aluminum Wire
M-ROLL ,Polycotton
Compress Paper, Fiberglass, Black Painting
SP 10HM
250 mm(10 in)
500 W
6 Ohm
1000 W
102.5 dB
70 Hz-15 kHz
76.2 mm/3”
4 Ohm
SP 8HM
200 mm(8 in)
400 W
6 Ohm
800 W
102 dB
120 Hz-20 kHz
60.6 mm/2.5”
4 Ohm
Mounting Information
SPL&IMP
Unit:mm/in
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
20
30
40
50
60
70
80
90
100
110 Ohm
3
4
5
6
7
8
9
10
20
30
40
50
60
70
80
90
100
SP 10HMSP 8HM
FeaturesFeatures
SP 10HMSP 8HM
SP 8HM
SP10HM
