SpectraDynamics HPDA-15RM-A User manual

SDI
SPECTRADYNAMICS, INC.
HIGH PERFORMANCE DISTRIBUTION AMPLIFIER
HPDA-15RM-A
OPERATING MANUAL
SPECTRADYNAMICS, INC •1849 Cherry St. Unit 2. •Louisville, CO 80027
Phone: [phone] •Fax: [phone]
www.spectradynamics.com

Copyright © SpectraDynamics, Inc. 2010
1
The HPDA-15RM-A is a high performance distribution and isolation amplifier. It contains
a high performance distribution module that provides five unity gain outputs. Typical
cross-channel isolation is 125 dB and reverse isolation is typically greater than 135 dB.
The phase noise of the module is exceptionally low, typically –150 dBc/Hz @ Fourier
frequency of 1 Hz and –172 dBc/Hz @ Fourier frequency greater than 10 kHz. Both the
input and output are matched to 50 ohms to obtain better than 25 dB return loss. All
outputs are AC coupled and the grounds are DC isolated to reduce the effect of ground
loops.
Description
SDI
SPECTRADYNAMICS,INC •1849 Cherry St. Unit 2. •Louisville, CO 80027 •Phone: [phone] •Fax: [phone]
Se habla español

Copyright © SpectraDynamics, Inc. 2010
2
CAUTION!
Voltages capable of causing injury or death are present in this instrument. Use extreme
caution whenever the instrument cover is removed.
Line Voltage
This instrument may be setup to operate on 100-120 or 220-240 VAC and a line
frequency of 50 to 60 Hz. The setup voltage for this HPDA-15RM-A is specified on
page 4.
Fuse
A 0.50 Ampere 250V slow-blow fuse is used for 100-120 VAC operation.
A 0.25 Ampere 250V slow-blow fuse is used for 220-240 VAC operation.
Only replace fuses with the same type and specifications.
Line Cord
The instrument has a detachable, three wire power cord for connection to a grounded
power source. The enclosure of the unit is directly connected to the outlet ground to
protect against electrical shock. Always use an outlet with a protective ground and do
not disable this safety mechanism.
Service
Do not attempt to service or adjust the instrument unless another person, capable of
providing first aid or resuscitation, is present. Contact SDI for any questions or repairs.
SpectraDynamics, Inc.
1849 Cherry Street Unit 2.
Louisville, CO 80027
USA
Tel: [phone]
Fax: [phone]
[e-mail]
www.spectradynamics.com
Safety and Preparation for Use
SDI

Copyright © SpectraDynamics, Inc. 2010
3
AC Power LED
The LED labeled POWER is on when power is applied to unit and the unit is operating
properly.
Signal LED
The LED labeled SIGNAL will turn on when you apply an input signal to the SMA input
connector greater than +7 dBm.
The Front Panel
SDI

Copyright © SpectraDynamics, Inc. 2010
4
AC POWER ENTRY MODULE
The HPDA-15RM-A is configured to operate on:
100-120 VAC
220-240 VAC
SMA INPUTS
The signal to be distributed should be connected to the SMA jack labeled INPUT.
SMA OUTPUTS
The five outputs of each amplifier module are DC isolated from the chassis ground to
prevent ground loops. Make sure that the amplifier ground does not float to a potential
greater than 50 VDC from the chassis ground. An output ground potential greater than
50 VDC will damage the amplifier and could cause injury or death to personnel.
The Back Panel
SDI

Copyright © SpectraDynamics, Inc. 2010
5
This unit is designed to operate only with the specified voltage on page 4. For
conversion to a different voltage of operation contact SDI.
To operate the unit, locate the AC power entry module on the rear of the enclosure and
connect the power cord. Plug the unit into an appropriate power outlet. A green LED
on the front panel labeled POWER will turn on. Attach the signal to be distributed to the
SMA input connector on the back panel. Any HPDA-15RM-A output may be used to
drive the input of another distribution module.
Absolute Maximum Ratings
Input power +20dBm Maximum
Reverse Power +20dBm Maximum
Input DC Voltage 10 VDC Maximum
Output DC Voltage 50 VDC Maximum
Storage Temperature -10 to +75 ºC
Operation Environment 0 to +50 ºC
Rack Mount Chassis 1U H, 19“ W, 14” D
Operation
SDI

Copyright © SpectraDynamics, Inc. 2010
6
PARAMETER
CONDITIONS
MIN
TYP
MAX
UNITS
Input power
1 dB compression
17
18
-
dBm
Bandwidth
+/- 1 dB
1 - 20
-
-
MHz
Gain
@ 5 MHz
-
-
+/- 0.5
dB
Impedance
input
output
-
-
50
50
-
-
Ohms
Return loss
Input (S11) 5MHz
Output (S22) 5MHz
-
-
-35
-25
-25
-25
dB
Distortion
+13 dBm
+17 dBm
-
-
-48
-40
-43
-
dBc
Isolation
output to output
output to input
120
120
126
135
-
-
dB
Phase noise
1 Hz
10 Hz
1 kHz
10 kHz
-
-
-
-
-150
-160
-171
-172
-147
-157
-169
-170
dBc/Hz
Temperature-delay
coefficient
0 - 50 ºC
25 - 35 ºC
-
-
3
1.5
5
-
ps/ºC
All tests done at 5 MHz and +13 dBm input unless otherwise specified.
Specifications
SDI

Copyright © SpectraDynamics, Inc. 2010
7
The HPDA-15RM-A is warranted to be free of defects under normal operating
conditions, as specified, for one year from date of original shipment from
SpectraDynamics, Inc (SDI). SDI’s obligation and liability under this warranty is
expressly limited to repairing or replacing, at SDI’s option, any product not meeting the
said specifications. This warranty shall be in effect for one (1) year from the date a
HPDA-15RM-A is sold by SDI. SDI makes no other warranty, express or implied, and
makes no warranty of the fitness for any particular purpose. SDI’s obligation under this
warranty shall not include any transportation charges or costs of installation or any
liability for direct, indirect, or consequential damages or delay. Any improper use,
operation beyond capacity, substitution of parts not approved by SDI, or any alteration or
repair by others in such manner as in SDI’s reasonable judgement affects the product
materially and adversely shall void this warranty. No employee or representative of SDI
is authorized to change this warranty in any way or grant any other warranty.
SDI
Warranty
SDI
SPECTRADYNAMICS,INC •1849 Cherry St. Unit 2. •Louisville, CO 80027 •Phone: [phone] •Fax: [phone]
Se habla español

HPDA-15RM-A:1I-5O/R02
