Spectrum Industries 95513 User manual

Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts or
accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
1. Assemble the sling side and base using (2) 1/4-20 wing nuts as shown in Figure 1.1.
2. Thread the straps through the slots in sling side and base as shown in Figure 1.2
with the tails hanging down. (The center slot can be used for smaller CPU’s.)
3. Thread each strap through the buckles as shown.
Wing nut
(2) required
Center slot used
for smaller CPU’s
Sling side
Sling base
Figure 1.1 Figure 1.2
Strap / buckle
assembly
Strap / buckle
assembly
1
/
8”
(for desks without
threaded inserts)
0100192R6 Page 1 of 4
Assembly InstructionsAssembly Instructions
TM
Adjustable CPU SlingAdjustable CPU Sling
9551395513
Assemble and adjust CPU sling
1
(3) 0103619
Adhesive bumper
1/2” x 1/16” thick
(1) 0166363
Leg bracket
(2) 034195
1/4-20 Wing nut
(2) 026017
1/4-20 x 1/2” PHMS
(1) 042025
1/4-20 x 3/8” THMS
(2) 021605
#10 x 1-3/4”
PHSM
(1) 0100193
2” x 2” x 1” shim
(2) 026547
1/4-20 x 1-1/2”
PHMS
(2) 0103894
54” Strap / buckle
assembly
(2) 026057
#10 x 3/4” PHSM
(1) 060047
Sling side
(1) 060048
Sling base
(1) 042139
Drill template
(1) 044890
1” Nylon spacer

2” x 2” x 1” shim
Support brace
(on some desks)
1” x .275”ID x .5”
OD nylon spacer
1/4-20 x 1-1/2”
PHM screw
1/4-20 x 1/2”
PHM screw
Worksurface
Drill here
Leg
Drill here
Drill template
042139
3/4” deep
Drill with 1/8” bit
Tape
0100192R6 Page 2 of 4
TM
Attach sling to desk
2
With threaded inserts:
1. Determine whether the CPU sling will mount on the right or left side of the desk and align the top sling holes
with the appropriate set of inserts. Figure 2.1, 2.2 shows a sling being mounted on the left side of a desk.
2. Attach the sling to the worksurface using two 1/4-20 PHM screws and tighten.
Without threaded inserts:
1. Determine whether the CPU sling will mount on the right or left side of the desk.
2. Fold and tape the enclosed drill template (042139) to the underside of the worksurface in the
position shown in Figure 2.3.
3. Wrap a piece of tape around a 1/8” drill bit to mark 3/4” from the end of the bit. Figure 2.4.
4. Drill through the template on the two marked holes closest to the leg, 3/4” deep. Figure 2.3.
5. Attach CPU sling to worksurface using (2) #10 sheet metal screws.
Note: Desks without support brace Figure 2.1
use two 1/4-20 x 1/2” PHM screws (026017.)
Note: For desks with support brace Figure 2.2, use one nylon spacer
(044890) in the front hole, and one 2” x 2” x 1” shim (010093) in the
back hole with the longer 1/4-20 x 1-1/2” PHM screws (026547.) The
front of the sling will extend past the support brace.
Note: Desks without inserts or support brace use two #10 x 3/4”
PHSM Screws (026057.) Desks without inserts that include a support
brace as in Figure 2.3, use one nylon spacer (044890) in the front
hole, and one 2” x 2” x 1” shim (010093) in the rear hole using the lon-
ger #10 x 1-3/4” PHSM screws (021605.) The front of the CPU sling
will extend past the support brace (See Figure 2.2 for reference.)
Figure 2.1 Figure 2.2
Desks without support brace Desks with support brace
CPU
sling
CPU
sling
Figure 2.3
Figure 2.4

Attach leg bracket
3
Figure 3.3
Figure 3.1 Figure 3.2
0166363
Leg bracket
CPU Sling
Leg
1/4-20 x 3/8”
THMS
Slot in
CPU sling
0100192R6 Page 3 of 4
TM
1. Detemine which type of leg you have (welded or adjustable) and apply
the adhesive bumpers accordingly. Figure 3.1-3.2.
2. Line up the bracket with the front slot of the CPU sling as shown and
install (1) 1/4-20 x 3/8” THM screw (042025). Figure 3.3.
3. Adjust the leg bracket until it is snug against the leg, then tighten 1/4-
20 x 3/8” THM screw to secure.
Note: If the CPU sling is being used on an Evolution™ desk, one of
the included leg brackets should be secured to the sling. This bracket
hooks onto the desk leg to provide additional support for the sling.
Note: The adhesive on the bumpers is designed to work with powder
coated metal and has a strong bond. It is not easy to remove and repo-
sition without damaging the bumper. Be sure each bumper is centered
on the bracket in the locations shown before applying to the metal.
Bumper Installation - Welded leg Bumper Installation - Adjustable (one-piece) leg
Bumpers
(optional)
Leg bracket
CPU Sling CPU Sling
Leg bracket
Bumper Bumper
Bumper

1. Slide the base to the widest position and carefully place the CPU unit into the sling.
2. Slide the base tight against the CPU and tighten the two wing nuts underneath.
3. Make sure the CPU will be fully-supported by both straps. Tighten the straps around
the CPU while keeping the buckles positioned as high as possible to avoid interference.
Figure 4.1. The center slot can be used with smaller CPU’s. Figure 4.2.
Figure 4.1 Figure 4.2
Standard
CPU
Small
CPU
0100192R6 Page 4 of 4
1500 RIVER STREET, PO BOX 400, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2021 Spectrum Industries Inc., All rights reserved.
Install CPU and adjust straps
4
