Owner’s Manual

0190103R2 Page 1 of 8

Important

Before using this product:

• Read this manual

• Comply with all safety and operating instructions

• Ensure all parts and correct quantities are included

Any parts damaged during shipment must be reported

within 5 days of receipt. To report information regarding

missing parts or damage, to purchase parts or acces-

sories, or if you have any questions, please contact us.

Thank you for purchasing Spectrum products!

Spectrum Industries, Inc

925 First Avenue, Chippewa Falls, WI 54729 USA

800 235 1262

715 723 6750

www.spectrumfurniture.com

Freedom One Sit-to-Stand (S2S) Workstation

For Sprout 1.55 by HP® , and Sprout Pro G2

55368-Q45

55368-Q46

0190103R2 Page 2 of 8

DANGER - General Safety:

1. SAVE THESE INSTRUCTIONS

2. Do not allow children to move.

3. Do not leave unit unattended in areas where children have access.

4. Keep unit locked when unattended.

5. Proceed slowly and carefully when moving.

6. Close supervision is necessary when this furnishing is used by, or

near children, invalids, or disabled persons.

7. For indoor use only. Do not install or store where it will be exposed to

moisture.

8. Do not block the ventilation openings.

9. Avoid uneven loading of the equipment into the unit. Uneven weight

distribution could cause unit to tip when mobile.

10. Do not allow anyone to sit, stand, or climb on the unit.

11. When loading, place heavier objects near the bottom of the unit to

avoid tipping.

12. To clean dirty surfaces, use a damp, soft-cloth, or sponge, with mild

soap or detergent solution. Do not use harsh solvents or abrasives.

13. Never drop or insert any object into any opening.

14. This unit is intended for institutional, commercial use only.

15. Use this furnishing only for its intended use as described in these

instructions. Do not use attachments not recommended by the

manufacturer.

16. This unit does not have any user-serviceable parts. If servicing is

necessary, please contact Spectrum Industries for assistance.

WARNING

Relocating audio and/or video equipment to furniture not speci cally

designed to support audio and/or video equipment may result in serious

injury or death due to the furnishing collapsing or over turning onto a child.

WARNING

A remote control or toys placed on the furnishing may encourage a child

to climb on the furnishing and as a result the furnishing may tip over

onto the child. Serious injury or death could occur when children climb

on audio and /or video equipment furniture.

IMPORTANT SAFETY INSTRUCTIONS:

DANGER - Read all instructions before using

DANGER - To reduce the risk of electric shock:

1. This furnishing is only to be used with the power supply unit provided.

2. Always unplug this furnishing from the electrical outlet before cleaning.

3. For added safety, plug the cart into a grounded outlet controlled by a

GFI (Ground Fault Interrupter) circuit breaker.

4. Keep the power switch in the OFF position before plugging or

unplugging from the wall outlet.

5. Turn devices OFF before plugging them in.

6. This furnishing has a polarized plug (one blade wider than the other).

This plug will  t into a polarized outlet only one way. If the plug does

not  t fully into the outlet, reverse the plug. If it still does not  t,

contact a quali ed electrician to install the correct outlet. Do not alter

the plug in any way

7. Do not plug the power cord into an extension cord.

8. Inspect the power cord for damage before each use. Do not operate if

cord or plug has been damaged, or has come into contact with water.

9. To disconnect power, turn all controls to the OFF position, then

remove plug from outlet. Do not pull on cord.

10. Disconnect power before adding or removing components.

11. Do not run power cords across hallways or classrooms. Do not step

on, drive over, drag, or place objects on cord. Keep cord away from

heated surfaces.

12. If servicing is necessary, please contact Spectrum for assistance.

13. Damaged electrical components can create signi cant hazards to

users and is not covered by the warranty. Repairs should always be

performed by a quali ed electrician.

14. Electrical devices are not toys. Children are often unaware of the

hazards associated with electrical devices. This cart must always be

used by adults or with adult supervision.

CAUTION

Risk of Electric Shock. This unit may have multiple power cords. Unplug

all power cords before moving or servicing this furnishing.

WARNING

To reduce the risk of burns,  re, electric shock,

or injury to persons, unplug from outlet(s)

before installing or removing components

Important Safety and Care Instructions

CAUTION

• Always unplug workstation before working under the worksurface.

• Do not place anything under worksurface when operating lift.

• Use caution when raising or lowering the worksurface!

• Be sure workstation movement does not interfere with objects

or people

Moving and parking the workstation

• Before moving, unplug and secure all power cords.

• Close and lock doors.

• Remove any items from the top of the worksurface.

• Unlock the casters.

• Push slowly and carefully. Do not move over uneven or irregular surfaces.

• Do not allow children to move.

• Lock the casters after moving.

• Do not park unit in areas of heavy trafc.

• Do not run power cords across hallways, classrooms, or other areas

where they will be walked on.

• Do not leave unit unattended in areas where children have access.

• Keep doors closed and locked whenever unit is unattended or parked.

• Keep casters locked whenever the workstation is unattended.

0190103R2 Page 3 of 8

(4) 0102297

7mm x 30mm JCWS

(2) 026059

1/4” Flat steel washer

(1) 0132918

Black plastic retainer bracket

(slotted holes)

(Works with Sprout 1.55 by HP,

and Sprout Pro G2

(1) 0132920

Black rear security bracket

(Designed exclusively for

the Sprout Pro G2)

(1) 0131416

Silver rear security bracket

(Designed exclusively for

Sprout 1.55 by HP)

(1) 025039

4mm Hex wrench

(1) 0103500

2.5” Plug

(4) 0114470

3/8-16 x 5/8” Bell glide

Hardware

See separate instructions for installation instructions

Assembly / Setup

0190103R2 Page 4 of 8

Tools

Required

4mm Hex

wrench

(included)

Figure 1

1/4” Washer

under plastic bracket

7mm x 30mm

JCWS

7mm x 30mm

JCWS

Rear security

bracket

1. Install security brackets

1. With the Sprout on worksurface, choose one rear security bracket.

(Bracket for Sprout 1.55, or Sprout Pro G2).

2. Install the rear security bracket with (2) 7mm JCWS. Figure 1. Be

sure bracket is snug up against Sprout before tightening.

3. Install the plastic retainer bracket (with slots) with (2) 7mm JCWS,

and (2) washers under the bracket.

4. Slide the bracket up tight to the Sprout Pro with the touch pad in

place to captivate the pad.

5. Tighten screws securely.

HP Sprout

computer

1. To adjust, tighten or loosen the nut 1/2 turn. Figure 2.

2. Push down the worksurface, then pull the release

handle to check the worksurface extension speed.

3. Repeat this procedure until the desired extension

speed is reached.

2. Column cylinder adjustment

Release handle

Cable adjustment

nut

The worksurface extension speed can be adjusted with

the cable adjustment nut located on the release handle.

Figure 2

Plastic retainer

bracket (with slots)

0190103R2 Page 5 of 8

Operating Instructions:

1. To latch cord - Pull cord out to full length. Allow the cord to retract 1-2 feet back into

the reel. Pull the cord out slowly. When a ‘click’ is heard, the cord will latch in place.

2. Plug into 110-125V (single phase), 3-conductor wall outlet.

3. To release cord - Unplug from wall outlet. Pull cord out slowly until clicking stops.

The latch will release and the cord can be guided back into the reel. Do not allow

the cord to y unrestricted back into the reel.

4. Do not overload or circuit breaker (15-amp maximum) will cut off current. To

restore power, remove overload, wait two minutes, then reset the circuit breaker by

pressing the button on the back of the 3-prong male power plug.

Maintenance:

1. Unplug cord reel before performing maintenance.

2. Remove dirt and grime as soon as it accumulates on the reel case by using a soft,

damp cloth (a mild detergent may be used if needed), being careful not to wet

the electrical plug. Never immerse any part of the unit in any solution to clean.

DO NOT use solvents such as gasoline, turpentine, etc. to clean unit.

3. Keep cord clean to assure smoothest automatic retraction. Simply pull cord to its

full length and allow to retract through a dampened rag. Pull out full length again

and sprinkle cord with talcum powder.

Specications:

1875W, 15A, 125V, 15’ retractable, 12 AWG with breaker, UL Listed

WARNING

• This cord reel is intended for general indoor use only. It is not

intended to be used in potentially dangerous locations such as

ammable or explosive atmospheres.

• The cord reel is not waterproof and not intended for use in potentially

wet locations.

• Do not overload (15-amp maximum).

Reset button

Power plug

CAUTION

1. USE IN COVERED AREAS. OUT OF RAIN & WEATHER

2. NOT FOR USE IN AREAS REQUIRING EXPLOSION-PROOF

FIXTURES.

3. REELS WITH ELECTRICAL OUTLETS:

• Do not overload - See instruction manual for amperage ratings.

• Pull entire cord from reel when using outlet.

4. WHEN HANGING REEL on ceiling (See Instruction Manual):

• BY HOOK - Close hook with pliers to prevent reel from

coming down.

• BRACKET & PIN - With reel in place, bend end of “L” shaped

pin to PREVENT PIN FALLING OUT and reel falling.

5. INSPECT CORD OFTEN and replace if damaged.

6. READ INSTRUCTION MANUAL BEFORE INSTALLING OR USING.

7. UNPLUG BEFORE PERFORMING SERVICE.

Cord reel option

Note: The cord reel is intended to provide temporary

access to electrical outlets for Spectrum mobile lec-

terns. Check local electrical codes prior to use.

Select workstations may have the optional cord reel

installed. It can can be mounted on the left or right-side of

the workstation. Figure 3A.

Phillips

screwdriver

Tools

Required

Pliers

0190103R2 Page 6 of 8

(1) 0115882

Universal mount-

ing bracket

Switching cord reel position

(1) 0114320

Cord reel with

15’ cord

(1) Connector pin

(3) 026064

1/4-20 x 5/8” PHMS

Left Right

Figure 3A

Figure 3B

1. Remove the (2) 1/4-20 x 5/8” PHM screws, and (1) 1/4-20 x 15mm JC

bolt under the cord reel. Figure 3B.

2. Lift out the cord reel / adapter assembly.

3. Remove the 1/4-20 x 15mm JC bolt from the new adapter location.

4. Rotate the cord reel/adapter assembly 180° and attach to the

opposite side with the (2) previously removed 1/4-20 x 5/8” PHM

screws, and 1/4-20 x 15mm JC bolt.

5. Route the power cord out the side grommet. Figure 3C.

Figure 3C

Remove 1/4-20 x 15mm

JC bolt, then re-install

here after adapter has

been moved

(2) 1/4-20 x 5/8”

PHMS

Adapter

New adapter

location

Cord reel

Remove 1/4-20 x 15mm

JC bolt, then re-install

here after adapter has

been moved

Rotate adapter

180°

Adapter

Cord reel

(1) 0131142

Adapter

Figure 4B

Locking caster on

instructor side

Locking caster on

instructor side

Place blocking here

1. Carefully tip up one side of the lectern using blocking. Figure 4B.

2. Remove the two casters.

3. Install two glides.

4. Repeat this procedure for the remaining two glides.

5. Remove blocking.

Casters / Glides

Tools Required

11/16” wrench

(for casters)

1/2” wrench

(for glides)

Note: The Freedom One Lectern comes with factory-installed

casters. If a more permanent non-moving lectern is needed, the

casters can easily be replaced with the included glides. Figure 4A.

Figure 4A

Caster Glide

0190103R2 Page 7 of 8

0190103R2 Page 8 of 8

WE WILL MAKE IT RIGHT FOR YOU!

Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each

product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations).

We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below

from the date of delivery. This warranty shall not apply to defects or damage resulting from misuse, abuse, neglect, improper care, modiﬁ cation or repair not

authorized by Spectrum, or any other cause outside the control of Spectrum. Spectrum will, at its sole option, either repair or replace the defective product.

This warranty is exclusive; no other warranty, written or oral, is expressed or implied. This warranty is given by Spectrum to Buyer and to no other per-

son or legal entity. No Spectrum dealer, distributor, agent or employee is authorized to make any modiﬁ cation or addition to this warranty.

NOTWITHSTANDING ANYTHING TO THE CONTRARY, SPECTRUM WILL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR INDIRECT OR LIQUI-

DATED DAMAGES, INCLUDING CONSEQUENTIAL, INCIDENTAL AND SPECIAL DAMAGES. IN NO EVENT SHALL SPECTRUM’S LIABILITY, WHETHER

UNDER CONTRACT OR WARRANTY, IN TORT OR OTHERWISE, EXCEED THE PURCHASE PRICE RECEIVED BY SPECTRUM FOR THE PRODUCT AT

ISSUE AND “RECALL ACTION” EXPENSES. SPECTRUM SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES, WHETHER ARIS-

ING OUT OF BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING NEGLIGENCE AND STRICT LIABILITY) OR OTHER THEORIES OF LAW, WITH

RESPECT TO PRODUCTS SOLD OR SERVICES RENDERED BY SPECTRUM, OR ANY UNDERTAKINGS, ACTS OR OMISSIONS RELATING THERETO.

Our Customer Service Department is ready to provide immediate attention to any questions, comments or concerns. They are available to answer your calls
