INSTRUCTION MANUAL
ST-AZ30 SERIES
spectrumoi Spectrum_oi Spectrum Optical Instruments

WARNING!!!
Please remember that
never look at the Sun
through a telescope without
proper solar filter, doing so
may permanently damage
your eyes.

Spectrum Optical Instruments’ AZ30
series telescope line is the perfect
telescope to start your night sky
adventure. Its compact design also
allows this scope to be carried around
easily making viewing sky anywhere
possible. It has everything for users
from a beginner to intermediate user
and with the included items, you are
able to view some of the most well-
known celestial objects. With a bonus
smart phone adapter, you can easily
take images of the sky on the go.
The AZ30 series comes with a variety of
apertures including 50,60, and 70
refractors.
INTRODUCTION

SKU
ST-AZ30-50600 ST-AZ30-60500 ST-AZ30-70400
Aperture (MM)
50 60 70
Focal Length (MM)
600 500 400
Telescope Type
Refractor
f/Ratio
f/12 f/8.33 f/5.7
Magnification
30X –180X 25X –150X 20X –120X
Optical Coatings
Fully Coated
Tube Mounting
Vixen Dovetail
View Finder
5x4 Optical View Finder
Mount Type
AZ30 Alt-AZ Mount
Tripod
Full size Aluminum adjustable Tripod with Accessory Tray
Eyepieces
1.25’’ 10mm, 20mm
Other Accessories
1.25’’ 90° Erect-image Diagonal, 1.25’’ 3X Barlow lens,
Bonus Smart Phone Adapter, Bonus Bluetooth Shutter
SPECIFICATIONS
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.

MAJOR PARTS & NAMES
Tripod (3)
Mount (2)
Optical Tube
Assembly (OTA) (1)
Accessory Tray (4)
Tripod leg lock (6)
Tripod leg (7)
Spreader bar (5)
Control Handler (12)
Saddle plate/Dovetail
receiver (10)
Azimuth lock knob (11)
OTA locking knob (13)
Dew shield (9)
Dovetail (8)

MAJOR PARTS & NAMES
Viewfinder locking
knob (15)
Eyepiece locking
screw (19)
Diagonal locking screw (17)
5x4 Optical View Finder (14)
Eyepiece (20)
Diagonal (18)
Red Dot View Finder
adjustment knobs X3 (21)
Focuser (16)

Set up video for ST-AZ30 series is available on our YouTube channel and TikTok, feel free to check those out!
SET UP INSTRUCTION
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.
Tripod & Mount
1. Release the tripod leg lock (6) and fully
extend the spread tripod legs (7) to set
the proper height
2. Place the tripod (3) on a relatively flat
ground where you have a clear view to
the sky (if you are viewing celestial
objects) or distanced ground (if you are
viewing land objects).
3. Adjust the height of the legs to level the
top of the tripod.
4. Attach the accessory tray (4) onto the
center spreader bars (5) and temporarily
place all the accessories there.
5. Rotate the control handler (12)counter-
clockwise to loosen the altitude axis.
Unfold mount till the saddle plate (10)is
relatively parallel to the ground.
6. Lock the altitude axis back by rotating
the control handler clockwise when
done.
7. With these steps done properly, your
tripod and mount are now set up
correctly.
OTA
1. Locate the two threaded holes on the
bottom of the Vixen dovetail (8) and
place the Optical Tube Assembly (OTA)
(1) onto the saddle plate (10)located on
the mount (2) and tighten the OTA lock
knob (9) to a firm feel.
2. Install the view finder (14)and secure it
by tightening the lock knob (15)to a firm
feel.
3. Install the diagonal (18)into the optical
tube, and secure the diagonal by
tightening the diagonal locking screw
(17).
4. Selectively install the Barlow Lens per
desire
5. Slide an eyepiece (20)into the diagonal
and secure it by tightening the eyepiece
locking screw (19).
View Finder Alignment
1. Point the OTA at a distanced land object during
the daytime, such as a distanced light pole.
2. Look through the lower-power eyepiece first
and center the object in the eyepiece
3. Focus the telescope by turning the focus knob
(16)till the object is sharp and clear.
4. Look though the viewfinder and adjust the
crosshair by tightening and loosening one of
the three view finder alignment knobs (21)at
the same time till the crosshair is overlapping
the same object centered in the eyepiece.
5. Repeating the same process at night by
pointing at a celestial object such as the Moon
will further align your viewfinder and OTA.

FAQs
What is aperture of a telescope?
Aperture of a telescope refers to the diameter of the diameter of the objective lens (for refracting telescope) or the primary mirror (for reflecting
telescopes). The aperture of the telescope determines how light the telescope and observe hence how much detail you can see. The rule of
thumb: the bigger the aperture, the more detail you can see.
Should I choose the larger aperture?
Aperture of a telescope is what determines how much light can a telescope observe. The larger the aperture, the more light can be collected,
which results in greater image resolution. In short, with a telescope with a larger aperture, you can see more detail and better detail than the one
with a smaller aperture. However, the larger the aperture, the more expensive the telescope is.
How to calculate the magnification of a telescope?
The magnification of a telescope is equal to the telescope’s focal length divided by the eyepiece’s focal length. Focal length of a telescope and an
eyepiece can be found on the specification sheet, on our telescope, the two are actually printed onto the body of the OTA and the eyepieces for
easier access. For example, with a 20mm eyepiece, a 900mm OTA will give you 45X magnification; with a 10mm eyepiece, a 900mm OTA will give
you 90X magnification.
What does the number on an eyepiece mean?
The number on an eyepiece refers to the focal length of the eyepiece which is usually measured in millimeter (MM). For example, a 25mm
eyepiece has a focal distance of 25mm. The bigger the number, the longer the focal which results in a lower magnification.
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.

FAQs
What does the number on an eyepiece mean?
The number on an eyepiece refers to the focal length of the eyepiece which is usually measured in millimeter (MM). For example, a 25mm
eyepiece has a focal distance of 25mm. The bigger the number, the longer the focal which results in a lower magnification.
How to take an image through a telescope with a phone?
Our telescopes are perfect for taking image of bright objects such as the moon. To take an image through a telescope with your phone is very
easy. Point the telescope at and focus on the object you want to take an image of, then use our included bonus smartphone holder to hold your
phone with, then simply take a picture.
Better yet, you can use our included Bluetooth shutter to control your phone to avoid any potential shaking induced by touching the screen of
your phone directly. You can of course simply hold your phone next to the eyepiece and take a picture.
Why is my OTA pointing at one object and my view finder is pointing at another?
In this case, there is ahigh possibility that your OTA is not properly aligned with the viewfinder.
We recommend aligning the two in the morning first. Point your telescope at a land object that is at a far distance, such as a street light or a
“STOP” sign, and center the object in the eyepiece. Adjust view finder alignment screws till the viewfinder is pointing at the same object you
have centered in your eyepiece.
Then, repeat the same procedure at night by pointing at a large ad bright celestial object such as the moon. Small adjustments may be required
at this point.
After these two steps. Your OTA and view finder are aligned properly.
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.

FAQs
What can be observed by my telescope?
With the included eyepieces, you can observe the crater of the moon, planets of our solar system (Saturn), as well as Orion Nebula. You can also
observe terrestrial objects such as sail boat. However, please keep in mind that never look at the Sun without a proper solar filter, this may
permanently damage your eyes.
There are 3 included eyepieces, which one should I start with?
Best practice is to start with lower power eyepiece because the lower magnification gives you a large Field of View (FOV) of the sky making
locating the object easier. After centering the object in the eyepiece, you may switch to a higher power eyepiece to see more detail.
Will this telescope work with my 1.25’’ eyepieces?
Yes, by default, this telescope has a 1.25’’ eyepiece adapter so it will work with all the 1.25’’ accessories.
What is a Barlow lens?
A Barlow in astronomy is a lens to increase the magnification of a telescope. Usually, a Barlow would be labelled “2X,” “3X,” and etc. a 2X Barlow
doubles the magnification of your telescope and a 3X Barlow trebles the magnification. For example, using a 2X Barlow on a setup that originally
give you 150X magnification will double your magnification making the overall magnification 300X
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.

CUSTOMER SOLUTIONS
If you have a question concerning your telescope, please reach out to Spectrum Optical
Instruments via any of the social media platforms below. You can also contact us via email at
cust[email protected].We will get back to you as soon as we can.
spectrumoi
Spectrum Optical Instruments
Spectrum_oi
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.

LIMITED WARRANTY
Every Spectrum Optical Instruments telescope and product is warranted by Spectrum Optical Instruments to be free
of defects in materials and workmanship for a period of ONE YEAR from the date of purchase in the US.If a defect is
identified on a new product, Spectrum Optical Instruments will repair or replace a product with proof of original
purchase. This warranty only applies to the original purchaser and it is not transferable.
This warranty is not valid where the product has been damaged due to abused or mishandled, attempted or
performed unauthorized repairs, or depreciation due to normal wear-and-tear. Spectrum Optical Instruments
specifically disclaims special, indirect, or consequential damages or lost profit which may result from a breach of
this warranty. Any implied warranties which cannot be disclaimed are hereby limited to a term of one year from the
date of original retail purchase.
This warranty gives specific rights. You may have other rights which vary from state to state.
Spectrum Optical Instruments reserves the right to change product specifications or to discontinue products
without notice.
A claim is required to be filed before return of a product. A claim can be filed by obtained from Spectrum Optical
Instruments by email. Each return product must include a written statement detailing the nature of the claimed
defect. As well as the original purchaser’s name, address, and contact information.
NOTE: buyers are responsible for return shipping and handling cost for warranty services after 30 days of original
purchase. Our warranty covers parts and labor only.
Please DO NOT look at the Sun through your telescope without a proper filter. This may damage your eyes permanently.
