Speedtech Instruments
Model: AE-2
Speedtech Angler’s EDGE PLUS
User’s Manual
10
5
20 4 6 8 10 12 14 16 18 20 2 2 24
-24 -22-20 -18 -16 -14-12 -10 -20
-4 -6 -8
FISH
0
W E
Hr
FUTURE

INTRODUCTION
Speedtech’s Angler’s EDGE PLUS is a
handheld precision instrument which tracks sun
and moon positions, barometric air pressure,
and predicts fish feeding activity based on
those measurements.
FEATURES
•Present fish feeding activity, 1-10
•4-hr future fish feeding activity forecast
•96-year fish feeding activity based on future
sun and moon information
•Barometric air pressure with 24-hr history
•Sunrise, sunset times
•Moon phase and position
•Weather forecast based on pressure
•EL backlight
SCIENTIFIC BASIS
Anglers and scientists alike identify several
key factors affecting fish behavior. For
centuries, fishermen have been aware that
moon phase and position relative to the earth’s
surface can greatly influence feeding activity.
Details of record game fish catches clearly
suggest that lunar phase has a bearing on fish
feeding activity, with specific lunar events such
as full or new moons being the most notable
times of good catch rates. This activity occurs
among both ocean-dwelling and freshwater
fish. The time of day and sun position are
important components as well.
Weather is another vital factor affecting fish
activity. Evaluations of bass and walleye
tournament summaries from across the United
States demonstrate the importance of local
weather patterns and events on fish behavior.
A wide range of other fish species, occupying a

variety of habitats, detect and respond to
barometric pressure changes associated with
weather patterns.
The algorithm developed for the Angler’s
EDGE combines moon phase, and sun and
moon position, with barometric pressure
effects. All of these factors have been
combined into one comprehensive relationship
to predict fish feeding activity. The factors
used in the instrument were derived from a
variety of sources, including discussions with
meteorologists, fish biologists, anglers, and
extensive surveys of the scientific and popular
literature.
A combined total of over 40 years of fishery
research experience and personal observations
contributed to the development of the software
used in the instrument. All of this information
has been consolidated into the Angler’s EDGE
to provide anglers with the ability to determine
the best times to fish.
INITIAL SET UP
1. Two CR2032 Lithium button-cell batteries
are included with your Angler’s EDGE.
2. Using the provided small screwdriver,
remove the battery cover and insert the
batteries (positive side facing up), closing the
cover. Be sure to seat the rubber gasket
properly (this may take some patience).
3. Follow the SETUP guide to set the time,
date, coordinates and other settings.

BASIC OPERATION
Refer to FULL OPERATION for detailed
instructions.
1. Press and hold the MODE button for 2
seconds to turn on (and off).
2. Press the TIME button to switch between
present and future modes.
3. Press the MODE button to cycle through
each screen of information
4. Press and hold the SET button for 2-seconds
to enter programming mode.
5. Press and hold the TIME button for
2-seconds to activate/deactivate the button
lock.
6. Press the SET button briefly to turn on
backlight for four seconds.
DISPLAY
A. Present fish feeding activity, 1-10 bars
B. 4-hour future activity (24-hour forecast in
the future time mode)
C. Weather forecast (on present mode only)
D. Moon phase
E. Sun and moon position
F. Time (this will change when the MODE
button is pressed)
E
PRESENT
10
5
20 4 6 8 10 12 14 16 18 20 2 2 24
0
W E
Hr

-- SETUP PROCEDURES --
INFO NECESSARY FOR SETUP
Proper set-up requires the local time and date,
time zone (hours from GMT), latitude and
longitude (in degrees and minutes), and
altitude. The fish feeding algorithm is directly
related to sun and moon positions, which are
set from latitude, longitude and time zone.
Barometric air pressure also affects fish
behavior, and the correct altitude must be
entered to establish the correct relative air
pressure.
TIME ZONE
The time zone setting is based on the deviation
from GMT (Greenwich Mean Time). If your
location follows Daylight Saving Time (DST),
the resulting time zone must be increased by
one during this time (summer time).
North American Time Zones:
Atlantic Time -4 (-3 during DST)
Eastern Time -5 (-4 during DST)
Central Time -6 (-5 during DST)
Mountain Time -7 (-6 during DST)
Pacific Time -8 (-7 during DST)
Alaska Time -9 (-8 during DST)
Hawaii Time -10 (-9 during DST)
LATITUDE, LONGITUDE, ALTITUDE
The correct latitude and longitude is necessary
for proper sun and moon information. The
correct altitude is required for proper
adjustment of air pressure. To locate your
latitude, longitude and altitude, refer to a GPS
unit, local airport, or the internet. The easiest
online source is www.topozone.com. Choose
“Get a Map” and enter in your town and state.
In the “Place Name Search”, it will show
elevation in feet and latitude/longitude as a
decimal. Double click on the town name and a
map will appear. At the bottom of the map,

select D/M/S. Then look above the map for
latitude/longitude in degrees/minutes (pay
attention to the direction as well; North/South
and West/East).
If you know the latitude/longitude in decimal
degrees only, use the whole number for the
degrees entry, and multiply the decimal by 60
to calculate the minutes. For example, 35.407°
is 35 degrees, and 24 minutes (.407 x 60).
Note: the continental US lies within Latitudes
N25
° - N49 ° and longitudes W67 ° - W123 ° .
For locations in Canada, use the website
www.nrcan-rncan.gc.ca. For locations outside
of North America, use www.mapquest.com or
www.world-gazetteer.com.
If there is trouble accessing your local
coordinates, please e-mail Speedtech at
[e-mail] for assistance.
DETAILED SETUP
If unit is off, press and hold MODE button for
two seconds to turn ON. There is a set-up for
the present mode and for the future mode,
depending on which mode the unit is in when
the programming mode is entered (press the
TIME button to switch modes). It is best to set
the present mode settings first.
1. Press and hold the SET button for two
seconds to enter the set-up mode (skip to #2 if
setting future mode); “12Hr” will flash. Press
the – or + button to select 12Hr (AM/PM) or
24Hr (“military” time). Press SET button to
confirm.
PRESENT
TIME
2. The hour will flash. Press the – or + button
to set the current hour (note AM or PM if in
12Hr mode). Press the SET button to confirm.

3. The minutes will flash. Press the – or +
button to set the current minute. Press the SET
button to confirm.
4. The month will flash. Press the – or +
button to set the current month. Press the SET
button to confirm.
5. The day will flash. Press the – or + button
to set the current day. Press the SET button to
confirm.
6. The year will flash. Press the – or + button
to set the current year. Press the SET button to
confirm. Skip to 9 for future mode.
7. (present mode only) The pressure unit
(inHg or mb) will flash. Press the – or + button
to select inHg or mb. Press the SET button to
confirm.
8. (present mode only) The altitude unit will
flash. Press the – or + button to select ft or m
(meters). This is for the altitude input for
pressure adjustment. Press the SET button to
confirm.
9. The time zone will flash. Press the – or +
button to set the local time zone. Press the SET
button to confirm.
10.The latitude direction will flash. Press the –
or + button to set N (North) or S (South). Press
the SET button to confirm.
11.The latitude degrees will flash. Press the –
or + button to set the latitude degrees. Press the
SET button to confirm.
12.The latitude minutes will flash. Press the –
or + button to set the latitude minutes. Press the
SET button to confirm.
13.The minutes will flash. Press the – or +
button to set the current minute. Press the SET
button to confirm.
14.The longitude direction will flash. Press the
– or + button to set W (West) or E (East). Press
the SET button to confirm.
15.The longitude degrees will flash. Press the –
or + button to set the longitude degrees. Press
the SET button to confirm.

16.The longitude minutes will flash. Press the
– or + button to set the longitude minutes.
Press the SET button to confirm.
17.(present mode only) The altitude
compensation will flash. Press the – or + button
to set the local altitude (in feet or meters, as
selected in step 8). Press the SET button to
confirm.
The set up is now complete.
Note: the future time and date can only be set
for a time and date in the future or current time
and date. If a past time and/or date is set, the
time and date will default to the current set
time and date.
-- OPERATION AND FEATURES --
DISPLAY MODES
Press the MODE button to scroll through
information, in either present or future modes;
no pressure will display in future mode.
TIME →DATE →YEAR →PRESSURE
→SUNRISE →SUNSET →TIME
When in pressure mode, the graph at the top
will display 24-hour history.
The display will revert to the time display if no
buttons are pressed for one minute and will
turn off when no button is pressed for five
minutes (all settings remain, and air pressure is
still tracked).

FISH FEEDING FORECAST
The unique feature of Speedtech’s Angler’s
EDGE is the fish feeding prediction. The graph
on the right side of the LCD displays the
present fish feeding activity level, on a scale
from 1 (low) to 10 (high). In present mode, this
is for the current time; in future mode, this is
for the set time and date.
HIGH
FISHING
ACTIVITY
MEDIUM
FISHING
ACTIVITY
LOW
FISHING
ACTIVITY
The graph at the top of the LCD (except when
viewing air pressure) shows the future fish
feeding activity. The current level is displayed
as “0 Hr” on the left. In present mode, the
activity is for the next four hours; for future
mode this is for the next 24 hours.
Present 4-hour graph:
10
5
20 4 6 8 10 12 14 16 18 2 0 22 24
0
Hr
Future 24-hour Graph
10
5
20 4 6 8 10 12 14 16 18 2 0 22 24
0
Hr
Note that the “future” mode may be set for any
time and date through 2099, including the
current time. The fish feeding activity based on
sun/moon position only.

FUTURE MODE FEATURES
When viewing the time in future mode, the –
and + buttons can be pressed to scroll ahead or
backward hour-by-hour. The time scrolled to
will remain set. This is useful for preparing for
a future fishing trip and planning the best times
to fish.
If the future time and date is equal to the
current time and date, it will track along. This
feature is good for planning shorter-term
fishing plans, over the next 24 hours.
No weather prediction or barometric air
pressure can be viewed when in future time
mode.
BAROMETRIC AIR PRESSURE
The built-in barometer senses the changes in
barometric air pressure every 15 minutes, even
when the unit is “off”. When viewing the
current air pressure, the chart on the top of the
LCD will display the air pressure history for
the past 24 hours. Each column, right to left,
represents one hour in the past. Each dot
represents a change in air pressure, up or down,
relative to the current air pressure, or “0 Hr”.
To read the graph, follow the chart from left to
right. The graph will increase when the air
pressure rose, and decrease when the pressure
fell. The pressure trend for the past 6 hours is
the most useful for short-term weather
forecasting.
>+4
<-4
0
-24 -22 -20 -18 -16 -14-12 -10 -20
-4 -6 -8
hPa
Hr

WEATHER FORECAST
The Angler’s EDGE measures changing air
pressure and predicts short-term changes in
weather over a small area. In general, falling
air pressure results in worsening weather, and
rising air pressure results in fairer weather.
Rapidly falling pressure signals an approaching
storm, while rapidly rising pressure will result
in strong winds. The weather forecast is for the
next 6 to 12 hour period, over an area of 20 to
30 miles. The accuracy of any pressure-based
forecast is about 75%, although less in areas
where pressure does not affect weather as
much.
SUNNY PARTLY
CLOUDY CLOUDY RAINY
SEVERE WEATHER WARNING
By definition, severe weather occurs when
barometric air pressure has changed by 6
milibars (up or down) during a three hour
period. Severe weather, including wind and
rain, generally accompanies falling barometric
air pressure. Rising pressure will result only in
high winds.
When severe weather is detected, the unit will
give out an audio warning and flash the
weather icon. The alarm is muted by pressing
any button. The alarm will sound even if the
display is off, unless this feature is disabled.
To disable the severe weather warning, press
and hold the – button for three seconds while in
present mode. A beep will sound once. To
activate the alarm, press and hold the + button
for three seconds while in present mode. A
series of three beeps will sound.

MOON PHASE
The moon phase is indicated in eight symbols,
as shown below. The moon phase is for either
the present date, or for the set future date,
depending on which mode is viewed.
N
ew moon Waxing crescent First quarter Waxing gibbous
Full moon Waning gibbous Last quarter Waning crescent
SUN AND MOON POSITIONS
A useful feature of the Angler’s EDGE is the
chart displaying sun and moon positions. Once
understood, the current positions of the sun and
moon can be determined at a glance. The
center circle represents the earth, with the sun
and moon revolving from East (rising) to West
(setting).
The exact sunrise and sunset times can be
located by pressing the MODE button and
cycling through the modes, in either present or
future mode.
WWWW EEEE
MOON
RISE
MOON
OVERHEAD
MOON
SET
MOON
UNDERFOOT
WWWW EEEE
SUNRISE SUN
OVERHEAD
SUNSET SUN
UNDERFOOT
**If the sunrise and sunset times appear to be
off by an hour, check to be sure the correct
time zone is set, taking into account daylight
saving time. If it appears to be off by more than
an hour, check the latitude and longitude,
including the direction.
KEY LOCK
The buttons may be locked to prevent
accidental changes. Press and hold the TIME

button for two seconds to activate/deactivate
the key lock.
CONDITIONS AFFECTING ACCURACY
When the unit is subjected to a change in
altitude, which can occur when ascending or
descending a building or when traveling across
uneven terrain, the pressure readings are
affected. Since the present fish feeding
prediction, weather forecast, and severe
weather alarms rely on changing air pressures,
those readings should be ignored until the
altitude has been steady for two to three hours.
Also be sure to set the altitude adjustment to
the current altitude (if known).
BELT CLIP, CARRY POUCH
A belt clip (which can also be used as a
mounting bracket) is attached and can be
removed if desired. A carry pouch is also
included to protect the unit from the elements.
MAINTAINENCE
The Angler’s EDGE is designed to withstand
moderate elements, but like most electronic
devices should be handled carefully to avoid
damage. Do not submerge in water.
WARRANTY
Speedtech’s Angler’s EDGE is warranted
against manufacturing defects for one-year.
This does not cover physical damage as a result
of misuse. Please refer to the instructions or
contact us for answers and assistance.
Speedtech Instruments
45449 Severn Way, STE 165
Sterling, VA 20166
703-430-8055
703-430-8066 (fax)
9:00 – 5:00 pm Eastern, M - F
[email protected]
www.speedtech.com
