WS-9057U-IT FAQS
The links below will work in most PDF viewers and link to the topic area by clicking
the link. We recommend Adobe Reader version 10 or greater available at:
http://get.adobe.com/reader
CONTENTS
WS-9057U-IT FAQS............................................................................................................ 1
Batteries ................................................................................................................................ 2
Forecast Station Factory Restart .................................................................................. 2
Outdoor Temperature/Humidity Transmitter........................................................... 3
Compatible Outdoor Transmitters.................................................................................... 3
Power Requirements .......................................................................................................... 3
Dashes shown for Outdoor Temperature/Humidity ...................................................... 3
Outdoor Temperature/Humidity Changes Constantly .................................................. 3
Inaccurate Outdoor Temperature/Humidity Reading ................................................... 4
Intermittent Outdoor Temperature/Humidity................................................................ 4
Outdoor Transmitter Fell and No Longer Works............................................................ 4
Outdoor Transmitter Drains Batteries Quickly............................................................... 5
Outdoor Temperature/Humidity Is Stuck or OFL .......................................................... 5
Fahrenheit/Celsius.............................................................................................................. 5
MIN/MAX Temperature Readings..................................................................................... 5
Channels............................................................................................................................... 6
Multiple Outdoor Transmitters.......................................................................................... 6
Mounting/Positioning Outdoor Transmitter .................................................................... 6
Position Forecast Station................................................................................................... 7
Distance/Resistance/Interference.................................................................................... 7
Forecast Station.................................................................................................................. 8
How Tall are the Time Numbers?..................................................................................... 8
Supported Time Zones....................................................................................................... 8
12-Hour or 24-Hour Time Format.................................................................................... 8
Power Requirements .......................................................................................................... 8
Manually Set Time/Date: Program Menu ...................................................................... 9
No WWVB Tower Icon.......................................................................................................10
Dashes, OFL or Stuck Indoor Temperature/Humidity.................................................10
Inaccurate Indoor Temperature/Humidity Reading.....................................................10
Time is off by hours...........................................................................................................10

La Crosse Technology, Ltd. Page 2
Set Time Alarm ..................................................................................................................10
Activate/Deactivate Time Alarm......................................................................................10
Snooze Alarm .....................................................................................................................11
Forecast Icons Inaccurate................................................................................................11
Forecast Arrows .................................................................................................................11
Barometric Pressure..........................................................................................................11
Pressure History.................................................................................................................12
Moon Phase.........................................................................................................................12
Forecast Station has Missing Segments ........................................................................12
Forecast Station is Dim.....................................................................................................13
Forecast Station has Distorted Display..........................................................................13
Forecast Station Display is Frozen..................................................................................13
Forecast Station is Blank: No Letters, Numbers or Dashed Lines.............................13
Forecast Station Drains Batteries Quickly .....................................................................13
Comfort Level Indicator....................................................................................................14
Batteries
Half of all warranty issues can be resolved with fresh batteries of the appropriate
voltage.
We suggest name brand alkaline batteries for forecast stations.
Use batteries dated at least six years in advance of the current year. Batteries
dated earlier than six years from now may still work, but may be unstable in
performance.
Alkaline batteries manufactured this year will have an expiration date 10 years
in the future. Battery technology has improved and batteries will maintain
voltage longer in storage. However, the environment the batteries reside in for
the 10 years can deplete the power.
Good name brand batteries make less noise, which reduces the chance of RF
(radio frequency) interference from the battery compartment.
A minimum voltage of 1.48V for each battery is necessary for proper
performance.
Forecast Station Factory Restart
DISTANCE: bring the transmitter, forecast station together inside, and place
both 5-10 feet apart with nothing between them.
REMOVE POWER: Remove batteries from the transmitter and forecast station.
DISCHARGE ELECTRICITY: Press one of the buttons on the forecast station least
20 times to clear all memory. Verify that the forecast station is blank before
proceeding.
UNPOWERED 15 MINUTES: Let the forecast station and transmitter sit with
power removed for at least 15 minutes.

La Crosse Technology, Ltd. Page 3
Note: Failure to allow a display to rest for 15 minutes can result in failure to
connect with the outdoor sensor or missing segments on the display. The
instruction manual describes a setup for a new unit that has not had time to
build up residual electricity.
TRANSMITTER: Insert fresh batteries into the transmitter, observing the correct
polarity.
Keep the transmitter 5-10 feet from the Forecast Station.
FORECAST STATION: Insert fresh alkaline batteries in the Forecast Station.
WAIT: Wait for 5 minutes for the outdoor temperature/humidity to appear.
CONNECTION: When RF (radio frequency) connection is established, the
respective temperature & humidity will appear on the main unit. Allow the
transmitter and Forecast station to sit together for 15 minutes to establish a
strong connection.
PLACE TRANSMITTER OUTSIDE: For optimum 915MHz transmission, place the
outdoor transmitter a distance of no more than 330 feet (100 meters, open air)
from the Forecast Station.
See the section on mounting and distance/resistance/interference for details on
mounting the outdoor transmitter.
Outdoor Temperature/Humidity Transmitter
Compatible Outdoor Transmitters
The TX29UDTH-IT, TX21U-IT, TX44UDTH-IT, TX29UTH-IT and TX28U-IT sensors
(915MHz) will work with this station.
Power Requirements
2-AA batteries power the outdoor transmitter.
We recommend alkaline batteries for the transmitter.
Dashes shown for Outdoor Temperature/Humidity
Dashes means the connection is lost between the forecast station and the
outdoor transmitter.
Check the reading on the transmitter display.
Batteries often resolve the connection.
Distance/Resistance can cause loss of connection between the transmitter and
the Forecast Station.
Reorientation of the Forecast station 90 degrees towards the outdoor transmitter
may provide better reception by the antenna.
Try the factory restart.
Outdoor Temperature/Humidity Changes Constantly
The forecast station can read up to three outdoor transmitters.
Check the channel indicator. If it switches between 1, 2 or 3, your forecast
station is reading additional transmitters.
Check if the transmitter display reads the same as a channel on the forecast
station.
Press and release the SNOOZE/CH button to settle on one channel.

La Crosse Technology, Ltd. Page 4
Note: When first powered up it is natural for the forecast station to search
across all three channels for up to 15 minutes for outdoor transmitters.
You may have an additional compatible outdoor transmitter within range.
Occasionally a neighbor will have a compatible outdoor transmitter that is within
range.
Inaccurate Outdoor Temperature/Humidity Reading
The outdoor transmitter reads the environment. When mounted in the home it
will read inside temperature/humidity.
When the transmitter reads high during the day but not at night it is a
positioning problem.
Side-by-side test: Bring the outdoor transmitter in the house and place it next
to the Forecast station for 2 hours.
Compare indoor and outdoor temperature. The temperatures should be within 4
degrees to be within tolerance. The humidity should be within 14% to be within
tolerance.
If the transmitter reads correctly when next to the forecast station then try a
different location outside.
Look for heat sources such as sunlight, door or window frames, or reflected
heat.
Intermittent Outdoor Temperature/Humidity
RF (radio frequency) communication may come and go occasionally. This can be
normal in some environments (e.g. moister climates). If transmitter signal is
lost, please wait 2-4 hours for the signal to reconnect on its own.
Move the outdoor transmitter to a closer location.
Check Channels: The forecast station may be reading more than one
transmitter.
Freezer test: Confirm the forecast station is reading the correct outdoor
transmitter. Place the transmitter in the freezer for an hour and watch the
temperature drop on the forecast Station.
Indoor distance test: Please complete the Restart with transmitter and
forecast station 5-10 feet apart and inside to establish a strong connection.
After 15 minutes if there is a reading in the outdoor temperature area, move the
transmitter to another room with one wall between the transmitter and the
forecast Station. Observe to see if the temperature/humidity remains on
consistently for 1-hour.
If the temperature/humidity remains on while in the house then it is likely a
distance/resistance issue. Move the transmitter to different locations outside to
find a location where the temperature/humidity reading will hold.
Distance/Resistance can cause loss of transmitter signal.
Check Batteries.
Outdoor Transmitter Fell and No Longer Works
If there is no physical damage to the outdoor transmitter, the fall may not have
caused internal damage.
An outdoor transmitter that has fallen into a puddle or other standing water or
snow may have water damage.

La Crosse Technology, Ltd. Page 5
Transmitters are water resistant, not waterproof.
A fall can shock the transmitter or the batteries in the transmitter.
Batteries that have fallen on a hard surface may be damaged and unable to
function properly.
Complete a Restart with fresh batteries.
Use Batteries dated at least six years in advance of the current year. Batteries
dated earlier than six years from now may still work, but may be unstable in
performance.
Outdoor Transmitter Drains Batteries Quickly
Test a new set of alkaline batteries. Write down the date of installation and the
voltage of the batteries.
When the batteries fail, please note the date and voltage again. This is helpful in
determining the problem.
Check the distance and resistance between the transmitter and forecast station.
Transmitters at the end of the range may work while batteries are fresh but not
after they drain a bit.
Check for leaking batteries, which may damage the transmitter.
Battery life is over 24 months when using reputable battery brands for both
Alkaline and Lithium batteries.
Outdoor Temperature/Humidity Is Stuck or OFL
Check Batteries. Overpowered or underpowered batteries can cause this
reading.
Replace outdoor transmitter.
Fahrenheit/Celsius
Enter the program menu to switch from Fahrenheit to Celsius.
MIN/MAX Temperature Readings
This station will show the minimum and maximum temperatures from setup,
until you reset the min/max temperatures or remove the batteries from the
station.
To view a 24-hour min/max reading, reset the min/max temperatures at the
same time each day.
VIEW INDOOR MIN/MAX RECORDS: Press and release the IN button to display
Indoor Max, Min and Current records.
RESET INDOOR MIN/MAX RECORDS: Press and release the IN button to select
the record you wish to reset either MAX or MIN. Press and hold the SET button
for five seconds. The record will reset to the Current Date, Temperature and
Humidity.
NOTE: Each Min or Max value will need to reset separately.
VIEW OUTDOOR MIN/MAX RECORDS: Press and release the OUT/PLUS button
to display the Outdoor Max, Min and Current records.
RESET OUTDOOR MIN/MAX RECORDS: Press and release the OUT button to
select the record you wish to reset either MAX or MIN. Press and hold the SET

La Crosse Technology, Ltd. Page 6
button for five seconds. The record will reset to the Current Date, Temperature
and Humidity.
NOTE: Each Min or Max value will need to be reset separately
Channels
The Forecast station will accommodate up to three remote outdoor transmitters.
The SNOOZE/CH button on the Forecast station allows you to see the
temperature in various locations: outdoors, baby’s room, greenhouse,
basement, etc.
Press and release the SNOOZE/CH button to view channel 1, 2 or 3 on the
display when multiple transmitters are used.
Note: You cannot change channels if only one transmitter is connected.
Multiple Outdoor Transmitters
The wireless forecast station will accommodate up to three remote outdoor
transmitters (TX29UDTH-IT). The SNOOZE/CH button allows you to see the
temperature in various locations: outdoors, baby’s room, greenhouse,
basement, etc.
Remove the battery cover from all the transmitters.
Insert 2-AA batteries in the first outdoor transmitter.
Insert two NEW “C” batteries (not included) into the back of the wireless
forecast station. The Wireless Forecast Station will light up and show, indoor
temperature, humidity and pressure.
When the reading appears in the outdoor temperature area, move to the second
transmitter.
Insert 2-AA batteries in the second outdoor transmitter.
The outdoor temperature area should show a temperature reading on channel 1
and on channel 2.
When the readings appear in the outdoor temperature area (channel 2), move
to the third transmitter.
Insert 2-AA batteries in the third outdoor transmitter.
When RF (radio frequency) connection is established, the respective
temperature & humidity for each of the selected channels (1, 2, or 3) will appear
on the main unit. Allow the transmitters and wireless forecast station to sit near
each other for 15 minutes to lock in the signals.
Press and release the SNOOZE/CH button to view channel 1, 2 or 3 on the
Wireless Forecast Station when multiple transmitters are used.
Note: You cannot change channels if only one transmitter is connected.
Mounting/Positioning Outdoor Transmitter
Mount outdoor temperature/humidity transmitters vertically and under a bit of
an overhang.
Protect the outdoor transmitter from standing rain or snow, and from the
overhead sun, which can cause it to read incorrectly. Generally, mounting under
an eave or deck rail works well.
Construct a small roof or box for the transmitter if you do not have an overhang.
Please be sure it is well vented.

La Crosse Technology, Ltd. Page 7
Mount the transmitter on the North side to prevent sun from causing incorrect
readings.
Mount at least 6 feet in the air for a strong signal.
Outdoor transmitters are water resistant but not water proof.
Avoid more than one wall between the transmitter and the forecast station.
Do not mount near electrical wires, transmitting antennas or other items that
will interfere with the signal.
RF (radio frequency) signals do not travel well through moisture or dirt.
Place the outdoor transmitter and the forecast station in the desired shaded
locations, and wait approximately 1-hour before permanently mounting the
transmitter to ensure that there is proper reception.
Do not mount the transmitter on a metal fence. This significantly reduces the
effective range.
MOUNT
Remove the mounting bracket from the outdoor temperature sensor .
Place the mounting bracket over the desired shaded location (wall or table).
Through the screw holes of the bracket, mark the mounting surface with a
pencil.
Screw mounting bracket onto the mounting surface. Ensure that the screws are
flush with the bracket.
Insert the outdoor temperature sensor into the bracket.
Note: Mounting with adhesive tape is not recommended as a permanent
mounting solution. Only use the adhesive tape during set-up process.
Position Forecast Station
The Forecast station has pull out legs to sit on a desk or table, or it can hang on
a wall.
Choose a location 6 feet or more from electronics such as cordless phones,
gaming systems, televisions, microwaves, routers, baby monitors, etc., which
can prevent signal reception.
Place within range of the outdoor transmitter.
Be aware of electrical wires and plumbing within a wall. This will interfere with
signal reception.
The maximum transmitting range in open air is 330-feet (100 meters).
Obstacles such as walls, windows, stucco, concrete, and large metal objects can
reduce the range.
For best WWVB reception, orientate the forecast station with the front of the
back facing Ft. Collins Colorado.
Distance/Resistance/Interference
Distance:
The maximum transmitting range in open air is over 330-feet (100 meters)
between the outdoor transmitter and the forecast station.
Consider what is in the signal path between the forecast station and the
transmitter.
Consider the distance the forecast station is located away from other electronic
in the home.

La Crosse Technology, Ltd. Page 8
Resistance:
Obstacles such as walls, windows, stucco, concrete, and large metal objects can
reduce the range.
When considering the distance between the transmitter and the forecast station
(330 feet open air) cut that distance in half for each wall, window, tree, bush or
other obstruction in the signal path.
Closer is better.
Do not mount the transmitter on a metal fence. This significantly reduces the
effective range.
Interference:
Consider items in the signal path between the transmitter and the forecast
station.
Sometime a simple relocation of the transmitter or the forecast station will
correct the interference issue.
Windows can reflect the radio signal.
Metal will absorb the RF (radio frequency) signal.
Stucco is held to the wall by a metal mesh.
Transmitting antennas (ham radio, emergency dispatch center, airports, military
base etc.)
Electrical wires (utilities, cable etc.)
Vegetation is full of moisture and reduces signal.
Dirt: Trying to receive a signal through a hill is difficult.
Forecast Station
How Tall are the Time Numbers?
The time numbers are 0.59 inches tall.
Supported Time Zones
This Forecast station offers 25 time zones: 0-GMT +1 to +12 and -1 to -12
North American Time Zones are negative numbers.
-4h Atlantic
-5h Eastern
-6h Central
-7h Mountain
-8h Pacific
-9h Alaskan
-10h Hawaiian
12-Hour or 24-Hour Time Format
Choose to display time in 12-hour or 24-hour format.
Default is 12-hour time.
Use the Program Menu to switch time formats.
Power Requirements

La Crosse Technology, Ltd. Page 9
The Forecast station is powered by 2-“C” alkaline batteries.
Manually Set Time/Date: Program Menu
PROGRAM MENU: The SET button moves through the program menu. When you
press and release the SET button after each step, you will move to the next
step. The OUT/+ button will change a value.
CONTRAST: Hold the SET button for five seconds. LCD 4 will flash. To increase
or decrease the Contrast of the LCD display, press and release the OUT/+
button. Press and release the SET button once to move to the time zone.
TIME ZONE: The Time Zone will flash, showing a number following by the letter
h. Use the OUT/+ buttons to change the Time Zone. Please note North American
Time Zones are Negative Numbers: -4h Atlantic, -5h Eastern,-6h Central, -7h
Mountain, -8h Pacific, -9h Alaskan and -10h Hawaiian. The dash preceding the
Time Zone number must show for North America. Press and release the SET
button to move to DST setting.
DAYLIGHT SAVING TIME: DST will show and ON will flash. Most states use DST,
so this should be set to ON. However if your location does not use DST, use the
OUT/+ button to turn it OFF. Press and release the SET button once to select
radio-controlled time.
RADIO-CONTROLLED TIME: RCC will show and ON will flash. Use the OUT/+
button to set the RCC signal. (Leave this ON to receive WWVB signal) Press and
release the SET button once to select 12/24-hour time.
12/24-HOUR TIME MODE: Either 12h or 24h will flash. Use OUT/+ button to
change from 12 to 24 hour format time (12h for AM/PM, 24h for military time).
Press and release the SET button once to select hour.
HOUR: The Hour will flash. Use the OUT/+ button to set the Hour. If using 12-
hour Time Mode, be sure to check the hour for am or pm. Press and release the
SET button once to move to minutes.
MINUTES: The Minutes will flash. Use the OUT/+ button to set the minutes.
Press and release the SET button once to select the year.
YEAR: The Year will flash. Use the OUT/+ button to set the Year. Press and
release the SET button once to select the month.
MONTH: The Month will flash. Use the OUT/+ button to set the Month. Press
and release the SET button once to select the date.
DATE: The numeric day will flash. Use the OUT/+ button to set the Date
correctly. Press and release the SET button once to select Fahrenheit or Celsius.
FAHRENHEIT OR CELSIUS: A degree symbol will flash, followed by F or C. Use
the OUT/+ button to change to your preference. Press and release the SET
button once.
AIR PRESSURE UNITS: The barometric air pressure units will now flash. Press
and release the OUT/+ button to select inHg (inches of Mercury) or hPa
(hectopascal or milibars).Press and release the SET button once to set pressure
numbers.
RELATIVE AIR PRESSURE: The Relative Barometric Air Pressure number setting
will flash 29.92 inHg or 1012.8 hPA (default settings).Press and release the
OUT/+ button to increase the setting or the IN button to decrease the setting.
Press and release the SET button once to set forecast sensitivity.
FORECAST SENSITIVITY: Two tendency arrows will appear and a flashing
number (2, 3, or 4) will appear under the forecast icon. Press and release the
OUT/+ button to select the desired Forecast Sensitivity setting. The lowest

La Crosse Technology, Ltd. Page 10
number is for use near the coastline, the highest number is for the desert, and
middle number is for everywhere.
No WWVB Tower Icon
The forecast station has not received a WWVB time signal in the past 24-hours.
Enter the program menu to see if the display has RCC in the SET UP menu, this
must be ON to receive a signal from the atomic clock.
Position the forecast station for better reception.
Be sure you have good batteries in the Weather
Allow up to 5 nights to receive the time signal.
Dashes, OFL or Stuck Indoor Temperature/Humidity
This is generally a power related issue.
Batteries may be overpowered or underpowered. Remove batteries from
forecast station.
Press any button 20 times. Leave the forecast station unpowered for 1-2 hours.
Install fresh alkaline batteries with correct polarity.
If the indoor temperature/humidity is still dashes or OFL, the forecast station
may need to be replaced.
Inaccurate Indoor Temperature/Humidity Reading
Side-by-side test: Bring the outdoor transmitter in the house and place it next
to the forecast station for 2 hours.
Compare indoor and outdoor temperature/humidity. The temperature should be
within 4 degrees to be within tolerance. The humidity should be within 10% to
be within tolerance.
Look for heat sources such as sunlight, door or window frames, or reflected heat
of cold.
Time is off by hours
Check to see if the WWVB Tower icon appears on the forecast station. If not, the
forecast station has not received a WWVB time signal in the past 24-hours.
Reposition the Forecast station with the front or back facing Colorado.
Check that the Time Zone selected correctly reflects your location. Adjust the
time zone in the Program Menu.
Check that the DST indicator is correct for your location (most areas observe
DST so this should be ON). Adjust the DST indicator in the Program Menu.
Enter the program menu to see if the display has RCC in the SET UP menu, this
must be ON to receive a signal from the atomic clock.
Set Time Alarm
Press and hold the ALM/DATE button for five seconds. The alarm will begin to
flash to the right of the moon phase. Press and release the IN button to adjust
the hour (am or pm). Press and release the OUT/+ button to adjust the minute.
Press SNOOZE/CH to return to normal display.
Activate/Deactivate Time Alarm
