SPI CORP M2D Gimbal User manual

\"
SBUS"SPI"M2D"Gimbal"
Adapter"
LightBridge2"
Compa<bility"
V1.1A"

SBUS Adapter &
LightBridge2
Ver : 1.1
SPI CORP
www.x20.org!
Compilation and Publication Notice
This document covers the latest product descriptions and
specifications.
The contents of this manual and the specifications of this product are
subject to change without notice.
SPI reserves the right to make changes without notice in the
specifications and materials contained herein and shall not be
responsible for any damages (including consequential) caused by
reliance on the materials presented, including but not limited to
typographical and other errors relating to the publication.
- Page !of !–2 7
- SPI Proprietary and Confidential Information -

SBUS Adapter &
LightBridge2
Ver : 1.1
SPI CORP
www.x20.org!
Table of Content
1. Introduction 4......................................................................................
2. Architecture 4.....................................................................................
3. Connecting SBUS Adapter to Lightbridge 2 4...................................
4. Lightbridge 2 & Remote control configuration 5..............................
- Page !of !–3 7
- SPI Proprietary and Confidential Information -

SBUS Adapter &
LightBridge2
Ver : 1.1
SPI CORP
www.x20.org!
1. Introduction
The document describes SBUS Adapter and DJI LightBridge 2
compatibility.
2. Architecture
The architecture is depicted in the following:
3. Connecting SBUS Adapter to Lightbridge 2
The following image describes the cabling orientation when
connecting to the S-BUS Adapter. The cable connecting to the S-BUS
IN is supplied with the Lightbridge.
- Page !of !–4 7
- SPI Proprietary and Confidential Information -

SBUS Adapter &
LightBridge2
Ver : 1.1
SPI CORP
www.x20.org!
4. Lightbridge 2 & Remote control configuration
Follow the following steps when connecting to SBUS-Adapter with
factory defaults.
Control verification:
a. The CTRL green led should illuminate when the Lightbridge 2 Air
Station connects to Lightbridge 2 Base Station
!
Video verification:
b. Connect SBUS adapter to camera and to Lightbridge 2 Air
Station. The VIDEO green led should illuminate when the SBUS
adapter provides video to Lightbridge 2 air station:
!
Remote Control Configuration
- Page !of !–5 7
- SPI Proprietary and Confidential Information -

SBUS Adapter &
LightBridge2
Ver : 1.1
SPI CORP
www.x20.org!
c. Set Remote Control channel in accordance with the following
table:
Description
Channel
Camera roll
1
Camera pitch
2
Zoom channel
3
Day/IR/NUC/POLARITY
4
Check “SBUS Adapter Manual” to verify which
functionality is available in your system
