SPIELTEK VR-M1 User manual

M1
VIRTUAL REALITY
Smartphone
headset
USER MANUAL

Thank you
for choosing
spieltek.

3
Precautions
• Please read and follow these instructions, and keep this manual in
a safe place.
• Keep this unit away from water and any flammable gases or liquids.
• Prolonged use may cause fatigue.
• Use of the device may cause a loss of balance. Make sure that your
surroundings are safe and secure before putting on the headset
• Do not use while driving a vehicle.
• Clean the unit with only a soft, dry cloth.
• All images are for illustrative purposes only.

4
Overview
A. Head strap
B. Head strap loops
C. Visor locking tab
D. Size adjustment feet (×4)
E. Lenses
F. Focal adjusters
G. Interpupillary adjusters
C
E
D
F G
B
A

5
Attaching the Head Strap
1. Orient the T-strap with the fuzzy side facing out, and fit
the three ends through the attachment loops on the
sides and top of the headset.
2. Loop the ends over, and press them onto the touch-
fastener strips.
3. Continue to adjust the length of the straps until the
visor sits comfortably on your face without putting too
much pressure on the bridge of your nose.

6
Inserting the Phone
1. Open the visor by pulling the locking tab at the top of
the headset.
2. Rest your phone on the two feet inside the visor. For
smaller phones, remove the adjustment feet by sliding
them off of the mounts, and replace them with the
larger feet that are included with the headset.
3. Align the middle of the screen with the center bar
inside the headset.
4. Close the visor until it snaps shut.
Important! Be sure the visor is securely closed before
proceeding.

7
Adjusting the Lenses
Use the lens adjusters on the bottom of the headset to
move each lens forward or back to compensate for near-
or farsightedness until the picture is sharp and clear.

8
Using Your Phone with the
VR-M1
Insert your phone into the headset, and close the visor.
You can use wired headphones or attach a charging cable
while using the headset by extending the cables through
the gap between the visor and the headset.
Important! You cannot access the screen while using
the VR-M1 headset. To control your phone and camera
while using the headset, use a Bluetooth remote like the
Spieltek VR-BTR (available separately).

9
Compatibility Phones with screens 3.5 to 6 in.
(8.9 to 15.2 cm)
Lens size 40 mm
Lens material Spherical resin
Field of view 95° to 100°
Dimensions (W ×D ×H) 7 × 5 × 4 in. (17.8 × 12.7 × 10.2 cm)
Weight (without phone) 12.2 oz. (344.7 g)
Specifications

10
One-Year Limited Warranty
This Spieltek product is warranted to the original purchaser to be free
from defects in materials and workmanship under normal consumer
use for a period of one (1) year from the original purchase date or
thirty (30) days after replacement, whichever occurs later. The
warranty provider’s responsibility with respect to this limited warranty
shall be limited solely to repair or replacement, at the provider’s
discretion, of any product that fails during normal use of this product
in its intended manner and in its intended environment. Inoperability
of the product or part(s) shall be determined by the warranty provider.
If the product has been discontinued, the warranty provider reserves
the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse,
neglect, accident, alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY
PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR
ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. This warranty provides you with specific legal
rights, and you may also have additional rights that vary from state to
state.

11
To obtain warranty coverage, contact the Spieltek Customer Service
Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Spieltek along with
the RMA number and proof of purchase. Shipment of the defective
product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit
www.spieltekgaming.com or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Spieltek is a registered trademark of the Gradus Group.
© 2016 Gradus Group LLC. All Rights Reserved.

www.spieltekgaming.com
