Splash Lab TSL.GR.45.18 Maintenance and service guide

TSL GR 18. .45.
TSL GR. .45.24
. .45.36TSL GR
. .45.42TSL GR
straight grab rail
installation + maintenance

2 Technical Data
3 Before You Install
5 How to Install
6 Cleaning
6 Maintenance
6 Operation
7 Warranty
Back Cover Contact Details
contents
2 + TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 STRAIGHT GRAB RAIL MANUAL
Stainless steel grade AISI 304 stainless steel
Warranty 2 years from date of purchase
technical data
Finishes CS(Brushed Stainless)
CP(Brushed Copper)
BK(Brushed Black)
BR(Brushed Brass)
Weight TSL.GR.45.18 - 2.9lb 45.7oz
TSL.GR.45.24 - 3.3lb 52.8oz
TSL.GR.45.36 - 4.2lb 66.8oz
TSL.GR.45.42 - 4.8lb 77.6oz

The rail is to be installed in accordance with the current ADA regulations in force. The
rail must be mounted with fixings appropriate to the wall construction.
before you install
Location
TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 STRAIGHT GRAB RAIL MANUAL + 3
TSL.GR.45.18 TSL.GR.45.24
3"
21-1/2"
1-15/16"
18"
16 1/16"
1-15/16"
1-15/16"
3"
27-1/2"
Ø 1/4"
1-15/16"
1-15/16"1-15/16"
Ø 3-7/16"
24"
22-1/16"
Ø 1/4"
Ø 3-7/16"

4 + TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 STRAIGHT GRAB RAIL MANUAL
before you install
TSL.GR.45.36 TSL.GR.45.42
3"
39-1/2"
3"
1-15/16"
36"
34 1/16"
1-15/16"
1-15/16"
Ø 1/4"
Ø 1/4"
1-15/16"
1-15/16"
1-15/16"
Ø 3-7/16"
42"
40-1/16"
45-1/2"
Ø 3-7/16"

how to install
1
Prise the cover plates off that conceals
the fixing holes.
2
Position the rail on the wall at the desired
location and mark the fixing holes.
3
Using appropriate fixings (not supplied),
fasten the rail to the wall and tighten
securely.
4
Refix the cover plates.
TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 STRAIGHT GRAB RAIL MANUAL + 5

All grades of stainless steel will stain or discolor if due care and attention is not
taken. The surface must be regularly cleaned to ensure a long service life of the bar.
Use a soft cloth or sponge with a mild solution of soapy water as part of the regular
washroom janitorial routine. Do not use abrasive or cream cleaners as these will
damage the surface finish.
If the rail is subjected to a highly-chlorinated environment eg swimming pools or
marine coastal locations, a further treatment, in addition to the regular cleaning as
described above, is recommended by the application of a household cleaning
product containing silicone.
Contact The Splash Lab technical team for more detailed stainless steel care
guidelines. 
cleaning
maintenance
The fixings securing the rail should be periodically inspected to ensure the rail is
firmly attached to the wall.
operation
The user is to grasp the rail firmly to provide sufficient support to enable them to
change their position.
6 + TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 STRAIGHT GRAB RAIL MANUAL

We believe the future is personal. With a global mindset, we challenge conventional
restroomnormsviaproductinnovationtocreateconsideredrestroomsolutionsfor
corporateandeducationalspaces.Weuserichrawmaterials,cutting-edgeautomation
andconsideredrestroomdesigntopowerfullyandpositivelyinfluencethelivesof
people.WeareTheSplashLab.
Demonstratingourcommitmenttoqualityandourbeliefinthestrengthofourdesigns,
wecanof ferthefollowingwarranties.
The Splash Lab will warrant that its products will be free of manufacturing and material
defectsduringnormaluseandenvironmentalconditionsasdetailedbelow:
Straight Grab Rail 2 years
If a defect is found in normal use, The Splash Lab will, at their discretion, repair, provide
areplacementpartorproduct, ormakeappropriateadjustments.Damagecausedby
accident,misuse,orabuseisnotcoveredbythiswarranty.Impropercareandcleaning
willvoidthewarranty.
Non-operation of the product due to environmental conditions beyond our control,
installationerror,incorrectmaintenance,waterquality,fairwearandtear,incorrector
inappropriateinstallation,misuseandabuseisnotcoveredbythewarranty.
Proofofpurchase(originalsalesreceipt)mustbeprovidedtoTheSplashLabwithall
warrantyclaims.
The above warranty is valid for goods supplied within North America.
ForgoodssuppliedoutsideofNorthAmerica,TheSplashLabwillhonortheabove
statedwarrantyperiodsforthepartsonly.
THESPLASHLABDISCLAIMANYLIABILITYFORSPECIAL,INCIDENTALOR
CONSEQUENTIALDAMAGES.
warranty
TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 STRAIGHT GRAB RAIL MANUAL + 7

TSL.GR.45.18 / TSL.GR.45.24 / TSL.GR.45.36 / TSL.GR.45.42 • • (US) REV 4-09/02/21
contact
General information
310 410 5008
Technical support
[e-mail]
For further contact information visit:
www.thesplashlabusa.com
Warehouse + Offices:
20809 Higgins Court, Torrance CA 90501
Showroom:
8745 Washington Boulevard, Studio D, Culver City CA 90232
