Sportwerks Raven BX RTR Installation and operating instructions

Sportwerks®Raven™BX RTR
Assembly and Operation Manual
Specifications:
Scale ..............1/10
Length . . . . . . . . . . . . . 15 in
(381mm)
Front Track. . . . . . . . . . 9.75 in
(248mm)
Rear Track . . . . . . . . . . 10 in
(254mm)
Weight . . . . . . . . . . . . . Varies with
battery used
Wheel Size . . . . . . . . . . 2.2 in

2 • Raven BX
®
Table of Contents
Introduction ....................................................................................... 2
Warranty ............................................................................................ 3
Safety Precautions ............................................................................. 3
Required Equipment .......................................................................... 4
Tools You Will Find Handy .................................................................4
About the Radio System .................................................................... 5
The Receiver and Servo ..................................................................... 6
Tazer 15T Electronic Speed Control (ESC)......................................... 6
Service and Maintenance................................................................... 7
Shocks............................................................................................... 7
Cleaning Tip ....................................................................................... 7
Motor Maintenance............................................................................ 8
Setting the Gear Mesh ....................................................................... 8
Tuning Tips ........................................................................................ 9
Camber .............................................................................................. 9
Toe-In/Out.......................................................................................... 9
Ride Height ...................................................................................... 10
Battery Placement............................................................................ 10
Slipper Adjustment .......................................................................... 10
Troubleshooting Guide..................................................................... 11
Parts Listing..................................................................................... 12
Parts Breakdown........................................................................ 13–15
Introduction
Thank you for choosing the Sportwerks®Raven™ BX. Your Raven comes
complete with a Sportwerks 2-channel AM radio system, Dynamite® Tazer™
15T Electronic Speed Control and a high performance 19T motor. Although
this is an entry-level radio control product, it is not a toy and requires some
basic mechanical ability and adult supervision. This manual contains basic
instructions for safety, operation and maintenance. It’s essential to read and
follow all the instructions and warnings in this manual, prior to assembly,
setup or use, in order to operate correctly and avoid damage or injury.

Raven BX • 3
®
Warranty
Horizon Hobby, Inc. guarantees this product to be free from defects in
both material and workmanship at the date of purchase. This warranty does
not cover any component parts damaged by use or modification. In no case
shall Horizon Hobby’s liability exceed the original cost of the purchased kit.
Further, Horizon Hobby reserves the right to change or modify this warranty
without notice.
As Horizon Hobby has no control over use, setup, final assembly,
modification or misuse, no liability shall be assumed nor accepted for any
resulting damage or injury. By the act of assembly, setup or use, the user
accepts all resulting liability.
Your local hobby store and/or place of purchase cannot provide warranty
support or repair. Once assembly, setup or use of the model has been
started, you must contact Horizon Hobby, Inc. directly. This will enable
Horizon to better answer your questions and service you in the event that
you may need any assistance.
If you as the purchaser or user are not prepared to accept the liability
associated with the use of this product, you are advised to return this kit
immediately in new and unused condition to the place of purchase.
For warranty issues, questions or concerns, please contact.
Horizon Product Support.
4105 Fieldstone Road
Champaign, Illinois 61822
(toll free) 877- 504-0233
[e-mail]
A Division of Horizon Hobby, Inc.
www.SportwerksRC.com
Safety Precautions
The Sportwerks®Raven™ is a sophisticated radio controlled product that
must be operated with caution and common sense. Failure to operate your
model in a safe and responsible manner could result in injury or damage to
the model or other property. This product is not intended for use by children
without direct adult supervision.
Horizon Hobby shall not be liable for any loss or damages, whether direct,
indirect, special, incidental, or consequential, arising from the use or misuse
of this product or any product required for operating it.
• This model is controlled by a radio signal that is subject to
interference from many sources outside your control. This
interference can cause momentary loss of control, so it is
advisable to always keep a safe distance in all directions around
your model as this margin will help to avoid collisions or injury.
• Always operate your model in an open area away from cars,
traffic, or people.
• Avoid running your model in the street where injury or damage
can occur.
• Never run the model out into the street or populated areas
for any reason.
• Never run your model with low transmitter batteries.
• Carefully follow the directions and warnings for this and any
optional support equipment (chargers, rechargeable battery
packs, etc.) that you use.
• Keep all chemicals, small parts and anything electrical out of the
reach of children.
Moisture causes damage to electronics. Avoid water exposure to all
equipment not specifically designed and protected for this purpose.

4 • Raven BX
®
Required Equipment
You will need the following items to operate your Raven™ BX buggy.
• 8 “AA” batteries for the transmitter.
• Charger capable of charging 7.2-volt Ni-MH batteries. (We
recommend the DYN4049 Prophet Plus™ LCD AC/DC
Peak Charger.
Tools You Will Find Handy
In addition to the tools included in this kit, you will find the following items
useful when performing maintenance or repair to your Raven BX.
• Quality tip 2.5 Allen driver
• 6.5 and 7mm nut drivers
• #2 Phillips head screwdriver
• Needle-nose pliers
• Hobby knife
• Lexan scissors

Raven BX • 5
®
About the Radio System
The following is an overview of the operation of the Sportwerks®radio
system and its various functions and adjustments. Since your Raven™
BX operates using a radio you control, it’s important for you to read and
understand about all of these functions and adjustments before driving.
Steering Wheel: Controls direction
(left/right) of the model.
Throttle Trigger: Controls speed and
direction (forward/reverse) of the
model.
Antenna: Transmits signal to the
model.
On/Off Switch: Turns the power on for
transmitter operation.
Indicator Lights: Green (top) light
indicates adequate battery power.
Red light (bottom) indicates signal
strength.
ST. Trim: Adjusts the “hand off”
direction of the model.
TH. Trim: Adjusts the motor speed to
stop at neutral.
Steering Rate: Adjusts the amount
the front wheel moves when turned
left or right.
ST. REV: Reverses the function of the
steering when the wheel is turned left
or right.
TH. REV: Reverses the function of the
Speed Control when pulled back or
pushed forward.
Bottom Cover & Battery Tray: Covers
and holds the batteries that power the
transmitter.
Transmitter Crystal: Determines
frequency/channel you transmit on.
The receiver must have a matching
frequency/channel to operate.

6 • Raven BX
®
The Receiver and Servo
1. Receiver: Receives the signal from the transmitter to control
the model.
2. Receiver Crystal: Determines which channel it will receive.
3. Antenna Wire: Receives the signal from the transmitter.
4. Steering Servo: Controls steering movement.
5. Steering Servo Plug: Connects to the receiver in position 1.
Tazer 15T Electronic Speed Control (ESC)
1. Electronic Speed Control: Controls forward, reverse, and
braking functions.
2. ESC Plug: Connects to the receiver in position 2.
3. Battery Plug: Connects to the 7.2-volt battery.
4. Motor Connectors: Orange (positive) and Black (negative) will
connect to the motor leads.
5. On/Off Switch: Used to turn the vehicle on.
6. Set Up Button: Used for programming the ESC.
7. Indicator Lights: Green indicates throttle at neutral position. Red
indicates full forward or full reverse.

Raven BX • 7
®
Service and Maintenance
Shocks
The shocks will need to be rebuilt periodically when the fluid gets
low or dirty.
1. Remove the shocks from the vehicle, unscrew the aluminum cap,
dump the fluid and clean thoroughly.
2. Refill with silicone shock fluid to the top of the body (the factory
setup is 30 weight oil in the front and 20 weight oil in the rear).
3. Slowly move the piston up and down to remove air bubbles.
4. Move the piston to the midway point of the body and
install the cap.
5. Tighten the cap slowly letting excess oil bleed off.
When properly filled the piston can be pushed and should rebound
about 3/8”.
Cleaning Tip
Performance can be hindered
if dirt gets in any of the
moving suspension parts.
Use compressed air or a soft
paintbrush or toothbrush to
remove dust and dirt. Avoid
using solvents or chemicals, as
they can actually wash dirt into
the bearings or moving parts
as well as cause damage to the
electronics.

8 • Raven BX
®
Motor Maintenance
After about 10 runs, the motor should be cleaned and the brushes
inspected for wear. Proper maintenance will not only increase motor life,
it will improve performance.
1. You will first need to remove the gear cover and pinion gear. Then
remove the 2 motor retaining screws.
2. Disconnect the bullet connecters from the ESC.
3. Remove the brush springs and brushes. Inspect the brushes (if
severely worn or discolored they should be replaced).
4. Spray the motor thoroughly with a high quality cleaner like
DYN5500 Magnum Force Cleaner.
5. Before re-installing, oil each motor bushing with a drop of quality
bushing lubricant.
Setting the Gear Mesh
Proper gear mesh is important to the performance of your vehicle. If the
mesh is too loose, it will cause the spur gear to fail (strip); if set too tight, it
will decrease speed and cause the motor to overheat.
To set the gear mesh, loosen the motor screws and insert a small piece of
paper between the two gears.
Push the gears together and re-tighten the screws. Finally remove the paper,
the gear should be able to rock back and forth slightly.

Raven BX • 9
®
Tuning Tips
Camber
Camber is the angle of the tires to the racing surface when viewed from the
front or rear of the vehicle. With negative camber, the wheel leans inward and
with positive camber, the wheel leans outward.
The best setting range is between 0 and 1 degrees negative camber. More
negative camber in the front will result in a more aggressive feel, increases
steering and improves handling through bumpy sections. More negative
camber in the rear will decrease side bite and increase steering. Camber can
be adjusted by lengthening or shortening the threaded turnbuckles. Many
dealers sell inexpensive adjustment tools for measuring camber.
Toe-In/Toe-Out
Toe-in (negative toe) and toe-out (positive toe) refers to the angle of the tires
as viewed from the top of the vehicle. Toe-in will provide more stability under
acceleration but decreases steering on corner entry. Toe-out will improve
steering into corners but not be as stable at full speed. The factory setting is
0 degrees. Toe can be is adjusted by lengthening or shortening the threaded
steering links.

10 • Raven BX
®
Ride Height
Ride height is an adjustment that affects the way your car jumps, turns, and
goes through bumps. To check the ride height, drop one end of the buggy
from about 6 inches onto a flat surface. Once the buggy settles into position
check to see that the front arms are equal and level to the ground. When
looking at the rear, it should be set so that both dogbones are level to the
ground. Lowering the front ride height will increase the amount of steering;
lowering the rear will increase traction but decrease steering.
Battery Placement
The battery position in your Raven™ BX can be adjusted by moving the
foam block provided with your kit. Moving the battery forward will increase
steering. Moving the battery to the rear will increase traction.
Slipper Adjustment
The slipper clutch helps eliminate parts breakage in the transmission and
also aids drivers in low traction conditions coming off corners and landing
jumps. To adjust the slipper tension, simply loosen or tighten the nut on
the outside of the spur gear. Set your vehicle on the ground and punch the
throttle. The slipper should slip for one to two feet at most. If it doesn’t slip
for at least one foot, back the nut off 1/8 of a turn and retry.

Raven BX • 11
®
Troubleshooting Guide
Problem Things to Check Remedy
Short Runtime Battery not charged/bad Check/charge battery pack
Motor dirty or brushes worn Clean/replace
Sluggish Action Motor dirty/brushes worn Clean/replace
Bind in drivetrain Remove pinion and check/repair as necessary
Motor/ESC Overheated Over-geared Install smaller pinion
Doesn’t Operate Transmitter battery Replace “AA” batteries
Transmitter not on Turn on
ESC not on Receiver not on
Battery Make sure battery is charged
Poor Range/ Glitches Transmitter batteries low Check/ replace
Transmitter antenna loose Check/tighten
Battery Pack not charged Charge and retry
Receiver antenna cut/worn Check/send in for repair
Motor dirty/worn brushes Check/clean/repair
Loose plugs or wires Check all plugs and wires

12 • Raven BX
®
Key# Stock# Description Price
1 SWK5200 Raven ST Body, Clear $17.99
2 SWK5201 Raven BX Painted Body, Red $29.99
3 SWK5202 Raven BX Painted Body, Blue $29.99
4 SWK5206 1/10 Multi Rib FR Buggy Tires Mntd $15.99
5 SWK5207 1/10 Mini Pin RR Buggy Tires Mntd $17.99
6 SWK5216 Main Chassis Plate $12.99
7 SWK5010 Bulkhead/Kickplate Set $8.99
8 SWK5218 Front Suspension Arms $4.99
9 SWK5220 Rear Suspension Arms $4.99
10 SWK5222 Front Shock Tower $3.99
11 SWK5224 Rear Shock Tower $3.99
12 SWK5020 Front/Rear Pivot Block Set $2.99
13 SWK5022 Battery Hold-Down Strap $3.99
14 SWK5024 Steering Blocks $2.49
15 SWK5026 Front C-Hubs $2.99
16 SWK5028 Rear Hubs $2.99
17 SWK5030 Tranny Gear Bag $5.99
18 SWK5230 Spur Gear 76T $2.99
19 SWK5034 Upper Shock Mount Bushings $2.99
20 SWK5036 Servo Saver Plastic Parts $3.99
21 SWK5038 Transmission Case $3.99
22 SWK5040 Chassis/Tranny Brace Set $5.99
23 SWK5042 Front Bumper/Motor Guard Set $3.99
24 SWK5044 Gear Cover & Cap Set $3.99
25 SWK5046 Ball Cup Set $5.99
26 SWK5048 Rear Axles $5.99
27 SWK5050 Diff Outdrive Set $5.99
28 SWK5254 Dogbones $7.99
29 SWK5054 Servo Saver Metal Parts Set $5.99
30 SWK5056 Hinge Pin Set $5.99
Key# Stock# Description Price
31 SWK5058 Diff Pinion & Idler Shaft Set $3.99
32 SWK5060 Front/Rear Suspension Pin Brace Set $4.99
33 SWK5062 Motor Plate $5.99
34 SWK5064 Slipper Plate $8.99
35 SWK5066 Transmission Main Shaft $6.99
36 SWK5250 Front Axles $3.99
37 SWK5070 Ball Studs $5.99
38 SWK5072 Slipper Rebuild Kit $5.99
39 SWK5074 4-40 Locknuts $3.99
40 SWK5076 Body Clips $2.99
41 SWK5252 Camber/Steering Link Bag $9.99
42 SWK5080 Shock Rod End Balls $3.99
43 SWK5082 Rear Axle Drive Pins $4.99
44 SWK5084 Sealed Bearings 8x12x3.5mm $4.99
45 SWK5086 Sealed Bearings 3/16x3/8 $3.99
46 SWK5088 Sealed Bearings 3x6x2.5mm $3.99
47 SWK5090 E-Clip Bag $0.99
48 SWK5263 23T Pinion Gear $2.99
49 SWK5094 Raven Screw Set (68pcs) $11.99
50 SWK5096 Shock Rebuild Kit $4.49
51 SWK5098 Medium Shock Shafts $3.49
52 SWK5244 Short Shock Shafts $3.49
53 SWK5102 Medium Shock Body Set $9.99
54 SWK5246 Short Shock Body Set $9.99
55 SWK5240 Short Shock Springs Silver $3.99
56 SWK5242 Medium Shock Springs, Black $3.99
57 SWK5248 Assembled Short Shock Set $19.99
58 SWK5110 Assembled Medium Shock Set $19.99
59 SWK5226 Rear Body Post Set $3.99
60 SWK5207 Front Dish Wheel $3.99
61 SWK5211 Rear Dish Wheel $4.99
Please see your favorite retailer or
visit our web site
(www.SportwerksRC.com)
to find the latest in new
replacement and option parts
releases for your Raven™ BX.
Parts Listing

Raven BX • 13
®
24
45
38
34
33
45
44
31
17
21 27
44
45
38
60
4
45
61 5
Parts Breakdown
Note: All screws are included with
Key #49 (Raven BX Screw Set)

14 • Raven BX
®
20
20
36
39 37
30
30
23
54
52
54
54
55
50
50 4747
50
50
42
32 29
29 46
20
46
25 37
7
7
46
29
10
39
57
42
30 41
47
8
53
51
53
53
56
Parts Breakdown
Note: All screws are included with
Key #49 (Raven BX Screw Set)

Raven BX • 15
®
23
28
25
41
30
47
45
26
37
45
16
43
39
9
76
32
12
22
13
22
58
39
11
Parts Breakdown
Note: All screws are included with
Key #49 (Raven BX Screw Set)

© 2006 Horizon Hobby, Inc.
4105 Fieldstone Road
Champaign, Illinois 61822
[phone]
www.horizonhobby.com
9514.2
