Sporty's E6B User manual

SPORTY'S E6B
ELECTRONIC FLIGHT COMPUTER
Sporty's E6B Flight Computer is designed to perform 23
aviation functions and 14 standard conversions, and
includes timer and clock functions.
We hope that you enjoy your E6B Flight Computer. Its use
has been made easy through direct path menu selection
and calculation prompting. As you will soon learn, Sporty's
E6B is one of the most useful and versatile of all aviation
computers.
Copyright © 2008 by Sportsman's Market, Inc.
Version 08A
1

2
CONTENTS
BEFORE USING YOUR E6B................................ 3
DISPLAY SCREEN ........................................... 4
PROMPTS AND LABELS .................................... 5
SPECIAL FUNCTION KEYS ................................ 7
ARITHMETIC FUNCTIONS.................................. 8
AVIATION FUNCTIONS...................................... 8
CONVERSIONS ................................................ 9
CLOCK FUNCTION...........................................11
ADDING AND SUBTRACTING TIME.....................12
TIMER FUNCTION ...........................................13
PRESSURE AND DENSITY ALTITUDE .................14
PLANNED TRUE AIRSPEED ..............................15
HEADING AND GROUND SPEED ........................16
LEG TIME ......................................................17
FUEL REQUIRED.............................................18
CROSSWIND, HEADWIND AND TAILWIND ...........19
ACTUAL TRUE AIRSPEED.................................20
WIND SPEED AND DIRECTION ..........................21
GROUNDSPEED. .............................................22
FUEL PER HOUR.............................................23
PLANNED MACH NUMBER. ...............................24
REQUIRED TRUE AIRSPEED.............................25
REQUIRED CALIBRATED AIRSPEED ..................26
DISTANCE FLOWN ..........................................27
ENDURANCE ..................................................28
ACTUAL MACH NUMBER ..................................29
WEIGHT AND ARM...........................................30
WEIGHT AND MOMENT ....................................33
PERCENT MAC ...............................................35
REQUIRED RATE OF CLIMB..............................36
REQUIRED RATE OF DESCENT .........................37
TOP OF DESCENT...........................................38
SPECIFIC RANGE............................................39
APPENDIX A: SAMPLE PROBLEMS ....................40
WEIGHT AND MEASURE CONVERSIONS. ............46
BATTERY REPLACEMENT ................................47
TROUBLESHOOTING AND CARE........................48
WARRANTY INFORMATION ...............................49
NOTES ..........................................................50

3
BEFORE USING YOUR E6B
Sporty's E6B Flight Computer requires three 1.5V AAA
batteries (not included) for operation. New batteries should
be installed in the battery compartment located in the top
rear of the computer. Make sure that battery polarity is
aligned correctly.
An opaque plastic film has been placed over the display
screen to protect your E6B during shipping. This film is
easily removed by peeling up one corner and pulling
gently.
This manual is designed to offer an introduction to the
operation of the E6B. For each calculation, a sample
problem has been given.
In order to save power, the display screen automatically
turns off approximately 4 minutes after the last keystroke.
However, the internal clock and timer will continue to run. If
the timer is counting down, it will not shut off for
approximately thirty minutes.
This multi-function computer is authorized and acceptable
for use during FAA and Canadian written tests. All memory
is erased by removing and reinstalling the batteries. NOTE:
This also removes clock settings. References: FAA
Advisory Circular 60-11B and FAA Order 8081D, Conduct
of Airmen Written Tests, April 10, 1989.

DISPLAY SCREEN
T-DCN WDIR -LEMAC
WT PALT DIST MCLM
I°C ARM -GS RATE
WSPD T°C ZULU
MOM CAS -%MACRQ/DN
RWY CRS HOME TIME
CG TAS -FPH
IALT MROC
X-WIND RF -MAC SPRNG
GS MACH# BARO CRALT
H-WIND GW -FUEL FXDIS
HDG DALT LOCAL %
NAUT CALC CONV TIMER
°C FEET SPCRANGE TOP DSCN REQ/DSCN
WT/ARM WT/MOM %MAC P-D/ALT PLAN TAS
HDG/GS LEG TIME FUEL REQ X/H-WIND ACT TAS
WIND GS FPH PLAN M# REQ TAS
REQ CAS DIST FLN ENDUR ACT M# REQCLIMB
8888
8888
8888
8888
8888
8888
The figure above shows all possible displays, prompts and
labels on the E6B. The numeric display is surrounded by
labels for specific problems. Below this are lines of text
representing display prompts, labels, and aviation
functions. Aviation functions available on the E6B will
remain visible whenever the power is on. The display
prompts and labels are only visible when in use.
4

5
PROMPTS AND LABELS
WT: Weight
I°C: Indicated Temperature in Celsius
W SPD: Wind Speed
MOM: Moment
RWY: Runway
CG: Center of Gravity
X-WIND: Crosswind
GS: Ground Speed
H-WIND: Headwind
HDG: Heading
W DIR: Wind Direction
P ALT: Pressure Altitude
ARM: Arm
T°C: True Temperature in Celsius
CAS: Calibrated Air Speed
CRS: Course
TAS: True Air Speed
RF: Reduction Factor
MACH#: Mach number
GW: Gross Weight
D ALT: Density Altitude
LEMAC: Leading Edge Mean Aerodynamic Chord
DIST: Distance
ZULU: Coordinated Universal Time Clock Label

6
PROMPTS AND LABELS (cont.)
%MAC: Percent Mean Aerodynamic Chord
HOME: Home Time Clock Label
FPH: Fuel Per Hour
TIME: Time
I ALT: Indicated Altitude
MAC: Mean Aerodynamic Chord
BARO: Altimeter Setting in Inches (Barometer)
FUEL: Fuel
LOCAL: Local Time Clock Label
°C: Temperature in Celsius Label
FEET: Feet
NAUT: Nautical
CALC: Calculator Function
CONV: Conversion Function
MCLM: Minimum Climb
MROC: Required Rate of Climb
%Climb Gradient
CRALT: Crossing Altitude
FXDIS: Fix Distance
RQ/DN: Required Descent Rate
SPRNG: Specific Range
RATE: Descent Rate
T-DCN: Top of Descent

SPECIAL FUNCTION KEYS
ON Turns power on and resets E6B to main menu.
OFF Turns display screen off.
TIMER Starts and stops timer function.
ENTER Selects menu function and enters data input.
=Totals regular calculator functions.
CONV Converts keys to alternate functions.
CLK Controls display and setting of clocks.
C Clears current input line.
Controls function menu cursor. The
function on which cursor is located will
blink. Arrows return computer to main
menu when in an aviation function mode.
+/- Changes negative to a positive and positive to
a negative. A negative number will be denoted
by a minus sign near the upper right hand
corner of the number. For example, to input
-17:
Press 1 7 +/-
And the screen will read 17.-
7

ARITHMETIC FUNCTIONS
7 8 9
÷
8
4 5 6
X
1 2 3 -
0 • =+
Your E6B performs all of the standard arithmetic functions
with the keys shown above, (addition, subtraction,
multiplication, and division). These functions as well as any
conversions can be performed at any time, even while
performing an aviation function. The E6B will display up to
six digits of the answer.
The =key should be used to compute any arithmetic
function
AVIATION FUNCTIONS
The aviation function menu is displayed on the bottom of
the screen. Your E6B will automatically save computed
values from one aviation function to another. To override
this option, key in new value when prompted. The E6B will
save true airspeed, groundspeed, time, and fuel per hour
functions. It will also save cumulative weight and balance
totals.

CONVERSIONS
Conversions are displayed above the appropriate key, and
are listed on the next page. All conversion functions are
keyed into the computer in the same manner. For example,
to convert decimal hours to hours, minutes and seconds:
Input 4 . 2 6 2 5
PressCONV
9
Press 6
The answer, 04:15:45, will appear on the display.
There are no conversion keys for kilometers to statute
miles or statute miles to kilometers. To convert from
kilometers to statute miles, first convert kilometers to
nautical miles, then nautical miles to statute miles.
To convert statute miles to kilometers, first convert from
statute miles to nautical miles, then nautical miles to
kilometers.
NOTE: Conversions may be made at any time and during
any other function. For example, if a calculation prompts
for temperature in Celsius and only Fahrenheit is available,
the Fahrenheit can be entered and converted without
exiting the calculation.

CONVERSIONS (cont.)
0pounds to kilograms
•kilograms to pounds
1feet to meters
2meters to feet
3Fahrenheit to Celsius
-Celsius to Fahrenheit
4nautical miles to kilometers
5kilometers to nautical miles
6decimal hours to hours, minutes, seconds
Xhours, minutes, seconds to decimal hours
7nautical miles to statute miles
8statute miles to nautical miles
9U.S. gallons to liters
÷liters to U.S. gallons
10

THE CLOCK FUNCTION
The E6B has three clocks that run simultaneously. They
are labeled as ZULU (#1), HOME (#2) and LOCAL (#3).
To display clocks (repeat to cancel):
Press CLK then press 0
11
To set 11:25:00 on ZULU clock:
Press CLK then press 1
Key in 11 then press :
Key in 25 then press CLK to start clock
To set hours for HOME and LOCAL clocks:
Press CLK then press 2(for HOME)
or 3(for LOCAL).
To synchronize minutes and seconds on clocks, press:
CLK 1 CLK

ADDING AND SUBTRACTING TIME
Time can be entered into the E6B in either decimal hours
or as hours, minutes and seconds. To enter in decimal
hours, simply key in a normal decimal number. For
example, entering 2.75 hours is the same as entering
02:45:00.
To key in time in hours, minutes and seconds mode, the
:key must be used. For example, to enter 3 hours,
14 minutes and 25 seconds:
Key in 3then press : and key in 14
Press :and key in 25
The display will read 03:14:25
To key in 5 hours even:
Key in 5and press :
The display will read 05:00:00
To key in 15 seconds:
Key in 0then press :twice and key in 15
The display will read 00:00:15
Time can be added in either mode; times from different
modes can also be added without converting.
For example, to add 3.45 hours and 2:45:00:
Key in 3.45 and press +
Key in 2:45 and press =
The display will read 06:12:00.
12

TIMER FUNCTION
The timer can be used in either a count down or count up
mode.
To enter TIMER mode, press TIMER
Once in TIMER mode, the TIMER key acts as a
start/stop button. The timer is set to count up.
To change counting direction, press CONV TIMER
The timer can be cleared by pressing:
C CLK TIMER
To input a time other than 00:00:00:
Press Cthen input a time in hours, minutes,
seconds (HMS) or decimal format then press CLK
TIMER . To count up, press TIMER
To count down, press CONV TIMER
Upon reaching zero in count down mode, the timer will
count time since zero was reached. To denote this, a
negative sign will appear to the right of the timer. The
count down timer can be used as a reminder of when to
switch fuel tanks, to fly a non-precision approach (LEG
TIME function) or measuring ground speed from one
checkpoint to another checkpoint (GS).
Any function requiring time to be entered, the timer may be
used by pressing TIMER ENTER when prompted
for time. The timer can be set to 00:00:00 or another time
and then count up or down in these calculations.
Activating the count down timer will keep the screen from
turning off until approximately thirty minutes without use.
13

PRESSURE AND DENSITY ALTITUDE
(P-D/ALT)
This function will compute the pressure and density altitude
given the indicated altitude, barometric pressure (altimeter
setting in inches), and true temperature in Celsius. In this
example, indicated altitude is 10,000 feet, the barometer is
29.94 inches, and the temperature is 5°C.
Select P-D/ALT from main menu
Press ENTER and the display will prompt for IALT
Key in 10000 and press ENTER
14
The display will prompt for BARO
Key in 29.94 and press ENTER
The display will prompt for T°C
Key in 5and press ENTER
The display will read:
(FLASHING) P ALT 9980.
5.
10000.
29.94
11093.
I ALT
T°C
BARO
(FLASHING) D ALT

15
PLANNED TRUE AIRSPEED
N
This function is used to ulate tru speed for preflight
planning. It will compu he true ts and
Mach number and density altitude, given the pressure
altitude, temperature, and c knots. In
this example, pressure altitu mperature
is 2°C, and CAS is 200 knots.
Select
ENTER and the display will prompt for PALT
Key in 10000
(PLA TAS)
calc
te t
e air
airspeed in kno
alibrated airs
de is 10,000 f
peed in
eet, te
PLAN TAS from main menu
Press
and press ENTER
The display will prompt for T°C
Key in 2and press ENTER
The display will prompt for CAS
Key in 200 and press ENTER
y will read:The displa
P ALT
T°C
CAS
(FLASHING) TAS
(FLASHING) MACH#
(FLASHING) D ALT
10000.
2.
200.
234.7
0.36
10775.

16
AND GROUND SPEED
(HDG/GS)
This function will compute heading and ground speed
given wind direction, wind speed, course, and true
airspeed. In this example, the wind is from 270° at 20,
course is 180°, and true airspeed is 185.
Select HDG/GS from main menu
Press ENTER and the display will prompt for WDIR
Key in 270 and press ENTER
y will prompt for WSPD
Key in 20 a
HEADING
The displa
nd press ENTER
The display will prompt for CRS
Key in 180 and press ENTER
The display will prompt for TAS
Key in 185 and press ENTER
The display will read:
270.
20.
180.
185.
W DIR
W SPD
CRS
TAS
183.9
(FLASHING) GS
186.2
(FLASHING) HDG

17
LEG TIME
(LEG TIME)
This function computes the time required to fly a particular
distance given distance and ground speed. In this
example, distance is 25 and ground speed is 185.
Select LEG TIME from main menu
Press ENTER and the display will prompt for DIST
Key in 25 and press ENTER
play will prompt for GS
Key in 185 and press
The dis
ENTER
The display will read:
P ALT
R F
:25.
185.
00:08:06
G S
TIME (FLASHING)
DIST
ulated, the count down timer can be
activated starting at the calculated time by pressing
CONV TIMER
After LEG TIME is calc

18
FUEL REQUIRED
(FUEL REQ)
Since it is one of the most important aviation calculations,
this function flashes on the main menu when the computer
is turned on. It calculates fuel requirements given time and
fuel per hour consumption. In this example, flying time is 3
hours 15 minutes and fuel per hour consumption is 14
gallons.
Select FUEL REQ from main menu
and the display will prompt for TIME
FPH (fuel per hour)
y in 14 and pres
y will read:
ress ENTERP
Key in time of 3 hours, 15 minutes and press ENTER
T e display will prompth for
s ENTERKe
The displa
03:15:00
14 FPH
TIME
FUEL (FLASHING)
45.5
utes fuel
serves
NOTE: The Fuel Required function comp
ke required fuel reconsumption only; it does not ta
into account.

CROSSWIND, HEADWIND AND TAILWIND
(X/H-WIND)
This function computes the crosswind component and
headwind or tailwind component given wind direction, wind
speed and runway number. In this example, the wind is
from 270° at 20, and the runway number is 30. Note that
the runway number, not heading, is asked for, and
therefore 30 should be entered, not 300.
Select X/H-WIND from main menu
Press ENTER and the display will prompt for WDIR
press ENTER
Key in 30 and press E
Key in 270 and
19
The display will prompt for WSPD
Key in 20 and press ENTER
The display will prompt for RWY
NTER
The display will read:
270.
20.
30
RWY
W SPD
W DIR
.
17.3
10.
(FLASHING) X-WIND -
-
ositive numbers, while left
ve numbers. A positive
(FLASHING) H-WIND
Right crosswinds are shown as p
crosswinds are shown as negati

20
tailwind, while a negative
L TRUE AIRSPEED
(ACT TAS)
This function calculates true airspeed, Mach number and
density altitude given pressure altitude, indicated
temperature in Celsius and calibrated airspeed. In this
example, pressure altitude is 10,000 feet, temperature is
3°C, and airspeed is 200.
Select ACT TAS from main menu
Press ENTER and the display will prompt for PALT
he display will prompt for CAS
value for H-WIND denotes a
value denotes a headwind.
ACTUA
Key in 10000 and press ENTER
The display will prompt for I°C
Key in 3and press ENTER
T
Key in 200 and press ENTER
The display will read:
