/Recold M Series Fluid Cooler - Evap Condenser /

/Recold M Series /
Designed To Perform. Built To Last.
Look closely at any Recold M Series Fluid Cooler
or Evaporative Condenser and you’ll soon
discover many reasons for its long-term value.
It shows in the high-performance design.You
can see it in the superior materials. And it’s very
apparent in the durable construction.
Every single feature—from the high-performance
fans to the stainless steel access doors—has been
designed to achieve one goal: to reduce your
cost of ownership and protect the value of your
investment over the long haul.
The Recold M Series has proven itself in
application after application, including HVAC,
refrigeration, and a wide array of industrial
processes—such as plastics, heat-treating and air
compressor cooling. What’s more, we frequently
add value by configuring systems for special
requirements.This might well include custom
control panels, unique materials of construction
or redundant systems for emergency backup or
enhanced energy efficiency.

■ Proven Copper Coil Technology
Every Recold heat-exchange coil is 100% copper.
Nothing else can match its combination of performance,
cost-effectiveness, durability and corrosion resistance.
Plus, copper coils are lighter than steel.
And we offer a variety of wall thicknesses to meet specic
application needs.
■ High Efficiency Fan Technology
Constructed of glass-reinforced polypropylene, M Series fans
offer improved performance and energy efciency.
The advanced design has fewer blades, which pull rather than
push air out of the system.
This approach generates lower noise while using less power.
■ Hydrospray™Water Distribution System
This unique water distribution system delivers a full
360° spray over the coil for high-efciency heat transfer.
What’s more, the non-clogging nozzles guarantee
unfailing performance.
Durable PVC construction further ensures that nozzles
and piping will withstand the test of time.
■ Durable Stainless Steel Construction
The sump pan, tube sheets and access doors are constructed of
heavy-gauge stainless steel.
All access doors are strategically located for easy access, reducing
maintenance costs.
In custom application, we can use stainless steel to protect other
water contact surfaces as well.

The standard of value in fluid cooling.
The bottom line is there’s no better long-term investment than Recold Fluid Coolers
or Evaporative Condensers.They truly set the standard for quality materials, innovative
design and ease of maintenance.
Over 120 years of innovation and quality have built our reputation for products that
perform for decades. And the closer your look, the clearer this becomes. Just ask any owner.
You’re likely to hear about our total commitment to service, too.
So take the first step toward lasting performance.To learn more about the Recold
M Series—or any Fluid Cooler, Evaporative Condenser or CoolingTower—call or visit us
online today.
RECOLD PRODUCTS
550 W MERCURY LANE
BREA, CALIFORNIA 92821
UNITED STATES
704 529 6080
[email protected]
spxcooling.com
In the interest of technological progress,
all products are subject to design and/or
material change without notice.
©2008 SPX Cooling Technologies, Inc.
Printed in USA | RECOLD M-06
