Frigidaire FFU17G9H User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU17G9HW0 FFU17G9H 134A white 115
FFU20G9HW0 FFU20G9H 134A 115 115
MARKET
North America
Publication No.
5995325841
990719
-EN/SERVICE /GS
365
FREEZER
Model No.
FFU17/20G9H
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216569300
OWNER’S GUIDE - # 216657700
SERVICE DATA SHEET - #216569300

07/99 2
Publication No. FFU17/20G9H
5995325841
DOOR

# = Fast-moving Parts 3 07/99
* = Non-Illustrated Parts
FFU17/20G9H Publication No.
5995325841
DOOR
A = FFU17G9HW (FFU17G9HW0)
B = FFU20G9HW (FFU20G9HW0)
POS. NO PART NO DESCRIPTION
1 216522309 A - Gasket-door,white
1 216522312 - B Gasket-door,white
2 # 5303925107 A B Lock Assy
5 # 216388700 A B Key,lock
6 5300158222 A B Screw-anchor,8-18
9 216527806 A - Panel-inner door,white
9 216528108 - B Panel-inner door
11 5303925471 A - Panel-door,white
11 5303925472 - B Panel-door,white
12 218364004 A B Frame-nameplate,white
12A 215008604 A B Label-nameplate,white
13 08016354 A B Door Stop
14 5303313518 A B Washer,sealing
17 216087400 A B End Cap,white ,(2)
18 216518000 A B Handle,center
19 216208900 A B Insert,handle top
20 216209001 A B Insert,handle bottom
21A 08005520 A B Screw-door stop mtg,flat hd met., 4.0 x 0.7-19.7
22 216443600 A B Bearing
22A 216503200 A B Bearing-hinge,btm
25 216022800 A B Screw,washer head ,8-18 X 1/2
26 216524200 A B Gasket,secondary
27 5303212828 A B Clip,panel
32 5309950074 A B Valve-breather
37 216373300 A - Trim-handle,upper
37 216211200 - B Trim-handle,upper
37A 216087600 A B Trim-handle,bottom
39 08016809 A B Fastener,door strip
62A 131420300 A B Screw,cr truss head ,8-18AB x 0.750
64 216403700 A B Plug-button,base door
72 216514100 A B Shelf,tilt out ,wire
73 216513900 A B End Cap,tiltout ,LH
74 216514000 A B End Cap,tiltout ,RH
76 216521800 A B Support psuedo bin,LH
77 216522100 A B Support psuedo bin,RH
78 216579500 A B Rack shelf,psuedo ,32
93 5303161215 A B Screw
* 5303925098 A B Insulation
* 216485600 A B Label-frozen food

07/99 4
Publication No. FFU17/20G9H
5995325841
CABINET

# = Fast-moving Parts 5 07/99
* = Non-Illustrated Parts
FFU17/20G9H Publication No.
5995325841
CABINET
A = FFU17G9HW (FFU17G9HW0)
B = FFU20G9HW (FFU20G9HW0)
POS. NO PART NO DESCRIPTION
3 216503100 A B Screen-drain
5 # 216325600 A B Fan Blade
6 216604200 A - Breaker Kit w/corners
6 216604100 - B Breaker Kit w/corners
7 216603700 A - Breaker Kit w/corners,lock catch
7 216603600 - B Breaker Kit w/corners,lock catch
9 216603300 A B Breaker Kit w/corners,32" , top or bottom
13 216570900 A B Motor-evap fan
14 216472300 A B Switch-light plunger
15 216222700 A B Light Bulb/Lamp
16 5300136117 A B Socket-light/lamp
18 216591700 A B Knob-control
19 216511300 A - Gasket-evap cover
19 216511301 - B Gasket-evap cover
20 216230300 A B Cover,temp control
21 216521100 A B Control-temperature
22 05878562 A B Clamp,cap tube ,cold control
23 5308002706 A B Light-signal,amber
24 5300052943 A B Screw-clamp,truss hd cr ,control
25 216084100 A - Cover,evaporator
25 216084200 - B Cover-evaporator
26 216503300 A B Ramp,closer ,door
27 5303205738 A B Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 A B Hinge-bottom
32 5308005500 A B Drain
34 216557606 A B Shield-light
38 5303925086 A B Hinge-upper
39 5303294372 A B Nut-insert,hinge
40 5303212912 A B Cover-hinge
41 5303212937 A B Screw-top hinge
42 216458400 A - Shelf,14.50x27.88 ,WH
42 216458500 - B Shelf,wire ,16.69x26.88 ,white ,(3)
42A 216458200 A - Shelf,12.50x27.88 ,white
42A 216546000 - B Shelf-fixed w/frame,white
44 # 5303017178 A B Switch-rocker
46 08037851 A B Screw,PH type AB ,8-32x1/2 , wiring harness
47 5303288233 A B Baffle-plate
48 08000456 A B Spacer-baffle plate
50 216394000 A B Bracket-motor mtg fan
56 09950853 A B Screw-control knob,phillips ,4-40 x 3/8
59 216372800 A - Basket,(2)
59 216154400 - B Basket
59A 09948791 - B Stop-basket
60 5303212693 A - Slide-basket
62 131420300 A B Screw,cr truss head ,8-18AB x 0.750
63 216396900 A B Foot-adjustable
64 08016369 A B Bracket
66 # 08016367 A B Buzzer,alarm
68 08009560 - B Glide-basket
69 5305878546 A B Bumper-basket
72 216591118 A B Grille/Kickplate,32"
77 # 5308037992 A B Sensor Assy
78 3205349 A B Housing-sensor
79 3017666 A B Nut-insert
80 06594601 A B Bracket,control
90 08037849 A B Screw
93 5303161215 A B Screw
93A 5303302760 A B Screw
96 08016772 A B Light-signal,red
108 216388600 A B Trap-drain
132 5303283898 A B Screw,6-20AB x 3/8
* 09948773 A B Insulation,drain tube
* 216533300 A B Wire-ground,fan motor
* 216539100 A B Wiring Harness,alarm
* 5303305324 A B Paint,touch-up ,white
* 5303311565 A B Clip-cable
* 5303916855 A B Tube,plastic ,clear ,sensor sleeve

07/99 6
Publication No. FFU17/20G9H
5995325841
SYSTEM

# = Fast-moving Parts 7 07/99
* = Non-Illustrated Parts
FFU17/20G9H Publication No.
5995325841
SYSTEM
A = FFU17G9HW (FFU17G9HW0)
B = FFU20G9HW (FFU20G9HW0)
POS. NO PART NO DESCRIPTION
1 # 5300083897 A B Condenser
2 5308000110 A B Strap-evap/heater,aluminum ,(2)
4 216634500 A B Drier-filter
5 # 216578300 A B Wiring-diagram,main
14 216608500 A B Heater-defrost
15 # 216195900 A - Evaporator
15 # 216660700 - B Evaporator
15A# 216385200 A B Heat Exchanger
17 06599546 A B Spacer-support,evaporator ,(2)
18 06599531 A B Insulation Block,RH
19 3017674 A B Insulation Block,LH
20 5303917954 A B Thermostat-defrost
23 # 216517400 A B Timer
24 08016580 A B Bracket
26 216511900 A B Spacer tube,(3)
27 216498900 A B Grommet,compressor
29 216639700 A - Compressor,Service
29 216639900 - B Compressor,w/o electricals
30 # 216594300 A B Starter
31 # 216100115 A - Overload Protector
31 # 216100119 - B Overload Protector
31A 5303925444 A B Pan-drain
32 5303006412 A B Strap-cover mtg
34 5306594529 A B Sleeve-compressor
35 5303272328 A B Screw,Ind hex sems ,1/4-28 unfx , compressor
43 09950610 A B Clip,cord
43A 216629700 A B Clip-harness
52 08013198 A B Retainer,spacer evap
53 08006982 A B Cover-terminal
86 216036600 A B Screw,rwhd (gx-ca) ,8-32 x 1/2
87 08037849 A B Screw
130 06599544 A B Support-evaporator
