Frigidaire FFC07M5C User manual

FREEZER
Model No.
FFC07M5C
©2001White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216372500
OWNER’S GUIDE - # 216768600
SERVICE DATA SHEET - #216372500
PRODUCT NO. BASE MODEL NO. COLOR VOLTS
FFC07M5CW4 FFC07M5C white 115
MARKET
USA
Publication No.
5995352985
010425
-EN/SERVICE /DJH
365
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O.BOX 212378, AUGUSTA, GA 30917

04/01 2
Publication No. FFC07M5CW
5995352985
DOOR

# = Fast-moving Parts 3 04/01
* = Non-Illustrated Parts
FFC07M5CW Publication No.
5995352985
DOOR
POS. NO PART NO DESCRIPTION
1 216480901 Gasket-door,white
2 # 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216067300 Panel-inner door/lid,white
10 216141101 Plug button,white
11 216113119 Panel-outer lid,white
12 216208100 Bezel-nameplate
12A 216683000 Insert-bezel
18 216140200 Handle,recessed ,white
23 3200895 Light-signal,round ,amber
27 5303212828 Clip,panel
31 08009392 Gasket,white
35 5303297015 Washer,signal light
44 # 5303017178 Switch-rocker
46 216707800 Screw,PH ,8-32 x 1/2 ,wiring harness
47 # 216552700 Harness,electrical
53 # 5303208483 Buzzer,alarm
55 216164000 Housing,switch
56 216694200 Sealing cap
61 5309948955 Clip-panel
93 5303161215 Screw
* 5303917276 Insulation-door,fiberglass ,(bulk)

04/01 4
Publication No. FFC07M5CW
5995352985
CABINET

# = Fast-moving Parts 5 04/01
* = Non-Illustrated Parts
FFC07M5CW Publication No.
5995352985
CABINET
POS. NO PART NO DESCRIPTION
1 216117700 Catch-lock
3 216502600 Plug-drain,interior ,interior
4 216073900 Plug-drain,exterior
6 216112800 Breaker-hinge,white
7 216112900 Breaker-lock side
11 216105600 Breaker-ends,white
18 216707200 Knob-control cold
21 # 216714500 Control-temperature
27 216337700 Screw,hex washer head ,10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners,white
59 216142600 Basket
70 216375100 Handle-basket,teal
71 131168200 Screw,8-18 x 0.31
75 216329402 Panel-access,white
* 5303305324 Paint,touch-up ,white

04/01 6
Publication No. FFC07M5CW
5995352985
SYSTEM

# = Fast-moving Parts 7 04/01
* = Non-Illustrated Parts
FFC07M5CW Publication No.
5995352985
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5300120780 Condenser
4 216634500 Drier-filter
5 # 216552700 Harness,electrical
22 216056400 Clip-spring mtg
25 216022800 Screw,washer head ,8-18 X 1/2
27 5308002681 Grommet,compressor
29 # 5303925442 Compressor,w/electricals
29 # 216511000 Compressor,w/o electricals
30 # 216511200 Starter
31 # 216100113 Overload Protector
46 216707800 Screw,PH ,8-32 x 1/2 ,wiring harness
53 216347800 Cover terminal,cover-comp term
