SPYSONIC PANEL XXL+ User manual

DELIVERY SET
SPYSONIC PANEL XXL+jammer –1 pcs.
Power adapter –1 pcs.
Adjusting resistors –4 pcs.
User’s manual –1 pcs.
TECHNICAL DATA
Characteristic
Min
Typ
Max
Units
Supply voltage of jammer
7
9
10
V
Supply voltage of power adapter
100
220
240
V
Supply current in jamming mode
–
2
3
A
Frequency range of interference (2 bands)
24.4
25.0
25.6
kHz
17.5
18.0
18.5
kHz
Type of interference selection
ULTRANOISE-2 or ULTRASOUND-2
Adjustment of interference power
4 levels
Overload and reverse polarity protection
Yes
Operating temperature
-20
–
+50
⁰С
Data in Typ column is at 20⁰C and 9V.
GUARANTEE AND SALE MARKS
Manufacture guarantee for faultless work of the electronics within 3 years since
the date of sale.
SELLER _______________ DATE OF SALE _______________
www.spysonic.ru
SPYSONIC PANEL XXL+
HIGH POWER 2nd GENERATION DUAL BAND ULTRASONIC JAMMER
USER’S MANUAL
GENERAL DESCRIPTION
SPYSONIC PANEL XXL+ is a high power 2nd generation dual band ultrasonic
jammer of audio recorders with 2 working modes: ULTRASOUND-2 & ULTRANOISE-
2. The jammer is made as panel, which can be installed into celling, wall or some
office furniture. Panel dimensions (cm) 32x22x3. Number of ultrasoud
transmitters: 60 + 4.
Ultrasonic jammer of audio recorders (jammer of audio transmitters, jammer of
wired microphones, supressor of audio recorders in mobile phones) is an
ultrasound generator that affects microphones and preamplifiers of various
recording devices.
Compared to SPYSONIC 21XL+, SPYSONIC PANEL XXL+ provides 2 times bigger
jamming range. The jammer supresses all iPhones, including iPhone6 and iPhone6
plus, microphones in laptops and headsets, as well as various bugs.

ULTRANOISE & ULTRASOUND
Operating modes ULTRANOISE-2 and ULTRASOUND-2 are 2 different algorithms of
formation of ultrasonic noise.
COMMON IN ULTRANOISE-2 AND ULTRASOUND-2 MODES
Ultrasonic carrier is modulated by noise signal of audible range. In sound recorder
microphone this modulated signal turns into loud noise which covers all other
sounds. In the 2nd generation jammers, 2 ultrasonic frequencies are used, which
significantly expands the number of types of recording devices suppressed.
DIFFERENCES IN ULTRANOISE-2 AND ULTRASOUND-2
The main difference is the modulation depth of the ultrasonic carrier. Ultranoise
mode has maximum depth of modulation, which provides maximum suppression,
but the signal of the jammer is heard by the human ear as a sound resembling the
background AC sound of unattached loudspeaker. In Ultrasound mode the
jammer is almost silent, but the radius of suppression decreases approximately
1.3 times.
CONTROLS AND INDICATORS
At the back of the panel there is a power connector, red power button combined
with on/off indicator and green Ultranoise/Ultrasound switch button.
USAGE
To activate the device, just connect the power supply and press the red button. It
is advisable to point the jammer toward possible location of sound recording
device. Placing the jammer on the celling usually is not the best option, because in
such a way the jammer is closer to persons’heads than to possible recording
devices. Often the optimal location of the suppressor is under the table, as close
as possible to the place of the probable location of an audio recorder.
SWITCHING JAMMING MODES
In ULTRANOISE mode the sound of the jammer is perceived by the human ear as a
light crackling. If you want the suppressor to work as quietly as possible, you
should enable silent mode ULTRASOUND by pressing the green button.
POWER ADJUSTMENT
If it is necessary to change the power of ultrasound, voltage can be change within
10 to 7 volts. To do this, unplug the AC adapter and change the adjusting resistor
on the side of the adapter. We supply 10V, 9V, 8V and 7V resistors. The
recommended voltage is 9V. To slightly increase power, change it for 10V. To
decrease power, use 8V or 7V resistors.
CONDITIONS OF EXPLOITATION
SPYSONIC PANEL XXL+ can be used over a wide temperature range (-20⁰C ... + 50⁰C)
with humidity up to 95%. Operating in direct exposure to rain or snow is not
allowed. In the event of a short circuit or reverse polarity, SPYSONIC has built-in
protection.
APPROXIMATE DISTANCES OF SUPPRESSION
SPYSONIC PANEL XXL+ provides probably the best range of suppression, but its
efficiency is not the same for various devices.
For iPhones 4 and 5 and most Chinese transmitters (bugs) jamming distance is
more than 10 m. For iPhone 6 and iPhone 6 plus the distance is 3 - 5 m. For video
cameras, microphones in headsets and laptops, suppression distance is in the
range 4 - 8 m. For some smart phones the distance of suppression may not exceed
2 m. In Ultrasound mode the radius of suppression decreases approximately 1.3
times. If microphone is covered with some cloth, the jamming distance is reduced.
