KEY
FW540C
CD Mini System
3 CD Changer with 100 Watts Total Power
and 4-Speaker Surround Sound System
• 2 x 50 Watts RMS Stereo
• 4-Speaker Surround Sound System
• Sound Navigation and 26 Digital Sound Control modes
• 3-Step Dynamic Bass Boost
• 7-Band Spectrum Analyzer with 3 Display modes
• 2-Bay Bass Reflex Speaker System with Detachable Grilles
• CD-Rewritable Compatible
• 40-Track CD Random Program
• AM/FM Stereo DigitalTuner with 40 Presets
• One Touch CD Synchro Recording
• Repeat Track/Disc/All
• Subwoofer Ready
• Bedroom Clock with Wake-up Alarm and Sleeptimer
• Oversized, Multicolor, Digital FTD Display
• 24-Button Remote Control
• 4-Color Packaging
100watts
Total PowerTotal Power
SETEASY
RADIO
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
w
a
k
e
u
p
/
s
l
e
e
p
t
i
m
e
r

Sound Enhancement
2 x 50 Watts RMS Stereo
50 watts continuous RMS power output per channel, at 6
Ohms, from 80Hz-16kHz, with no more than 10% Total
Harmonic Distortion (THD).
4-Speaker Surround Sound System
Delivers the full, three-dimensional effect of a live
performance from music and movies. The front left and
right speakers fill the room with all the music's detail and
directional sound, producing the "wall of sound". Both the
rear left and right surround speakers add the ambient
reflected sound with echoes and delay for a more life-like
audio experience.
Sound Navigation
The up/down of this feature adds a new dimensions in
fine-tuning the sound settings to suit your personal taste.
26-step Digital Sound Control
The feature offers 26 different sound settings based on 6
basic settings : (CLASSIC - 1 setting, ROCK - 5 settings,
VOCAL - 5 settings,TECHNO - 5 settings, OPTIMAL - 5
settings, JAZZ - 5 settings)
3-Step Dynamic Bass Boost (Beat, Punch, Blast)
Bass reproduction is essential for deep and rich music. 3
Step DBB offers the optimal level for any kind of music.
2-Way Bass Reflex Speaker System
Equipped with one 5 1/4" woofer, one 2 1/2" ferro-fluid
cooled tweeter, 2-way enclosures feature a wider range
of frequency response for greater listening pleasure.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system ensures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Design
Design Concept
The attractive and shelf appealing emphasis on the sound
control panel dominates and determines this range's
character. The sound control panel emphasis which
supports the entire sound story is reinforced by 2
distinctive up/down jog (sound jog and volume) that builds
itself logically up the range with features, finishing, colors
and product design detail difference. Uninterrupted display
and cassette window lens set on a strong underlying profile
gives strong rational while the use of appropriate
backlighting, lightstrips and rings coupled with choice colors
evokes the emotional appeal.
Oversized, MultiColor, Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format
makes it easy to recognize different functions at a glance.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
Convenience
3-Disc CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
CD-Rewritable Compatible
The player offers 100% playback guarantee of CD-
Rewritable CD's over the entire lifetime of the player. Even
CD-RW audio recordings on computers can be used.
24-Button Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY,
STOP, PAUSE, REPEAT, SHUFFLE, PROGRAM, DISC 1,
2, 3 ), CD, AUX, TAPE 1/2, TUNER, SLEEP TIMER,
SURROUND and sound enhancement features including
Dynamic Bass Boost, and Digital Sound Control.
Easy Set
Press Standby ‘ON’ for 5 secs to automatically program
40 tuner presets.
40-Random Channel Presets
Random memory presets allow pre-programming of up to
40 AM and FM station frequencies into the tuner memory.
Auto Store
Automatically stores up to 40 preset FM or AM stations.
40-Track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
Video/AUX Input
For connection of audio accessory pieces such as a LD
or DVD player, television, stereo VCR or external cassette
deck.
Auto Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press “STOP” for 5 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
Change While Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the sequential
order in which they were originally recorded.
UPC Code: 0378 4987 6831
Product Dimensions:
10.4"W x .12.2"H x 14.3"D (electronics)
9.48"W x 12.2"H x 12.2"D (speakers)
7"W x 3.54"H x 7"D (surround)
Package Dimensions:
26"W x 21"H x 28.3"D
Product weight: 44 lbs.
Carton contains: 3CD Changer Mini System, 2 Surround Speakers,
Multi-Function Remote Control, Batteries, Operating instructions,
Warranty information
Printed in Singapore
Date Printed : Nov 1998
©1998 Koninklijke Philips Electronics N.V.
All right reserved.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Incredible Surround™ is a Trademark of Philips Consumer Electronics
Company
Repeat track/disc/all
Repeat your favorite track, disc or all.
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track
instantly.
Dual MechanicalTape Deck
Feature full function control via a simple, easy-to-use
mechanical push button assembly.
Clock/Timer and Sleeptimer
Set the alarm portion of a built-in digital clock to wake you
to music from your favorite CD or an AM/FM radio station
at any desired time of the day. Sleeptimer settings of 60, 45,
30 or 15 minutes.
3 Display modes (including nite mode)
2 different display options showing different amounts of
display activity can be selected and 1 nite mode display which
shows minimal display activity and turns most of the lights off.
Stereo Headphone Jack
2
21 3
TUNERTAPE 1/2CD
SLEEP TIMERAUXSURROUND
REPEAT PROGRAM
SHUFFLE
DBB SIDE DSC
Å
CD DIRECT
VOLUME
á
à
ë
í
É
Ç
FW540C
CD Mini System
