SQ Professional Blitz Series User manual

instruction manual
BEFORE OPERATING THIS UNIT, PLEASE CAREFULLY READ THE FOLLOWING INSTRUCTIONS.
SQIM 5589-8306 28-05-2020 V3
POWER JUICER

SQIM 5589-8306 28-05-2020 V3 Power Juicer | SQ Professional Ltd © 2020 All rights reserved
Power Juicer Instruction Manual
TABLE OF CONTENTS
CONTENTS
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
IMPORTANT SAFEGUARDS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
ASSEMBLY OF THE POWER JUICER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
USING THE POWER JUICER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
JUICING TIPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
ENVIRONMENTAL PROTECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
2

All images are for illustration purposes only. Actual products may vary.
SAFETY
Power Juicer Instruction Manual
IMPORTANT!
Due to fast moving parts and potential
hazards the appliance is not suitable for
the use of children under 8 years old.
When off please keep the appliance and
cord out of the reach of children.
Children over 8 must be supervised by an
adult at all times when using or cleaning
the appliance. This is not a toy!
The appliance can be used by persons
with reduced physical, sensory or
mental capabilities if they have been
given supervision and instruction and
understand the use and hazards involved.
Always disconnect the appliance from the
mains supply socket if it is left unattended
and before assembling, disassembling or
cleaning.
If the mains cable is damaged, it must be
replaced by qualified persons in order to
avoid any hazards.
3

SQIM 5589-8306 28-05-2020 V3 Power Juicer | SQ Professional Ltd © 2020 All rights reserved
Power Juicer Instruction Manual
FEATURES
FEATURES
1 Interlocking safety arm
2 Juice spout
3 Mesh filter holder
4 Stainless steel micro-mesh filter
5 Pulp container
6 Juicer cover
7 Feed chute
8 Food pusher
9 Juice jug
10 Rotary switch
11 Motor block
12 Juicing bowl
SPECIFICATIONS
Rated Voltage: . . . . . . . . . . . . . . . . . . . . . . .220-240V
Frequency:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50-60Hz
Rated Power:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800W
Juice Jug Capacity:. . . . . . . . . . . . . . . . . . . . . . .700ml
Pulp Container Capacity: . . . . . . . . . . . . . . . . 1.4L
READ THE INSTRUCTIONS AND
KEEP THEM SAFE. REMOVE ALL
PACKAGING BEFORE USE.
2
4
5
6
7
8
9
10
11
12
1
3
SHARP PARTS!
4

All images are for illustration purposes only. Actual products may vary.
IMPORTANT SAFEGUARDS
Power Juicer Instruction Manual
IMPORTANT SAFEGUARDS
WHEN USING ANY ELECTRICAL APPLIANCE, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
1 Read all instructions carefully before using the appliance.
2 This appliance is intended for household use only.
It is not suitable for commercial use such as staff
kitchen areas and other working environments.
3 Ensure that the appliance is always placed on a firm and flat
surface, away from the edge of the work top. Do not place
the appliance onto a metal tray or metal surface whilst in use.
Do not place the appliance on, or near, a hot gas or electric
burner or in a heated oven. Do not operate the appliance with
wet hands or barefoot.
4 Keep the appliance and mains cable away from the edges of
work tops and out of reach of children. Route the cable so
it does not overhang, and cannot be tripped over or caught.
5 Do not let the cable run across an open space, such as
between a low socket and a table, or across any hot area, such
as cooker. Heat may damage the mains cable.
6 The connections on both sides of the mains cable (the
appliance and socket) should never be strained. If the mains
cable is damaged it must be replaced by qualified person or
service to avoid any hazards.
7 Do not use the appliance in a bathroom, near
water, or outdoors. Do not immerse any of the
parts (appliance, mains cable, plug) in water or
other liquids to protect against fire, electric shock
and personal injury.
8 Do not use the appliance if it is damaged or
malfunctions. Do not leave the appliance unattended
whilst in use. Use and store it out of reach of children.
9 This appliance must not be operated by an external timer or
a remote control system.
10 SQ Professional Ltd may not be held liable for eventual
damages to persons, animals or objects caused by incorrect
installation or deriving from improper, erroneous or
unreasonable use.
11 The mesh filter holder
3
and the micro-mesh filter
4
should always be kept dry. Before washing and drying
disconnect the power supply; ensure that the mesh filter
holder
3
and the micro-mesh filter
4
are completely dry
before assembling and before you reconnect the appliance
to power supply.
12 Before operating the appliance ensure that the mesh filter
holder
3
has the juice spout
2
attached and is securely fit
onto the motor block
11
before you insert the micro-mesh
filter
4
.
13 Only switch on the appliance when pulp container
5
and
juice jug
9
are in place, and the juicer cover
6
is securely
locked with the interlocking safety arm
1
. The ingredients
should be cleaned and cut in pieces small enough to fit into
the feed chute
7
.
14 Do not open the juicer cover
6
or attempt to
remove the micro-mesh filter
4
or mesh filter
holder
3
whilst the appliance is running.
15 Keep hands and utensils away from the moving
parts while blending to reduce the risk of severe
injury to persons or damage to the juicer. Always
use the food pusher
8
to push food down the
feeding chute
6
.
16 Switch off the juicer and unplug from the socket before
changing attachments or approaching parts that move while
in use. Unplug the juicer when not in use.
17 Ensure that the juicer has come to a complete stop before
cleaning and storing away. Keep the attachments, motor
block
11
, cable, and plug away from sources of heat. Store
in a dry place.
18 Do not use the juicer for any other purpose than
its intended use.
19 Use only the attachments supplied with the motor block
11
(and vice versa) and do not tamper with the mesh filter
holder
3
in any way.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
5

SQIM 5589-8306 28-05-2020 V3 Power Juicer | SQ Professional Ltd © 2020 All rights reserved
Power Juicer Instruction Manual
USE & CARE
BEFORE FIRST USE
ALL PARTS OF THE JUICER ARE TO BE THOROUGHLY CLEANED BEFORE
BEING USED FOR THE FIRST TIME (SEE THE SECTION ON CLEANING).
Carefully wash and dry all parts which come into contact with
food – juicer cover, food pusher, micro-mesh filter, juicing bowl, pulp
container and juice jug. Wipe the motor block with a damp cloth and
dry immediately with a soft cloth. Assemble the appliance, take out the
required length of the cable and plug it into the mains supply.
ASSEMBLY OF THE POWER JUICER
EXERCISE EXTREME CARE WHEN INSERTING OR REMOVING THE
MICRO-MESH FILTER. IT CONTAINS SMALL, VERY SHARP TEETH AND
A CUTTER ON ITS BASE.
1 Place the motor block
11
on a flat, stable surface and push the
interlocking safety arm
1
down. Place the juicing bowl
12
on
the motor block
11
and attach the juice spout
2
. image 1
2 Place the micro-mesh filter
4
over the mesh filter holder and
press down firmly until it snaps into place. image 2
3 Place the juicer cover
6
on the juicing bowl
12
with the feed chute
7
positioned centrally above the micro-mesh filter
4
. image 3
4 Raise the interlocking safety arm
1
up and lock it into the
grooves on either side of the juicer cover
6
. image 4
5 Tilt the pulp container
5
slightly forward and push it
upwards under the pulp spout. image 5
6 Slide the food pusher
8
into the feed chute
7
by aligning
the grove on the pusher. Lift the cover on the juice jug
9
and
align the jug spout with the juice spout
2
. image 6
DISASSEMBLING THE POWER JUICER
1 Turn the switch
10
to “0” and unplug from the mains supply.
Ensure that the appliance has come to a complete stop.
2 Remove the pulp container
4
by holding it with both hands
and pivoting its lower end away from the juicer.
3 Place both hands on either side of the interlocking safety arm
1
, pull back and lift over the grooves on either side of the
juicer cover, then lower it.
4 Hold the juicing bowl
12
with both hands and lift it off the
motor block with the micro-mesh filter
4
still in place.
5 Place the juicing bowl
12
into the sink and remove the juice
spout
2
.Turn the juicing bowl upside down to remove the
micro-mesh filter
4
.
USING THE POWER JUICER
1 Wash the ingredients and remove any hard or inedible parts
(stones, pits, hard skin, rind, pith, etc. ).
2 Ensure that the appliance is correctly assembled, the juice jug
9
is placed under the juice spout
2
, and pulp container
5
is in position before commencing juicing (the pulp container
can be lined with a bio-degradable or food-safe bag for easier
disposal or further consumption of the pulp).
3 Plug the cable to the mains supply and turn the power ON at
the power outlet.
4 Place the ingredients into the feed chute
7
and turn the switch
10
to desired speed to switch the appliance on:
1LOW SPEED - for juicing soft fruit and vegetables such as
apricots, berries, cabbage, cauliflower, broccoli, cucumber,
grapes, kiwis, mangoes, oranges, pears, watermelons,
tomatoes, watermelons, etc.
2HIGH SPEED - for juicing hard fruit and vegetables such as
apples, carrots, brussels sprout, fennel, plums, beetroot,
celery, etc.
PULSE SHORT BURSTS OF VERY HIGH SPEED - for very hard
ingredients. The switch does not permanently engage in
the ‘PULSE’ setting. You have to hold the dial or turn it
repeatedly to the ‘PULSE’ setting.
After juicing, always turn the switch to the ‘0’ setting and unplug
the appliance from the mains socket.
5 With the motor running use the food pusher
8
to gently guide
food down and extract the maximum amount of juice. The juice
will flow into the juice jug
9
and the pulp will separate and
accumulate in the pulp container
5
. Do not use your fingers or
other utensils to push the ingredients down the chute.
6 Do not allow the pulp container
5
to overfill as this may
prevent correct operation or cause damage to the appliance.
To empty the pulp container during juicing, turn the Power
Juicer off by turning the switch to “0” and remove it as
described in disassembling instructions. Replace the empty
pulp container
5
before continuing to juice.
1
2
3 4
5 6
1 2
3
4
5 6
1 2
3
4
5 6
1 2
3 4
5
6
1
2
3 4
5 6
1 2
3 4
5
6
6

All images are for illustration purposes only. Actual products may vary.
USE & CARE
Power Juicer Instruction Manual
JUICING TIPS
• Always use fresh fruit and vegetables and wash them well
before using and storing.
• If using ingredients with hard or inedible skin always peel
before juicing. Fruits with pits, hard seeds or stones must be
pitted before juicing.
• Add a little lemon juice to apples, pears and similar fruits to
prevent browning.
• Start juicing the softer ingredients first on low speed 1, then
increase the speed 2or PULSE when adding harder ingredients.
• When juicing herbs, sprouts or leafy vegetables, wrap them
together into a bundle or mix them with softer ingredients and
juice on low speed for best extraction.
• Always push the food pusher down slowly to maximize juice
extraction.
USING THE PULP
Pulp remaining after juicing fruits or vegetables is rich in cellulose
and fibre, containing vital nutrients and can be used in many
ways. Just like juice, the pulp should also be used on the day to
avoid oxidation and loss of nutrients. The pulp can be used to
thicken sauces, soups and casseroles, in deserts and bakes, and
is also great as compost in the garden. Before using the pulp for
consumption ensure that any hard pieces of fruits or vegetables
are removed.
CLEANING
ALWAYS ENSURE THAT THE APPLIANCE IS DISCONNECTED FROM THE
MAINS SUPPLY BEFORE DISASSEMBLING, CLEANING AND STORING.
NEVER IMMERSE THE MOTOR BLOCK IN WATER. THOROUGHLY
CLEAN ALL THE SURFACES THAT COME INTO CONTACT WITH FOOD
DURING THE NORMAL USE.
1 Immediately after each use, rinse all the removable parts
under running water and allow to air dry.
2 Soak the micro-mesh filter
4
for about 10 minutes in warm
soapy water, then hold it under the running water and use the
supplied brush to ensure that all the pulp is removed from
the mesh and any openings.
3 If there is any dried up pulp, soak the micro-mesh filter
4
in
warm soapy water then use the brush again. Never soak the
micro-mesh in bleach and always treat it with care as it can
be easily damaged.
4 After disassembling the appliance thoroughly wash all the
removable parts with warm soapy water or in a dishwasher
on the top rack.
5 Wipe the motor block with a damp cloth and immediately dry
with a soft cloth.
WIRING UK PLUGS
Should the power cable or the power
plug become damaged, arrange for
these to be replaced by Customer
Service or qualified person before
continuing to use the appliance.
The appliance is fitted with an ASTA
approved 13A fuse (BS1362) in a 13A
plug (BS1363).
The appliance must not be used without the fuse
cover fitted.
ENVIRONMENTAL PROTECTION
To avoid environmental and health problems due
to hazardous substances in electrical and electronic
goods, appliances marked with this symbol must not
be disposed of with unsorted municipal waste, but
recovered, reused or recycled.
SERVICE
The product is not user-serviceable. If it is not working, read the
instructions, check the plug fuse and main fuse/circuit breaker. If
it is still not working, consult your retailer. If that does not solve the
problem ring Customer Service – they may be able to offer technical
advice. Please have the Model Number to hand, as they will not
be able to help you without it.
If you are advised to return the product to us, pack it carefully,
include a note with your name, address, day phone number, and
description of the problem. If under a guarantee, say where and
when it was purchased and include a valid VAT receipt. Send it to
SQ Professional Ltd.
GUARANTEE
THE GUARANTEE FOR THIS PRODUCT IS COVERED BY
SQ PROFESSIONAL LIMITED. ANY FAULTS WITH THIS PRODUCT
ARISING THROUGH A MANUFACTURER DEFECT WILL BE COVERED
FOR 1 YEAR FROM THE DATE OF PURCHASE, SUBJECT TO A VALID
VAT RECEIPT BEING PRESENTED.
THIS DOES NOT INCLUDE FAULTS OR DAMAGE CAUSED BY MISUSE
OF GENERAL WEAR AND TEAR.
PLEASE CONTACT CUSTOMER SERVICES ON 01992 716 070
OR SEND AN E-MAIL TO [email protected],
MONDAY TO FRIDAY FROM 09:30 - 17:30.
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
13 AMP
7

SCAN THE QR CODE TO EXPLORE
OUR FULL PRODUCT RANGE.
Voltage Business Centre, Units 1 - 3
6 Mollison Avenue, Enfield, EN3 7XQ
T: 01992 716 070 | F: 01992 700 538
E: [email protected]
WWW.SQPROFESSIONAL.COM
